NAPCO 2WAY-UNIVKF User manual

WI1024B 03/01
© NAPCO 2001
®2WAY-UNIVKF
Bi-Directional LCD KeyFob
Installation Instructions

2WI1024B 2WAY-UNIVKF Installation Instructions
Easy LCD ICON Indicators
Burglar Alarm
Fire Alarm
Armed - Away
Armed - Stay
Armed - Zones Bypassed
Disarmed - Zones Faulted
Disarmed - System Ready
Transmit
System Trouble
Note: Grey ICON indicates pulsing
NAPCO introduces the new 2WAY-UNIVKF, the security industry’s only
universal bi-directional Keyfob with LCD status display and integral mini
sounder, supported by a revolutionary 2-way receiver.
Designed to be compatible with most major control panel brands, including
NAPCOs Gemini and Magnum and others such as ADEMCO, DSC and
more, this 2-Way Keyfob is super-miniaturized for portability yet packs
tremendous sales potential and consumer market appeal.
System Status is indicated through 8 intuitive ICONS (a lock, a house, a
flame, etc.) on the LCD display, accompanied by corresponding beep
sequences on its mini sounder. Providing both easily understood visual and
audible feedback, the user always knows with certainty that the system has
carried out their command.
In addition to the many standard commands it can issue the system, it can also
control up to 2 groups of lighting control, such as X-10, and up to 2 separate
Garage Doors.
NAPCO 2WAY-UNIVKF keyfobs are also sold in a kit with the 2-way
receiver, Model 2WAY–UNIVKFKIT. Each receiver supports up to 7
keyfobs.
2WAY-UNIVKF - The 2-Way Universal LCD Keyfob that puts the power of a keypad in your pocket.

3
General Description
The 2WAY-UNIVKF is a miniature
remote control device which provides 4
buttons to issue commands to a security
system and confirms status visually and
audibly through an LCD ICON screen
and a mini sounder. It is keypad bus
compatible with the NAPCO GeminI
Series control panels as well as the
Ademco Vista 10 and 20 series. It is
also universally compatible with any
control panel which offers keyswitch
arming and an armed status output.
Keypad Bus compatible control panels:
NAPCO: GEM-P816
GEM-P1632
GEM-3200
GEM-P9600
Ademco: Vista 10
Vista 20
Vista 40
For additonal information and details on
universal operation, see system
overview on page 4.
Features
• 3 Form C Relay Outputs
• Arm/Disarm
• Panic
• Garage Door Control
• Lighting Control or Second Garage Door
control
Specifications
• Input Voltage: 12V DC Nominal
• Input Current: 40mA standby, 90mA max.
(all relays active)
• Operating Temperature: 0-49°C (32-
120°F)
• Maximum # of KeyFobs supported: 7
• Dimensions:
• Receiver: 6 3/4“ X 3 5/8” X 1 1/2”
• KeyFob: 2 “ X 1 3/8” X 1/2”
• Relay Contact Rating: 1A @ 24 VDC
• KeyFob Battery: 1.5V Alkaline AAA size
• Frequency: 431 Mhz
• Operating Range: 750 feet (open air)
TABLE OF CONTENTS
Section Page
GENERAL DESCRIPTION.....................................................3
SYSTEM OVERVIEW.............................................................4
WIRING DIAGRAM/ CONFIGURATION.................................5
CONTROLS AND AUDIBLE INDICATORS..........................6
VISUAL INDICATORS.............................................................7
BUS MODE WIRING AND CONFIG......................................8
BUS MODE ENROLLING KEYFOBS...................................9
BUS MODE ENROLLING USER CODES............................10
BUS MODE GARAGE DOOR & SPECIAL APPS.............11
BUS MODE - TYPICAL APPLICATIONS.............................12
UNIVERSAL MODE WIRING ARM/DISARM/PANIC...........13
UNIVERSAL MODE ENROLLING KEYFOBS.....................14
UNIVERSAL MODE ARM / ALARM SENSE.......................15
UNIVERSAL MODE WIRING FOR STAY MODE................16
UNIVERSAL MODE GARAGE DOOR CONTROL..............17
CHANGING THE KEYFOB BATTERY..................................17
UNIVERSAL MODE - TYPICAL APPLICATIONS................18
WARRANTY..............................................................................20
For Technical Assistance, Contact the NAPCO
Toll Free Helpline ( [phone]
NAPCO Security Systems, Inc.
333 Bayview Avenue l Amityville, New York 11701
For Sales and Repairs, call Toll Free: [phone]

4WI1024B 2WAY-UNIVKF Installation Instructions
SYSTEM OVERVIEW
The 2WAY-UNIVKF is compatible with virtually any control panel either through bus compatible operation or universal mode
operation. When used on a panel on which it is bus-compatible, full functionality is realized, including lighting, appliance and X10
control. When used in the Universal Mode, functionality is dependent on the feature set of the control panel, such as a keyswitch
arm zone for arm / disarm capability, an armed output to provide an Armed indication, a steady bell output for an alarm indication
and a pulsing bell output for a fire alarm indication.
This manual is divided into 3 sections which are marked on the outer border of each page - General Information (pages 2-6),
which applies to both modes of operation, NAPCO Gemini / Ademco Bus Operation (pages 8-12) and Universal Operation
(pages 13-19). After reviewing the General Information section for an overview on the system, refer to the section which applies
to the type of installation at hand, Bus or Universal Operation and follow all indicated steps.
Bus Mode Features
Keyfob Commands
• Arm / Disarm
• Stay Mode Arming
• Panic
• Garage Door Control
• Appliance Control 1 / † Relay Group 1 Control
• Garage 2 or Appliance Control 2/ † Relay Group 2 Control
Keyfob Indicators
• Armed
• Armed Stay
• Armed / Zones Bypassed
• Disarmed / System Ready
• Disarmed / Zones Faulted
• Alarm
• Alarm Memory
• Fire Alarm
• System Trouble
• KeyFob Low Battery † NAPCO GEM-P3200 & P9600 only
Universal Mode Features
Keyfob Commands Required Control Panel Feature
• Arm / Disarm Keyswitch arm zone or input
(Momentary)
• Stay Mode Arming Automatic Interior Bypass
• Panic 24 hour panic zone
• Garage Door Control Standard
Use these tables to determine the Keyfob functionality you
can expect when used on a particular control panel.
General Information
Keyfob Indicators Required Control Panel Feature
• Armed / Disarmed Armed output or lug (high or low)
• Armed Stay Automatic Interior Bypass
• Alarm Steady bell output (high or low)
• Alarm Memory Steady bell output (high or low)
• Fire Alarm Pulsing Bell output (high or low)
• KeyFob Low Battery Standard

5
41 2 3 85 6 7 129 10 11 1613 14 15
WIRING DIAGRAM AND SYSTEM CONFIGURATION
A B
Invert Alarm Sense A Invert Armed Sense B
Enroll Mode Push Button Receiver LED
General Information
RED +12V DC
BLACK Ground
GREEN RX
YELLOW TX
Armed Sense Input
Alarm Sense Input
PGM
Relay 1 N/O
Relay 1 COM
Relay 1 N/C Relay 2 N/O
Relay 2 COM
Relay 2 N/C Relay 3 N/O
Relay 3 COM
Relay 3 N/C
RES RE4 RE3 RE2 RE1 R2T AR A3 A2 A1
Reserved J1
Invert Stay Mode PGM J2
Panel Type J3 Panel Type J4 Panel Type J5
Relay 2 momentary J6
Reserved J7
Keypad Address J8 Keypad Address J9 Keypad Address J10
System Configuration Jumpers
••
12345678910
Receiver LED Indications
KeyFob Enroll Mode Rapid Flash
User Enroll Mode Rapid Flash / Pulse
Universal Mode
Normal Operation Steady
Bus Mode Normal
Operation Pulsing
If not pulsing in Bus Mode,
check the following:
• Keypad not programmed
• Bus wiring incorrect

6WI1024B 2WAY-UNIVKF Installation Instructions
Audible Indicators
Each time a command is
issued, the KeyFob’s mini
sounder will issue an
audible confirmation beep
with the visual indication.
# of
Beeps Status
1Armed
2Disarmed
3Armed,
Stay mode
4Armed, zones
bypassed
5 †System Trouble
6...
(repeats) Alarm !
CONTROLS AND INDICATORS
General Information
Press ON/OFF to arm or
disarm the alarm system.
Hold Down ON/OFF to Arm
the system in STAY mode.
Press STATUS to
update the display
with the current
system status.
The proper icon(s)
will appear, accom-
panied by the appr-
opriate beep(s). (see
Audible Indicators)
The icon(s) will
automatically go out
in about 6 seconds.
ON/OFF ∗
∗
AND
Press ON/OFF and ∗∗ simultaneously to
activate lighting or other special application.†
†Bus Operation Only
The KeyFob antenna
may be extended for
increased operating
Controls
The KeyFob’s 4 command buttons provide complete system control. Commands are issued to
the alarm system by either pressing or holding down (for 2 seconds) the appropriate button.
Hold Down PANIC
for 2 seconds to
activate a panic
alarm.
PANIC
ON/OFF
∗ ∗
Press ∗∗ to open
garage door
Hold Down ∗∗ for 2
seconds to activ-
ate lighting or
other special appl-
ication. †
OR
Hold Down ∗∗ for 2
seconds to open a
second garage
door. †
STATUS

7
CONTROLS AND INDICATORS
General Information
Visual LCD Indicators
The 2WAY-UNIVKF uses a series of icons to convey the status of the system. Each time the STATUS button is pressed, or
a command is issued, the appropriate icon(s) will display for about 6 seconds. For example, if ON/OFF is pressed to arm the
system, the Armed Icon will light in a few seconds to confirm that the command was successfully carried out. Below is a
description of each icon indicator. Please note that the icons marked “†” are optional and may not apply to all systems.
Armed
The system is armed. System Ready The system is
disarmed, with all zones secure.
The system is ready to arm.
Transmit Each time a button is
pressed the transmit ICON will light to
indicate that the KeyFob is
transmitting to the receiver.
Armed Bypassed †
(slowly flashing) the system is
armed with zones bypassed.
Zones Faulted †(slowly flashing)
Disarmed, zones faulted.
Stay Mode †The system
is armed with interior zones
bypassed.
Fire Alarm †(flashing) The
system is in a fire alarm condition
System in Alarm / Alarm Memory
(flashing) The system alarm is sounding
or an alarm has occurred while you were
away. Proceed with caution!
System Trouble † The alarm system is in a
trouble condition. Consult keypad and owners
manual for the exact nature of the trouble.

8WI1024B 2WAY-UNIVKF Installation Instructions
STEP 1 - WIRING AND CONFIGURATION
Mounting
The 2 way receiver should be mounted in a location which is centrally located
in the area of anticipated usage. It is not recommended that the receiver be
installed in an attic or mounted within 24 inches of any metallic objects.
Installation in a basement will result in reduced range. It should not be mounted
in the control panel enclosure. The receiver should be positioned with the
antennas pointed up.
Wiring
The 2WAY-UNIVKF is compatible with the keypad bus of the NAPCO Gemini
GEM-P816, GEM-P1632, GEM-P3200 and GEM-P9600 control panels. It is
also compatible with the keypad bus of the Ademco models Vista 10 and 20.
Note: for Bus Operation, DO NOT connect any wires to terminals 5 & 6.
Programming
The Gemini control panel must be programmed for an additional keypad. For
example if the installation currently has 2 keypads, an additional keypad,
keypad # 3 must be enabled in programming. This is not required for the
Ademco Vista 10 and 20.
If KeyFob panic is desired, Keypad Panic should be enabled in the control
panel program. For the Ademco Vista 10 and 20, zone 95 must be programmed
for 24 Hr Audible or 24 Hr Silent. For the Vista 20 zone 99 must be
programmed for 24 Hr Audible or 24 Hr Silent.
Configuring the Receiver Address
For the NAPCO Gemini bus operation, the receiver must be addressed to
match the address of the additional keypad enabled in programming above. For
example, if the receiver is to be addressed as keypad 3, refer to the Receiver
Address Chart and install the appropriate address jumpers (J8 off, J9 ON,
J10 ON). This is not required for the Ademco Vista 10 and 20.
Configuring the Control Panel Type
For a bus compatible installations only, refer to the Panel Type Configuration
RECEIVER
GND+12V TX
41 2 3
RX
12
9
10
11
RED
BLACK
GREEN
YELLOW
GEMINI PANEL
RECEIVER ADDRESS CHART
KEYPAD ADDRESS JUMPERS
# J8 J9 J10
1off off off
1off off ON
2off ON off
3off ON ON
4ON off off
5ON off ON
6ON ON off
7ON ON ON
PANEL TYPE CONFIG. CHART
PANEL TYPE CONFIG. JUMPERS
J3 J4 J5
NAPCO GEM-P816, P1632, P3200, P9600 off off off
Ademco Vista 10, 20 off off ON
Ademco 40, 50 off ON off
RECEIVER
GND+12V TX
41 2 3
RX
RED
BLACK
GREEN YELLOW
ADEMCO PANEL
NAPCO Gemini & Ademco Bus Operation

9
STEP 2 - ENROLLING KEYFOBS
Enrolling and Removing KeyFobs
Each KeyFob to be used in the system must be enrolled into the receiver. The following procedure is used to enroll
the unique RF ID number stored in the non volatile memory of each KeyFob into the receiver memory.
1Arm system from any keypad
2Disarm system from any keypad
3Enter Unique Code 1114 [ON/OFF] / [STAY] The Enroll Mode LED will flash rapidly.
The keypad will give error beeps - ignore.
4Press the ∗∗ button on KeyFob 1 The KeyFob will sound a confirmation beep.
.... Repeat for each KeyFob to be enrolled
• Press [RESET] on Keypad OR [ON/OFF] on Keyfob Exit Enroll Mode - the Enroll Mode LED will go out
• All instructions which require keystroke entry on the NAPCO or Ademco keypad will be followed by the appropriate button in
[NAPCO] / [Ademco] format. For example [ON/OFF] / [STAY].
• The Keyfob Enroll Mode may also be entered / exited by pressing the the Enroll Mode Push Button on the top of the
receiver. See page 15 for more information.
To Remove a lost KeyFob from the system: Enter and then exit the Keyfob Enroll Mode. Enter 1114 [ON/OFF] /
[STAY] and then press [RESET]. All keyfobs will be deleted from the system.
NAPCO Gemini & Ademco Bus Mode

10 WI1024B 2WAY-UNIVKF Installation Instructions
STEP 3 - ENROLLING USER CODES
Enrolling User Codes into the 2 Way receiver
The 2 way receiver must be “taught” the User code which will represent each KeyFob to be used on the system. This allows the
receiver to uniquely identify each KeyFob and log KeyFob opening and closing activity in the control panel’s event buffer as well
as report openings and closings by KeyFob user if desired.
Note: Before proceeding, a 4 digit User Code representing each KeyFob must be programmed into the control panel.
1Arm system from any keypad
2Disarm system from any keypad
3Enter Unique Code 1113 [ON/OFF] / [STAY] Enroll Mode LED will flash / pulse
The keypad will give error beeps -
ignore.
4Enter 4 digit User Code to represent KeyFob # 1, press [ON/OFF] / [AWAY] System will Arm
5Reenter the 4 digit User Code for KeyFob # 1, press [ON/OFF] / [OFF] System will Disarm
System will automatically test
code by quickly Arming and
Disarming.
... Repeat steps 4 & 5 for each KeyFob to be enrolled
• Press [RESET] on Keypad Exit Enroll Mode - the Enroll
Mode LED will go out
NAPCO Gemini & Ademco Bus Operation

11
When installed on the bus of a Gemini Series or Ademco control panel, the receiver Relays 1 and 2 are available for other
applications such as lighting or appliance control, while Relay 3 remains dedicated to the control of a garage door opener. It is also
possible to configure Relay 2 to control a second garage door (or other access application requiring a momentary closure).
Pressing [∗∗] will activate Relay 3 momentarily and holding down [∗∗] for 2 seconds will activate Relay 2 momentarily when
configured for garage door 2 operation. (Install Jumper 6 - Relay 2 momentary).
GARAGE DOOR CONTROL / SPECIAL APPLICATIONS
Gemini Relay Control Group Support
When used on a Gemini series control which supports Relay Control Groups (GEM-P3200 & P9600), each time the
KeyFob is used to activate Relay 1 or Relay 2, Relay Control groups 1 & 2 are also simultaneously activated, allowing
control of external relays and/or X-10 devices connected to the control panel.
Press [∗∗] to momentarily activate
Relay 3 to open a garage door.
COM
N/O N/C
14 15 16
Garage door opener wall mounted
push-button, or normally open
garage door opener input.
Garage Door Control
Lighting or other special
application device.
Press [ON/OFF] and [∗∗]
simultaneously to toggle
Relay 1 On / Off
COM
8
N/O N/C
9 10
+-
Relay 1 Appliance
Control
Low
Voltage
Hold Down [∗∗] for 2 seconds to
toggle Relay 2 On / Off
COM
11
N/O N/C
12 13
Lighting or other special
application device.
+-
Relay 2 Appliance
Control
Low
Voltage
Hold Down [∗∗] for 2 sec. to
momentarily activate Relay 2 to
open a second garage door.
COM
N/O N/C
11 12 13
Garage door opener wall mounted
push-button, or normally open
garage door opener input.
Relay 2 Second Garage
Door Control
Install Jumper
across Config
Pins J6
J6
NAPCO Gemini & Ademco Bus Mode

12 WI1024B 2WAY-UNIVKF Installation Instructions
TYPICAL APPLICATIONS
1 2 3 4 5 6 7 8 910
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
6
7
8
9
10
5
11
12
REMOTE PWR +
GEM-P3200 / GEM-P9600
13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
REMOTE PWR -
RX
TX
GEM-X10
R
COMPUTERIZED SECURITY SYSTEM
GEMINI
ARMED
STATUS
SYSTEM ARMEDSYSTEM ARMED
01/01/97 12:00AM01/01/97 12:00AM
1 2
4
3
5 6
7 8 9 0
A
B
C
DE
F
G
NEXT/YES
PRIOR/NO
AREA
SYSTEM ARMED
01/01/00 12:00 AM
2WAY-
Garage Door
Control
Door 1
Door 2
Appliance
Typical Gemini control panel application controlling 2
Garage doors and X-10 devices and appliances through
the 2WAY-UNIVKF Keyfob.
12 3 4 5 6 7 8 9 10
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
VISTA-20se
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
2WAY-UNIV
Typical Ademco control panel application controlling 1
Garage door and 2 appliances through the 2WAY-
UNIVKF Keyfob.
RED
BLK
GRN
YEL
RED
BLK
GRN
YEL
Appliance
Appliance
Garage Door
Control
NAPCO Gemini & Ademco Bus Operation

13
Wiring for Arm / Disarm
Program a zone on the control panel for “Keyswitch Arm”
• When [ON/OFF] is pressed, the Arm/Disarm relay will
change state (from normally closed to normally open) for 2
seconds and then restore, causing the control panel to arm
or disarm.
Zone programmed for
Keyswitch Arm
Typical Keyswitch wiring
for a zone using
End of Line resistors
EOLR
COM
8
N/O N/C
9 10
Typical Keyswitch wiring
for a “zone doubled” zone
Zone programmed for
Keyswitch Arm
COM
8
N/O N/C
9 10
ZDR*
Wiring for Panic
Program a zone on the control panel as a 24 Hour Panic
Zone.
• When [PANIC] is pressed, the Panic relay will change
state (from normally closed to normally open) for 2
seconds and then restore, causing an alarm on the the
control panel Panic Zone.
Zone programmed for
24 hour panic
Typical Panic wiring
for a zone using
End of Line resistors
Zone programmed for
24 hour panic
Typical Panic wiring
for a “zone doubled” zone
EOLR
COM
11
N/O N/C
12 13
COM
11
N/O N/C
12 13
ZDR
STEP 1 - WIRING FOR ARM / DISARM AND PANIC
Universal operation requires the use of control panel zones to provide Arm / Disarm and Panic operation. One zone must be
programmed as a keyswitch arm zone which will process a 2 second violation as an Arm / Disarm command. The other zone must
be programmed as a 24 hour panic zone, which will process a 2 second violation as a panic alarm. The wiring instructions below
include wiring schemes for control panels which support zone doubling, such as the NAPCO Express series.
EOLR PANEL ZONE DOUBLED PANEL EOLR PANEL ZONE DOUBLED PANEL
* ZDR = Zone Doubling Resistor * ZDR = Zone Doubling Resistor
Universal Operation

14 WI1024B 2WAY-UNIVKF Installation Instructions
Universal Operation
Enrolling and Removing KeyFobs
Each KeyFob used in the system must be enrolled into the receiver
using the following procedure:
1Use a pen or pencil to depress and hold the recessed
Enroll Mode Push Button on the top of the receiver.
Release when the Enroll Mode LED begins to flash.
Entered Enroll Mode - The Enroll Mode LED will
continue to flash.
2Press the ∗∗ button on KeyFob 1. The KeyFob will sound a confirmation beep.
3Press the ∗∗ button on KeyFob 2 (if more than one). The KeyFob will sound a confirmation beep.
... Repeat for each KeyFob to be programmed into system.
• Hold Down Enroll Mode Push Button or KeyFob ON/OFF.Exit Enroll Mode - the Enroll Mode LED will go out.
To remove a lost KeyFob from the system: Enter and then exit the Keyfob Enroll Mode. (Hold down Enroll Mode
Push Button until Enroll Mode LED flashes, release and then hold down again to exit Enroll Mode). All keyfobs will be
deleted from system.
!
Enroll Mode
LED
Receiver
Enroll Mode
Push Button
STEP 2 - ENROLLING KEYFOBS

15
Universal Operation
Wiring for Arm Sense
In Universal Mode, the receiver requires an Armed output from
the control panel in order to pass the system status to the
KeyFob. It may be configured for either a positive sense or
negative sense.
Wiring to a control panel with
an Armed output which goes
negative upon arming.
5
Wiring to a control panel with
an Armed output which goes
positive upon arming.
5
STEP 3 - WIRING FOR ARM & ALARM SENSE
Wiring for Alarm Sense
In Universal Mode, the receiver requires an Alarm output from
the control panel in order to pass the correct status to the
KeyFob. Typical connection will be to the bell output of the
control panel. It will automatically display a siren icon for a
steady input and a fire icon for a pulsing or temporal fire output.
The Alarm Sense input may be configured for either a positive
or negative output.
Wiring to a control panel with
an Alarm output which goes
positive upon alarm.
Wiring to a control panel with
an Alarm output which goes
negative upon alarm.
6
+
Positive
Bell
Output
6
-
Negative
Alarm
Output
Negative = less than 3 V DC
Positive = greater than 7 V DC Negative = less than 3 V DC
Positive = greater than 7 V DC
Remove Jumper
from Config Pin A
A
Install Jumper on
Config Pin A
A
Remove Jumper
from Config Pin B
B
Install Jumper on
Config Pin B
B

16 WI1024B 2WAY-UNIVKF Installation Instructions
Universal Operation
Wiring for Stay Mode
When installed on a control panel which provides “Automatic Interior Bypass”, the system can be armed in either the AWAY or
STAY mode through the KeyFob. A system which provides “Automatic Interior Bypass” controls the Interior protection by
automatically bypassing the motion zones if the system is armed and the exit/entry door is not opened. Program the control
panel for “Automatic Interior Bypass”, or for “Home Away with Delay” (for the NAPCO Express Series stay mode). Each time the
system is armed by a press of KeyFob button [ON/OFF], the system will arm in the AWAY mode, providing complete protection.
If the KeyFob button [ON/OFF] is held down for 2 seconds, the system will arm in the in the STAY mode, providing perimeter
protection only.
Choose the appropriate wiring scheme for your control panel.
• When KeyFob button [ON/OFF] is pressed, the PGM terminal of the receiver will cause a violation of the exit entry zone, which
will arm the system in the AWAY mode.
• If KeyFob button [ON/OFF] is held down for 2 seconds, the system will arm without the PGM violation of the E/E zone, which
will arm the system in the STAY mode.
For the NAPCO Express Series
and GEM-P400/P800 controls:
• Program the interior zones for
for home away with delay and
wire as shown.
• Install jumper J2 to invert PGM
operation
Zone programmed
for Exit Entry
Typical STAY mode wiring for a control
panel using End of Line resistors
Protective zone
device and EOLR
PGM
56 7
+-
EOLR
Typical STAY mode wiring for a control
panel using Zone Doubling
Zone programmed
for Exit Entry
Protective zone device and
Zone Doubling Resistor.
PGM
56 7
+-
ZDR
Wiring for Stay Mode
Install Jumper
across Config
Pins J2
J2
EOLR PANEL ZONE DOUBLED PANEL

17
Universal Operation
Wiring for Garage Door Control
In Universal operation, the 2WAY-UNIVKF may be used to
control a garage door opener, or any other access control
device which requires a momentary closure for activation.
The typical installation will require that the N/O and COM
terminals of Relay 3 be wired across the wall mounted
push-button switch for the garage door control as shown in
the diagram below.
• Pressing the ∗∗ button will provide a 2 second short
across these terminals, prompting the garage door
opener to activate.
Garage door opener wall mounted
push-button switch, or normally open
garage door opener input.
Typical wiring for a controlling a
garage door opener from KeyFob.
COM
14
N/O N/C
15 16
GARAGE DOOR CONTROL
Note: There is no need to re-enroll the KeyFobs after
a battery change.
Use only AAA 1.5 Volt alkaline battery.
3Replace battery compartment cover
Changing the KeyFob battery
G
1Open battery compartment on back of Keyfob.
AAA
+
2Remove old battery and replace with new.

18 WI1024B 2WAY-UNIVKF Installation Instructions
TYPICAL APPLICATIONS
6
7
8
9
5
12
REM.PWR +
MA1008e
13 14 15 16 17 18 19 20 21 22 23 24 25 26
REM. PWR -
1 2 3 4 5 6 7 8 910
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
2WAY-UNIV
4
3E4 ARMED LUG
10
11 +Z1-+ + +-Z2 Z4Z3 + + +
Z5 Z7Z6
-
VVVV
VVV
EOL VVV
EOL
EOL
ARM SENSE
ALARM SENSE
+ PWR
- PWR
STAY MODE PGM (3)
KEYSWITCH ZONE 7 (1) PANIC ZONE ZONE 6 (2)
E/E ZONEà
NOTES:
(1) Enable Keyswitch Input on Zone 7 [183-8].
(2) Program Panic Zone 6 for 24 Hour [199-2].
(3) Enable Automatic Group Bypass [065-4]
and program all Interior Zones for Group
Bypass [196 -X, 197-X]
(4) For BOTH Fire AND Burg sense, (2) IN4001
1 2 3 4 5 6 7 8 910
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
2WAY-UNIV
Garage Door
Control
VVV
3.9K
KEYSWITCH ARM
NOTES:
(1) Enable Keyswitch Input on Zone 6 [26-1].
(2) Enable Armed Output on PGM [25-4].
(3) Program Zone 5 for 24 Hour [05-5].
(4) Enable Home/Away with Delay [01-X] for all
E9 Fire LUG
E10 Burg LUG
(4)
Garage Door
Control
VVV
2.2K
ZONE 6 (1)
PANIC ZONE
ZONE 5 (3)
VVV
E/E ZONE 1 à
STAY MODE PGM (4)
ARM SENSE (2)
2.2K
ALARM SENSE
GEM-P800
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Z1/2
+-+ +
Z3/4 Z5/6
-15
PGM
- PWR
+ PWR
+ BELL OUTPUT
16 17 18 19
Typical Universal Mode applications with EOLR Control Panel (MA1008e) and Zone Doubled Control Panel (GEM-P800) using Arm
and Alarm sense with Stay Mode and Garage Door control.
Universal Operation

19
Universal Operation
TYPICAL APPLICATIONS
Typical Universal Mode applications with EOLR Control Panels using Arm and Alarm sense with Stay Mode and Garage Door
control.
12 3 4 5 6 7 8 9 10
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
2WAY-UNIV
Garage Door Control
VVV
EOL
VVV
EOL
PANIC ZONE (3)
KEYSWITCH ARM ZONE (1)
STAY
BELL + 24
BELL - 23
COM 18
AUX PWR + 17
Z8 16
COM 15
Z7 14
Z6 13
COM 12
Z5 11
Z4 10
COM 9
Z3 8
Z2 7
COM 6
Z1 5
AUX OUT 4 4
AUX OUT 3 3
AUX OUT 2 2
AUX OUT 1 1
Caddx
NX8
NOTES:
(1) Enable Keyswitch Input (Example Zone 8, Location 25, Segment 8=11)
(2) Enable Armed Output on AUX OUT 1. Location 47, Segment 1= 21, Segment 2=0)
(3) Program Panic Zone (Example Zone 7 (24 Hour Silent) Location 25, Segment 7= 7
and other appropriate options such as reporting, audibles, etc...)
(4) Enable Automatic Interior Bypass (Location 23, Segment 1 = 3) and set for all Interior
Zones (Location 25, Segment X=18).
ARM SENSE (2)
ALRM SENSE (5)
MODE PGM
(4)
1 2 3 4 5 6 7 8 910
12345678910 11 12 13 14 15 16
2WAY-UNIV
NOTES:
(1) Enable Keyswitch Input (Example Zone 8 Location
001=22)
(2) Enable Armed Output on PGM1 Location 009=05)
(3) Program Panic Zone for 24 Hour (Example Zone 7
Location 001=16)
(4) Enable Automatic Interior Bypass for all Interior
STAY MODE PGM (4)
DSC Power 832
PC5010
3 4 5 6 11 12 13 14
Z1
+-+ +
Z2 -
15
PGM1
+AUX - AUX
+ BELL OUTPUT
16 17 18 19 20 21 22 23 24
Z3 + Z4 +- Z5 + Z6 +- Z7 + Z8
KEYSWITCH ARM ZONE (1)
VVV
EOL
VVV
EOL
PANIC ZONE (3)
ALARM SENSE
ARM SENSE (2)
Garage Door Control

20 WI1024B 2WAY-UNIVKF Installation Instructions
NAPCO SECURITY SYSTEMS, INC. (NAPCO) warrants its products to be free from
manufacturing defects in materials and workmanship for thirty-six months following the date
of manufacture. NAPCO will, within said period, at its option, repair or replace any product
failing to operate correctly without charge to the original purchaser or user.
This warranty shall not apply to any equipment, or any part thereof, which has been repaired
by others, improperly installed, improperly used, abused, altered, damaged, subjected to
acts of God, or on which any serial numbers have been altered, defaced or removed. Seller
will not be responsible for any dismantling or reinstallation charges.
THERE ARE NO WARRANTIES, EXPRESS OR IMPLIED, WHICH EXTEND BEYOND THE
DESCRIPTION ON THE FACE HEREOF. THERE IS NO EXPRESS OR IMPLIED
WARRANTY OF MERCHANTABILITY OR A WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE. ADDITIONALLY, THIS WARRANTY IS IN LIEU OF ALL OTHER
OBLIGATIONS OR LIABILITIES ON THE PART OF NAPCO.
Any action for breach of warranty, including but not limited to any implied warranty of
merchantability, must be brought within the six months following the end of the warranty
period.
IN NO CASE SHALL NAPCO BE LIABLE TO ANYONE FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY,
EXPRESS OR IMPLIED, EVEN IF THE LOSS OR DAMAGE IS CAUSED BY THE SELLER'S
OWN NEGLIGENCE OR FAULT.
In case of defect, contact the security professional who installed and maintains your security
system. In order to exercise the warranty, the product must be returned by the security
professional, shipping costs prepaid and insured to NAPCO. After repair or replacement,
NAPCO assumes the cost of returning products under warranty. NAPCO shall have no
obligation under this warranty, or otherwise, if the product has been repaired by others,
improperly installed, improperly used, abused, altered, damaged, subjected to accident,
nuisance, flood, fire or acts of God, or on which any serial numbers have been altered,
defaced or removed. NAPCO will not be responsible for any dismantling, reassembly or
reinstallation charges.
This warranty contains the entire warranty. It is the sole warranty and any prior agreements
or representations, whether oral or written, are either merged herein or are expressly
canceled. NAPCO neither assumes, nor authorizes any other person purporting to act on its
behalf to modify, to change, or to assume for it, any other warranty or liability concerning its
products.
In no event shall NAPCO be liable for an amount in excess of NAPCO's original selling price
of the product, for any loss or damage, whether direct, indirect, incidental, consequential, or
otherwise arising out of any failure of the product. Seller's warranty, as hereinabove set forth,
shall not be enlarged, diminished or affected by and no obligation or liability shall arise or
grow out of Seller's rendering of technical advice or service in connection with Buyer's order
of the goods furnished hereunder.
NAPCO RECOMMENDS THAT THE ENTIRE SYSTEM BE COMPLETELY TESTED
WEEKLY.
Warning: Despite frequent testing, and due to, but not limited to, any or all of the following;
criminal tampering, electrical or communications disruption, it is possible for the system to
fail to perform as expected. NAPCO does not represent that the product/system may not be
compromised or circumvented; or that the product or system will prevent any personal injury
or property loss by burglary, robbery, fire or otherwise; nor that the product or system will in
all cases provide adequate warning or protection. A properly installed and maintained alarm
may only reduce risk of burglary, robbery, fire or otherwise but it is not insurance or a
guarantee that these events will not occur. CONSEQUENTLY, SELLER SHALL HAVE NO
LIABILITY FOR ANY PERSONAL INJURY, PROPERTY DAMAGE, OR OTHER LOSS
BASED ON A CLAIM THE PRODUCT FAILED TO GIVE WARNING. Therefore, the installer
should in turn advise the consumer to take any and all precautions for his or her safety
including, but not limited to, fleeing the premises and calling police or fire department, in order
to mitigate the possibilities of harm and/or damage.
NAPCO is not an insurer of either the property or safety of the user's family or employees,
and limits its liability for any loss or damage including incidental or consequential damages to
NAPCO's original selling price of the product regardless of the cause of such loss or
damage.
Some states do not allow limitations on how long an implied warranty lasts or do not allow the
exclusion or limitation of incidental or consequential damages, or differentiate in their
treatment of limitations of liability for ordinary or gross negligence, so the above limitations or
exclusions may not apply to you. This Warranty gives you specific legal rights and you may
also have other rights which vary from state to state.
WI1024B 03/01
NAPCO LIMITED WARRANTY
NAPCO Security Systems, 333 Bayview Avenue, Amityville, NY 11701
FCC ID: AD82WAYUNIVKF
This device complies with part 15 of the FCC Rules. Operation is subject
to the following:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesired operation.
