National Mower Company 2006 Master Parts List
PART
NUMBER DESCRIPTION
02012 HHCS 5/16-24 X 1
02036 HHCS 3/8-24 X 2 1/4
02070 BOLT, 1/2 20 X 2 3/4
02097 SCREW, 1/4-20 X 3/4 BUTT ON HD
02106 SCREW, 1/2-13 X 2 SFMS
02109 SCREW, 5/16 X 24 X 3/4 FSCS
02114 WHEEL BOLT 7/16-20 X 1 7/32
02149 SCREW, 1/4-20 X 1 1/4 FLAT HD
02154 HHCS 1/2-13 X 1/2"
02212 NUT, HEX, 1/2"-20 NF
02228 FHJN 5/16-24
02236 FHJN 9/16-18
02238 FHJN 5/8-11
02240 FHJN 3/4-16 BZ
02250 WHEEL NUT 7/16-20
02262 FHN N/E 5/16-24
02263 FHN N/E 3/8-24
02272 FHJN N/E 1-12
02277 FHJN 5/16-24 FLEX LOC
02286 FHJN 7/8-9
02294 NUT, CASTLE, 3/4-16
02296 FHJN 5/16-18
02301 WASHER, LOCK 1/4"
02402 WASHER, FLAT 5/16 SAE
02407 WASHER, FLAT 5/8
02501 WASHER MACH 1 1/4 X 3/4 X .030
02502 WASHER MACH 1 1/4 X 3/4 X .060
02503 WASHER MACH 1 1/4 X 3/4 X .134
02505 WASHER, 1/32" X 7/8" I.D.
02506 WASHER, 1/16" x 7/8" I.D.
02507 WASHER, 1/8" X 7/8" I.D.
Page 1 of 34

National Mower Company 2006 Master Parts List
PART
NUMBER DESCRIPTION
02510 WASHER, 1/8" X 1-1/8" I.D.
02511 THRUST WASHER
02512 THRUST WASHER
02602 DUST CAP, 3/4" I.D.
02603 DUST CAP, 7/8" I.D.
02607 WASHER, AXLE, OUTSIDE 1/8"
02621 WASHER
02622 WASHER, BEARING CARRIER
02623 WASHER, 1" I.D.
02624 WASHER, 1-5/8" I.D.
02632 DUST CAP, ROLLER BRACKET
02637 INNER SEAL WASHER, ROLLER
02641 ROLLER WASHER
02644 PUSH ARM WASHER
02651 WASHER, FLAT 3/4 SAE
02751 HEX JAM NUT, NYLOCK,3/4-16
03010 BEVEL GEAR, SIDE DIFF.
03011 PINION GEAR, DIFFERENTIAL
03102 SPROCKET, REAR MOWER,
03103 SPROCKET, CLUTCH
03105 SPROCKET, REAR MOWER,
03106 SPROCKET, REAR MOWER CTS
03107 SPROCKET, SLOW DOWN, 20T
03108 SPROCKET, HI SPEED, 15T
03109 SPROCKET, REAR MOWER, 16T
03111 DRIVE SPROCKET 11T
03115 SPROCKET, REEL 28 TOOTH
03116 SPROCKET, REAR MOWER CTS
03119 SPROCKET, IDLER
03502 O-RING, 7/8"
03503 SEAL, OIL
03504 O-RING, 1-1/8"
03506 OIL SEAL
03507 SEAL, REAR AXLE
03508 REEL CARRIER SEAL
03509 OIL SEAL, INNER
Page 2 of 34

National Mower Company 2006 Master Parts List
PART
NUMBER DESCRIPTION
03510 OIL SEAL, OUTER
03511 O-RING, 3/4" I.D. (PREC.)
03512 SEAL, REAR AXLE (HX835)
03513 OIL SEAL, OUTER PARTS ONLY
03514 O-RING, 2-5/8" I.D. (PREC.)
03516 OIL SEAL , INNER (ROLLER)
03517 GEAR SHIFT OIL SEAL
03518 OIL SEAL 8400 WHEEL HUB
03601 PULLEY, WING MOWER, BC50 X 3/4
03602 2300 X 1"
03603 PULLEY, DRIVE, LOWER CTS
03604 PULLEY, MOWER, LOWER CTS
03606 PULLEY, HIGH SPEED
03607 PULLEY (PLATE YELLOW ZINC)
03608 PULLEY, ENGINE CLUTCH
03609 PULLEY, MOTOR 2250x1
03613 PULLEY, CTS., (SLOW DOWN)
03614 PULLEY
03615 PULLEY, COUNTERSHAFT, BC50 7/8
03617 IDLER MAIN MOWING CLUTCH
03618 PULLEY, STEP
03623 PULLEY, MOWING CLUTCH
03629 PULLEY D2800 X 3/4 (2) 5/16-18
03630 PULLEY BC38 X 3/4 (2 5/16-18
03631 PULLEY-IDLER
03655 PULLEY
03901 BELT, A29, COUNTERSHAFT
03902 BELT, DRIVE, B66
03903 BELT, 6844 GATES, POWER RATED
03904 BELT, 6843 GATES, POWER RATED
03905 BELT, A42, REAR MOWER
03906 BELT, WING MOWER A36
03908 BELT, MAIN MOWER CLUTCH,
03909 BELT, MAIN DRIVE, NOTCHED BX83
03911 BELT, REAR MOWER, B47
03913 BELT, TRANSPORT CLUTCH A42BARE
Page 3 of 34

National Mower Company 2006 Master Parts List
PART
NUMBER DESCRIPTION
03914 BELT, MOWING CLUTCH
03916 BELT, WING MOWER, B43
03918 BELT B-41
03919 BELT, HI SPEED B42
03921 BELT, ENGINE, WISC A43/ BS A45
03922 BELT, TRANSPORT,
03923 BELT, MAIN DRIVE, B85
03924 BELT, ENGINE, A38V NOTCHED
03926 BELT, TRANSPORT DL68 6841
03928 BELT-GATES #6840
03929 BELT-GATES #BX58
03930 BELT-GATES #BX38
03931 WING MOWER BELT (A34)
03932 WING MOWER BELT (A35)
03935 GATES #6941 POWERRATED BELT
03939 BELT, MOWING & TRANS. IM 25
03945 BELT, GATES 6834
03946 RM BELT 8400 B48
04006 GREASE FITTING, 1/4-28
04007 SET SCREW, 5/16-18 X 3/8
04008 ROLL PIN 5/16 X 1 1/8
04011 SNAP RING, 3/4"
04013 WOODRUFF #11 KEY
04015 GREASE FITTING, 45° 1/4-28THD
04016 ROLL PIN 1/4 X 1 3/4
04020 SNAP RING, 7/8"
04022 PIN, CLEVIS, 3/8" I.D. X 1-1/4
04029 COTTER PIN .125 X 1.5
04030 RIVETS, BEDKNIFE, PAN HEAD
04035 GREASE FITTING, 90°
04049 PLUG, WELCH, DIFF. CASE
04055 ROLL PIN 1/8 X 3/4
04056 ROLL PIN 1/4 X 1 1/8
04069 WOODRUFF #5 KEY
04071 SNAP RING, 2" EXTERNAL
04074 STEERING ROD END
Page 4 of 34

National Mower Company 2006 Master Parts List
PART
NUMBER DESCRIPTION
04076 ROD END #SPF-6
04077 ROD END #SPF-8
04079 EXT. RET.RING, 1.00 ID, H/D, McM #98585A121
04087 PRESSURE RELIEF VALVE
04096 BALL JOINT
04097 ROD END-CYLINDER
04099 KEY 3/16 SQUARE
04100 KEY 3/16 SQUARE
04101 SNAP RING, 7/8 EXTERNAL
04102 SNAP RING, 5/16"
04104 SET SCREW, 5/16-18 X 5/8
04107 U-BOLT 1/4-20 x 1.25 ID x 2.25
04501 SPRING, MAIN BELT IDLER ARM
04502 SPRING, SHIFTER LEVER
04504 SPRING, REAR MOWER
04505 SPRING, PULL ROD, WING MOWER
04506 SPRING, CLUTCH, RM
04510 SPRING, COUNTERSHAFT
04511 SPRING, BELL CRANK, WING MOWER
04512 SPRING, SEAT
04515 SPRING, CLUTCH RELEASE
04516 Spring, Rear Mower
04517 TORSION SPRING
04519 SPACER, DIFFERENTIAL BEARING
04520 SPRING, BRAKE RETURN
04521 SPRING, W.M. PULL YOKE
04522 SPRING, HI-SPEED PIVOT BRACKET
04523 SPRING, HI-SPEED PIVOT BRACKET
04524 SPRING, PEDAL
04526 LOCK RING,
04531 SPRING, PINION PAWL
04533 LIFT SPRING, RIGHT
04535 REEL ADJUST SPRING
04538 LIFT SPRING, LEFT
04540 IDLER SPRING
04541 BELT TENSION SPRING
Page 5 of 34

National Mower Company 2006 Master Parts List
PART
NUMBER DESCRIPTION
04543 CU C_BALANCE SPRING
04544 CU C_BALANCE SPRING
04547 SPRING(PLATED)-LIFT CHAIN
04549 REEL ADJUSTING SPRING 2" REV B
05001 ADJUSTER, STEERING GEAR
05002 BOLT, FOR CARRYING HANDLE
05022 PIN, CLUTCH, REAR MOWER
05050 COLLAR
05072 SPACER
05073 PUSH ARMS SHAFT
05075 REEL HEX ADJUSTER
05078 ROLLER PIN
05080 ROLLER SHAFT
05105 NUT,BED KNIFE ( USE WITH
06002 BUSHING SAE 841
06003 BUSHING, REVERSE GEAR C321
06004 BUSHING, BULL GEAR C304
06005 BUSHING, WHEEL HUB, RIGHT
06006 BUSHING SAE 841
06007 BUSHING, PULLEY, RM, CTS E344
06008 BUSHING, AXEL PIVOT
06009 BUSHING SAE 841
06010 BUSHING, 1-1/6" O.D.
06011 BUSHING,
06012 BUSHING,
06014 BUSHING, CTS HOUSING
06015 BUSHING, ROLLER, EXTRUSION
06016 BUSHING, ROLLER HI-CUT
06026 BSH. 84" MAN. LIFT KIT
06030 BUSHING (#FF1011-4)
06031 BUSHING-PUSH ARM
06032 BUSHING #AA-1212-2
06035 BUSHING #AA-2203-7
06036 BUSHING (FF-600-5)
06038 THRUST BEARING
06039 BUSHING #AA-1043-4
Page 6 of 34

National Mower Company 2006 Master Parts List
PART
NUMBER DESCRIPTION
06042 BUSHING #AA838-5
06101 BEARING, NEEDLE, 7/8" I.D.
06102 BEARING, NEEDLE, 3/4" I.D.
06103 BEARING, NEEDLE, 1-3/8" I.D.
06104 BEARING, BALL, 1-1/8" I.D.
06105 BEARING, LOWER COUNTERSHAFT
06107 BEARING, NEEDLE, 7/8" I.D.
06108 BEARING, ROLLER, 1-31/32" I.D.
06109 BEARING, PILLOW BLOCK, 7/8" ID
06110 BEARING, SEALED, 7/8" I.D.
06112 BEARING, BALL, FLANGE, 3/4" ID
06113 BEARING, BALL, FLANGE, 7/8" ID
06117 BEARING, CLUTCH PULLEY
06118 BEARING, ASSEMBLY, STEER GEAR
06119 BEARING, SEALED, ROLLER
06120 REEL BEARING
06121 RACE, TAPER REEL BEARING
06122 RACE , ROLLER BRG.
06123 CONE , ROLLER BRG.
06124 BEARING-FLANGE
06125 BEARING-PILLOW BLOCK
06127 BEARING BLOCK
06129 NEUTRAL RETURN CONTROL BRG.
06130 REAR FORK BEARING
06131 REAR FORK BRG. RACE
06132 2 BOLT FLUSHMOUNT BEARING
06133 3 BOLT ECONOMOUNT BEARING
06136 BEARING, UPPER COUNTERSHAFT
06140 BEARING, BALL
06141 BEARING, C_SHAFT
06142 BEARING, ROLLER
070008 BELT TOOL KIT
070009 H.O.C. KIT
07001 TIE ROD COMPLETE
070018 COUPLING REPLACEMENT KIT
07003 GASKET, BACK PLATE COVER
Page 7 of 34

National Mower Company 2006 Master Parts List
PART
NUMBER DESCRIPTION
07006 GASKET SET, 2-07010 1-07006
07007 GRIP, SHIFTER, 1/4 X 1"
07009 GASKET SET, 1-07009 1-07011
07018 WHEEL & TIRE, REAR
07019 1 1/2" SADDLE CLAMP
07021 CHAIN, REAR MOWER
07023 GRIP, LEVER, 3/16" X 3/4"
07024 KNOB VENDOR #0065-C 732-01 RED
07032 THROTTLE, WIRE & CONDUIT
07033 INTERLOCK SWITCH
07034 KEY SWITCH, BRIGGS & STRATTON
07035 SWITCH, SAFETY, NORMALLY OPEN
07036 SEAT, PADDED -V1500 (68")
07037 DECALS, SET, 68"
07038 WHEEL & TIRE, FRONT
07039 GRIP, HANDLE, 3/8" X 1-1/4"
07043 SPACER, ROLLER 1-15/32"
07045 ROLLER, ANTI-SCALP KIT
07048 CHAIN, CTS #50X42P
07049 LINK, MAIN CONNECTING
07050 LIFTER CHAIN
07051 1/4" COLD SHUT
07053 JOINT, BALL
07054 CALIPER
07057 SOLENOID
07060 KEYSWITCH, ELECTRIC
07061 WIRING HARNESS, KOHLER ELEC.
07063 METER, HOUR 2"
07064 METER, AMP 2" FARIA APO532
07065 SWITCH,IGNITION (B&S VANGUARD)
07071 LEGEND STEERING WHEEL-HARD RIM
07073 WHEEL, REAR 8 X 12
07075 TIRE & WHEEL, 23/850 X 12
07076 DECALS (SET)
07077 CHAIN-RM-#40 47P
07078 LINK, CONNECTING
Page 8 of 34

National Mower Company 2006 Master Parts List
PART
NUMBER DESCRIPTION
07079 LINK, CONNECTING
07090 SWITCH, SAFTEY, N/C REV.A
07101 SEAT, ADJUSTER
07102 PLUG, WIRING HARNESS
07104 WIRE, BATTERY GROUND
07109 HARNESS, WIRING,
07110 CABLE, CHOKE
07112 THROTTLE
07127 WIRE & CONDUIT, ONLY
07128 WHEEL, FRONT, ONLY (NO TIRE)
07130 LUG TIRE, RT.
07136 TIRE 8 X 12
07137 FRONT TIRE, ONLY, 16-650X8
07138 FRONT WHEEL, W/BRG., LESS TIRE
07140 GAS CAP, METAL TANK
07161 THROTTLE CONTROL, (COMPLETE)
07165 VALVE, INLINE, GAS TANK
07167 GAS TANK, PLASTIC
07175 GAS LINE CLAMP
07176 GAS CAP, PLASTIC TANK
07177 ATV - RIM ONLY
07178 ATV - TIRE ONLY
07181 KNOB, ENGAGEMENT LEVER
07203 LUG TIRE LT. 68"
07220 CENTER CAP FOR STEERING WHEEL
07226 GRIP, WING MOWER, ARM
07230 GRIP, 84" MAN. LIFT KIT
07240 LINK-LIFT VALVE
07241 THROTTLE CONTROL
07252 DECAL-NATIONAL
07256 DECAL-DOWN
07257 DECAL-UP
07258 CAP-BEARING
07261 NON-SKID R.H.
07262 NON-SKID L.H.
07265 LIFT CHAIN 6 LINKS REV A
Page 9 of 34

National Mower Company 2006 Master Parts List
PART
NUMBER DESCRIPTION
07269 WHEEL BOLT 1/2-20 NF
07272 MODEL 11 PUMP 1120-039
07274 LIFT VALVE
07276 FILTER ASSY
07277 FILTER HEAD
07278 FILTER ELEMENT
07299 HOSE-CASE DRAIN R.H.
07303 HOSE-MOTOR TO TEE
07305 HOSE-MOTOR TO TEE
07308 LINE-TEE MOTOR CASE DRAIN
07318 HUB-REAR WHEEL
07325 SWITCH-REEL CONTROL
07326 SWITCH-NEUTRAL CONTROL
07328 WIRE HARNESS
07332 SWITCH-SEAT
07333 SEAT
07338 BASKET-FRONT
07339 OIL TANK CAP
07347 RH BRAKE CABLE
07348 LH BRAKE CABLE
07350 RH BRAKE CALIPER
07351 LH BRAKE CALIPER
07352 BRAKE DISC
07354 ROLLER SPACER 1 1/32"
07355 RUBBER TANK BASE
07358 DECAL SET
07361 WM SHIELD SHAFT PLUG
07365 LIFT CHAIN 7 LINK REV A
07372 CE MARK 84"
07375 LINE-PUMP TO VALVE
07382 HOSE-BULKHEAD TO BULKHEAD
07384 WIRE-HARNESS TO TOGGLE SWITCH
07385 WIRE-SOLENOID GROUND
07386 TOGGLE SWITCH
07388 WHEEL MOTOR
07399 KNOB DAVIES PN# 3035
