Nebula RGBW 4in1 User manual

1
USER MANUAL
RGBW 4in1
LED Moving Head Beam
Please Read Over This Manual Before Operating The Light Fixture

2
Contents
1. Foreword…………………………………………………3
2. Security indication……………………………………3
3. Operating provisions………………………………..4
4. Technical specification……………………………...5
5.Controller choose function…………………………6
6. LCD Panel indication………………………………….6
7. Using construction ……………….…………………..7
8. Connect multiple fixtures…………………………...8
9. Cleaning and Maintenance…………………………..8
10.Appendix……………………………………………….…9

3
Foreword
Thanks for you using The LED moving head light of our Guangzhou Nebula
Professional Stage Equipments Co., Ltd. Please read this product manual carefully before
using.
Anyone undertake the installation, operation and maintenance of light fixture, should be
as follow:
------- Required professional qualification & experience
------- Comply strictly with the instruction of this manual
------- Reserve this manual all the time when using light until it is no longer in use.
------- Completely record in this manual when light fixture has occur any change or
maintenance
When unpacking and before disposing of the carton, check there is no transportation
damage before using the projector. Should there be any damage caused by transportation,
consult your dealer and do not use the apparatus.
Security indications
Every unit is tested completely before leave the factory, and make sure it in good
condition to performance. In order to keep the light in best situation and safety using,
please read and comply with the Safe usage instruction & notice of this manual
Very important: If who non-compliance the safe indication of this manual, may cause
personal injuries & property damage. This loss no include in the range of quality assurance
If the light fixture has suffered fierce expand with heat and contract with cold (For
example, under insolate during transportation), do not turn on the current immediately,
because the water arising therefrom will damage the light. Should turn on light until it
recover the ambient temperature
This light belong to First-grade protective product, it must use First-grade protective
safe jack. Light fixture must be grounded reliably.
Do not connect this light with Dimmer.
Before turn on light, please check and make sure the supply power should not higher
the power which marks on the bottom panel; light power switch should turn to off; and

4
check the power cord whether distorted or damaged by sharper.
Do not let power cord touch other cord directly, and be careful when operate power
cord & all joints etc! Only can hold its joints when move power cord. Hold joints then draw
carefully from jack when need to cut power, and do not draw cord directly.
Light fixture may cause some fog or smell when turn on power first, that is a normal
condition which not denote it has quality problem.
During use the light, its housing will be heated and the part of light temperature is
high, that is a normal condition which should not touch it by hand to prevent injured.
Please choose the same type bulb & protective tube when they needed to replace.
Please turn off the light then removal power cord joints when light fixture is nonuse
or required maintenance.
At least use 2 safety ropes to install light (height almost 100cm), and ropes must be
able to carry tenfold weight of light.
Child & non-professional do not touch light fixture! Professional should watch over
light when it using.
This light could not maintained by user, except bulb & protective tube, repairing &
maintaining must follow authorized dealer.
If customer change light setting privately, or operate light by non-professional
privately, both may cause damage to light or injure yourself & property. Any damage
caused by improper use will not be assumed by the manufacturer.
Operating provisions
This LED moving head light is available for stage show, discotheque and other
amusement places. It use 200-240 V 50Hz current and only for indoor use.
Please familiar with its specification before operate the light fixture. Check the light
appearance & housing carefully, to confirm whether it install stability or screws tight or
not.
This light use Gas Discharge bulb, and do not turn on the current before install
suitable bulb.
Please do not shake the light fiercely when install or operate which should avoid
force.
When move the light, should raise its handle beside bottom to avoid strike other part.
Especially do not raise its head or rocker because improper operate will damage light.
The light should prevent to be exposing under too heat, wet or dust environment
during install, and do not lay too many cord around light, otherwise it may endanger

5
yourself or others.
Keep the distance at least 1 m between light and receiving surface.
Whatever install, uninstall or repair, please insure enclose the light bottom properly.
At lease use 2 safe cords and safe cord can not use the same lifting hole with light
hook.
Environment temperature can not higher 45°C, otherwise bulb will turn off and light
also stop work 5 minutes.
Not allow non-professional operate light because most of damage to light due to this
non-professional operate.
If light need shipment transport, please use original packing include box and
polystyrene.
Forbid to change any light setting with no authorization for security consideration.
Operate light in other way which different to this manual declaration, light may suffer
damage, and cause its quality invalidation. Even this may induce short circuit, burning or
shut down etc.
Technical specification
Feature
Lamp:10w(RGBW 4in1) 4pcs led high brightness lamp
Lifetime:6000 hours
Voltage:AC 90-220V, 50-60HZ
Rated power:80 watt
Channel:16/45 CH
Strobe:1-25hz
X/Y:540 270 with pan/tilt fine
Lens:8 degree
Dimmer:1-100% liner dimmer
IP 20
Mode:DMX 512,sound,auto,Mast-slave
Function:4 pieces mini led moving head with one，4 beam can be parallel。Every mini
led moving head can be sole controlled，XY，dimmer，strobe，XY speed。
NW：11 KGS
GW：14 KGS

6
Dimension：80*9*25 cm
Controller choose function 16channels
16channel
4 head beam bar CH16 mode channel list
channe
lfunction channel value description
CH1 total dimmer 0 fixture stop closing lighting and stop macro function
1-255 when 0,light brightness ratio control,0%~100%
CH2 choose light
0 All
51-100 Light 1
101-150 Light 2
151-200 Light 3
201-255 Light 4
CH3 X 0-255
CH4 Y 0-255
CH5 XY speed 0-255 XY speed adjustment,from fast to slow
CH6 R 0-255
CH7 G 0-255
CH8 B 0-255
CH9 W 0-255
CH10 strobe 0-3 no
4-255 strobe, from slow to fast
CH11 macro function
0-15 no
16-35 macro1_light flowing(jump change）(XY controllable)
36-55 macro2_light flowing(gradual change）(XY controllable)
56-75 macro3_light RGB gradual change(XY controllable)
76-95 macro4_light flowing+strobe(XY controllable)
96-115 macro5_macro 1~macro 4(XY controllable)
116-135 macro 6_XY auto 1(light controllable)
136-155 macro 7_XY auto 2(light controllable)
156-175 macro 8_XYauto 1+light
176-195 macro 9_XY auto 2+light
196-215 random auto
216-235 macro9 sound
236-255 random sound control
CH12 macro speed 0-255 macro function adjustment,from slow to fast

7
45channels
CH13 X fine 0-255
CH14 Y fine 0-255
CH15 dimmer speed 0-255 from slow to fast
CH16 reset 0-249 no effect
250-255 stay five second all motors reset
4 head beam bar CH45 mode channel list
channel function channel value description
CH1 X1 0-255
CH2 Y1 0-255
CH3 XY1 speed 0-255 XY speed, from fast to slow
CH4 strobe 1 0-3 no
4-255 strobe，from slow to fast
CH5 R1 0-255
CH6 G1 0-255
CH7 B1 0-255
CH8 W1 0-255
CH9 X2 0-255
CH10 Y2 0-255
CH11 XY2 speed 0-255 XY speed, from fast to slow
CH12 strobe 2 0-3 no
4-255 strobe，from slow to fast
CH13 R2 0-255
CH14 G2 0-255
CH15 B2 0-255
CH16 W2 0-255
CH17 X3 0-255
CH18 Y3 0-255
CH19 XY3 speed 0-255 XY speed, from fast to slow
CH20 strobe 3 0-3 no
4-255 strobe，from slow to fast
CH21 R3 0-255
CH22 G3 0-255
CH23 B3 0-255
CH24 W3 0-255
CH25 X4 0-255

8
CH26 Y4 0-255
CH27 XY4 speed 0-255 XY speed, from fast to slow
CH28 strobe 4 0-3 no
4-255 strobe，from slow to fast
CH29 R4 0-255
CH30 G4 0-255
CH31 B4 0-255
CH32 W4 0-255
CH33 X1 fine 0-255
CH34 Y1 fine 0-255
CH35 X2 fine 0-255
CH36 Y2 fine 0-255
CH37 X3 fine 0-255
CH38 Y3 fine 0-255
CH39 X4 fine 0-255
CH40 Y4 fine 0-255
CH41 total dimmer
0fixture stop closing lighting and stop macro
function
1-255 when 0,light brightness ratio
control,0%~100%
CH42 dimmer speed 0-255 from slow to fast
CH43 macro function
0-15 no
16-35
macro1_light flowing(jump change）(XY
controllable)
36-55
macro2_light flowing(gradual change）(XY
controllable)
56-75 macro3_light RGB gradual change(XY
controllable)
76-95 macro4_light flowing+strobe(XY controllable)
96-115 macro5_macro 1~macro 4(XY controllable)
116-135 macro 6_XY auto 1(light controllable)
136-155 macro 7_XY auto 2(light controllable)
156-175 macro 8_XY auto 1+light
176-195 macro 9_XY auto 2+light
196-215 random auto
216-235 macro9 sound
236-255 random sound control
CH44 macro function speed 0-255 macro function adjustment,from slow to fast
CH45 reset 0-249 no effect
250-255 stay five second all motors reset

9
Using construction
first Menu second Menu value remark
d.001(DMX address) 1-512
MANU
P.000(Pan) 0-255
overall
T.000(Tilt) 0-255
R.000(Red) 0-255
G.000(Green) 0-255
B.000(Blue) 0-255
W.000(White) 0-255
S.000(Strobe) 0-255
AUTO
At.50 0-99
built-in program auto，0-99
speed fast to slow
rd.50 0-99
random auto，0-99 speed fast
to slow
SOUD
At.
built in program，one sound
beat one step
rd. random，one sound beat one
step
SET
CH.16 16/45 channel mode choice
EC.On off/on coding wheel
rP.of off/on pan reverse
rt.of off/on tilt reverse
CAL(reset adjustment)
P1.50 0-99
50 means no fine
t1.50 0-99
P2.50 0-99
t2.50 0-99
P3.50 0-99
t3.50 0-99
P4.50 0-99
t4.50 0-99
Sen(coding wheel
monitoring)
P1.00 99.-99
show the 2 bit LSB of coding
wheel reading，Measuring
range is（-65535，65535），
show value range is（-99，
99），“99.”means -99. if Y
decided by Hall, then shows
t1.01 or t1.00,"01" means
t1.00 99.-99
P2.00 99.-99
t2.00 99.-99
P3.00 99.-99
t3.00 99.-99
P4.00 99.-99

10
detected magnetism，
"00"means not detected
magnetism
t4.00 99.-99
Connect multiple fixtures
Note: Avoid twisted cables, especial the signal wire and power wire, either close to each
other. Otherwise, the projector may not work normally
Connect multiple fixtures with 3 round pin/XLR plug of shielded signal, or directly connect
to DMX512 controller.
XLR plug and socket: this projector has a 3 round pin/XLR socket, 3 round pin/XLR plug of
shielded signal can be used when it connects. If the controller has the same 3 round
pin/XLR socket, you can connect the DMX signal output of controller to DMX signal input of
projector with distributive signal cables. If the controller have other output/input sockets.
for example,5 round/XLR socket, you must need to buy or make adapter cable. As follow
Master-slave synchronic chain/DMX512 Chain: connect the first fixture’s DMX output
cable to the second fixture’s DMX input cable with a signal cable, connect the second
fixture’s DMX output cable to the third fixture’s DMX input cable, eventually, and connect
the last fixture’s output cable. if connect the first DMX512 controller to the first projector’s
DMX input, then will form a DMX512 chain, if the first projector doesn’t connect with any
DMX controller, then it will can be the master, also, all the projectors are the master, then
there will be a master-slave synchronic chain.
Note! The last fixture, DMX output should connect with a signal plug, there is a 1200OM
resistor between the second and the third pin of 3 round pin/XLR socket, and it will form
a signal plug.
1. DMX initial address settings
Control panel which on the base of the projector is used for operating this projector,
including DMX 512 initial address setting and so on. this address is the first channel of the
DMX512 controller
There are 16 channels, if the initial address is the first channel, then the projector should
use the 1st channel to 16th channel, and the first channel of the second projector should be
17th channel. Avoid repeatedly, make sure each projector independently and accurately
control
With the same initial address of projectors, keep in synchronism
Initial address settings as follow:
---press< ESC> until there is （A001）or (AXXX) on the display
---press<ENTER>, A will be disappear
---press on or down, choose what initial address you want.
---press <ENTER> to save what your choose, if not, press < ESC>

11
Cleaning and Maintenance
Note should cut off the power before to clean and maintaining of the projector. Do not
use the projector if the lens is damaged, such as crack or scratch and so on, make sure
to keep its normal functions
Users should keep taking a full testing for the light security & installation every year by
an empirical person and each four years by the specialist.
When make the testing, should consider the following:
1. the screws, bolts of this projector should be locked, and not corrupted
2. Should not any deformation at the case. Fixing or installation’s joining(including the
ceiling ,lantern support and so on)
3. The accessory of mechanical such as axle, rocker must not allow to be wearing, and
also no unbalanced rotation.
4. the power cable should not be damaged, cracked and so on, if so, should change a new
one
The lens and fan should be cleaned one time each month, to make sure its function
Gobo flat, gobo wheel should be cleaned one time each month by soft brush
Soft cloth and typical glass cleaning products should be used for cleaning, do not use
any organic solvent, e.g. alcohol.
To keep the rotation smoothly, suggest putting some lubricating oil to gobo wheel each
three months, the quantity of lubricating oil should be less, avoid spilling over.
Color wheel, color flat, and the inter lens of the projector should be cleaned one time
each month
There are not user serviceable parts inside the projector except the lamp and fuse.
Pls uses the same model and standards fuse when replace it
Only the authorized distributor can maintain and service the projector
If in need of any accessories, pls get it from the original factory.
Please ask advice in case of doubts

12
Appendix
Technical specification
Weight and size
Length---------------------------------------------------------------------------800mm
Width----------------------------------------------------------------------------200mm
Height---------------------------------------------------------------------------250mm
Weight------------------------------------------------------------------------------11.5kg
Power
Voltage------------------------------------------------------------100V/240V 50/60HZ
Power Consumption---------------------------------------------------------------80W
Lamp
LED------------------------------------------------------------------------10W RGBW 4in1 led
Color temperature----------------------------------------------------------------6500K
Illumination
Degree -------------------------------------------------------------------------------8°
Range
Pan-----------------------------------------------------------------------------------540°
Tilt------------------------------------------------------------------------------------210°
Heat
Max temperature--------------------------------------------------------------------40°C
Control and program
Data input-------------------------------------------------------------3-pin XLR (anode)
Data output----------------------------------------------------------3-pin XLR (cathode)
DMX channels-----------------------------------------------------------------------16/45
Warranty -----------------------------------------------------------------------one year
