NAYATI NGETL 5-50 CE Manual

Group
Service
w w w . v i r t u s n e t . d e
Virtus Group GmbH
Hüsers raße 53
59075 Hamm / Germany
%+49 (0)2381/973 71–0
7+49 (0)2381/973 71– 88
w w w . v i r t u s n e t . e u
Virtus s.r.l.
via Milano 95/e
27045 Cas eggio (PV) / I aly
%[phone]
7+39 0 383809601

Manual Instructions for Gas Economic Table Low
ORIENTAL 1
INSTALLATION, OPERATION and MAINTENANCE,
INSTRUCTIONS
Note: The picture is illustration only We reserved the right to make technical changes in the interest in
progress without prior notice
GAS ECONOMIC TABLE LOW
MODEL:
NGETL 5
-
50
CE

Manual Instructions for Gas Economic Table Low
ORIENTAL 2
Dear customer,
Thank you for choosing our product as your trusted partner We ensure you that we always give
our best as we produce this appliance by using the finest materials NAYATI Gas Economic Table
Low is excellent choice to cook In order to obtain maximum benefits of this appliance, please read
this manual instruction carefully Please notice the warnings and safety instructions to keep your
safety DO NOT use this appliance except its utility
If you have any question or difficulty in operating this appliance, please contact your dealer or
NAYATI to acquire mechanic assistance

Manual Instructions for Gas Economic Table Low
ORIENTAL 3
Page
Cover ………………………………………………………………………………………… 1
Preface ……………………………………………………………………………………………… 2
Table of Content …………………………………………………………………………………… 3
General Information ……………………………………………………………………… 4
Safety Instructions ………………………………………………………………………………… 5
Technical Data ……………………………………………………………………………………… 7
•Data Tables ……………………………………………………………………………… 7
•Overall Dimension ………………………………………………………………………… 8
Technical Data Plates ……………………………………………………………………………… 9
Component List …………………………………………………………………………………… 11
Installation (for the Installer) ……………………………………………………………………… 13
•Position and Fixing ……………………………………………………………………… 14
•Gas Supply Connection ………………………………………………………………… 15
•Checking Gas Pressure and Nominal Heat Input …………………………………… 16
•Primary Air Adjuster……………………………………………………………………… 17
Control Panel Description ………………………………………………………………………… 20
Use Instructions (for user) …………… ………………………………………………………… 21
•Warning …………………………………………………………………………………… 21
•Turn ON / OFF …………………………………………………………………………… 22
Routine Cleaning and Maintenance …………………………………………………………… 23
Trouble Shooting ………………………………………………………………………………… 25
Warranty …………………………………………………………………………………………… 26
TABLE OF CONTENT

Manual Instructions for Gas Economic Table Low
ORIENTAL 4
Please read this manual instruction carefully before operating this appliance
NAYATI Gas Economic Table Low is an excellent cooking appliance This appliance is using gas
This appliance used for making stock in large quantity It is very important to keep this instruction
book together with the appliance for future consultation If this appliance sold or transferred
elsewhere, make sure this book goes with it Therefore, the new user can read about its functions
and other relevant information
If you have any question about the appliance, please contact your nearest dealer or contact
NAYATI
GENERAL INFORMATION

Manual Instructions for Gas Economic Table Low
ORIENTAL 5
Very important!: Before installing, place the appliance on solid, flat, stable and horizontal surface
and connection availability
Read this manual instruction carefully before using NAYATI Gas Economic Table Low This
appliance is for food preparation only Below are safety instructions that strictly conformed:
•Improper installation, maintenance, cleaning, or modification to the appliance could lead to
severe injury or death and could damage the appliance
•The mechanics must instruct staff regularly to avoid accident and damage of the appliance
•NAYATI Gas Economic Table Low may be used for skilled staff only
•DO NOT place the appliance in a toxic area or have a risk of explosion
•DO NOT place the appliance near flammable materials such gasoline, fat, clothes, liquid
gas, paper, etc
•DO NOT place the appliance in wet or humid room or condition such in rain or near water
leaks, etc
•DO NOT use the appliance for drying clothes, paper, or living animals
•DO NOT use the appliance to heat non-food products
•Put the appliance in a good ventilated room
•Before cleaning or maintaining the appliance, detach the gas line and allow it to cool
•DO NOT touch the area This sign means VERY HOT Beware of severe burning
injury
•DO NOT attempt to dismantle or repair the appliance The authorized mechanics must do
all jobs
SAFETY INSTRUCTIONS

Manual Instructions for Gas Economic Table Low
ORIENTAL 6
EXPLOSION RISK
!
-DO NOT over the burners or drawers below or the air holes
on the sidewalls with Aluminum or silver foil or similar
materials. This may ause a wrong air ir ulation and gas
ombustion and lead to overheat.
INJURY RISK
!
-DO NOT lean to Main Burner during ignition pro ess. High
flames from the range may ause severe burning injury.

Manual Instructions for Gas Economic Table Low
ORIENTAL 7
NAYATI Gas Economic Table Low is made of stainless steel This appliance is used to make stock
in large capacity There is a gas burner and gas tap The burner is atmospheric and supplied by a
mixture of liquid gas and air or natural gas and air The Main Burner ignition carried by Pilot Burner
The Main Burner equipped by Safety Thermocouple
•Data Tables
Table 1: Technical Specification
Te hni al Spe ifi ation
Model
NGETL 5
-
50
Overall Dimension (mm)
Width
Depth
Height
500
500
450
Gas Conne tion R ¾”
Nominal Heat Input
Natural Gas
: 13 kW
LPG : 11 5 kW
Gas Conne tion Pressure
G 20 :
2
0 mbar
G 25 : 20 – 25 mbar
G 30 / G 31 : 28
–
30
/ 37 mbar
G 30 / G 31 : 50 mbar
Ignition
Manual
TECHNICAL DATA

Manual Instructions for Gas Economic Table Low
NAYATI
ORIENTAL 8
•Overall Dimension
NGETL 5-50 CE

Manual Instructions for Gas Economic Table Low
ORIENTAL 9
Figure 1:
Technical plate reports the current gas setting, Gas Economic Table Low nominal data, gases
table, categories, and pressures for other CE countries
TECHNICAL DATA PLATES
Fig
1

Manual Instructions for Gas Economic Table Low
ORIENTAL
10
Figure 2:
Technical Plate reports warnings in European languages and destined languages
Figure 3:
Technical plate reports warning and current setting on appliance packaging
Fig
2
Fig
3

Manual Instructions for Gas Economic Table Low
NAYATI
ORIENTAL
11
•Burner Components
COMPONENT LIST

Manual Instructions for Gas Economic Table Low
ORIENTAL
12
NO.
P / N
QTY
1
GS 4030
Burner Head NS 9000
1
GS 4023
Burner NS 9001
1
GS 4232
Burner Plug 3/8 x 1/4
1
2
GS 4357
Air Chamber Mixing Jumbo Burner
1
GS 4358
Air Cham
ber Plate Jumbo Burner
1
GS 2825
Air Chamber Bush 1 ½”
1
GS 2826
Air Chamber Pipe 1”
1
GS 2851
Fixing Bush 1 ¼”
1
3a
GS 283D
Nozzle
Jumbo Burner D
-
1 80 mm f/ G 30 / G 31 (28
-
30 mbar)
1
3b
GS 282E
Nozzle Jumbo Burner D
-
1 80 mm D
–
1,60 mm f/ G
30 / G 31 (50 mbar)
1
3c
GS 283E
Nozzle Jumbo Burner D
-
1 80 mm
D
–
3,05 mm f/ G
20 (20 mbar)
1
3d
GS 283F
Nozzle Jumbo Burner D
-
1 80 mm
D
–
3,15 mm f/ G
25 (25 mbar)
1
3f
GS 283G
Nozzle Jumbo Burner D
-
1 80 mm
D
–
3,30 mm f/ G
25 (20 mbar)
1
4
GS 387
B
Gas Valve w/ Clamp Pipe ¾” (Mod 21 S)
1
5
PD 4052 EA
Gas Knob dia 8mm (250C)
–
ArKn08 w/ dot marking
1
PD 4055IL
Ring label api model 1
-
ArKn
1
6
GS 3851
Bunsen Pilot 3F / 3H (3020006)
1
7
GS 3890
Thermocouple 9 x 1 1000 mm (P/N: 0200015)
1

Manual Instructions for Gas Economic Table Low
ORIENTAL
13
Very important!: Before installing, place the appliance on solid, flat, stable and horizontal surface
and connection availability
The following instructions are intended for authorized and qualified installer Before doing
installation, adjustment, and maintenance operations, the installer must follow local and legal
regulations Cut the electrical power before doing any installation
1 This appliance is using gas Gas services should be installed according to:
a Local and international standards
b Local recommendation, such as building standards and recommendation concern with
combustion
c Directions and regulations from the gas and power supply companies
d Regulation concern with prevention accident measures
2 Remove all packaging material and protective coatings
3 Ensure gas supply is sufficient to operate this appliance
4 Install the appliance by using Qualified Gas Filter
5 Before testing, put the appliance in a good ventilated room and keep all flammable material
away
6 Take a leakage test by using soapy water solution Spread the soapy solution on joints and pipe
fitting A leakage will be indicated by bubbles comes from the joints or pipefitting Another way
is by looking at the gas counter If there is no movement on the gas counter, it means no gas
leakage
7 Before cleaning or maintaining the appliance, please isolate gas supply to the safe place
8 Install the appliance by following Safe International Gas Standards
INSTALLATION (for the installer)

Manual Instructions for Gas Economic Table Low
ORIENTAL
14
9 If the appliance has not preset to the gas availability, you must convert it into another gas type
Authorized personnel must do this by referring to the technical data (primary air regulation and
nozzle table), changing the main burner and pilot burner nozzles Once this has been done, a
new rating data plate should be affixed to the new data by referring to the new gas type
•Position and Fixing
Authorized personnel must do the installation Install the appliance according to National
Safety Standard about gas-heated standard Place the appliance in good ventilated room with
permanent ventilation ducts to guarantee sufficient exchange of air and keep the work place
healthy If the Gas Economic Table Low not connected to a flue, it is recommended to install it
under efficient hood, which could evacuate burned gases and cooking steams Make sure that
any object around or under Gas Economic Table Low does not obstruct air volume required for
combustion Put away any flammable materials near Gas Economic Table Low When the
appliance is freestanding, keep a distance at least 20 cm from side, and 10 cm from rear walls
Especially when the appliance close to wall and does not protected with fire-resistant materials
made Install the appliance separately or side by side with other appliance according to
recommended range Put Gas Economic Table Low on solid, flat, and horizontal floor Adjust
the height of the four feet by using brackets Before turn the appliance ON, remove the
protective film Remove any adhesive with appropriate solvent Eliminate all packaging
material according to national laws
Warning !
NEVER USE FREE FLAME TO FIND GAS LEAKS!

Manual Instructions for Gas Economic Table Low
ORIENTAL
15
•Gas Supply Conne tion
-Before installing and connecting Gas Economic Table Low to gas supply, carefully
control the fixed part of gas system, which conformed to National Building
Regulation
-Verify gas pipes sections to guarantee sufficient supply for all gas heated
appliances Install it in similar condition to avoid excessive pressure drops
-The pipes must be made of steel (with junctions made using white cast iron, or
galvanized steel fittings, or autogenously welded joints) or copper pipes (with
mechanical joints and couplings without seals or mastics or brazed joints)
-Control the gas bottle (if any) placed correctly and protected in dry area
-Check whether the gas pipes can easily inspected If the pipes installed in floor
and wall, make sure that this work done according to professional standard with
reference points that make it possible to find the pipes
-Before installing Gas Economic Table Low, makes sure that it is set for the gas
and pressure (see Technical Data Plates) Consult the paragraph “Gas
Conversion”
-Connect Gas Economic Table Low to gas supply using solid fittings or flexible
steel pipes with suitable sections related to nominal power and length
-Check whether the flexible pipes does not pass or near hot surfaces, put under
stress and traction, contact with sharp edges, or other things that could damage
the pipe
-Install quick ON – OFF valve between the gas mains and each single appliance
where easy to reach
-After install Gas Economic Table Low safely, take a pressure test the whole gas
circuit by using leak finder spray or non-corrosive foams

Manual Instructions for Gas Economic Table Low
ORIENTAL
16
•Che king Gas Pressure and Nominal Heat Input (Fig. 2)
At the first installation, specialized technician must control Gas Economic Table Low nominal
heat input, maintenance, and gas conversion DO NOT improve Gas Economic Table Low
performance and increase nominal heat affirmed by the manufacturer Control heat input by
using gas counter and chronometer Measure the exact amount of gas flow per unit of time
which consumed by the appliance at maximum power Compare the measurement to the
consumption data on Data Technical Table 3, ± 5% tolerance is allowed When you are
measuring top deviations, carefully check the diameters and the quality of installed injectors
and gas main pressure If you want to measure the main pressure while Gas Economic Table
Low is ON and using a pressure gauge for liquids (for example U manometer, with minimum
resolution 0 1 mbar), please follow direction below:
1 Connect the flexible pipe “E” of the Manometer “M” to the inlet pressure point “C” after
unscrewing its cap
2 Measure the connection pressure: if the reading is not within the values given in the
following table, the appliance cannot work properly The gas company must be informed to
find out the supply pressure problems If necessary, install a pressure regulator
3 Once the connection pressure has been measured, disconnect flexible pipe “E”, retighten
the screw cap of the inlet pressure point “C” Restore the components inversely
Table 3:
Gas Type
Inlet pressure (mbar)
Normal
Minimal
Maximal
Natural gas G
20
20
18
25
Natural gas G
2
5
20
18
25
Liquid gas G
30/
G
31
30
28
37
Liquid gas G
30/
G
31
50
42 5
57 5

Manual Instructions for Gas Economic Table Low
ORIENTAL
17
•Primary Air Adjuster
The Primary Air is fixed and sealed by the factory according to the destined country and the gas
type The adjustment is attached on the packing and the type shield If there is any conversion, the
Primary gas adjustment must follow the data table below:
C
=
Inlet pr
essure point
D
=
Gas pipe
E
=
Flexible pipe
G
=
Inlet gas connection
M
=
Manometer
R
=
Gas tap
Fig 4

Manual Instructions for Gas Economic Table Low
ORIENTAL
18

Manual Instructions for Gas Economic Table Low
ORIENTAL
19
WARNING! After doing onversion please remember to:
•Atta h an indelible sti ker on te hni al data plate with the new installation data.
•Fix the new seals on the regulated parts (Primary Air Bush, Inje tor, and By-pass
s rew).
•Take pressure test of gas ir uit and he k for leaks.
•Properly ontrol Gas E onomi Table Low work a ording to these instru tions.
Please he k main burners’ ross-lighting, stability, and flame fa tor.
