Narvitech NS120 User manual

1

2
Content
How to live stream via Xsplit with NS120 3
Download and install 3
Video and Audio settings 7
Start streaming 9
Start recording 12
How to live stream via OBS with NS120 13
Download and install 13
Setting 14
Start streaming 17
Start recording 19
Statement 20
Get assistance 21

3
How to live stream via Xsplit with NS120
The XSplit which included with the NS120 is a fully functional and easy-to-use live broadcast
software. Before starting to introduce the software, please be sure to complete the
connection process on the quick guide (please refer to: How to connect?). The following live
broadcast process will be demonstrated by using a PS4 as video source.
1. The software only supports Windows 10 and Windows 8.1
2. The software serial number card (one month only) is provided in the NS120 package, and the
software needs to be downloaded from the XSplit o󽗋cial website.
3. The serial number attached is for XSplit Broadcaster Professional Edition (one month)
Download and install
First, go to XSplit's o󽗋cial website and click "Download Broadcaster"
Then, open the file and start to download. After the download is complete, select the
language: English

4
Start installation
After the installation is completed, the login window will pop up, click "Sign In or Sign Up"
Click "Continue without upgrading"

5
After entering the main screen of XSplit Broadcast, click "Uppgrade" at the top
After entering the website, scroll up and click Broadcaster
After entering the serial number, restart XSplit Broadcast
Enter the serial number card
included in the NS120 package

6
After restarting, "Your plug-in has been updated" appears in the upper left corner of the
window interface, indicating that the professional version has been successfully upgraded.

7
Video and audio settings
After entering the serial number, click "Add Resource" in the lower left corner and then click
[Device> Video> Narvitech Video Capture Wand Video]
1. If the main screen is black after selecting the device video, please turn o󽗈 the HDCP of the
video source device [PS4: Settings> System> HDCP> O󽗈] [PS5: Settings> System> HDMI> HDCP>
O󽗈]
Click "Settings" in the lower left corner to open the window, click [Con󽗉gure> Video
Output]. Adjust the live screen output size according to your personal needs. If you want to
stream in 1080p, it is recommended that your upload bandwidth is at least 15Mbps or more
(Can be tested through Google Fiber)

8
The video setting of NS120 is now completed, and you are ready to start live broadcasting!
1. Click any resource in the list below and press "Delete" to delete it.
2. For other detailed settings and functions, please go to [XSplit o󽗋cial website> Support> XSplit
Broadcaster> User manual]
3. For live streaming, it is recommended that the resolution setting is adjusted to 1080p or 720p,
and the frame rate is adjusted to 60FPS or 30FPS
Next is the audio input. After selecting HDMI (Narvitech Video Capture Wand Audio), you can
adjust the volume of the NS120 input to the live broadcast

9
Start streaming
After the hardware connection and software settings are completed, you can prepare to
stream. Please be sure to test before the live broadcast (for example: sign up a test account
to check for your streaming quality) to ensure that the resolution, volume, and content of
the live broadcast are what you want.
1. To stream on Youtube, an account must be signed up 󽗉rst
2. Youtube activation process: [Youtube homepage> click "Create" in the upper right corner of
the page> Live broadcast and wait for 24 hours to activate the account.]
3. The highest resolution of Facebook live streaming only supports 720P
First click on the upper left corner [Broadcast> Create a new output> Choose one of the
platforms (Twitch as an example)]
Click "Authorize XSplit to use Twitch" and open the login window. After entering the
account and password, the system will automatically send a veri󽗉cation code to your
email. Copy the veri󽗉cation code from the email and paste it to the 󽗉eld.

10
Next, enter the live broadcast settings and go directly to [Video Encoding>
Bitrate(kbps)]. Generally, it is recommended to be around 2000~2500. If there is no
special requirement, the other settings do not need to be changed.
After all settings are completed, click [Broadcast> Twitch] in the upper left corner to
start live streaming directly.
After clicking the next step, XSplit will automatically set it up, based on your network
bandwidth and computer performance, to recommend you a suitable server and image
quality settings. After that, please click Finish
