Navman’s 300 series GPS Sport.Tools provide an affordable and
reliable way to track and store a variety of personal performance
indicators.
Please read this guide carefully and familiarize yourself with
the interface and functions, as well as the intended use and
limitations of the Navman M300 GPS Sport.Tool.
This product complies with CE, FCC, Canada 210, and C-Tick
regulations.
Operation is subject to the following two conditions:
(1) this device may not cause interference
(2) this device must accept any interference, including interference that
may cause undesired operation of the device.
WARNING: Entering information or handling the Navman
Sport.Tool while moving is unsafe and may cause you to
be distracted or fail to observe safe practices necessary to
avoid death, serious injury, collisions or accidents to you or
others. Use the memory functions to review data when you
are not moving.
CAUTION: The Navman M300 GPS Sport.Tool is intended
for recreational use only. Do not use this product for
obtaining measurements that require professional or
industrial precision. Consult your physician before starting
or changing any exercise programs.
Welcome
Welcome

M300 1-5
NAVMAN
Content
M300 - Content
1.0 General information 1-6
1.1 Checklist 1-6
1.2 Care and maintenance 1-6
1.3 Water resistance 1-6
1.4 Changing the battery 1-7
2.0 Navman M300 interface 1-8
2.1 Button functions 1-8
2.2 Display screen 1-8
3.0 Getting started 1-9
3.1 Be outdoors 1-9
3.2 Fit the M300 1-9
3.3 Startup 1-9
3.3.1 Enter setup 1-10
3.3.2 Start normal operation 1-10
4.0 Setup 1-11
4.1 Setting options 1-11
4.1.1 Set time format 1-12
4.1.2 Set date format 1-12
4.1.3 Beep 1-13
4.1.4 Set speed units 1-13
4.1.5 Set offset (set local time) 1-14
4.1.6 Editing settings (overview) 1-15
5.0 Normal operation 1-16
5.1 Modes 1-16
5.1.1 Speed mode 1-17
5.1.2 Speed (Average) mode 1-17
5.1.3 Speed (Maximum) mode 1-18
5.1.4 Odometer mode 1-18
5.1.5 Heading mode 1-19
5.1.6 Clock mode 1-20
5.1.7 Timer mode 1-21
5.1.8 Timer recall mode 1-21
5.1.9 Mode operation (overview) 1-22
6.0 Restoring default settings 1-23
7.0 Glossary 1-24
8.0 Copyright 1-24
9.0 Additional warnings, disclaimers, and limitations on
liability 1-25

M300
1-6
NAVMAN
1.0 General information
1.1 Checklist
The M300 package should contain the following items:
• Navman M300 GPS Sport.Tool
• armband
• quick guide
• user guide
• 1 x AA battery
• registration card
1.2 Care and maintenance
Do not attempt to disassemble the M300; there are no user
serviceable components in this product.
The M300 is of robust design. However, care should be taken to
protect from shocks or extreme heat.
Clean using only a soft cloth with mild soap and warm water. Do
not use abrasive cleaning materials or products. We recommend
rinsing the M300 with fresh water after any exposure to salt
water.
CAUTION: Please ensure battery cover is in place during
cleaning.
Store the M300 away from direct sunlight or extreme heat
sources. (Remove battery before storing for an extended
period.)
1.3 Water resistance
The Navman M300 GPS Sport.Tool is water resistant.
M300 – General information

M300 1-7
NAVMAN M300 - General information
1.4 Changing the battery
Always shut down the M300 before changing the battery.
Note: All system settings, and the calculated data that was stored
at the last controlled shutdown*, are retained when the battery is
removed. This information persists indefinitely until updated or reset.
If battery power becomes low during operation the battery icon
is displayed.
For best performance:
General use = Alkaline
Below 5 oC = NiMH
!
constant = low power
flashing = approx 5 min before automatic shutdown**
* Press and hold to perform a controlled shutdown.
** When battery power becomes too low to continue operation,
a controlled shutdown is automatically executed (current data
is saved).
battery icon
PM
1. Turn D-ring anti-clockwise and slide enclosure cover down to
open battery enclosure.
2. Insert battery with «» end as indicated inside enclosure.
3. Replace enclosure cover (ensuring lugs at the bottom of the
cover are aligned with slots in the enclosure surround), turn
D-ring clockwise to seal.

M300
1-8
NAVMAN
2.1 Button functions
There are two control buttons, and . These buttons are
pressed separately or together to turn the unit on and off, cycle
through modes, and select mode options.
Throughout this guide the button icons are used as follows:
= press this button
= press this button
= press both buttons together
Note: where it is required to press and HOLD buttons, a countdown
begins. To perform the required action continue to hold until the
counter reaches zero; if you release the button sooner the action will
not be performed.
2.2 Display screen
The illustration above shows the complete display capability of the M300.
Only a sub-set of these elements appear at any time during operation.
The upper screen section displays the antenna and battery
icons, as well as all values and units. The lower screen
section displays the mode icons and the setup icon (System
Set).
Mode Icons
2.0 Navman M300 interface
RCL
AVG
MAX
M300 - Interface
Clock
Timer
Timer recall
Speed
Speed (Average)
Speed (Maximum)
Odometer
Heading
83 72
8 7 2
3S
N
SYSTEM
SET
kmminmiPM
LAP
km/hmphknots
RCL MAX
AVG
S
N

M300 1-9
NAVMAN M300 - Getting started
3.1 Be outdoors
The M300 is not intended for operation indoors or under
water as it uses Global Positioning System (GPS) satellites to
get time and date information, and to calculate distance and
speed. For best results, always use the M300 outdoors with an
unobstructed view of the sky.
3.2 Fit the M300
The M300 is designed to be worn on the left upper arm. The
easiest way to fit the unit is to feed the strap through the
fastener to create a loose enclosure. Then slide your left arm
through the enclosure and tighten the strap after the unit is in a
comfortable position.
3.3 Startup
Press and hold to turn the power on and enter setup, OR
press to turn the power on and start normal operation.
First start may take up to 80 seconds to get all the satellite data
Flashing = seeking GPS data
Constant = GPS data obtained
3.0 Getting started
!Always enter setup first if you wish to change settings.
To enter setup after starting normal operation, you will
need to shut down and re-start the unit.
�

M300
1-10
NAVMAN
M300 - Getting started
3.3.1 Enter setup
To enter setup
Press and hold to turn the power on and enter setup.
When the counter reaches zero, the M300 will enter setup. If
you release before the counter reaches zero the M300 will
immediately start normal operation.
Note: To enter setup after starting normal operation you will need
to restart the M300. For details about changing settings see Section
4.0.
To leave setup
Press and hold to leave setup and start normal operation.
When the counter reaches zero, the M300 will leave setup and
start normal operation in Speed mode. If you release before
the counter reaches zero the M300 will remain in setup.
Note: you must leave setup first if you want to turn the power off.
3.3.2 Start normal operation
To start normal operation
Press to turn the power on and start normal operation.
When starting directly into normal operation, the M300 will start
in the mode it was in at last shutdown. (Speed mode is always
displayed first when starting normal operation after leaving
setup.) For details about normal operating modes see Section
5.0.
counter
counter

M300 1-11
NAVMAN
4.1 Setting options
Press and hold to turn the power on and enter setup.
Press repeatedly to step through the setting options.
Setting options are accessed in the order shown below. See
subsequent sections for details about editing settings.
Set (12hr)
lets you set 12hr or 24hr time format
Set (31-12)
lets you set dd-mm or mm-dd date format
Beep
When beep is ON a beep will sound when the buttons are
pushed.
Set units (knots)
lets you set the speed units to knots, km/h or mph
Set offset (set local time)
lets you adjust the M300 to display local time
Press and hold to leave setup and start normal operation.
M300 - Setup
Set (12hr) Beep
Set offset
Set (31-12)
Set units (knots)
4.0 Setup

M300
1-12
NAVMAN
M300 - Setup
4.1.1 Set time format
Set 12hr or 24hr time display format.
To access this option
If necessary, press and hold to turn the power on and enter
setup. Press repeatedly until the screen appears as shown
above.
To set time format
1) Press to start editing (time format option flashes).
2) Press or to select 12hr or 24hr.
3) Press to stop editing.
4) Press to go to the next option, or hold to leave setup.
4.1.2 Set date format
Set ‘dd-mm’ or ‘mm-dd’ date display format.
To access this option
If necessary, press and hold to turn the power on and enter
setup. Press repeatedly until the screen appears as shown
above.
To set the date format
1) Press to start editing (date format example flashes).
2) Press or to select dd-mm or mm-dd.
3) Press to stop editing.
4) Press to go to the next option, or hold to leave setup.
time format
date format
SYSTEM
SET
SYSTEM
SET

M300 1-13
NAVMAN M300 - Setup
4.1.3 Beep
Set beep ON or beep OFF. When beep is ON, an audible ‘beep’
will sound when buttons are pressed.
Access this option
If necessary, press and hold to turn the power on and enter
setup. Press repeatedly until the screen appears as shown
above.
To set button beep status
1) Press to start editing (setting status flashes).
2) Press or to select On or OFF.
3) Press to stop editing.
4) Press to go to the next option, or hold to leave setup.
4.1.4 Set speed units
Set units for speed (knots, km/h or mph).
Access this option
If necessary, press and hold to turn the power on and enter
setup. Press repeatedly until the screen appears as shown
above.
To set speed units
1) Press to start editing (speed units flash).
2) Press or to select knots, km/h or mph.
3) Press to stop editing.
4) Press to go to the next option, or hold to leave setup.
Note: Distance is displayed in units that correspond to user selected
speed units. For example, if you select speed units ‘km/h’, then
distance is displayed in ‘km’.
speed units
status
SYSTEM
SET
SYSTEM
SET
knotsnmi

M300
1-14
NAVMAN
M300 - Setup
4.1.5 Set offset (set local time)
This option lets you adjust the M300 to display local time*. You
only need to do this once, unless operating the unit in a new
time zone. (* By default the M300 displays GPS time. The M300
will perform all functions accurately without adjusting the offset
to display your local time.)
Note: If you attempt to change the time offset before all GPS data are
obtained, the screen displays ‘no GPS’ and the antenna icon flashes until all
GPS data are received.
Access this option
If necessary, press and hold to turn the power on and enter
setup. Press repeatedly until the screen appears as shown
above.
To set local time
1) Press to start editing (the screen now appears as shown
below). The current time value flashes. The date is displayed
to ensure that adjustments are made in the correct direction.
2) Press repeatedly to set time display forward (press and
hold to set time display forward quickly), or press
repeatedly to set time display backward (press and hold to
set time display backward quickly).
3) Press to stop editing.
4) Press to go to the next option, or hold to exit setup.
current datecurrent time
SYSTEM
SET
SYSTEM
SET
PM

M300 1-15
NAVMAN M300 - Setup
4.1.6 Editing settings (overview)
KEY
= press this button
= press this button
= press both buttons together
settings editing details
beep beep
beep ON
beep OFF
set units (knots) set units (km/h)
set units (knots)
set offset
set 12hr
set 31-12
set 24hr
set 12-31
set units (knots)
set (12hr) set (12hr)
set (31-12)set (31-12)
time (date)
edit accept
�
�
edit accept
edit accept
edit accept
edit accept
set units (mph)

M300
1-16
NAVMAN
M300 - Normal operation
5.1 Modes
Press to turn the power on and start normal operation.
Press repeatedly to step through the modes (press and hold
to cycle through the modes quickly).
Modes are accessed in the order shown below. See subsequent
sections for details about using different modes.
Speed mode
shows distance and speed
Speed (AVG) mode
shows distance and average speed
Speed (MAX) mode
shows distance and maximum speed
Odometer mode
shows total distance from last odometer reset
Heading mode
shows current heading in degrees from true North
Clock mode
shows current time and date
GPS time is displayed unless you set local time, see Section 4.1.5.
Timer mode
shows session* and lap* times
Timer recall mode
recalls stored session and lap times
(*See glossary.)
83 72
Speed Speed AVG Speed MAX Odometer
HeadingClockTimer
Timer RCL
MAX
AVG
RCL
5.0 Normal operation
S
N

M300 1-17
NAVMAN M300 - Normal operation
5.1.1 Speed mode
This mode lets you monitor session distance and current speed.
To access this mode
If necessary, press to turn the power on and start normal
operation. Press repeatedly until the screen appears as
shown above.
While in Speed mode
• Press to store current lap data (the screen briefly shows the
lap distance, lap number, and lap time that is being stored).
• Press and hold to clear all* session data. (*Does not clear
odometer.)
• Press to go to the next mode.
5.1.2 Speed (Average) mode
This mode lets you monitor session distance and average
speed.
To access this mode
If necessary, press to turn the power on and start normal
operation. Press repeatedly until the screen appears as
shown above.
While in Speed (average) mode
• Press to store current lap data (the screen briefly shows the
lap distance, lap number, and lap time that is being stored).
• Press and hold to clear all* session data. (*Does not clear
odometer.)
• Press to go to the next mode.
current speed
session distance
average speed
session distance
nmi knots
nmi knots
AVG

M300
1-18
NAVMAN
M300 - Normal operation
5.1.3 Speed (Maximum) mode
This mode lets you monitor session distance and maximum
speed.
Access this mode
If necessary, press to turn the power on and start normal
operation. Press repeatedly until the screen appears as
shown above.
While in Speed (maximum) mode
• Press to store current lap data (the screen briefly shows the
lap distance, lap number, and lap time that is being stored).
• Press and hold to clear maximum speed only.
• Press to go to the next mode.
5.1.4 Odometer mode
This mode shows total distance since odometer was last reset.
Access this mode
If necessary, press to turn the power on and start normal
operation. Press repeatedly until the screen appears as
shown above.
While in Odometer mode
• Press to store current lap data (the screen briefly shows the
lap distance, lap number, and lap time that is being stored).
• Press and hold to clear odometer only.
• Press to go to the next mode.
Note: The M300 displays distance in units corresponding to speed
units (see section 4.1.4).
maximum speed
session distance
total distance
nmi knots
MAX
8 7 2
3
nmi

M300 1-19
NAVMAN M300 - Normal operation
5.1.5 Heading mode
This mode shows the current heading in degrees from true
North.
Access this mode
If necessary, press to turn the power on and start normal
operation. Press repeatedly until the screen appears as
shown above.
While in Heading mode
• Press to store current lap data (the screen briefly shows the
lap distance, lap number, and lap time that is being stored).
• Press to go to the next mode.
current heading
S
N

M300
1-20
NAVMAN
M300 - Normal operation
5.1.6 Clock mode
Clock mode shows the current time and date.
(Time is only displayed while GPS satellite signals are available.
By default, GPS time is displayed. See section 4.1.5 for
instructions on setting local time.)
Access this mode
If necessary, press to turn the power on and start normal
operation. Press repeatedly until the screen appears as
shown above.
While in Clock mode
• Press to store current lap data (the screen briefly shows the
lap distance, lap number, and lap time that is being stored).
• Press and hold to clear all* session data. (*Does not clear
odometer).
• Press to go to the next mode.
Note: If GPS signals are not yet obtained a ‘no GPS’ alert is
displayed. The antenna icon flashes until GPS signals are received.
current time current date
PM
