Navico SonicHub 2 User manual
*988-10964-002*
90.0 mm
(3.54”) 50.0 mm
(1.97”)
225.0 mm
(8.85”)
207.5 mm
(8.17”)
107.2 mm
(4.22”)
62.0 mm
(2.44”)
193.6 mm
(7.62”) 107.2 mm
(4.22”)
LEFT
RIGHT
ZONE 1
LEFT
RIGHT
ZONE 2
WHITE
POWER L.E.D.
WHITE/BLACK
GREY
GREY/BLACK
GREEN
GREEN/BLACK
PURPLE
PURPLE/BLACK
HIGH LEVEL INPUT (MIC.)
BATTERY (+12 V DC)
BROWN
BROWN/WHITE
BATTERY (-)
RED
BLACK
EXT. AMPLIFIER POWER CONTROL
BLUE/WHITE
POWER CONTROL BUS
(IGNITION)
YELLOW
ANTENNA
(Not Supplied)
SUBWOOFER
OUT
ZONE 3
OUT
VIDEO
OUT
SATELLITE IN
(AUX 2)
AUXILARY
IN
NMEA 2000
USB x 2
SonicHub™ 2
Marine Audio Server
INSTALLATION GUIDE
Dimensions
Wiring connectors Parts included
A Sonichub™2
B Mounting screws
C Documentation pack
D ISO wiring harness
E NMEA 2000 T-Connector
F NMEA 2000 Cable
Compliance statements
Navico®, Lowrance and B&G, are registered trademarks of Navico
Simrad® is used by license from Kongsberg.
NMEA® and NMEA 2000® are registered trademarks of the National
Marine Electronics Association.
The Bluetooth® word mark and logos are registered trademarks owned
by the Bluetooth SIG, Inc. and any use of such marks by Navico is under
license.
Other trademarks and trade names are those of their respective
owners.
Europe
Navico declare under our sole responsibility that the product conforms
with the requirements of:
• CE under RED 2014/53/EU
United States of America
Navico declare under our sole responsibility that the product conforms
with the requirements of:
• Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference
received, including interference that may cause undesired
operation.
! Warning: The user is cautioned that any changes or modications
not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
¼NOTE: The equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that
the interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit dierent
from that of the receiver is connected
• Consult the dealer or an experienced technician for help
ISED Canada
This device complies with ISED (Innovation, Science and Economic
Development) Canada’s license-exempt RSSs. Operation is subject
to the following two conditions: (1) This device may not cause
interference; and (2) This device must accept any interference,
including interference that may cause undesired operation of the
device.
La traduction française de ce document est disponible sur le site Web
du produit.
Australia and New Zealand
Navico declare under our sole responsibility that the product conforms
with the requirements of:
• Level 2 devices of the Radiocommunications (Electromagnetic
Compatibility) standard 2017
• Radiocommunications (Short Range Devices) Standards 2014
Declarations
The relevant declarations of conformity are available at:
• www.simrad-yachting.com
• www.lowrance.com
• www.bandg.com
Bluetooth®
SonicHub2 features integrated Bluetooth and allows you to stream
audio from a smart device. Refer to the relevant smart device manual or
website for Bluetooth connectivity instructions.
A
B
D
EF
C
WM-3
Weather Module
Tri-Cable Splitter
12-24Vdc
Power
Antenna
Network
Audio
Weather Module
2m (6.5 ft)
Amplier
Blue
EXT. Amp
PWR on
Amplied
Subwoofer
NMEA 2000 Backbone
Cable 4 m (13 ft)
Multi-Function Display
Multi-Function Display
Video In
RCA Male / Male
(Not supplied)
+
-
Hailer
VHF
Brown
Brown/ white
USB Stick
32GB Max
USB cable
Switch
(optional)
Fuse
Black
Red
Yellow
Battery
(12 V DC)
Power connection
¼Note: The unit will turn on/o when power is
applied/removed to the yellow wire.
NMEA 2000 network connection
Video out connection
USB Connection Zone 3 speaker connection MIC connection
SAT IN (AUX 2) connectionSubwoofer connection
Specications
General
Operating Voltage 10 - 16V DC
Current Draw Standby: <5mA
Maximum: 20 A
Fuse Value 15 A
NMEA 2000® LEN 1
Temperature Range Operating: -20 to 60°C (-4 to 140°F)
Storage: -40 to 80°C (-40 to 176°F)
Water Resistance Rating IPX2
Compliance FCC Part B, subpart J; CE per EN 60945;
C-Tick
Dimensions (L x W x H) 107.2 x 225.0 x 62.0 mm (4.2 x 8.9 x 2.4”)
Weight 0.88 kg (1.96 lbs)
Audio Amplier
Output per channel (x4) 26 W RMS (45 W max) @ 4 Ω
Total Output 200 W max
Frequency Response 20 Hz - 20 kHz
S/N Ratio >80 dB (Referred to 1 W)
Total Harmonic Distortion <1% @ 4 Ω (Referred to 1 W, 4 Ω load, 20
Hz - 20 kHz)
FM Tuner
FM Tuner
US: 87.9 to 107.9 MHz
EU: 87.5 to 108.0 MHz
JPN: 76.0 to 90.0 MHz
Usable sensitivity 3 dBuV = 1.4 uV for 30 dB S/N ratio
Auto seek sensitivity 24 dBuV = 15.8 uV for 30 dB S/N ratio
Signal to noise ratio 50 dB @ 10 dBuV signal
Ultimate S/N ratio >70 dB @ 60 dBuV signal
Distortion <0.1% @ 10 dBuV signal
AM Tuner
AM Tuner US: 530 to 1710 kHz with 10 kHz/step
EU: 531 to 1611 kHz with 9 kHz/step
Usable sensitivity 28 dBuV = 25 uVfor 20 dB S/N ratio
Auto seek sensitivity 36 dBuV = 63 uVfor 20 dB S/N ratio
Signal to noise ratio 50 dB @ 60 dBuV signal
Ultimate S/N ratio >60 dB @ 80 dBuV signal
Distortion <0.4% @ 60 dBuV signal, 80% modulation
Audio Inputs
AUX 1, AUX 2 (SAT) 1V RMS (Line inputs 2 V peak to peak)
MIC/High Level Input
Sensitivity 1V RMS
High level input 6V RMS (max)
AM/FM Antenna Coaxial (ISO/DIN Female)
Audio/Video Outputs
Zone-3 RCA output 2V RMS
Sub Woofer output 2V RMS
Video output PAL and NTSC
Bluetooth®
Prole A2DP, AVRCP, HFP
Core Specication v4.0
Codec SBC
Connection Range: Up to 33 ft / 10 m
USB
Interface v1.1, v2.0
Maximum Charge
Capacity 1 A
File Support Type FAT16, FAT32, NTFS
3
2
1
Mounting
