NBE BRAWN MIXER BDAQC Series User manual

OPERATION
AND
MAINTENANCE
MANUAL
SERIAL NUMBER
___________________
CUSTOMER:____________________________
SALES REP.:____________________________
BDAQC SERIES
B941794160

– THIS PAGE IS INTENTIONALLY LEFT BLANK –

BDAQC-SERIES OPERATION & MAINTENANCE MANUAL
12838 Stainless Drive, Holland, MI 49424 Phone: [phone] Fax [phone]
Copyright 2018 BRAWN Mixer www.BRAWNMIXER.com Page 1 of 3
6/29/2018
CONTENTS
Mixer Installation / Assembly / Dimension Drawings
Safety ............................................................................ 1
Customer Service Contact ............................................1
Start-up.......................................................................... 2
Air Motors...................................................................... 2
Storage.......................................................................... 3
Warranty........................................................................ 3
SAFETY
The precautions mentioned in this manual are not
intended to cover all hazards that may exist in a plant or
on this equipment. Using safety mechanisms require the
constant attention of everyone in the vicinity of this (or
any) equipment.
A plant and the related equipment are only as safe as the
personnel are safety-minded. Proper equipment
maintenance and the use of personal safety devices will
contribute as much toward safety as will any number of
mechanical safety devices.
WARNING
To assure maximum safety, optimum performance,
and to gain knowledge of the product, it is essential
that you or any other operator of this equipment read
and understand the contents of this manual before
the mixer is operated.
Installation, operation and maintenance must be
performed only by qualified personnel.
Do not operate this equipment unless all safety
devices are installed and working properly. Check
all devices prior to starting the equipment.
Do not touch rotating parts (keep all guards and
safety devices installed while operating).
Develop a safety checklist for this equipment and
perform regular maintenance to ensure continued
and proper operation.
Do not make any field changes or modifications
without reviewing the change with your BRAWN
Sales Representative or the BRAWN Customer
Service Department.
CUSTOMER SERVICE
Mixer Model #.......................................BDAQC-SERIES
Contact:
Customer Service............................... 616/399-5600
E-Mail [e-mail]
You have received a quality engineered and
manufactured BRAWN mixer. We value your business,
and we will strive to provide you with the proper service
and equipment to meet your needs.
The information contained in this BRAWN Mixer
Operator's Manual is designed to assist you in putting
your BRAWN mixer into operation without further delay.
Please read the entire manual before attempting to
start your mixer. If you have any further questions or if,
by some chance, there are some missing components,
contact your BRAWN Mixer Representative or the factory
immediately.
We welcome your comments and suggestions
concerning any BRAWN Mixer product. Please direct
these comments in writing to the National Sales Manager
at BRAWN Mixer located in Holland, Michigan. To
expedite troubleshooting service, please make your initial
contact through your BRAWN Mixer Representative. If,
for whatever reason, your representative cannot be
reached and you have an emergency condition, please
call us directly at 616/399-5600 and ask for the
Customer Service Department.
Remember, you are backed by your BRAWN Mixer
Technical Representative and the factory support team.
We are here to assist you; let us know how we can be of
help.

BDAQC-SERIES OPERATION & MAINTENANCE MANUAL
12838 Stainless Drive, Holland, MI 49424 Phone: [phone] Fax [phone]
Copyright 2018 BRAWN Mixer www.BRAWNMIXER.com Page 2 of 3
6/29/2018
START UP
1. Before operating the mixer, jog the motor and
observe mixer shaft rotation. Proper rotation is
clockwise, as viewed from the top, unless otherwise
noted.
2. Check all bolts and fasteners for tightness. It is good
maintenance practice to recheck all bolts after two
weeks of operation and periodically thereafter. Refer
to TABLE 1 for recommended torque values.
TABLE 1: RECOMMENDED TORQUE VALUES
HARDWARE
SIZE
TORQUE VALUES (FOOT POUNDS)
STANDARD GRADE 2
& 300 SERIES
STAINLESS
HIGH STRENGTH
GRADES 5 & 8
5/16
9
13
3/8-16
17
27
1/2-13
40
65
5/8-11
85
125
BOLT-TIGHTENING RECOMMENDATIONS:
Inadequately or improperly tightened hardware can
loosen due to vibration during mixer operation. This can
result in reduced mixer life or damage to equipment.
Recommended torque values for tightening all in-tank
and mounting hardware are listed in TABLE 1. These
average torque values should be considered only as a
guide and not as absolute values.
3. Do not attempt to start mixer with impellers buried in
solids or solidified liquids.
CAUTION
Do not operate mixer with the tank empty or the lowest
impeller submerged with less than ½ of the impeller
diameter of liquid above it. Damage to the mixer and/or
mounting structure may result.
AIR MOTORS
Since your mixer was supplied with an air motor, certain
precautions must be taken as follows:
1. The mixer was shipped with a needle valve installed
on the motor outlet port. A muffler is provided for
installation at the needle valve (See Air Motor
Diagram). The function of the needle valve is to
control the motor speed.
2. The air supply must be adequately sized to provide
the proper pressure and volume of clean, filtered, dry
air. A pressure regulator is required prior to
connection to the needle valve. An air line filter
should be capable of 25 microns or better.
3. Blow out the air supply line before connecting to the
motor to remove any dirt or debris in the air line.
AIR MOTOR ROTATIONAL
DIRECTION DIAGRAM

BDAQC-SERIES OPERATION & MAINTENANCE MANUAL
12838 Stainless Drive, Holland, MI 49424 Phone: [phone] Fax [phone]
Copyright 2018 BRAWN Mixer www.BRAWNMIXER.com Page 3 of 3
6/29/2018
STORAGE
Units shipped from Brawn Mixer are intended to be used
within 30 days after receipt and presumed to be stored
indoors in a heated building. Store mixers as packaged
by the factory. If you intend on storing units under
adverse conditions or for a long period of time, special
storage precautions will be necessary.
1. Store in a sheltered area away from chemical vapors
or steam.
2. Cover.
3. Do not store in sunlight or near high heat.
4. Rotate output shaft 360º every 3-4 weeks.
5. Mixers should not be stored near vibrating machinery
to avoid damage to the bearings.
WARRANTY
WARRANTY: All equipment or parts covered by this
manual are guaranteed free from defective material and
workmanship for a period of twelve (12) months from
date of shipment, under normal use and service. This
warranty does not cover failure of normal wear parts
unless the failure of such part has resulted from
defective material and workmanship. BRAWN Mixer will
repair or replace, at its option, any equipment which has
been found to be defective and is within the warranty
period, provided that the equipment is shipped, with
previous factory authorization, freight prepaid, to
BRAWN's plant in Holland, Michigan, USA.
All return shipments are made FOB BRAWN's factory.
BRAWN is not responsible for removal, installation, or
any other incidental expenses incurred in shipping the
equipment to or from BRAWN. In the case of
components purchased by BRAWN Mixer and
incorporated in the equipment, the component
manufacturer's guarantee shall apply.
NOTE: Any modifications or corrective work done to the
equipment which were not specifically authorized in
writing by BRAWN Mixer shall void this limited warranty,
and BRAWN Mixer shall accept no liability for any of the
corrective work or expenditures which were conducted
without their prior, written authorization. BRAWN Mixer
shall not be held liable for any further cost, expense, or
labor to replace equipment or replaceable parts, or
indirect or consequential damages.
With the exceptions of the limited warranty set out
above, there are no other understandings, agreements,
representations, or warranties implied (including any
regarding the merchantability or fitness for a particular
purpose), not specified herein, respecting this agreement
or equipment, hereunder. This contract states the entire
obligation of BRAWN Mixer in connection with this
transaction.
SHOULD WE MAKE A MISTAKE...
BRAWN Mixer's
Direct Returns Policy
To ensure proper handling of your return, please take a
moment to read the following:
ALL returns require a RETURN GOODS
AUTHORIZATION (RGA) NUMBER. We are unable
to process your return or issue proper credit without
an approved RGA number.
ALL returns must be COMPLETE, including all
original warranties, manuals, documentation, and
packaging.
ALL product must be received within 14 days of
issuing an RGA number.
How to Return Product
You must have a RGA number before you return any
product to BRAWN Mixer To obtain this number, call
616/399-5600 and ask for Customer Service. Be sure to
have available the following information:
your order number
the BRAWN product serial number
the part number and description of the product
the reason for the return
♦I M P O R T A N T ♦
The RGA number must be written clearly on all boxes
being returned. C.O.D. shipments will not be accepted.

43
42
25
26
27
41
14
15
40
17
17
3
44
8
10
9
4
5
6
8
9
10
2
BSB
* ALL DIMENSIONS AND WEIGHTS ARE FOR REFERENCE ONLY
UNLESS THE DRAWING IS CERTIFIED.
* ALL EQUIPMENT DESIGN AND APPLICATION DATA SHOWN
HEREIN IS CONFIDENTIAL AND THE PROPERTY OF BRAWN MIXER.
NO USE OR DISCLOSURE THEREOF MAY BE MADE WITHOUT OUR
WRITTEN PERMISSION.
REV.
DWG.
NO.
A-
MIXER MODEL
DRAWN BY:
DATE:
12838 Stainless Drive
Holland, MI 49424
PH: 616-399-5600
FAX: [phone]
TK0162
BD/BGM HOUSING
9/6/2018
APPROVED BY:
DIMENSION AND ASSEMBLY DRAWING
©
DATE:
2018
EXPLODED VIEW

PARTS PRICING: BGM SERIES
3389 128th Avenue Phone: [phone]
Holland, MI 49424 USA Fax: [phone]
Item #
on Drawing # Description
TK0162 OR TK0163
2 O-Ring
4 Coupling hub
5 Sleeve
6 Coupling hub
Housing (painted) - shell only
Housing (with internals) - chuck coupling
Housing (with internals) - rigid coupling
8 Ball bearing
9 Snap ring
10 Ball bearing
13 Oil Seal
Chuck shaft 1" (1)CF
Chuck shaft 3/4" (1)CF
18 Ball mount
23 Shoe
19-24 Clamp assembly
25-28, and 40-43 Rigid flange coupling assembly
19-23, 29 Cup plate
32 Gearbox
35 [BGM(F)] Plate mount w/shock absorbers
38 [BD(F)] Angle riser
44 O-ring
(1) Consult Factory: provide serial number with request for quotation.
SPARE PARTS KIT
Shaded items = Recommended Spare Parts Kit
500121
10028602
Part Number
(1)CF
(1)CF
100695
500086
500079
500088
10033006
500075
5000803
10008602
10008501
10008603
10008801
500074
14
NOTES
7
10028601
(1)CF
(1)CF
(1)CF
100025
5000802
Copyright 2017 BRAWN Mixer
Page 2-2
03/15/2017

– THIS PAGE IS INTENTIONALLY LEFT BLANK –

– THIS PAGE IS INTENTIONALLY LEFT BLANK –

























