GENERAL DESCRIPTION
Napco's iBridge™IBR-TOUCH and the wireless IBR-
TOUCH-WL are high-
resolution LCD touchscreen
tablets that provide seamless
access to all the features of
your Gemini security system.
Both touchscreens are simple
to use, with intuitive menu-
driven icons and prompts to
help guide you.
FEATURES
Each touchscreen model has many convenient features:
 Touch screen control of security system
 The model IBR-TOUCH connects to the Gemini se-
curity system 4-wire bus
 The model IBR-TOUCH-WL is powered by a sup-
plied 12VDC adapter and wirelessly connects to your
security system
 Integrated IP video viewing of cameras
 High-speed, powerful quad core processor
 Large high-resolution 1024 x 600 pixel display for clari-
ty
 Intuitive capacitive touchscreen display with icons and
menu driven prompts
 802.11 Wireless Wi-Fi Connectivity
 Entry/Exit countdown displayed
 Add or delete User Codes
 Quickly and easily bypass zones
 The touchscreen is one part of the integrated Napco
iBridge™Remote Control Services that include a virtual
keypad, Z-Wave®Home Controls and integrated video.
Compatible with the following control panels:
 GEM-P816
 GEM-P1632
 GEM-P1664
 GEM-P3200
 GEM-P9600
 GEM-X255
Important: A standard wired keypad must be installed
and enrolled in the system before adding a IBR-TOUCH
or IBR-TOUCH-WL touchscreen. In addition, be aware
that this standard wired keypad must be available for arm-
ing or disarming should the touchscreen(s) be temporarily
disabled during a firmware update. Visit
www.napcosecurity.com for ordering information and ap-
proved Z-Wave devices.
SPECIFICATIONS
Electrical Ratings
Speaker: 1 Integral 2W
Electrical Ratings
Screen on, idle: 300mA
Clicking menu items: 380mA. Important: Ensure
system standby current is sufficient; if not, a separate
UL-Listed Security and Signaling power-limited 12V
power supply for each touchscreen is required (see wir-
ing diagrams).
Features
CPU: Quad core processor, (up to 1.6GHz)
Wi-Fi: 802.11b/g/n with integral antenna
LCD Size: 7 inch digital screen
Resolution Ratio: 1024 x 600 x, 16:9 aspect ratio,
16.7 million colors
Pixels: 1024 x RGB (3) x 600
Touch Screen: Digital and full-screen, capacitive
Housing
Dimensions (HxWxD): 5-3/8 x 7-7/8 x 7/8 in. (13.7 x
20 x 2.2 cm)
Weight: 14.3oz (405g)
Operating Temperature: 0-49°C (32-120°F)
SELECTING THE MOUNTING LOCATION
The touchscreen requires power supplied from the control
panel keypad bus (wires are intended to be hidden within
the mounting surface). Important: Ensure system
standby current is sufficient; if not, a separate UL-Listed
Security and Signaling power-limited 12V power supply
for each touchscreen is required (see wiring diagrams).
Mount the touchscreen indoors only, and avoid high con-
densation areas such as bathrooms. Avoid mounting in
locations where direct sunlight or bright light shines direct-
ly on the screen.
INSTALLATION - HOLLOW WALL
If installing into a 3-gang box, see instructions below. On
the Mounting Template (see page 12) and also shown in
the image below, note the location of the four rear case
mounting holes. In addition, four slotted holes are provid-
ed for mounting to a 2-gang box. Also note the location of
the center hole for use with routing the red/black/green/
yellow keypad bus wires (with the "wired" model IBR-
TOUCH) or the power wire (with the "wireless" model
IBR-TOUCH-WL). When the touchscreen is mounted,
the rear case center hole is intended to align with the cen-
ter hole on the template.
WI2296LF 6/18
333 Bayview Avenue, Amityville, New York 11701
For Sales and Repairs, [phone]
For Technical Service, [phone] or visit us at
http://tech.napcosecurity.com/
(Note: Technical Service is for security professionals only)
Publicly traded on NASDAQ Symbol: NSSC
© NAPCO 2018
IBR-TOUCH / IBR-TOUCH-WL
Touchscreen Tablets
.
.
IBR-TOUCH & IBR-TOUCH-WL
iBridge™Touchscreen Tablets
Installation Instructions

2
To secure the touchscreen directly to a hollow dry wall or
similar surface, proceed as follows:
1. Select a mounting location that is preferably at eye level
for easy viewing and that also allows the power / keypad
bus wires to be hidden within the mounting surface. At
the rear of the touchscreen, make note of the center hole
for the power / keypad bus wires (see image above).
2. With the final mounting location selected, place the
Mounting Template (see page 12) on the mounting sur-
face and mark the four touchscreen mounting holes and
the center hole for power / keypad bus wires. Use a lev-
el to ensure horizontal mounting.
3. Using a 3/16" bit, drill the four touchscreen mounting
holes in the mounting surface. Insert wall anchors into
the holes and tap anchors into wall with a hammer. Use
part MX1327 #6 wall anchor, supplied.
4. Drill the center hole for the power / keypad bus wires in
the mounting surface. Snake the keypad bus wires from
the control panel (or the power wire from the DC power
supply) into the interior of the mounting surface, then out
through the center hole drilled in the mounting surface.
5. Detach the rear case from the touchscreen: Insert a flat
head screwdriver into the two slots at the bottom of the
touchscreen, then push and turn the screwdriver to un-
hook the two plastic tabs.
6. Insert the wires from the wall center hole through the
center hole of the rear case. Insert screws through the
four rear case mounting holes into the four wall anchors
using the supplied #6 sheet metal Phillips pan head 1"
screws (part SC655).
7. Connect the keypad bus wires to the terminal strip locat-
ed inside the touchscreen (red to +12V, black to -GND,
yellow to YEL and green to GRN).
8. Push wires into the center hole in the mounting surface.
Place the top edge of the touchscreen over the two
hooks in the rear case and push the bottom of the
touchscreen until it snaps into place.
NOTE: If wiring to a 4-wire bus control panel, the IBR-
ZREMOTE or StarLink Connect radio must be wired
to the control panel bus and must have its own unique
keypad address. It is factory set as keypad address #1
but can be changed. If you wish to change the keypad
Touchscreen rear case mounting holes for hollow walls
(arrows) and the "center hole" for power / keypad bus wires
"center hole" for
power or
keypad bus wires
address with a touchscreen, the model IBR-TOUCH-WL
touchscreen MUST be used (or an IBR-TOUCH running
with the setting "Connect using Wi-Fi Only" enabled, and
thus is acting as a model IBR-TOUCH-WL). In addition,
the touchscreen must be connected to the same network
as the IBR-ZREMOTE or StarLink Connect radio. Any
attempt to change the keypad address using an IBR-
TOUCH without "Connect using Wi-Fi Only" enabled will
result in the changing of the keypad address of the inte-
gral RCM module located inside the IBR-TOUCH.
To change the keypad address, proceed as follows:
Power the touchscreen, place the control panel into Con-
figuration Mode and enter 11123 FUNCTION (as you
normally would for Keypad Configuration Mode) and then
press FUNCTION until you see "Keypad Address".
Change address number and then press ON/OFF to
save. Place the alarm control panel back in normal
mode.
INSTALLATION - 3-GANG BOX
If installing the touchscreen rear case directly to a hollow
dry wall or similar surface, see instructions above. To se-
cure to a 3-gang box, proceed as follows:
1. Select a mounting location that is preferably at eye level
for easy viewing. At the rear of the touchscreen, make
note of the center hole for the power / keypad bus wires
(see image on this page).
2. With the 3-gang box installed, snake the keypad bus
wires from the control panel (or the power wires from the
12VDC adapter) into the 3-gang box.
IMPORTANT: In the steps that follow, be careful not
to drill into the keypad bus / power wires inside the 3-
gang box.
3. Place the Mounting Template (see page 12) over the 3-
gang box and mark the location of the four mounting
holes in the 3-gang box.
4. Detach the rear case from the touchscreen: Insert a flat
head screwdriver into the two slots at the bottom of the
touchscreen, then push and turn the screwdriver to un-
hook the two plastic tabs.
5. Transfer the location of the four 3-gang box mounting
holes marked on the template in step 3 to the
touchscreen rear case.
6. Using a 3/16" bit, drill the four 3-gang box mounting
holes in the touchscreen rear case.
7. Insert the wires from the 3-gang box through the center
hole of the rear case. Insert screws through the four rear
case mounting holes (that were drilled in step 6) into the
four mounting holes in the 3-gang box. Use the supplied
#6 sheet metal Phillips pan head 1" screws (part SC655).
8. Connect the keypad bus wires to the terminal strip locat-
ed inside the touchscreen (red to +12V, black to -GND,
yellow to YEL and green to GRN).
9. Push wires from the center hole of the touchscreen into
the 3-gang box. Place the top edge of the touchscreen
over the two hooks in the rear case and push the bottom
of the touchscreen until it snaps into place.

3
