NavAtlas NA30C Installation instructions

INSTALLATION/OWNER'S MANUAL
AM/FM/WB receiver with Bluetooth
NA30C
IP66

2
NA30C
Please read entire manual before installation.
Before You Start
• Disconnect negative battery terminal. Consult a qualified technician for instructions.
• Avoid installing the unit where it would be subject to high temperatures, such as from
direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
Getting Started
• Remove trim ring from unit.
• Remove 2 transit screws located on top of the unit.
• Insert the supplied keys into the slots as shown, and slide the unit out of the mounting
sleeve.
• Install mounting sleeve into opening, bending tabs to secure.
• Connect wiring harness and antenna. Consult a qualified technician if you are unsure.
• Certain vehicles may require an installation kit and/or wiring harness adapter (sold
separately).
• Test for correct operation and slide into mounting sleeve to secure.
• Snap trim ring into place.
Preparation
TYPICAL DIN FRONT-LOAD MOUNTING METHOD

3
NA30C
FUSE
When replacing the fuse,
make sure new fuse is the
correct type and amperage.
Using an incorrect fuse could
damage the radio.
The NA30C uses one
30 amp ATM fuse located
in-line.
Wiring Diagram
BLACK----POWER CABLE
BLACK /RED----USB CHARGE (ONLY)
BLACK----USB PLAYBACK (ONLY)
BROWN/WHITE----FRONT LEFT CH
BROWN/RED----FRONT RIGHT CH
GRAY/WHITE----REAR LEFT CH
GRAY/RED----REAR RIGHT CH
BLACK/GREEN----SUB LEFT
BLACK/GREEN----SUB RIGHT
GRAY/VIOLET----CAMERA IN
BLACK----DIGITAL OUT
GRAY/RED----AUX IN
BLACK----ANTENNA INPUT(AM/FM )
GND(-)
REVERSE (+) REMOTE (+)
ACC (+)
* Rear view camera is sold separately.
** Digital output is designed to work for all amplied
Navatlas products only.
*
**

4
NA30C
Control Locations - Receiver
5. Mode/Camera (Hold 5 seconds)
6. Select/Preset Menu
7. Preset Up
8. Play/Pause/Band
1. Power/Mute
2. Audio/Menu
3. Tune/Track Down
4. Tune/Track Up

5
NA30C
Press to turn the unit on. Press and hold to turn the unit
off.
Press MODE to enter the Mode Menu, then press MODE or
rotate the volume knob to select between Radio, Auxiliary
Input, USB and Bluetooth modes. Modes of operation are
shown in the display.
The NA30C uses a 3.5mm connection to any external or
portable device for audio streaming. An optional extension
(model SU35) is available to mount this connection onto the
vehicle's dash for easy access. Refer to the wiring diagram
for connection instructions. Once connected, press MODE to
select auxiliary input mode.
Adjust volume using volume knob (00-46).
Press to silence the audio. Press again or rotate the
volume knob to resume audio.
The unit will display the time on the LCD display. Clock
settings are adjusted in the General setup menu.
The clock will display 12-hour AM/PM time or 24-hour time
(22:00). Frequency spacing is adjusted in the General setup
menu.
Press and hold MODE for 5 seconds to activate Camera mode.
The screen will display an image of the connected rear view
camera (sold separately). To exit, press MODE and select any
other source.
Power On/Off
Mode
Auxiliary Input
Volume
Mute
Set the Clock
12/24-hour Clock
Camera
General Operation

6
NA30C
Setup Menu
Press MENU to toggle through and select one of the following setup menus: Audio,
General, Screen and Bluetooth.
1. Once the desired menu is displayed, rotate the volume knob to scroll through the list
of menu options.
2. Press SELECT to select a specific option to adjust, then rotate the volume knob left/
right to adjust or activate the desired feature.
3. Press SELECT to confirm and save the changes.
Audio:
• EQ - Select between the following preset equalization curves: Flat, Rock, Jazz, Pop,
Classic, Beat or User (user defined)
• 60Hz, 150Hz, 400Hz, 1KHz, 3KHz, 7KHz and 15KHz - Adjust between -8 and 8.
• Balance - Adjust left/right balance between 8L and 8R.
• Fader - Adjust front/rear balance between 8F and 8R.
• Loudness - Turn loudness feature On or Off.
• Loud-Freq - Select 400Hz, 800Hz or 2400Hz.
• Subwoofer - Adjust subwoofer to 80Hz, 120Hz, 160Hz or Off.
• Subwoofer Volume - Adjust subwoofer volume 0-11.
General:
• Tuner - Select desired tuning region: USA, South America or Europe.
• Auto Station Store - Select to automatically find and store six preset stations.
• Local - Turn the local feature On or Off.
• Clock - Rotate the volume knob to select the hours, minutes and AM/PM.
• Clock Mode - Choose between 12-hour and 24-hour clock.
• Version - Display the current software version number.
• Default - Press SELECT to restore unit to default factory settings.
Screen:
• Brightness - Adust between 1 and 12.
• Contrast- Adust between 1 and 12.
• Hue - Adust between 1 and 12.
• Saturation - Adust between 1 and 12.
• Sharpness - Adust between 1 and 12.
Bluetooth:
• Bluetooth - Turn Bluetooth feature On or Off.
• Auto Connect - Turning Auto Connect to On will program the unit to automatically
the Bluetooth device when in range.

7
NA30C
Manual Tuning
Seek Tuning
Band
Storing Station Presets
Recalling Station Presets
PressTUNE
nn
orTUNE
ll
momentarilytochangeradiofre-
quency up or down one step at a time. Press and hold to
advance quickly.
PressTUNE
nn
orTUNE
ll
formorethantwoseconds(then
release) to automatically seek and tune to the next strong
station.
Press BAND to select between FM1, FM2, FM3, AM1, AM2
and WB (weather band) bands.
Tune to the desired station, press and hold the SELECT but-
ton for 3 seconds to enter the Preset Menu. Use the Volume
Knob to scroll to the desired preset, then press and hold the
SELECT button for 3 seconds to program and exit.
Press PRESET to cycle through the 1-6 presets in the current
band.
AM/FM Tuner Operation

8
NA30C
Playing MP3/WMA Files
Play/Pause
Next Track
Previous Track
Fast Forward/Reverse
File Search
Playback Functions
Intro
Random
Repeat
To play MP3 files, connect a USB device containing MP3/files.
“USB Loading" will flash in the display. Depending on the
number of files and folders, this may take several seconds.
Press the BAND button to pause or resume playback.
Press TUNE
ll
to advance to the next track.
Press TUNE
nn
to return to the beginning of the current
track, and press TUNE
nn
again to return to the previous
track.
Press and hold TUNE
nn
or TUNE
ll
to fast reverse or
fast forward a track.
Press SELECT to display a list of all files and folders on the
device. Rotate the volume knob to navigate to selected file
or folder, then press SELECT to begin playback.
Press and hold SELECT to display playback functions, then
rotate the volume knob to select one of the following
options: Intro, Random or Repeat. Press SELECT to choose
that function.
Rotate the volume knob to select between the following
options, then press SELECT to confirm.
• All - Plays the first 10 seconds of all songs on device.
• Folder - Plays the first 10 seconds of all songs in folder.
• Off - Cancels the Intro function.
Rotate the volume knob to select between the following
options, then press SELECT to confirm.
• On - Plays all songs on device in random order.
• Off - Cancels the Random function.
Rotate the volume knob to select between the following
options, then press SELECT to confirm.
• All - Repeats all songs on device.
• Folder - Repeats all songs in folder.
• One - Repeats the current song only.
Note: Folder repeat, random and intro options only function
on devices recorded with more than one folder.
USB Operation

9
NA30C
MP3/WMA Operation
Type Specification
Compatible File Types • MP3 data (.mp3)
• WMA data (.wma)
Incompatible File
Types
• DRM protected files
• WMA lossless
• Apple lossless
• WMA Pro
• MP3 Pro
• MP3 playlists
• M4A/AAC data
• WAV lossless
Sampling Frequency
Rate Compatibility
• MP3: 8kHz - 48kHz
• WMA: 32kHz - 48kHz
Transfer Bit Rate
Compatibility
• MP3: 32kbps - 320kbps
• WMA: 32kbps - 192kbps
Character Support
• Song Title: 32 characters
• Artist Name: 32 characters
• Album Name: 32 characters
• File Name: 32 characters
• Folder Name: 32 characters
ID3 Tag Support • MP3 Tags: Version 1.0 - 2.4
• WMA Tags
File/Folder Limit
• Maximum number of files: 999
• Maximum number of folders: 500 (plus the root folder)
• Maximum number of files in each folder: 999
Note: For devices with more than the maximum number of
files/folders, some files will be ingnored and may not function
properly.
USB/SD File System • FAT/FAT32 file system supported.
• HFS/NTFS/EXT2/EXT3 not supported.
File/Folder Compatibility and Support

10
NA30C
Bluetooth Operation
Before you can use a Bluetooth device, it must be paired and
connected. Make sure that Bluetooth is activated on your
device before you begin the pairing process.
The NA30C broadcasts the pairing signal constantly
when no devices are currently connected. Complete the
pairing sequence from your Bluetooth device. Refer to the
owner's manual for your device for more details.
The device name is "NA30C"
The Bluetooth passcode "0000"
Note: The NA30C can be in any mode of operation
when pairing is performed.
The NA30C supports A2DP (advanced audio distribution
profile) wireless streaming audio from your Bluetooth mobile
device directly to your head unit. You can also control your
music from the front panel of the head unit using AVRCP
(audio video remote control profile).
• To stream music to your head unit, your mobile device must
support the A2DP and AVRCP Bluetooth profiles. Check the
owner's manual of your mobile device for details.
• Streaming audio must be enabled from your mobile device.
This option will vary depending on the device. Some devices
allow streaming audio to be disabled.
After pairing, connecting and enabling streaming audio
from a compatible mobile device, begin playing music using
the music player on your mobile device. Once the music is
playing, the following functions can be used to control the
music:
• The
ll
button will skip to the next available audio track.
• The
nn
button will skip to the previous audio track.
• The
l
/ ll button will toggle between play and pause
during playback.
Note: Some Bluetooth devices may not fully support these
commands.
Preparation
Pairing a New Device
Streaming Audio

11
NA30C
Notes

12
NA30C
This warranty gives you specific legal
rights. You may also have other rights
which vary from sta te to state
NavAtlas warrants this product to the
original purchaser to be free from defects
in material and workmanship for a period
of one year from the date of the original
purchase.
NavAtlas agrees, at our option, during the
warranty period, to repair any defect in
material or workmanship or to furnish an
equal new, renewed or comparable product
(whichever is deemed necessary) in
exchange without charges, subject to
verification of the defect or malfunction
and proof of the date of purchase.
Subsequent replacement products are
warranted for the balance of the original
warranty period.
Who is covered?
This warranty is extended to the original
retail purchaser for products purchased
from an authorized NavAtlas dealer and
used in the U.S.A
What is covered?
This warranty covers all fefects in material
and workmanship in this product. The
following are not covered: software,
installation/removal costs, damage
resulting from accident, misuse, abuse,
neglect, product modification, improper
installation, incorrect line voltage,
unauthorized repair or failure to follow
instructions supplied with the product, or
damage occurring during return shipment
of the product.
Factory defects include:
· MID/Tweeter not playing or distorting
· Glue/adhesive separating or not
holding correctly
· Tinsel leads not attached/soldered
correctly
· LED not working out-of-box
What to do?
1. Before you call for service, check the
troubleshooting guide in your owner’s
manual. A slight adjustment of any
controls may save you a service call.
2. If you require service during the
warranty period, you must carefully
pack the product (preferably in the
original package) and ship it by
prepaid transportation with a copy of
the original receipt from the retailer to
an authorized service center.
3. Please describe your problem in
writing and include your name, a
return UPS shipping address (P.O. Box
not acceptable), and a daytime phone
number with your shipment.
4. For more information and for the
location of the nearest authorized
service center please contact us by one
of the following methods:
• Call us 1-562-946-7471
• E-mail us at [email protected]
Exclusion of Certain Damages:
This warranty is exclusive and in lieu of
any and all other warranti es, expressed
or implied, including without
limitation the implied warranties
of merchantability and fitness for a
particular purpose and any obligation,
liability, right, claim or remedy in
contract or tort, whether or not arising
from the company’s negligence, actual
or imputed. No person or epresentative
is authorized to assume for the
company any other liability in
connection with the sale of this
product. In no event shall the company
be liable for indirect, incidental or
consequential damages.
Limited One-Year Warranty

13
NA30C
Problem Cause Action
Unit will not turn on
(no power)
Yellow wire not connected or incorrect
voltage Red wire not connected or
incorrect voltage
Check connections for proper
voltage (11-16VDC)
Black wire not connected Check connection to ground
Fuse blown Replace fuse
Unit blows fuses
Yellow or red wire touching chassis
ground Check for pinched wire
Speaker wires touching chassis ground Check for pinched wire
Incorrect fuse rating Use fuse with correct rating
NO FILE appears
on display
WMA file is protected by DRM (Digital
Rights Management)
Use WMA files that are not
protected
No playable MP3/WMA files found on
the device
Check the device for valid
MP3/WMA files
Communication error Remove and reconnect the
device
NO SUPPORT appears
on display An invalid ID3 tag version is present Version 1.0 to 2.4 ID3 tags are
supported.
Troubleshooting

14
NA30C
Tuning range: 87.5MHz-107.9MHz
Usable sensitivity: 8.5dBf
50dB quieting sensitivity: 10dBf
Stereo separation @ 1kHz: >30dB
Frequency response: 30Hz-13kHz
Tuning range: 530kHz-1710kHz
Usable sensitivity: 22uV
Frequency response: 30Hz-2.2kHz
Preout Voltage: 4.5 Volts RMS
Dimensions: 4 1/16" x 2 13/16" x 3 1/2"
(104x73x98mm)
Design and specifications subject to change without notice.
FM Tuner
AM Tuner
General
Specifications

15
NA30C
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Compliance

Support Line: 1-562-946-7471
Monday-Friday, 9AM-5PM PST
www.navatlas.com
All rights reserved.
NSA0919-V01
Printed in China
