WelcometoTookiPor
Tooki by NAV TV is a Bluetooth phone integration system designed specifically for
yourphone-readyPorschevehicle.
When used properly, Tooki Por establishes a wireless Bluetooth link between the
Porsche PCM radio and your mobile phone, resulting in a hands-free operation of
yourphone.
Loaded with key features such as Phone book synchronisation (phone dependent),
Privacy mode, Radio keypad dial / call / hang up, and noise-canceling technology,
Tooki allows for a safer driving experience while keeping the driver connected to his
wirelessworld.
The Tooki is an extremely sophisticated product, therefore it is strongly advised that
you make yourself familiar with your Tooki system and read the instructions in this
manualbeforeoperatingthesystem.
Formoreinformationpleasevisit: www.nav.tv
Legend
Tookiis designedto work witha radio thathas a factorySIM cardbasedGSM phone
option rather than Bluetooth. As such, certain functions displayed on the radio are
notsupportedbyTooki.Pleasenotethatifyour
radio says “Insert SIM card” or “No card” then you have the factory phone option
installedandnottheTooki.
Thefollowinglegendwilleaseyourreadingthismanual:
Radio operation, button press
Rotate, then press the radio selector knob
Mobile phone operation, such as pairing
Operation not supported by Tooki
F
Legend
Welcome

Page 3 Page 4
PressTELonPCMRadio.
“TookiSearching”indicatesnophoneconnected.
Start the pairing procedure on your mobile phone. Make sure the
Bluetoothfeatureisturnedon.Consultyourphone'smanualforphone-
specificpairingprocedures.
Once your mobile phone discovers Tooki xxxx (last 4 digits will vary),
selectandpairTooki.
Whenpromptedforapasskey,enter6888onyourmobilephone.
Oncepairingiscomplete,youshouldseeyournetworkproviders
nameandsignalstrengthindicatoronthePCMRadio.
Youmaypairupto5differentmobilephones.Forinformationon
phoneselection,seetheCONNECTINGsection.
Note:thatonceaphoneispaired,youmustallowtheTookito
automaticallyconnecttoit.Initiatingtheconnectionfromthephone
willcauseunreliableoperation.
Note: the following phones require a special pairing code to be dialed
from the radio prior to pairing. Please enter the code that matches your
phone,thenpress.
F
Pairing
Pairing

Page 5 Page 6
If only one phone is paired, Tooki will attempt to connect this phone
as log as the PCM radio is active
Up to 5 phones may be paired and selected
If more than one on is paired, Tooki will attempt to connect to any of
the paired phones. Last connected phone has a priority over other
paired phones, but since different phones have different Bluetooth
latencies, it is hard to predict which phone will be connected if more
than one phone is present within range of Tooki. You may manually
connect to a paired phone following this procedure.
Selecting a paired phone:
Press TEL, select PHONEBOOK
Select the the phone you wish to connect. In this example a
Blackberry 8830, Nav TV Corp. and Nav-Tv are paired and we are
selecting Nav-Tv
Press the button on the PCM radio.
Tooki will display Dialling: Selecting... and will attempt to connect
to the phone selected. Radio will resume normal operation within a
few seconds.
Deleting a paired phone:
1. Highlight PHONENAME, press in on knob
2. Highlight DELETE then press in on knob again
3. Turn knob to YES, and press in again to confirm
NOTE 1: You may need to delete the phone more than once to
finalise
Connecting
Connecting

Page 7 Page 8
A received call will cause the following:
1. Mute the radio and generate a ring tone.
2. Display CALL: (Caller) at the bottom of the screen.
3. Display the Caller ID or caller name if the phone supports those features
and phonebook has been transferred.
To answer a call:
1. Press the TALK button, or
2. Press Answer when on TEL menu.
To answer a second call (Call Waiting):
1. Press the TALK button, or
2. Press Answer when on TEL menu.
To switch between 2 calls:
1. Select Swap from the TEL menu.
To end a call:
1. Press the HANGUP button, or
2. Select End Call when on TEL menu.
NOTES:
1. New Call and Hold Call may not work on all phones.
2. When receiving a second call (Call Waiting), if you do not wish to answer,
DO NOT reject (Ignore) the call, let it continue to ring. Rejecting it will end
both calls.
F
Receiving Calls
Receiving Calls

Page 9 Page 10
To place a call:
1. Press TEL, then dial a number on the PCM Keypad
2. Press
Alternatively, You may dial a number by selecting Dial Number,
then selecting each digit as depicted, followed by selecting Dial
NOTE: the Store option is not supported.
You may also dial numbers stored under the following:
Dialed Calls
Received Calls
Missed Calls
Pressing twice will redial the last number.
Most phones allow to dial, answer and end calls
via the phone buttons
Placing Calls
Placing Calls

Page 11 Page 12
Phonebook
Privacy Mode
It is often convenient to switch between hands free operation and the normal
phone use
Tooki alows for a quick privacy mode:
Press Tel, select Phone Off. Privacy On is displayed, use your mobile phone as
usual.
To switch back to hands free mode:
Press TEL, select Phone On
NOTE: The Phonebook feature is not supported by all phones. Please refer to
www.nav.tv for an up-to-date phone compatibility list and software updates.
The PCM Radio is limited to 255 Phonebook entries!
NOTE: Phonebooks that have a large number of contacts can take quite a long
time to synchronize, please be patient. During Phonebook synchronization,
attempts to pair or delete a phone will not operate reliably.
1. Press TEL, then select PHONEBOOK
2. Rotate the knob right or left to select your entry. Quick rotation will result in
skipping the search by 25 entries.
3. Press or select Dial to place a call.
NOTE: The Phonebook can not be modified, as it is stored in your phone. The
Add, Edit and Delete options will only appear to work, but no change is actually
made to your phone's content. The Phonebook will refresh and revert to the
phone's content upon re-connecting.

Page 13 Page 14
Your PCM radio was not designed for Bluetooth operation, but rather for a SIM
based GSM phone module.
Tooki emulates many of the functions supported by the radio.
However, certain functions are designed to work only with the factory
GSM phone and can not be used by Tooki. Therefore, you would notice some
unused menu items.
List of unused menu items:
Store - All changes are void at restart
Hold Call - Works with some phones
New Call - Works with some phones
Add - All changes are void at restart
Edit - All changes are void at restart
Delete - Will remove a phone from the Tooki!s list. When used on
Phonebook entries, all changes will be void at restart
SMS - Works with some phones
Forward Call - NOTAVAILABLE
PIN Setting - NOTAVAILABLE
Phone Setting - NOTAVAILABLE
IMPORTANT NOTE:Call Settings ->
Incognito is a feature only available on some GSM based phones. Setting this
feature On will block the display of your phone number to the called party. If
the connected phone is not GSM (SIM card) based, you MUST set this to “as
Unused Features
Unused Features

Page 15 Page 16
F
Your TOOKIPOR can be updated by the user via a bluetooth-
enabledlaptop
Latest software updates & installation instructions are available
at www.nav.tv. By selecting your Porsche Model then the
TOOKIPORpicture, allyourequire will beavailableto youunder
thetechnicaltab.
F
NAV TV
Unit R4, Capital Business Park
Wentloog, Cardiff CF3 2PU
Tel: [phone] Fax: [phone]
[e-mail] www.nav.tv
If you are in need of any further assistance
please do not hesitate to contact us on the number or email below
