NavTour G4 User manual

Contents
What’s included in the package
Installation
Turning on for the first time
Entering your first destination
What is on the screen
Planning a route
Other features
Additional info
1
3
5
8
10
11
12
15
Quick Start Guide

What’s included in the package
1
1. Cradle
5. Car holder
2. Car charger
6. 24 pin USB cable
3. Travel charger
7. DVD, warranty card, Quick Start Guide and Micro SD card
4. Car Holder Transmitter
12 3 4
5 76

What’s included in the package
1. External antenna jack
2. Sleep switch/button lock
3. Power indicator
4. Touch screen panel
5. Up button
6. Confirm button
7. Cancel button
8. Down button
9. 2.5mm earphone jack
10. Mini USB port
11. Speaker
12. Reset button
13. Micro SD card slot
14. 24 pin USB port
15. Power switch
9
10
11 12 13
14 15
2
1
3 4
5
6
7
8
2

Installation
3

Installation
4
To remove the car holder, please flip
the level down toward the device.
Pull the suction cup away
from the windshield.

Turning on for the first time
Using the Product
Follow the steps provided below to activate G4
Caution:
The time and alarm settings on the G4 will be restored to factory
default (time = 00:00 with the alarm disabled) every time the power
switch is pushed to “OFF”. It is not necessary to turn the G4 off
unless it will not be used for an extended period of time.
1 2
Insert the Micro SD card into the G4 (be sure to insert it in the correct
orientation) until a “click” is heard. Next, push the power switch
(located at the bottom of the unit) to “ON” (The power switch should
be at “OFF” when the product is shipped from the factory.)
Gently push the sleep
switch (located at the
upper edge of the unit)
as illustrated to activate
the G4.
5

Turning on for the first time
Located to the right of the display are four buttons for various operations (the
display itself offers touch screen functions). MTP operations are only available
in the main menu, the sub menu and file viewer. Basic MTP operations will be
covered below:
• Button operations: you will find four buttons on the MTP and their functions are as follows:
• Touch screen operations: the unit can perform various operations by detecting the user’s sliding movement on
the MTP. User may slide up or down on the MTP to correspond to the action of scrolling up/down in the menu.
MTP Operations
(Multiple Touch Pad)
6
Operating through the sliding bar
(20-level graduation sensor)
Scroll to the previous item
Scroll to the next item
Scroll through items
by sliding up or down
Operating through pushing buttons:
Confirm selection (activating menus/
executing files or accessing menus)
Exit (this function is similar to )

Turning on for the first time
Initial Configurations
After activating the unit, the system will run the navigation software directly. At this point a warning screen appears. Tap I
Agree after you have read and agreed to the warning. The map view appears and you are ready to set your first destination!
1. Tap I Agree. 2. The map view appears.
7
Please Note:
1. Expect 30 seconds - 1 minute to acquire satellite signal.
2. You may experience interference of the satellite signal reception if you have solar
window film, anti-blast security film or anti-UV glass installed on your vehicle.
If so, you can enhance signal strength by purchasing an external antenna.

Entering your first destination
Entering your First Destination
1. Tap Menu. The Menu appears. 2. Tap Destination. 3. Tap Address.
4. Tap Address. There are two ways
to enter the address:
by selecting the city first
by selecting the street first
You can set your destination the following ways:
Address
Intersection
Point of Interest (POI)
Favorites
Recent
City Center
8

Entering your first destination
3. Tap the Numbers or Letters A-D
to enter the house number. Tap OK
The Select Address screen appears.
2. Tap the Letters to enter the name
of the street. Tap OK when you
have selected the street. The Enter
House Number screen appears.
4. Select the address that matches
the location you want to go to and
tap Nav. The map appears, and the
guidance directions begin.
To Enter an Address as a Destination Using Street First
1. Tap Street First.
Menu → Destination → Address → Street First → Input Street Address → Nav
9

What is on the screen
What is on the Screen
1
2
3
4
5
7
6
9
8
10
1. The name of the next street
2. The direction and the distance of your next turn
3. Your current GPS position
4. Zoom Out
5. Return to the menu
6. Freeway information
7. Compass
8. Zoom In
9. Voice navigation
10. Configurable journey information including arrival time,
time to destination, distance to your destination and
your current speed
10

Planning a route
Planning a Route
You can set your destination the following ways:
Address
Intersection
Point of Interest (POI)
Favorites
Recent
City Center
1. Tap Menu. The Menu appears. 2. Tap Destination.
5. The guidance directions begin.
3. Tap Favorites.
4. Tap Nav.
11

Other features
Apart from precise navigation functions, the G4 also offers other useful features such including Multimedia playback,
Bluetooth, PDA and Settings.
Other Features
Multimedia The multimedia player available on the G4 can be used to play music or view pictures/videos for you to
indulge in your favorite music, photographs and video clips at anytime, anywhere.
12

Other features
PDA The PDA functions available on the G4 include World Time and e-Compass.
13

Other features
Setting You can use the Setting function to configure settings on Data Time, Volume, Screen, Language and
Memory and System. You can tweak the G4 according to your preference and personalize your G4.
14

Additional Info
Please use the G4 in an environment in temperature between 0~40 degrees Centigrade, free from
condensation.
Avoid using the G4 in an environment with static electricity, excessive dust, extreme temperatures, high
humidity or places where the unit may be exposed to direct sunlight or strong UV radiation for extended
period of time.
‧ Do not use a third party ac adapter with the product or plug it to a socket on an outlet with another
appliance plugged in as it may lead to fire or electrocution.
‧ Do not modify the ac adapter; do not bend (excessively), twist or pull the cable as it may lead to fire or
electrocution.
‧
Do not damage the cable of the ac adapter; do not place heavy objects on the cable or expose it to
excessive heat. A damaged ac adapter may lead to fire or electrocution.
‧
Do not touch the ac adapter when your hands are damp to avoid potential electrocution.
‧
When not in use for an extended period of time, unplug the ac adapter from the socket.
‧
Clean the area around the electrodes regularly; dust buildup around the electrodes may lead to fire.
‧
Be sure to keep the ac adapter well away from furnaces or other heat sources; high temperature may
cause the layer of insulation covering the ac adapter to melt, which may lead to fire or electrocution.
Points to Note
1. GPS System Architecture
2. Use with Care
3. AC adaptor and power
4. Operating environment
The GPS (Global Positioning System) is provided by the United States Department of Defense. Refer to the information
published by the United States Department of Defense regarding the precision of the system.
For your safety during driving, do not operate the system while driving to avoid potential accidents.
15

Additional Info
CE Compliance & FCC Compliance
This product, together with its original accessories, has been built in compliance with relevant EMC and safety
regulations. However, there is no guarantee that the usage of the product will still comply with the EMC standards
when third-party accessories or cables are used. Users who use third-party accessories or cables shall assume
full responsibility in ensuring that the product (along with its accessories and cables) will comply with all relevant
standards and requirements. To avoid common EMC issues, users are advised to:
‧ Use only accessories bearing the CE marking in conjunction with the product.
‧ Use properly shielded signal cables.
This device has been tested and found to comply with the limits of Class B digital device pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This device generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this device does cause interference to radio
or television reception, which can be determined by turning the device off and on, the user is encouraged to try to
correct the interference by one or more of the following measures
‧Increase the separation distance between the device and receiver.
‧Connect the device into an outlet on a circuit different from that to which the receiver is connected.
‧Consult the dealer or an experienced radio/television technician for help.
‧Reorient or relocate the receiving antenna.
Only electronic equipment certified to comply with the FCC Class B limits may be used for the product. Using non-
compliant peripherals or non-certified accessories may result in harmful interference to radio communication.
When connecting to an external device or a PC via its USB port, use only properly shielded cables. Changes or
modification not expressly approved by the manufacturer could void the user’s authority to operate the device. This
device complies with Part 15 of the FCC Rules, and operations conform to the following standards.
‧This device may not cause harmful interference.
‧This device must accept any interference received, including interference that may cause undesired operation.
16
