NEC E222W - MultiSync - 22" LCD Monitor User manual

www.necdisplay.com
Business Desktop
Elevate the eco-friendliness of your work environment. The 22” NEC MultiSync E222W
widescreen LCD display raises the standard for “green” LCD displays, featuring a
handful of components that lower total cost of ownership by saving energy, tracking
carbon footprint emissions and minimizing packaging. In addition, this model boasts
outstanding screen performance and advanced display technologies to optimize your
desktop computing experience.
It’s easy to be green. The MultiSync E222W is loaded with features that promote
environmental consciousness, including: a panel that consumes 50% less power and
contains half the amount of mercury compared to traditional LCD monitors; ECO
Mode™, Intelligent Power Manager (IPM) and an off timer for further energy savings;
a carbon footprint meter for tracking the conservation of green gas emissions;
construction using ecological materials such as recycled plastics; and a significant
reduction in packaging materials.
A new perspective on productivity. This display’s wide-format screen provides
roughly the same work area as two smaller-sized LCD screens, allowing you to work
simultaneously in multiple/side-by-side application windows.
Enhanced screen performance. With contrast ratios up to 1000:1 (typical) and brightness
quality of up to 250 cd/m2, outstanding LCD monitor front-of-screen visual performance
is NEC Display Solutions’ #1 goal. Rapid ResponseTM technology provides for lifelike full-
motion video display without distortion at a response time as quick as 5ms.
Wide compatibility for today and tomorrow. With Ambix® dual-input technology–
which utilizes both DVI-D and traditional 15-pin VGA connectors–you can bridge
the gap between analog and digital systems by allowing the same monitor to work seamlessly in either environment. Ambix provides
compatibility with today’s computer systems and is on the forefront of tomorrow’s digital output.
NEC MultiSync®E222W
Eco-friendly, desktop LCD ideal for corporate environments
Features & Benefits
ErgoDesign® with 4-way adjustable stand (110mm
height-adjust, pivot, tilt and swivel) adds flexibility
and comfort to your viewing preferences
ECO Mode helps save power, reduce heat and
extend the life of the display by allowing the user to
dim the backlight
Intelligent Power Manager (IPM) system and off
timer provide innovative power-saving methods and
reduce CO2emissions by shifting to a lower power
consumption level or automatically powering down
when the monitor is on but not in use
Carbon footprint meter helps track and calculate
the conservation of green gas emissions via OSD®
and NaViSet™Administrator
5-setting Dynamic Video Mode enhances video and
images with real-time optimization of brightness,
color and contrast
Built-in, multi-directional NaViKeyTM allows for
easy screen setting adjustments
Compact packaging helps reduce paper usage,
shipping costs and waste
EPEAT Silver compliance ensures the displays
reduce hazardous waste and electricity usage,
resulting in lower energy costs and increased
protection for the environment
ENERGY STAR 5.0 compliance reduces electrical
costs and lowers total cost of ownership
Rapid Response technology delivers virtually
uninterrupted, undistorted viewing of high-speed,
full-motion video
Ambix dual-input technology allows for digital/
analog compatibility with upgraded video cards
and software as well as connection to two systems
XtraView® technology provides for some of the
widest viewing angles available
NEC Display Solutions’ quality and reliability
provide peace of mind with a 3-year limited parts
and labor warranty (including backlight) and
unrivaled customer service and technical support

NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
Ambix, ErgoDesign, MultiSync and XtraView are registered
trademarks and ECO Mode, NaViKey and Rapid Response are
trademarks of NEC Display Solutions. All other brand or product
names are trademarks or registered trademarks of their respective
holders. Product specifications subject to change. 5/09 ver. 1.
©2009 NEC Display Solutions of America, Inc. All rights
reserved.
Model
Display
Viewable Image Size
Aspect Ratio
Pixel Pitch
Pixels Per Inch
Brightness (typical)
Contrast Ratio (typical)
Viewing Angle (typical)
Response Time (typical)
Display Colors
Synchronization Range
Horizontal
Vertical
Input Signal
Video
Sync
Inputs
Resolutions Supported
(Analog/Digital)
Native Resolution
Additional Features
Voltage Rating
Power Consumption
Typical
Power Savings Mode
ECO Mode ON
Dimensions (W x H x D)
Net (with stand)
Net (without stand)
Weight
Net (with stand)
Net (without stand)
VESA Hole Configuration
Specifications
Environmental Conditions
Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude
Limited Warranty
Technical Support
The MultiSync E222W features pivot
(A) capabilities and a height-adjustable
stand (up to 110mm) (B), allowing you
to create an ideal ergonomic display
orientation for maximum viewing
comfort. A built-in, recessed handle
(C) also makes the displays easily
transportable.
B
C
MultiSync E222W
22”
16:10
0.282mm
90 @ native resolution
250 cd/m2
1000:1
178° Vert., 178° Hor. (89U/89D/89L/89R) (CR>5)
Rapid Response (5ms)
More than 16.7million
31.5-82.3 KHz (Analog/ Digital)
56-75Hz (Analog/Digital)
Analog 0.7 Vp-p / 75 Ohms
Separate Sync: TTL Level (positive/negative)
DVI-D and VGA 15-pin D-Sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 75 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60-75 Hz
1280 x 1024 @ 60-75 Hz
1360 x 768 @ 60 Hz
1440 x 900 @ 60-75 Hz
1440 x 1050 @ 60-70 Hz
1680 x 1050 @ 60 Hz
1680 x 1050 @ 60 Hz
Thin-frame (bezel), widescreen format, carrying handle, NaViKey, height-adjustable stand (110mm), pivot,
tilt, swivel, No Touch Auto Adjust, cable management, AccuColor color control, digital smoothing, digital
controls, DDC/CI, NaViSet software, Plug and Play (VESA DDC 1/2B), VESA DPMS power management, OSD
user controls, ISO 13406-2 Class II, Windows Vista Premium-certified, Dynamic Video Mode, HDCP, ECO
Mode, carbon meter, EPEAT Silver, ENERGY STAR 5.0, TCO 5.0, RoHs compliancy
AC 100-120V / AC 220-240V
26W
0.5W
21W
20 x 15.1-19.5 x 8.4 in. / 507.8 x 384.5-494.5 x 213.9mm
20 x 13.1 x 2.8 in. / 507.8 x 332.1 x 71.8mm
15 lbs. / 6.8 kg
10.6 lbs. / 4.8 kg
100 x 100mm
5-35°C / 41-95°F
20-80%
2000m / 6562 ft.
-10-60°C / 14-140°F
10-85%
12,192m / 40,000 ft.
3 years parts and labor, including backlight
M - F (7am - 7pm CST)
A
