Using the UCD3138ACCEVM149
User's Guide
Literature Number: SLUUB82
March 2015

User's Guide
SLUUB82–March 2015
Using the UCD3138ACCEVM149
1 Introduction
This UCD3138ACCEVM149 evaluation module is to help evaluate the UCD3138A digital controller device
from Texas Instruments and aid in design of digitally controlled isolated power converters. The UCD3138A
device belongs to the UCD3138 family of highly integrated digital controller devices optimized for isolated
power supply applications.
The UCD3138ACCEVM149 is quite similar to the UCD3138CC64EVM-030. The UCD3138ACCEVM149 is
to be used either as a stand-alone control card to study the UCD3138A controller device or as a DPWM
controller board working with a power stage board to implement a fully regulated power converter. To help
the targeted off-line isolated power applications, this EVM has been designed to work seamlessly with
power converter EVM offered by TI: UCD3138ALLCEVM-150. Please contact Texas Instruments for
assistance with firmware needed to configure the UCD3138A device and successfully interface
UCD3138ACCEVM149 with the above mentioned power converter EVM.
Alternately the EVM can also be loaded with user’s custom developed firmware. In order to communicate
with the UCD3138A digital controller in this EVM, a separate USB Interface Adapter EVM from Texas
Instruments known as the “USB-TO-GPIO Adapter” is required. The USB-TO-GPIO adapter is NOT
supplied with UCD3138ACCEVM149 evaluation module and must be purchased separately. Texas
Instruments also offers a Graphical User Interface in order to program the UCD3138A controller and
configure parameters when used with the power converter EVM mentioned above.
2 Description
The UCD3138ACCEVM149 is an EVM board, functioning as a control card for UCD3138ARGC digital
power supply applications. This EVM is used to control a power converter topology such as LLC Resonant
Half-Bridge DC converter, etc., by downloading the associated firmware and interfacing with an
appropriate power stage board. The EVM works seamlessly with the following EVM board, together with
corresponding firmware, all developed by Texas Instruments.
• UCD3138ALLCEVM-150, a digital controlled LLC half-bridge DC-to-DC converter evaluation board
Contact Texas Instruments for assistance with firmware needed to configure the UCD3138A device and
successfully interface UCD3138ACCEVM149 with above mentioned power converter EVM.
2.1 Typical Applications
• Off-line Isolated Power Supply Applications (such as, LLC resonant half-bridge DC-to-DC power
converter, and phase-shifted full-bridge DC-to-DC power converter)
• Server Systems
• Telecommunication Systems
2.2 Features
• 40-Pin Digital Signal Connector (to connect digital signals to power converters)
• JTAG Connector
• LED Indicator
• PMBus Connector to PC Computer Connection through USB-to-GPIO Adapter
• Rich Test Points to Facilitate the Device Evaluation (system design and circuit and firmware
debugging)
• 12-V Input Capable With Onboard Regulator 3.3 V
2Using the UCD3138ACCEVM149 SLUUB82–March 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

www.ti.com Specifications
3 Specifications
Table 1. 3138ACC32EVM-149 Specifications
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
Connector J1
PMBus connector Port of connection to USB-to-GPIO, pin definition refer to Standard
TI standard USB-to-GPIO document SLLU093
Connector J2
3.3-V connection to PMBus Port to use on board 3.3 VD to bias PMBus(1) 3.25 3.30 3.35 VDC
Connector J3
Analog signal connection Pin definition in compliance with UCD3138 40-pin
Connector J4
Digital signal connection Pin definition in compliance with UCD3138 40-pin
Pin 39 External voltage source input 11.5 12.0 12.5 VDC
Connector J5
JTAG Standard JTAG communication connection Standard
Connector J6
3.3-V on board to external Port to use 3.3 V on board to bias external circuit 3.27 3.30 3.32 VDC
use
Connector J7
TDI pull up connection Jump across to use JTAG 2-pin
Connector J8
TDO pull up connection Jump across to use JTAG 2-pin
Operation Environment
Operating temperature range Natural Convection 25 °C
Mechanical Characteristics
Width 1.8
Dimensions Length 3.4 inches
Component height 0.5
(1) Apply jumper to provide a 3.3-V bias to board from USB-to-GPIO adapter.
3
SLUUB82–March 2015 Using the UCD3138ACCEVM149
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

D
C
RESET
TP2
TP3
TP1
TP6
TP22
TP11
TP23
TP8 TP9
TP10
TP21 TP24
TP25
TP26 TP27
TP28
TP29
TP32
TP33
TP34
TP35 TP36
TP30 TP31
1 2 3 4 5 6 7 8 9 10
J1
J2
1
3
2
D1
1
3
2
D2
100pF C7
1000pF C8
33pF C9
100 R5
R3R2 R4
16.0k R11
10.0k R10
2.0k R21
TP5
AD-06 AD-05 AD-04 AD-03
AD-01
EADC-N1 EADC-P1
EADC-N0
DGND
AD-02
AD-07
EADC-P2 EADC-N2
AD-09 AD-10 AD-12 AD-13
EADC-P0
AD-08
AD-00
AD-11
DGND
DGND
DGND
DGND
/RESET
PMBUS-CTRL
PMBUS-CLK
PMBUS-ALERT
PMBUS-DATA
3.3VD
3.3VD
3.3VD
3.3VD
DGND
DGND
DGND
3.3VA
AGND
AGND
1000pF C20 1000pF
C23
33pF C10
33pF
C15
33pF
C16
33pF
C17
1 2
34
S1
AGND
1
AD13
2
AD12
3
AD10
4
AD07
5
AD06
6
AD04
7
AD03
8
V33DIO
9
DGND
10
RESET 11
ADC_EXT_TRIG/TCAP/SYNC/PWM0
12
SCI_RX0 13
SCI_TX0 14
PMBUS_CLK/SCI_TX0 15
PMBUS_DATA/SCI_RX0 16
DPWM0A 17 DPWM0B 18 DPWM1A 19 DPWM1B 20 DPWM2A 21 DPWM2B 22 DPWM3A 23 DPWM3B 24
DGND
25
SYNC/TCAP/ADC_EXT_TRIG/PWM0 26
PMBUS_ALERT 27
PMBUS_CTRL 28
SCI_TX1/PMBUS_ALERT 29
SCI_RX1/PMBUS_CTRL 30
PWM0 31 PWM1 32
DGND
33
INT_EXT 34
FAULT0 35 FAULT1 36
TCK/TCAP/SYNC/PWM0 37
TDO/SCI_TX0/PMBUS_ALERT/FAULT0 38
TDI/SCI_RX0/PMBUS_CTRL/FAULT1 39
TMS 40
TCAP 41
FAULT2 42 FAULT3 43
DGND
44
V33DIO
45
BP18
46
V33D
47
AGND
48
AGND
49
EAP0
50
EAN0
51
EAP1
52
EAN1
53
EAP2
54
EAN2
55
AGND
56
V33A
57
AD00
58 AD01 59 AD02 60
AD05
61
AD08
62 AD09 63
AD11
64
PAD
65
U1
UCD3138ARGC
TCK
TDO
TDI
TMS
/RESET
TCAP
DPWM-0A
TP12
DPWM-0B
TP13
DPWM-1A
TP14
DPWM-1B
TP15
DPWM-2A
TP17
DPWM-2B
TP18
DPWM-3A
TP19
DPWM-3B
TP20
INT-EXT
EXT-TRIG
SCI-RX0
SCI-TX0
SYNC
FAULT-0 FAULT-1 FAULT-2 FAULT-3
SCI-TX1
SCI-RX1
PWM-0
TP4
PWM-1
TP7 TP16
DGND
NS1 Net-Tie
AGND
2.0k R22
2.0k R24
2.0k R27
2.0k R28
2.0k R29
100 R7
AGND
R1 0
R6
100R8
1.50k R13
100 R9
1.50k R14
1.65k R12
0.1µF C13
0.1µF C3
1000pF C30
1000pF C26
1000pF C27 1000pF
C28
1000pF C21
1000pF C19 1000pF
C29 1000pF
C31
1000pF C22
0.1µF C2
1000pF C25 1000pF
C24
0.1µF C5
0.1µF C11
0.1µF C4
10.0
R39
1000pF C14 100k
R15 100
R17 100
R16
100 R18
100 R25
100 R26
100 R23
100 R19 100
R20
1µF C6
1000pF C18
1µF C1
2.2µF C12
Schematics www.ti.com
4 Schematics
Figure 1. UCD3138ACCEVM149 Schematic (1 of 3)
4Using the UCD3138ACCEVM149 SLUUB82–March 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

If needed, use this jumper
to provide 3.3VD to application board
TP37
10.0k R35
10.0k R32
10.0k R33
10.0k R37 10.0k R38
0 R34
Green
12
D3
J6
3.3VD
TMS TDI TDO TCK
+12V_EXT
3.3VD
3.3VD
3.3VD
DGND
1 2 3 4 5 6 7 8 9 10
11 12 13 14
J5
DGND
IN 1
OUT
8
9
4
GND
U2A TPS715A33DRBR
1 2 3 4 5 6 7 8 9 10
11 12 13 14 15 17 19 21 23 25 27 29 31 33 35 37 39
16 18 20 22 24 26 28 30 32 34 36 38 40
J3
AD-00 AD-01 AD-02 AD-03 AD-04 AD-05 AD-06 AD-07 AD-08 AD-09 AD-10 AD-11 AD-12 AD-13
EADC-N2 EADC-P2 EADC-N1 EADC-P1 EADC-N0 EADC-P0
AGND
1 2 3 4 5 6 7 8 9 10
11 12 13 14 15 17 19 21 23 25 27 29 31 33 35 37 39
16 18 20 22 24 26 28 30 32 34 36 38 40
J4
DPWM-0A DPWM-0B DPWM-1A DPWM-1B DPWM-2A DPWM-2B DPWM-3A DPWM-3B FAULT-0 FAULT-1 SYNC FAULT-2
FAULT-3
SCI-TX1 SCI-RX1 PWM-0 PWM-1 TCAP SCI-TX0 SCI-RX0
INT-EXT EXT-TRIG
/RESET
+12V_EXT
DGND
DGND
301 R31
0.5 R30
0.1µF C34
10µF C33
1µF C32
0 R36
TDI
TDO
J7 J8
www.ti.com Schematics
Figure 2. UCD3138ACCEVM149 Schematic (2 of 3)
5
SLUUB82–March 2015 Using the UCD3138ACCEVM149
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

LOGO PCB Texas Instruments
FID2FID1 FID3
SV601149 A
PCB Number:
PCB Rev:
Assembly Note
ZZ1 These assemblies are ESD sensitive, ESD precautions shall be observed.
Assembly Note
ZZ2 These assemblies must be clean and free from flux and allcontaminants. Use of no clean flux is not acceptable.
Assembly Note
ZZ3 These assemblies must comply with workmanship standards IPC-A-610 Class 2, unless otherwise specified.
SH-J1
LOGO PCB
Pb-Free Symbol
LOGO PCB
FCC disclaimer
Schematics www.ti.com
Figure 3. UCD3138ACCEVM149 Schematic (3 of 3)
6Using the UCD3138ACCEVM149 SLUUB82–March 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

www.ti.com Test Equipment
5 Test Equipment
5.1 Operating System
Microsoft Windows XP (32-bit), or Vista (32-bit), or Windows 7 (32-bit).
5.2 USB-to-GPIO Interface Adapter
This adapter is to establish the communication between the control card UCD3138ACCEVM149 and the
PC computer through the PMBus and the GUI, Texas Instruments Fusion Digital Power Designer. To
order the USB-to-GPIO adaptor, visit: http://www.ti.com/tool/usb-to-gpio
5.2.1 USB-to-GPIO Interface Adapter (HPA172)
Accessories including:
(a) USB interface adapter (HPA172).
(b) USB cable, 5-pin B Mini Male to Type A Male.
(c) Ribbon cable, socket-to-socket, 10-pin, 2-headers, polarized.
Figure 4. USB-to-GPIO Interface Adapter (HPA172)
5.3 Oscilloscope
An oscilloscope of analog or digital type is capable of 200-MHz bandwidth with an appropriate
accompanying oscilloscope probe.
7
SLUUB82–March 2015 Using the UCD3138ACCEVM149
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

Equipment Setup www.ti.com
6 Equipment Setup
6.1 GUI (Graphical User Interface)
6.1.1 File for Installation
The GUI installation file is TI-Fusion-Digital-Power-Designer-Version-2.0.16.exe or newer version. To
obtain the latest version of GUI, visit http://www.ti.com/tool/fusion_digital_power_designer
6.1.2 Installation
Double click and launch the .exe file to start the installation. Click Next all the way through. When present,
click I accept the agreement after reading it. Then click Install. After the installation, click Finish to exit
setup. Then click Exit Program.
6.1.3 Launch UCD3138A Device GUI
The GUI for UCD3138ACCEVM149 board can be launched through the below steps:
1. Click the window start →click All Programs →click Texas Instruments Fusion Digital Power
Designer →click Device GUIs →click UCD3xxx & UCD9xxx Device GUI.
6.2 Hardware Setup
6.2.1 Setup Overview
Shown in Figure 5 is the connection between UCD3138ACCEVM149 and the PC computer through USB-
to-GPIO Interface Adapter.
USB Adapter Connection:
1. Connect one end of the ribbon cable to the EVM (SV601149), and connect the other end to the USB
interface adapter
2. Connect the Mini USB connector of the USB cable to the USB interface adapter, and connect the other
end to the USB port of the PC computer.
Figure 5. UCD3138ACCEVM149 Test Connections
8Using the UCD3138ACCEVM149 SLUUB82–March 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

www.ti.com Equipment Setup
Figure 6. UCD3XXX / UCD9XXX Device GUI
Figure 7. Firmware Code Downloading
9
SLUUB82–March 2015 Using the UCD3138ACCEVM149
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

Equipment Setup www.ti.com
6.3 List of Test Points
Table 2. The Functions of Each Test Point
Test Points Name Description
TP1 3.3VA 3.3-V analog on board
TP2 RC filter 2B DPWM2B RC filter
TP3 RC filter 3A DPWM3A RC filter
TP4 PWM-0 PWM0
TP5 AGND Analog GND
TP6 DGND Digital GND
TP7 PWM-1 PWM1
TP8 EADC-N0 EAN0
TP9 EADC-P1 EAP1
TP10 EADC-P0 EAP0
TP11 EADC-N1 EAN1
TP12 DPWM-0A DPWM0A
TP13 DPWM-0B DPWM0B
TP14 DPWM-1A DPWM1A
TP15 DPWM-1B DPWM1B
TP16 TCAP TCAP
TP17 DPWM-2A DPWM2A
TP18 DPWM-2B DPWM2B
TP19 DPWM-3A DPWM3A
TP20 DPWM-3B DPWM3B
TP21 AD-00 A to D converter channel AD01
TP22 EADC-N2 EAN2
TP23 EADC-P2 EAP2
TP24 AD-01 A to D converter channel AD00
TP25 to TP36 AD-02 to -13 A to D converter channels AD02 to AD13
TP37 12V_EXT External 12 V
J1 PMBus Connection PMBus connector, 10 pins
J2 3.3VD Jumper header, if jump across, 3.3 V supplied from USB connection
J3 Analog Connection 40-pin header, analog signals
J4 Digital Connection 40-pin header, digital signals
J5 JTAG Connection 14-pin header, JTAG connector
J6 3.3VD Jumper header, if jump across, 3.3 V supplied to outside need
J7 TDI Jump across to use JTAG
J8 TDO Jump across to use JTAG
S1 Reset UCD3138 reset, press to reset.
10 Using the UCD3138ACCEVM149 SLUUB82–March 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

www.ti.com Test Procedure
7 Test Procedure
7.1 Download Firmware Codes to UCD3138ACCEVM149
Set up the EVM connection based on Figure 5.
1. Set up the EVM connection based on Figure 5. The LED of USB adapter is light on.
2. Use provided jumper to jump across J2. The LED of the EVM will light up.
3. Launch the UCD3XXX / UCD9XXX Device GUI following the steps described in section 6.1.3. A
window shown in Figure 6 appears.
4. Click Firmware Download; then a new window appears as shown in Figure 7. Click Select File and
browse an intended firmware code file with file extension .x0 (eg. cyclone.x0), then click Download.
The firmware of cyclone.x0 will be downloaded to the UCD3138A device on the
UCD3138ACCEVM149 EVM. When prompted, click Yes to complete the download. Click Close to exit
the download window.
5. After the firmware code downloads to the UCD3138A device, the intended test can be performed.
7.2 Erasing Firmware Code from UCD3138ACCEVM149
Erasing the downloaded firmware from the UCD3138A flash memory can be done by following the steps
below and referencing Figure 6:
1. Click Device ID
2. Click Command Program to jump to ROM (SendByte 0xD9)
3. Click Set PFlash: 0xFF
7.3 Equipment Shutdown
1. Exit the GUI.
2. Disconnect the USB cable and the ribbon cable.
11
SLUUB82–March 2015 Using the UCD3138ACCEVM149
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

EVM Assembly Drawing and PCB Layout www.ti.com
8 EVM Assembly Drawing and PCB Layout
Figure 8 through Figure 13 show the design of the UCD3138ACCEVM149 printed circuit board. PCB
dimensions: L x W = 3.400 x 1.8 inch, PCB material: FR4 or compatible, four layers and 1oz copper on
each layer.
Figure 8. UCD3138ACCEVM149 Top Layer Assembly Drawing (top view)
Figure 9. UCD3138ACCEVM149 Bottom Assembly Drawing (no components on this side)
12 Using the UCD3138ACCEVM149 SLUUB82–March 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

www.ti.com EVM Assembly Drawing and PCB Layout
Figure 10. UCD3138ACCEVM149 Top Copper (top view)
Figure 11. UCD3138ACCEVM149 Internal Layer 1 (top view)
13
SLUUB82–March 2015 Using the UCD3138ACCEVM149
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

EVM Assembly Drawing and PCB Layout www.ti.com
Figure 12. UCD3138ACCEVM149 Internal Layer 2 (top view)
Figure 13. UCD3138ACCEVM149 Bottom Copper (top view)
14 Using the UCD3138ACCEVM149 SLUUB82–March 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

www.ti.com List of Materials
9 List of Materials
The EVM components list according to the schematics shown in Figure 1,Figure 2 and Figure 3 are listed
in Table 3.
Table 3. List of Materials
QTY DESIGNATOR DESCRIPTION PART NUMBER MANUFACTURER
3 C1, C6, C32 Capacitor, ceramic, 1 µF, 16 V, ±10%, X5R, 0603 C0603C105K4PACTU Kemet
7 C2–C5, C11, C13, C34 Capacitor, ceramic, 0.1 µF, 16 V, ±10%, X7R, 0603 C0603C104K4RACTU Kemet
1 C7 Capacitor, ceramic, 100 pF, 50 V, ±5%, C0G/NP0, 0603 CGA3E2NP01H101J080AA TDK
16 C8, C14, C18–C31 Capacitor, ceramic, 1000 pF, 50 V, ±10%, X7R, 0603 C0603C102K5RACTU Kemet
5 C9, C10, C15–C17 Capacitor, ceramic, 33 pF, 50 V, ±5%, C0G/NP0, 0603 06035A330JAT2A AVX
1 C12 Capacitor, ceramic, 2.2 µF, 10 V, ±10%, X5R, 0603 C0603C225K8PACTU Kemet
1 C33 Capacitor, ceramic, 10 µF, 10 V, ±10%, X5R, 0805 C0805C106K8PACTU Kemet
2 D1, D2 Diode, Schottky, 40 V, 0.3 A, SOT-23 BAT54AFILM ST Microelectronics
1 D3 LED, green, SMD, 1.6 x 0.8 x 0.8 mm LTST-C190GKT Lite-On
1 J1 Header (shrouded), 100 mil, 5 x 2, gold, TH 5103308-1 TE Connectivity
4 J2, J6, J7, J8 Header, 100mil, 2 x 1, tin, TH PEC02SAAN Sullins Connector Solutions
2 J3, J4 Receptacle, 2 mm, 20x2, R/A, TH NPPN202FJFN-RC Sullins Connector Solutions
1 J5 Header, 100 mil, 7 x 2, tin, TH PEC07DAAN Sullins Connector Solutions
0 R1–R4 Resistor, 0, 5%, 0.1 W, 0603 CRCW06030000Z0EA Vishay-Dale
12 R5, R7–R9, R16–R20, R23, Resistor, 100 Ω, 1%, 0.1 W, 0603 CRCW0603100RFKEA Vishay-Dale
R25, R26
3 R6, R34, R36 Resistor, 0 Ω, 5%, 0.1 W, 0603 CRCW06030000Z0EA Vishay-Dale
6 R10, R32, R33, R35, R37, Resistor, 10.0 kΩ, 1%, 0.1 W, 0603 CRCW060310K0FKEA Vishay-Dale
R38
1 R11 Resistor, 16.0 kΩ, 1%, 0.1 W, 0603 RC0603FR-0716KL Yageo America
1 R12 Resistor, 1.65 kΩ, 1%, 0.1 W, 0603 CRCW06031K65FKEA Vishay-Dale
2 R13, R14 Resistor, 1.50 kΩ, 1%, 0.1 W, 0603 CRCW06031K50FKEA Vishay-Dale
1 R15 Resistor, 100 kΩ, 1%, 0.1 W, 0603 CRCW0603100KFKEA Vishay-Dale
6 R21, R22, R24, R27–R29 Resistor, 2.0 kΩ, 5%, 0.1 W, 0603 CRCW06032K00JNEA Vishay-Dale
1 R30 Resistor, 0.5 Ω, 1%, 0.1 W, 0603 RL0603FR-070R5L Yageo America
1 R31 Resistor, 301 Ω, 1%, 0.1 W, 0603 CRCW0603301RFKEA Vishay-Dale
1 R39 Resistor, 10.0 Ω, 1%, 0.125W, 0805 CRCW080510R0FKEA Vishay-Dale
1 S1 Switch, tactile, SPST-NO, 1VA, 32 V, 6.3 x 5.36 x 6.6 mm, SMT KT11P2JM34LFS C&K Components
1 SH-J1 Shunt, 100 mil, flash gold, black, 1 x 2, Closed Top SPC02SYAN Sullins Connector Solutions
16 TP1–TP4, TP6, TP7, Test point, miniature, white, TH 5002 Keystone
TP12–TP20, TP37
1 TP5 Test point, compact, black, TH 5006 Keystone
1 U1 Highly Integrated Digital Controller for Isolated Power, RGC0064B UCD3138ARGC Texas Instruments
1 U2 Single Output LDO, 80 mA, fixed 3.3 V output, 2.5 to 24 V input, with low TPS715A33DRBR Texas Instruments
IQ, 8-pin SON (DRB), –40°C to 125°C, Green (RoHS & no Sb/Br)
0 FID1–FID3 Fiducial mark. There is nothing to buy or mount. N/A N/A
0 TP8–TP11, TP21–TP36 Test Point, Miniature, White, TH 5002 Keystone
1 PCB Printed Circuit Board SV601149 Any
15
SLUUB82–March 2015 Using the UCD3138ACCEVM149
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

References www.ti.com
10 References
1. UCD3138A Data Manual, Texas Instruments Literature Number: SLUSC66 – January 2015
2. UCD3138 Monitoring and Communications Programmer’s Manual, Texas Instruments Literature
Number: SLUU996 – July 2012
3. UCD3138 Digital Power Peripherals Programmer’s Manual, Texas Instruments Literature Number:
SLUU995 – July 2012
4. UCD3138 ARM and Digital System Programmer’s Manual, Texas Instruments Literature Number:
SLUU994 – July 2012
5. Fusion Digital Power Designer GUI for Isolated Power Applications User Guide (for UCD3138,
UCD3138064, UCD3138A applications), Texas Instruments Literature Number: SLUA676 – June 2014
6. Code Composer Studio v6 Wiki, Texas Instruments,
http://processors.wiki.ti.com/index.php/Category:Code_Composer_Studio_v6
7. UCD3138A Migration Guide, Texas Instruments Literature Number: SLUA741 – October 2015
16 Using the UCD3138ACCEVM149 SLUUB82–March 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

Appendix A
SLUUB82–March 2015
Summary of Using Code Composer Studio v6
In this appendix, the basic steps of how to use Code Composer Studio v6 to compile firmware for
UCD3138 family of devices is described. A design flow is described while detailed steps for firmware code
creation, and firmware debugging along with hardware are obviously beyond the scope of this user’s guide
and this appendix.
A.1 Importing a CCSv6 project
Upon running CCSv6 for the first time, the Workspace Launcher window will appear as shown in
Figure 14. It is left to the user do decide whether or not to use a workspace, where it is located, and/or to
check the box that says Use this as the default and do not ask again. For this guide, a workspace will
not be used, so click OK.
Figure 14. CCSv6 Workspace Launcher
17
SLUUB82–March 2015 Summary of Using Code Composer Studio v6
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

Importing a CCSv6 project www.ti.com
When the main window opens, click Project in the top navigation menu, then choose Import CCS
Project… as shown in window as shown in Figure 15.
Figure 15. Import Existing CCS Project
This will open the window shown in Figure 16. Under Select-search directory, click Browse, navigate to
the target project, and click OK. For this example, the project is called UCD3138_Lab_02_solution.
Check the box next to the discovered project, and do not check Copy projects into workspace, or
Automatically import referenced projects. Click Finish.
Figure 16. Importing a CCSv6 Project
18 Summary of Using Code Composer Studio v6 SLUUB82–March 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

www.ti.com Build/Compile a Project using Code Composer Studio v6
The project should be imported into CCSv6 and should be shown in the Project Explorer as shown in
Figure 17. At this point, files in the project can be edited as required.
Figure 17. Project Explorer
A.2 Build/Compile a Project using Code Composer Studio v6
For the UCD3138 family of devices, compiling a project produces an Intel-hex (.x0) firmware file that can
be downloaded to, and run on the UCD3138 or related target device using the UCD3XXX / UCD9XXX
Device GUI (part of the Fusion Design Online software from TI).
After finished editing the project files, Right-Click on the project in the Project explorer, and choose Build
Project.
NOTE: If this is the first time building a UCD3138 or related project, and Cygwin is also installed on
the PC that is performing the compilation, the instructions in Section 3.3 of the Application
Note entitled “Converting UCD3138 Firmware Project from Code Composer Studio Version
3.3 to 6.0” must be followed. Mainly, the C:\CYGWIN or other similarly named directory must
be renamed temporarily during this first build. This will allow the new ARM library to be built
properly. After this first build, the CYGWIN directory can be rolled back to its original name,
and future builds can compile successfully.
19
SLUUB82–March 2015 Summary of Using Code Composer Studio v6
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

Build/Compile a Project using Code Composer Studio v6 www.ti.com
Builds may take up to a minute to compile, or longer for a first time build. Figure 18 shows the state of a
successful build:
Figure 18. Successful Build of UCD3138 Related Source Code
When the build has finished, the .x0 file should be created and will be placed in the project directory’s
debug folder. The filename that prefaces the .x0 will be the name of the project that was built (i.e. a
project named UCD3138_Lab_02_solution will create UCD3138_Lab_02_solution.x0 as its firmware
file). However, it must be noted that the project name must have no spaces, otherwise the .x0 file will not
be generated.
This .x0 file can be and run on the UCD3138 target device using the UCD3XXX / UCD9XXX Device GUI.
20 Summary of Using Code Composer Studio v6 SLUUB82–March 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated
