NEAT Electronics SMOKE User manual

SMOKE
User Manual
NE41 06004-02 v2.0

SMOKE User Manual NE41 06004-02 v2.02 of 16
Contents in an SMOKE kit
The list below shows the included parts in the package. If any part is missing or is
defect, please kontakt your reseller or distributor.
#Denominaon
①SMOKE with Adaptor board
②9V Li Baery
③This User Manual
We, NEAT Electronics AB, Varuvägen 2, 246 42 Löddeköpinge, SWE-
DEN, hereby declare under our sole responsibility that this product,
SMOKE, is in conformity with the direcves:1999/5/EC, 2006/95/EC,
2004/108/EC, 2002/95/EC and conforms to the following product
specicaons:
Safety EN 60950-1:2006+A11:2009
EMC EN 301 489-1 v1.8.1
Radio EN 300220-1 v2.1.1, EN 300220-2 v2.1.2
Ulrik Lundberg
Managing Director
© Copyright 2015 NEAT Electronics AB
Document number: NE41 06004-02 v2.0
Revision date: 2015-09-28
NEAT Electronics AB
Varuvägen 2
SE-246 42 Löddeköpinge
Sweden
Phone: +46 (0)46 70 70 65
Fax: +46 (0)46 70 70 87
www.neat-group.com/se/en
①② ③

SMOKE User Manual NE41 06004-02 v2.0 3 of 16
1 About SMOKE
SMOKE is a smoke detector with a radio adapter board and can be used
with all NEAT radio receivers and is inteded to be used in warden facilies
or in households.
This user manual is valid for SMOKE with ADAPTER board revision 2 or
later, see “2 Adapter board”.
When delivered SMOKE is congured by default to operate as Stand
Alone, see “5 Stand Alone mode”.
1
Picture 1. The SMOKE detector
#Denominaon
1SMOKE unit test buon (B1)
Table 1. SMOKE unit test buon placing
1.1 Mounng
The smoke detector must be mounted at the ceiling preferably in the
middle of the room. It can cover a room with maximum 60 m2 oor
surface and at most 6 m room height. The minimum distance from the
walls and other equipment (for instance light tubes and lamps) should be
0.5 m. In a hall way and narrow passages (up to 3 m wide) the detector
covers 7.5 m to each side.
1.2 Installing
Use the accompanying screws and plugs to mount the socket at the
ceiling. Connect the baery, ensure to get the correct polarity. Then
connect the smoke detector to the socket by turning to the right. There is
a disnct click when the detector part is locked to the socket.
SMOKE can not be installed unless the baery is mounted.

SMOKE User Manual NE41 06004-02 v2.04 of 16
1.3 Tesng
Aer a successful mounng the smoke detector should be tested. The
alarm signal is very loud and can be harmful to your hearing so please
keep a distance of at least 0.5 m when tesng.
Press the SMOKE test buon (B1), at least 2 s, the detector LED should
be blinking and a loud tone should sound. Then the smoke detector is
working properly.
If no alarm sound is heard, change the baery and push the test buon
again. If there is sll no alarm sound, the device is defect and has to be
replaced.
To test the link between units when units are in linked modes, keep the
test buon (B1) pressed at least 10 seconds.
2 Adapter board
The adapter board is equipped with a radio module and works with all
NEAT radio receivers.
1
23
Picture 2. PCB Outline of Adaptor board LINK
#Denominaon
1Adaptor PCB Board Revision
2Programming buon (S1)
3LED (D1)
Table 2. Adaptor board main items
The PCB board revision is read from the last digits, in this case the “R2” is
the current PCB revision.
The programming buon (S1) is used for operang the adaptor board.
The adaptor board can be in two states:
• Stand by (default)
• Programming

SMOKE User Manual NE41 06004-02 v2.0 5 of 16
2.1 Buon operaon
The programming buon (S1) is used for operang the adaptor board.
Aer each press type the LED (D1) responds with a light schedule to
indicate acon.
Press type Acon
1 short Manual radio transmission
1 long (3 s) Enter programming state
Double (i.e. 2 short) Indicate group mode
Table 3. Basic buon (S1) operaon
2.1.1 Manual Radio transmission
Pressing S1 shortly iniates a manual Radio Transmission. On the Master
and Slave in Indvidual group mode this is indicated with a short red LED
blink and when the unit recieves an ACK the LED blinks green.
On a Slave in Group mode there is no LED indicaon.
Unit mode LED indicaon response
Stand alone Short red blink (green ACK)
Group mode (master) Short red blink (green ACK)
Group mode (slave) No LED indicaon
Individual group mode Short red blink (green ACK)
Table 4. Basic buon S1 operaon LED indicaons
2.1.2 Enter programming mode
Press and hold S1 for more than 3 seconds to enter the Programming
state. The red LED starts blinking and the unit stays in this state for 30
seconds aer which it automacally returns to Stand by state.
The unit can be returned prematurely to Stand by state by pressing short-
ly on buon S1 when in Programming state.

SMOKE User Manual NE41 06004-02 v2.06 of 16
2.1.3 Indicate group mode
To indicate the unit’s Group mode, double press buon S1.
If the unit is in a Linked mode the green LED blinks either once or twice
to indicate the current Linked mode.
If the unit is Stand alone mode, the green LED blinks either one or twice
to indicate the current Linked mode, BUT followed by 10 rapid red LED
blinks.
Group mode Indvidual group mode
Stand alone 1 green, 10 red 2 green, 10 red
Linked mode 1 green 2 green
Table 5. Group mode LED indicaons
3 Operaon modes
The SMOKE operates in dierent modes, which is useful in dierent
environments.
Available operaon modes are:
• Stand alone (Mode 1), see ”5 Stand Alone mode”.
• Group mode (Mode 2), see ”7 Group mode”.
• Individual group mode (Mode 3), see ”6 Individual group mode (recom-
mended linked mode)”.
The operaon modes can be divided into two categories, Stand Alone
mode and Linked modes.
Individual group mode
Linked modes
Stand alone
Group mode
Picture 3. SMOKE operaon modes
By default SMOKE is congured as Stand Alone. The rst me SMOKE is
congured as a linked unit it automacally enters Individual group Mode.
When a linked unit is in either of the two linked modes, it’s possible to
toggle between the modes, see “9 Toggle between linked modes”.

SMOKE User Manual NE41 06004-02 v2.0 7 of 16
4 Adding a SMOKE to NEO
This is the recommended procedure for adding a SMOKE to a NEO.
1. Enter programming mode on NEO and select appropriate (rst availa-
ble) radio posion. (For more informaon about how to enter pro-
gramming mode in NEO, see corresponding NEO documentaon.)
2. Press the Programming buon (S2) on the adaptor board to acvate
the adaptor board.
3. Exit from programming mode in NEO and make a test alarm to the
alarm central by pressing the SMOKE test buon.
It is important that this procedure is followed since it transmits correct
alarm types to the alarm central when tesng.
All SMOKEs must be programmed to dierent radio posions.
5 Stand Alone mode
When a SMOKE is operang in Stand Alone mode, it operates as a single
unit with no interconnecon between other SMOKEs and communicates
directy with the radio receiver, e.g a Care Phone NEO or a portable
tranceiver TREX2G.
All alarms (user and technical alarms) are sent directly to the radio
receiver and handled individually.
neat
1
R
S
Picture 4. SMOKE in Stand Alone mode
#Denominaon
S SMOKE
RRadio Receiver (in this example a Care Phone NEO)
Table 6. Part denominaons in Stand alone mode

SMOKE User Manual NE41 06004-02 v2.08 of 16
If several SMOKE in Stand Alone mode are used and are to be connected
to the same radio receiver, each SMOKE must be added individually to
that radio receiver.
A SMOKE in Stand Alone mode will NOT listen to any radio transmissions.
This mode is the preferred mode when only one SMOKE is used, e.g. in a
single house hold.
5.1 Smoke alarm
In the event of re the SMOKE starts sounding with the acouscal indica-
on and the unit’s Test buon LED blinks red and a Smoke alarm is sent
to the radio receiver.
5.2 Low baery
The built in logic checks the baery level and sends a Baery low alarm
to the radio receiver well before the units starts to indicate by blinking its
red LED and sounding acouscally.
6 Individual group mode (recommended linked mode)
In Individual Group Link Mode all units communicates directly with the
radio receiver. Allthough all SMOKEs communicates directly with the
receiver R, one SMOKE must be set as Master.
• All SMOKEs must be added individually to the radio receiver
• Correct alarm type MUST be assigned for each added SMOKE in the
radio receiver
• All SMOKEs must be within radio range of the radio receiver.
The radio range between a SMOKE and the radio receiver R, can be ex-
tended with REPO and/or REPO+ (oponal accessories) but radio range
can NOT be extended between SMOKEs.

SMOKE User Manual NE41 06004-02 v2.0 9 of 16
neat
S1
S2
S3
R
Picture 5. SMOKE units in Individual Group mode
When smoke is detected, e.g. by S2, the slave sounds with the acous-
cal signal, the LED is ashing red and a smoke alarm is sent to the radio
receiver R (a Care Phone NEO). S1 and S3 also receives this smoke alarm
and starts sounding but without ashing its LED.
To reset a Smoke alarm, see “Reseng an alarm” on page 12.
To link the units, see “Linking/unlinking devices” on page 13.
6.1 Low baery
The built in logic checks the baery level and sends a Baery low alarm
to the radio receiver well before the units starts to indicate by blinking its
red LED and sounding acouscally.
7 Group mode
In Group mode, one SMOKE is set as Master and the other SMOKE
detectors are linked to this Master. This master is then connected to a
radio receiver, e.g. NEO or TREX2G.
In this mode only the Master is communicang directly with the radio
receiver and the slaves will work as repeaters for any other connected
SMOKE units in the installaon.
To link the units, see “Linking/unlinking devices” on page 13.
7.1 Installaon paerns
The linked units in Group mode can be installed in dierent paerns be-
cause the Slaves can act as repeaters for other SMOKE in the installaon
and these paerns are menoned Star paern or Chain paern.

SMOKE User Manual NE41 06004-02 v2.010 of 16
7.1.1 Star paern
In a typical setup the units are placed in a star paern, i.e. the Master is
in the center of the Slaves, see below.
neat
1
1
1
1
S1
S2
S3
R
M
Picture 6. SMOKE units in a Star paern setup
#Denominaon
M Master
S1 Slave
S2 Slave
S3 Slave
RRadio Receiver (in this example a Care Phone NEO)
Table 7. Part denominaons used in this user manual
In this conguraon all Slaves must be in radio range from the Master,
which in turn must be in radio range from the Radio receiver. Radio range
between the Master and receiver can be extended with REPO and/or
REPO+ (oponal accessory).
Example of star paern
Look at the setup in Picture 6; “SMOKE units in a Star paern setup”
above.
When smoke is detected, e.g. by Slave S2 the slave sounds with the
acouscal signal, the LED is ashing red and a smoke alarm is sent. This
smoke alarm is received by the Master Mand relayed to the radio receiv-
er R (a Care Phone NEO).
S1 and S3 also starts sounding but without ashing its LED.

SMOKE User Manual NE41 06004-02 v2.0 11 of 16
7.1.2 Chain paern
neat
S2 S1 M R
Picture 7. SMOKE in a Chain paern set up.
In this conguraon all units must be in radio range of each other, but it
is not neccesary that all Slaves are in radio range of the Master since the
Slaves relays radio messages to and from each other. Only the Master M
must be in radio range of the radio receiver R.
There is a 7 second delay between units when congured as a chain. This
means that a Smoke alarm sent from S2 takes approx. 21 seconds before
it reaches the Radio receiver.
Also here radio range between the Master and Receiver can be extended
with REPO and/or REPO+ (oponal accessory), see “7.1.1 Star paern” on
page 10.
Example of chain paern
Look at the setup in Picture 7; “SMOKE in a Chain paern set up.” above.
When smoke is detected, e.g. by Slave S2 the slave sounds with the
acouscal signal, the LED is ashing red and a smoke alarm is sent. This
smoke alarm is relayed to the radio receiver R (in this case a Care Phone
NEO) via Slave S1 and Master M. The slave S1 also receives this smoke
alarm and starts sounding but without ashing its LED.
7.2 Reseng alarms
To reset a Smoke alarm, see “Reseng an alarm” on page 12.
7.3 Low baery
The built in logic checks the baery level and sends a Baery low alarm
to the radio receiver well before the units starts to indicate by blinking its
red LED and sounding acouscally.

SMOKE User Manual NE41 06004-02 v2.012 of 16
8 Reseng an alarm
Smoke alarms can be reset on two levels and is done by pressing the
unit’s Test buon (B1). The levels are :
• Global reset, see below.
• Local mute, see below.
For both resets, the acouscal indicaon goes silent.
The originang unit automacally stop sounding and blinking and sends a
reset alarm when the units no longer detects smoke.
8.1 Global reset
A Global reset is done on the originang unit, i.e. the SMOKE unit where
the Smoke alarm originally was sent from and thus the unit sends out a
Reset Alarm which will be recived by all linked units.
A Global reset may take approx. 30 seconds to go through all the linked
units.
8.2 Local mute
A Local mute is done on a linked device (NOT the originang sender of
the Smoke alarm) and will only mute that parcular SMOKE unit. No
Reset alarm is sent and the unit will not listen to any incoming radio
transmissions for a period of 2 minutes.

SMOKE User Manual NE41 06004-02 v2.0 13 of 16
9 Toggle between linked modes
• Enter Programming state on the unit
• Press the Programming buon quickly three (3) mes
• The green LED indicates the new linked mode
• The unit returns to stand by mode
Mode Green LED Indicaon
Group mode (Mode 2) 1 blink
Individual group mode (mode 3) 2 blinks
If the unit is in Stand alone mode, the red green LED indicates mode
according to above (1 or 2 blinks depending on mode) and then ashes
rapidly 10 mes.
10 Linking/unlinking devices
When linking new devices, the unit automacally changes operaon
mode from Stand Alone to Group Mode. If Individual Group mode should
be used, each unit’s mode must be toggled manually, see “Toggle be-
tween linked modes” on page 13.
10.1 Linking devices
Linking devices requires one unit to be the Master, regardless of the
linked operaon mode.
• Open and place all devices on a table. Determine which unit should be
Master.
• Enter programming state on all devices.
• Press and hold the Master’s test buon for at least 7 seconds. The
Slaves receives data and conrms the recepon by lightning the green
LED for 5 seconds and then automacally returns to Stand by state.
10.2 Unlinking
When unlinking a device it returns to Stand Alone mode.
• Enter programming state
• Press the programming buon for 3 seconds.
• The Unliked unit ashes rapidly 8 mes and the goes into Stand by
state.
When unlinking the unit it automacally stores the last linked operaon
mode, so in the event of re-linking the unit, the last linked mode is used.

SMOKE User Manual NE41 06004-02 v2.014 of 16
11 Use and maintenance
11.1 Safety notes
• Read instrucons prior to use.
• Always test the system per instrucons prior to use.
• The product may not be suitable for all persons.
• Check device regularly and replace when necessary.
• Always check the funcon of the product aer making adjustments.
• Our units are NOT intended for any life support device, thus intending a
device whose malfuncon may result in damage to a life.
11.2 Use
• Use only original parts.
• Do not expose to direct sunlight.
• Keep away from dust, moist and dirt.
• Do not drop, knock, twist or shake the device.
• Do not warm up the device or use it near re.
• The SMOKE may not be painted.
• For repairs, contact a NEAT dealer.
11.3 Cleaning
• Clean the device with a so cloth, dampened slightly with mild soapy
water.
• Do not clean the device with harsh chemicals, solvents or other
corrosive substances.
11.4 Recycling
• Dispose of properly. The worn out product must be returned to a
recycling facility for proper disposal or returned to NEAT Electronics.

SMOKE User Manual NE41 06004-02 v2.0 15 of 16
Appendix A Technical data
Data Value
Measures with socket (Ø x H) 100 mm x 51 mm
Dimensions (W x H x D) 35 x 44 x 11 mm
Weight X g
RF Frequency 869.200-869.250 MHz (Social alarms)
RF FrequencyLink 868.2125 MHz
Baery life me Approx. 2 years
Baery 9V Lithium
Protecon (EN 60529) IP 43
Temperature range -10 C° to +60 C°
Detector principal Opcal scaering chamber
Alarm indicaon Opcal and acousc
Coverage 60 m2and <6 m in height
Acon indicaon Red LED
Signal tone >85 dB(A) @ 3 m
Sasfy regulaon ISO 12239
Drill hole distance 28 mm <> 56 mm
Case/colour ABS/White
Table 8. SMOKE technical data

NEAT Electronics AB
www.neat-group.com/se
Table of contents
