Disclaimer
Back Track
User Manual
Version: V1.0
Compass Systems Corp.
E-mail: [e-mail]
This user manual is only intended for the personal use of the purchaser. The purchaser may not copy or
otherwise publish any part of this user manual for any purpose, in any form or through any method, be it
electronic or mechanical, photographic records included, except with the prior consent in writing of
Compass Systems.
Compass Systems reserves the right to modify without notice any of the information contained within this
user manual. Compass Systems reserves the right to change, improve or modify its product or its content
at any time without having to notify any person or organization.
© Copyright 2009, Compass Systems Corp.
All rights reserved.

4
Warning
The correct and safe use of the Back Track requires the user's familiarity with certain items of knowledge.
Please read through this user manual before operating the device.
The Back Track is only intended to be an auxiliary device and can't be held legally liable for any
accidents resulting from errors in measurement through the user's incorrect operation or use of the Back
Track.

5
About GPS
GPS (Global Positioning System) is a satellite navigation system developed by the U.S. Department of
Defense. GPS consists of 32 satellites orbiting around 11,000 miles above the surface of the Earth.
These satellites travel at speeds that allow them to orbit the planet twice a day and emit a low-powered
radio signal. These signals are received and recorded using five ground stations with extremely accurate
clocks. By using these extremely accurate clocks, the ground stations can determine with great precision
the position of every satellite in their orbit. Your GPS receiver is capable of "reading" the signals
transmitted by these satellites. By knowing the position and distance of al least 4 satellites, it's possible to
accurately calculate the receiver's current latitude, longitude and elevation.
WAAS enhances the accuracy of your GPS. WAAS stands for Wide Area Augmentation System and was
developed by the Federal AviationAdministration to augment the accuracy of GPS for aviation use. It
consists of additional ground stations that are placed at specific locations where the exact coordinates
are known. When used with a master station, the accuracy of satellite positioning signals can be
improved to almost three meters.
The Back Track must scan and detect signals from at least 3 such satellites in order to calculate your
current location and movement. The Back Track is designed for recreational use only. Please do not use
this product for industrial or professional surveying.

6
Conditions for Use:
The Back Track is not designed for indoor or underwater use. The device uses GPS satellites to
calculate distances and is designed to serve as an auxiliary navigation aid for personal between the
temperatures 0°C to +60°C.
If you find that any of the standard accessories listed in this manual are missing or damaged, please
contact your local distributor or retailer.

7
1 Introduction
1.1 Package Contents:
Before using this product, please check that the following items were included within the package. If
there are any missing items, please contact the distributor you purchased this product from immediately.
1. Back Track.
2. User Manual.
3. Neck Lanyard.
1.2 Maintenance:
1. Do not attempt to disassemble the Back Track.
2. This device contains no user-repairable parts.
3. Please store the Back Track out of direct sunlight or high temperatures.

8
1.3 Replace Battery:
Rotate screw counterclockwise to open
Twist the round battery cover on the back of the Back Track counterclockwise srew to open it (see
photo), and insert two “AAA” alkaline or lithium batteries in the direction marked inside the battery
compartment. Replace the cover, rotating it clockwise. Replace the batteries when the display’s “Battery”
icon indicates
low power.

9
1.4 Introduction to the Hardware
1. Mode/Power button: Use to turn power on（Hold on 1sec）/off（Hold on 3sec）and switch between
operating modes（Push）.
2. Mark/Backlight button: Marks locations（Hold on 3sec）/backlight on（Push）/Setup mode(Hold on
3sec).

10
1.5 Basic Specifications
Interface Graphical Display
POI 4
Receiver Chip High sensitivity
receiver chip
Positioning Time
Hot Start < 1 sec
WarmStart < 38 sec
ColdStart < 42 sec
Data Refresh Rate Once every second
Positioning Accuracy
Single unit
positioning with no SA
interference
<10M
Antenna Internal
Power Supply
Battery Type 2xAAA
Size 88(L)x 54(W) x
29(D)mm
Mass <100g
Display Size 33x42mm
Water Resistance IPX6
Operating Temperature
Range
0 °C to + 60 °C
