Nauto 3 Device User manual

Installation Guide
Nauto® 3 Device
US Installation Guide
June 2021

Table of Contents
2
Overview 3
Installation Tool List and Components 4
Installation 5
OBD Connection/Power Cable Connection 6
Device Registration 7
Device Installation 8
Vehicle Information 12
Additional Resources 13
© Nauto 2020. All RightsReserved.

Overview
WARNING
This equipment may only be located in a position where it cannot
interfere with the normal and safe operation of the vehicle, or
present a hazard to the driver, or passengers. When routing all
cables ensure that the insulation does not become worn or
damaged. All cabling must be secured utilizing industry standard
methods.
If you are unsure about the placement or installation of this
equipment, stop work, and contact your Nauto representative
immediately.
Under no circumstances should any part of the Nauto system be
installed inside the engine compartment area.
This equipment should not be operated in hazardous
environments, or in areas that contain explosive materials or
flammable vapors.
This equipment should not be operated in aircraft or in close
proximity to medical equipment.
Unauthorized changes or alterations to the equipment may
invalidate the Nauto warranty and may also affect the vehicle
manufacturer’s warranty.
DISCLAIMER & SAFETY INFORMATION
Due to ongoing development, information and specifications may change at any time without notice. While the information is believed
to be accurate, it may include errors or inaccuracies. Nauto shall not be liable for any use of this installation guide or information
supplied in it.
The installation of the Nauto 3 Device may adversely affect other vehicle components or safety equipment. Nauto assumes no
responsibility and disclaims any liability for any damage to any vehicle components or safety equipment, or bodily injury, that may arise
due to installation or use of Nauto’s products and services.
THE INFORMATION IN THIS INSTALLATION GUIDE IS PROVIDED “AS IS” AND TO THE EXTENT PERMITTED BY LAW, IS PROVIDED WITHOUT
WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY,
FITNESS FOR ANY PARTICULAR PURPOSE, OR NON-INFRINGEMENT.
Nauto shall not be liable for any damages, losses, costs or expenses, direct, indirect or incidental, consequential or special, resulting from
the use of this installation guide.
This guide is not written for any specific vehicle since the proper wiring and installation of electronics differs for each vehicle. Installation
should be completed by qualified individuals who are trained to wire electronics such as the Nauto 3 Device. It is your responsibility to
know how to wire in electronics such as the Nauto 3 Device for your specific vehicle. Improper wiring may cause injury or damage and
void the warranty. Any changes or modification to the Nauto 3 Device not expressly approved by Nauto or the entity responsible for
compliance may void any warranties and your authority to operate the Nauto 3 Device.
This installation guide contains proprietary information that is protected by copyright. All rights are reserved. This guide may not be
copied, reproduced, or translated into another language without Nauto’s prior written consent.
3© Nauto 2020. All RightsReserved.
PURPOSE
The purpose of this document is to provide guidelines for the installation of the Nauto 3 Device. The installation guidelines, specifications,
materials and examples provided in this document are for information purposes only, are non-exhaustive, and must not be relied upon for
the specific installation in any vehicle. This guide is not intended to replace any regulatory requirements in the jurisdiction where the Nauto
3 Device is installed or used.
Before starting the Nauto 3 Device installation and configuring the system, please ensure that you have read this guide thoroughly. If you
have any questions or concerns regarding the installation of the Nauto 3 Device, please contact Nauto Support at 1 [phone] or
[e-mail].

Installation Tool List
The following tools are recommended to perform installation of the Nauto 3 Device:
Digital multimeter with sharp leads (or wire piercing leads) Trim panel removal tool
T5 Torx driver with handle Crimp Connectors
Electrical tape Zip/Nylon ties
Wire strippers (self strippers) 18AWG ring terminals
Wire crimpers (capable of crimping insulated terminals) Self-tapping screws
4© Nauto 2020. All RightsReserved.
Nauto Components
Nauto 3 Device
1.
2. Windshield Mounts
4. Fuse Holder w/ 3amp fuse
3. Mark Button (see Mark Button Install Guide)
This is optional and may not be included.
If included, donot dispose of small bag
with “MAC address” label.
5. Power Cable
2 versions: hardwire and OBD
6. OBD Y-Cable
This is optional and may not be included 1
2
3456
Note: Vehicle specific tools may also be required.
Nauto Recommended Connection Methods
6
Poke &Wrap Requires splicing into a low voltage wire for aconnection. See above
Posi-Tap Requires posi-tap connectors to tap into wires without cutting or splicing. Proper sized posi-taps
Solder Requires aheated tool to bond wires using afiller metal with low melting point. Soldering iron
Connection Method Description Recommended Tools
Add a Fuse Power splitter installed in the vehicle’s fuse box Proper size fuse connection

Installation | Power Source Connection
IMPORTANT
When searching for the correct wires, DO NOT use a test light style circuit
tester. Damage to vehicle computers and vehicle air bag restraint systems may
result from the use of atest light causing ashort circuit.
5
Locating Correct Vehicle Wires
1. Use amultimeter.
2. Set your multimeter to DCvoltage.
3. Attach the negative (-) probe to the vehicle chassis ground.
4. Probe the wires you suspect of being the constant and ignition power sources.
Note: The Nauto 3 Device can support vehicles with a 24-volt power source
© Nauto 2020. All RightsReserved.
Constant +12V or 24V Power Connection (Nauto 3 Device Red Wire)
1. Find asource of constant +12V or 24V under the dashboard of the driver side of the car.
a. There are multiple places where this can be found, and locations vary between vehicles. Plan your installation according to your needs. You may find specific wiring
details by specific vehicle online,such as on The 12 Volt (www.the12volt.com).
b. Ensure that the wire you choose is aconstant source of +12V or 24V.If you use amultimeter, it should show approximately 12V or better between your source and
chassis ground regardless of the ignition switch position, open or closed doors, on or off lights and other accessories, etc.
2. Using your preferred connection method (poke &wrap, solder, or posi-tap), using the provided inline fuse holder, connect the red wire from the power cable to one side of the
inline fuse holder, and the other to the source of +12V or 24V.Be sure NOT to permanently disconnect the 12V or 24V source from other circuits in the vehicle and take care to make
astrong connection to survive vibration and temperatures.
a. Do not exceed the max amperage that the circuits fuse can handle, keeping in mind the cumulative amps of other after-market devices.
Ground Connection (Nauto 3 Device BlackWire)
1. Crimp or solder aring terminal at the end of the black wire.
2. Connect it directly to asuitable metal spot on the vehicle’s chassis to create asolid ground. One method that may be appropriate is using aself-tapping screw. The driver’s
kick panel under the dashboard is acommon grounding area, or any painted metal surface.
Ignition Source (Nauto 3 Device White Wire)
1. Locate the wire that you suspect will have ignition power.
2. If you use amultimeter, probe the suspected wire with the meter lead to check:
a. There should be zerovoltage. (key off)
b. With the key turned to the “ON” position in the ignition (do not start the vehicle), the wire should show 12 volts DC or more.
c. With the meter lead still probing the wire, start the vehicle. While the starter is cranking, the wire’s voltage should not drop by more than 2volts.
d. Turn the key to the “OFF” position. The voltage should return to 0.
3. Using your preferred connection method (poke &wrap, solder, or posi-tap), connect the white wire from the power cable to the source of Ignition.Be sure NOT to permanently
disconnect the ignition source from other circuits in the vehicle and take care to make astrong connection to survive vibration and temperatures.
a. Do not exceed the max amperage that the circuits fuse can handle, keeping in mind the cumulative amps of other after-market devices.
WARNING Do not plug harness into the Nauto 3 Device while making connections.

© Nauto 2019. All RightsReserved.
Installation | OBD Connection
OBD Port Connection (with Y-Cable)
1. Locate the OBD port within the vehicle, removing vehicle panels as necessary.
2. Gently remove the factory OBD plug from the mount.
3. Replace the vehicle’s OBD port with the female end of the Nauto Y-cable.
4. If there was an existing device in the vehicle’s OBD port, reconnect it utilizing the Nauto Y-cable.
5. Plug the male end of the Nauto Y-cable into the vehicle’s OBD port. Ensure ignition is off when connecting.
6. Zip tie all connections to help ensure plugs will not disconnect.
6
OBD Port Connection (without Y-Cable)
1. Locate the OBD port within the vehicle.
2. Insert male end of the Nauto OBD power cable into the vehicle’s OBD port
© Nauto 2020. All RightsReserved.
Installation | Power Cable Connection
Power end of powercable
Power Cable Connection
1. Locate the power end of the power cable, or the end with the small black block (see image
for reference).
2. Leave 8-10” of the cable exposed at the rearview mirror and route the cable safely and
securely to the power supply unit.
3. One way to do so that may be appropriate is as follows:
a. Start tucking the cable under the windshield headliner starting just above the
rearview mirror.
b. The cable should be buried under the headliner so that it will not slide out or drop
from the headliner.
c. Route the cable to the left (driver’s side of the vehicle) and remove the A-pillar
panel to route the cable around, behind, and away from all airbag components and
related vehicle accessories.
d. Pull the door gasket away from the body of the vehicle and run the power cable
into the channel near the pinch weld, but without crossing over the pinch weld,
towards the power supply unit.
4. Bundle and secure all excess wiring so it will not interfere with vehicle and driver controls.
5. Mount the bundled cable in a secure location under the dash of the vehicle with zip ties.

Download the Nauto Installer App
from the App Store or Google Play store.
2. Select “NewInstallation”.
1. Login
Your username and password will
be provided to you prior to
installation.
3. Scan QRCode.
The QR code is located on the
device. You may alsomanually
enter the serial number,which is
located next to the QR code on
the Nauto 3 Device.
7© Nauto 2020. All RightsReserved.
Installation | Device Registration
4. Review and confirm fleet name.
Note: if this unit was removed from
another vehicle in a swap, you will be
prompted to confirm.

Installation | Device Installation
5. Perform the installation
8
6. Take photo of connection
and confirm
Take a clear unobstructed photo of
the power connections made if
hardwired. If connected via OBD,
take photo of OBD connection.
Once taken the app will ask you to
confirm the photo.
© Nauto 2020. All RightsReserved.
7. Images from the device
The app will now communicate with the
device to get live images to help
properly align the device. See next page
for more details.

Installation | Device Installation
1. Connect the Nauto 3 Device to power.
Insert the power cable end that extends from under the headliner
into the device’s power port. The Nauto 3 Device will now boot up.
2. Check for green lights on the device.
This can take up to one minute. Blue lights will appear on the device
first, meaning the device is updating software, followed by flashing
green lights indicating that it is in install mode.
3. Fit the windshield mount to the back of the Nauto 3 Device.
Select the appropriate angled mount that provides the best viewing
angle. Do not remove the adhesive backing at this time.
4. Locate the small screw on the accessible side of the device.
Find this on the opposite side from the rearview mirror. Rotate the T5
screw clockwise to lock the Nauto 3 Device into place. The other screw
will not be tightened.
5. Determine the optimal mounting location.
With the driver’s side sun visor in the down position, locate an
unobstructed location on the windshield away from any sensors,
metallic surfaces, or tint.
6. Review live images from the Nauto 3 Device.
The Nauto Installer app will show live images from both interior and
exterior cameras. This can take a few minutes. Use these images to
adjust positioning of the camera for optimal viewing.
a) Driver facing camera should have a clear unobstructed view of the
driver from head to waistline.
b) Forward facing camera should have a clear unobstructed and
horizontal view. Little to no body panels should be visible.
9
Camera views during installation
© Nauto 2020. All RightsReserved.

Installation | Device Installation
7. Mark location for the Nauto 3 Device.
Using the live images as guidance, mark the location for the Nauto 3
Device on the windshield with tape or marker. For optimal device
performance:
a. The forward-facing camera should have a clear view of the front
of the vehicle with no obstructions.
b. The forward-facing camera should not be blocked by window tint or
metal film found near the rearview mirror. If neither side of the
rearview mirror will produce the desired result, please contact Nauto
for additional options.
c. The driver-facing camera should not be easily obstructed by the
driver-side visor or other OEM or aftermarket equipment.
d.If the device can be placed behind the rearview mirror, the driver-
facing camera should be located halfway between the rearview mirror
and the headliner.
e. The cameras should not block any sensors or rearview mirror functions.
f. The rearview mirror should maintain a full range of motion.
8. Clean the desired location using the provided swab.
Dry the area with a clean paper towel, removing all film and residue.
9. Peel the liner from the adhesive on the windshield mount.
10. Slowly align the device into position.
Check the live images on the app. If your view is properly aligned, gently
press the whole assembly to the windshield.
-Ensure that the top of the Nauto 3 Device is not touching the
headliner
- If necessary for optimal placement, only allow a portion of the
adhesive to be on the frit/metallization
Interior view of Nauto 3 Device
10© Nauto 2020. All RightsReserved.
FMCSA Exemption
Important Note: Nauto has received an
exemption from the FMCSA that allows for
installation of the device up to 8 inches
below the upper edge of the area swept
by the windshield wipers, provided it
remains outside of the driver's and
passenger's normal line of sight to the
road. This may allow you to place a device
below the rearview mirror/monitor.
Please confirm this placement is
acceptable with the customer's fleet
manager.
REMINDER: DO NOT EXCEED THIS 8-INCH
LIMIT.

Installation | Device Installation
11. Press and hold.
Press and hold the complete mount to the windshield for at least 15 seconds.
15 seconds is the minimum time for the adhesive to adhere properly. Failure
to properly secure the Nauto 3 Device may cause it to detach from the
windshield, which may lead to catastrophic damage or injury.
12. Verify the mount and Nauto 3 Device are securely attached.
From the outside of the vehicle, verify that the bracket adhesive is
completely attached. Press and hold for an additional 15 seconds if not.
Please see picture to right for how adhesive should look from the outside.
13. Secure all dash panels.
Make sure all cables are secure and out of the driver’s view and movement.
11© Nauto 2020. All RightsReserved.

Installation | Vehicle Information
© Nauto 2019. All RightsReserved. 12
6. Take photo of camera location
and confirm
From the driver's seat, capture a photo of
the camera position on the windshield.
Once taken the app will ask you to
confirm the photo.
7. Take photo of license plate
and confirm
From the back/front of the vehicle,
capture a photo of the license plate.
Once taken the app will ask you to
confirm the photo.
8. Final check
After you have completed all steps, the
app will ask you to submit the final
check. You must be in LTE or WiFi for
this to complete.
6. Enter vehicle information
Enter the vehicles VIN number,
License Plate number, and the
Vehicle Name or Asset ID. You may
need to consult the fleet manager
for this information.

Additional Resources
For any questions orsupport
888.628.8690
[e-mail]
Nauto Support is available Mon -Fri 6AM -6PM PST.
13© Nauto 2020. All RightsReserved.
Device LED Feedback
Solid Green: Ready and Functioning
Flashing Green: Device is in Install Mode
Flashing Blue: Device is downloading or installing updates
Orange: Searching for Cellular Network
Red: Possible Hardware issue (contact support)
Dim Red: Commonly confused as LEDS. These are infrared sensor for night mode.
Installation Video
https://www.nauto.com/install
