Business Desktop
Taking care of business never looked so stylish. With its NEC MultiSync 5 Series, which boasts
cutting-edge technologies and dynamic design accents, NEC Display Solutions gives you the abil-
ity to increase your productivity with monitors that add a modern flair to your desktop. The series
includes the feature-rich 17” NEC MultiSync LCD175VX+ and 19” NEC MultiSync LCD195VX+,
and the speaker-integrated 17” NEC MultiSync LCD175VXM+. The widescreen 19” NEC MultiSync
LCD195WXM, 20” NEC MultiSync LCD205WXM and 22” NEC MultiSync LCD225WXM not only
tout speakers but provide a work area significantly larger than standard aspect ratio screens, allow-
ing you to work simultaneously in multiple/side-by-side application windows.
Enhanced screen performance. With contrast ratios as high as 1000:1 (typical) and brightness qual-
ity up to 300 cd/m2, outstanding LCD monitor front-of-screen visual performance is NEC Display
Solutions’ #1 goal. Rapid ResponseTM technology provides for lifelike full-motion video display
without distortion at response times as swift as 5ms.
Wide compatibility for today and tomorrow. With Ambix® dual-input technology–which utilizes both
DVI-D and traditional 15-pin VGA connectors–you can bridge the gap between analog and digital
systems by allowing the same monitor to work seamlessly in either environment. Ambix provides
compatibility with today’s computer systems and is on the forefront of tomorrow’s digital output.
NEC MultiSync®5 Series
17" - 22" LCDs ideal for corporate environments Series Features & Benefits
Exceptional screen performance provides a more
comfortable and productive visual experience
with crisp, sharp and accurate text and images
Height-adjustable stand adds flexibility and
comfort to your viewing preferences
Swivel capability creates more viewing options
for your desktop (LCD195WXM, LCD205WXM,
LCD225WXM)
Wide-format screen increases productivity by
expanding your working area for multiple
application windows (LCD195WXM,
LCD205WXM, LCD225WXM)
Rapid Response technology delivers virtually
uninterrupted, undistorted viewing of high-
speed, full-motion video
Ambix dual-input technology allows for digi-
tal/analog compatibility with upgraded video
cards and software as well as connection to
two systems
Built-in multimedia speakers provide quality
sound (LCD175VXM+, LCD195WXM,
LCD205WXM, LCD225WXM)
XtraView® technology provides for some of the
widest viewing angles available
Built-in power supply allows for easy mounting
of the display
No Touch Auto AdjustTM reduces setup time
and provides optimal image settings upon
initial power-on
NaViSetTM software offers an expanded and
intuitive interface, allowing you to more easily
adjust display settings via mouse and keyboard
Wall/arm mounting capability adds flexibility
and comfort, while freeing up valuable desktop
space (using third-party product)
Adheres to ISO 13406-2 Class II requirements
for quality screen performance
RoHS compliance ensures the displays are free
of hex-chrome, cadmium, PBDE and PBB, with
reduced mercury and lead
ENERGY STAR 4.0 compliance/low power
consumption reduces electrical costs and low-
ers total cost of ownership
NEC Display Solutions’ quality and reliability
provide peace of mind with a 3-year limited
parts and labor warranty (including backlight)
and 24/7 customer service and technical support
The built-in speakers (pictured at left) of the LCD175VXM+ and widescreen
models boost the senses with amazing sound during presenta-
tions or other display applications. Integrated into the bottom
of the cabinet, the speakers add multimedia excitement to
the desktop computing experience without adding bulk to
the display’s design. The height-adjustable stand (pictured
at right) and tilt function bring the display to your preferred
comfort level, while the swivel capability (available on widescreen models) cre-
ates new viewing options on your desktop.
Featuring
height-adjustable &
swivel stands and
touch integration
capabilities

NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
Ambix, MultiSync, OSD and XtraView are registered trademarks
and NaViSet, No Touch Auto Adjust and Rapid Response are
trademarks of NEC Display Solutions. All other brand or product
names are trademarks or registered trademarks of their respec-
tive holders. Product specifications subject to change.
©2007 NEC Display Solutions of America, Inc. All rights
reserved. 06/07 ver. 4.
MultiSync LCD225WXM
22”
0.282mm
90 @ native resolution
300 cd/m2
1000:1
176° Vert., 176° Hor.
(88U/88D/88L/88R) (CR>5)
Rapid Response (5ms)
More than 16 million
31.5-81.1 kHz
(Analog/Digital)
56-76 Hz
Analog 0.7 Vp-p / 75 Ohms
Separate Sync: TTL Level
(positive/negative)
DVI-D and VGA 15 pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 75 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60-75 Hz
1280 x 1024 @ 60-75 Hz
1360 x 768 @ 60-75 Hz
1440 x 900 @ 60-75 Hz
1400 x 1050 @ 60-75 Hz
1680 x 1050 @ 60 Hz
1680 x 1050 @ 60 Hz
Thin-frame (bezel), wide-
screen format, integrated
speakers, height-adjust-
able stand, tilt, swivel, No
Touch Auto Adjust, cable
management, touchscreen-
compatible, AccuColor color
control, digital smoothing,
digital controls, DDC/CI,
NaViSet software, Plug and
Play (VESA DDC 1/2B), VESA
DPMS power management,
OSM user controls, ISO
13406-2 Class II, Windows
Vista-certified
Designed for integration
AC 100-120V / AC 220-240V
45W
2W
19.9 x 15.1-17.1 x 10.2 in. /
505.7 x 384.6-434.6 x 260mm
19.9 x 13.5 x 3 in. /
505.7 x 344.1 x 76.7mm
18.7 lbs. / 8.5 kg
13.9 lbs. / 6.3 kg
100 x 100mm
5-35°C / 41-95°F
10-80%
3048m / 10,000 ft.
-10-60°C / 14-140°F
10-85%
12,192m / 40,000 ft.
3 years parts and labor,
including backlight
24 hours / 7 days
MultiSync LCD205WXM
20”
0.258mm
98 @ native resolution
300 cd/m2
1000:1
170° Vert., 170° Hor.
(85U/85D/85L/85R) (CR>5)
Rapid Response (5ms)
More than 16 million
31.5-81.1 kHz
(Analog/Digital)
56-75 Hz
Analog 0.7 Vp-p / 75 Ohms
Separate Sync: TTL Level
(positive/negative)
DVI-D and VGA 15 pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 75 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60-75 Hz
1280 x 1024 @ 60-75 Hz
1360 x 768 @ 60-75 Hz
1440 x 900 @ 60-75 Hz
1400 x 1050 @ 60-75 Hz
1680 x 1050 @ 60 Hz
1680 x 1050 @ 60 Hz
Thin-frame (bezel), wide-
screen format, integrated
speakers, height-adjust-
able stand, tilt, swivel, No
Touch Auto Adjust, cable
management, touchscreen-
compatible, AccuColor color
control, digital smoothing,
digital controls, DDC/CI,
NaViSet software, Plug and
Play (VESA DDC 1/2B), VESA
DPMS power management,
OSM user controls, ISO
13406-2 Class II, Windows
Vista-certified
Designed for integration
AC 100-120V / AC 220-240V
45W
2W
18.6 x 14.2-16.2 x 10.2 in. /
471.4 x 360.9-410.9 x 260mm
18.6 x 12.6 x 3.1 in. /
471.4 x 320.4 x 80mm
16.1 lbs. / 7.3 kg
12.8 lbs. / 5.8 kg
100 x 100mm
5-35°C / 41-95°F
10-80%
3048m / 10,000 ft.
-10-60°C / 14-140°F
10-85%
12,192m / 40,000 ft.
3 years parts and labor,
including backlight
24 hours / 7 days
MultiSync LCD175VX+/M+*
17”
0.264mm
96 @ native resolution
270 cd/m2
600:1
170° Vert., 170° Hor.
(85U/85D/85L/85R) (CR>5)
Rapid Response (5ms)
More than 16 million
31.5-81.1 kHz
(Analog/Digital)
56-76 Hz
Analog 0.7 Vp-p / 75 Ohms
Separate Sync: TTL Level
(positive/negative)
DVI-D and VGA 15 pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 70-75 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60-75 Hz
1280 x 1024 @ 60-75 Hz
1280 x 1024 @ 60 Hz
Thin-frame (bezel), height-
adjustable stand, tilt, No
Touch Auto Adjust, cable
management, touchscreen-
compatible, AccuColor color
control, digital smoothing,
digital controls, DDC/CI,
NaViSet software, Plug and
Play (VESA DDC 1/2B), VESA
DPMS power management,
OSD user controls, ISO
13406-2 Class II, Windows
Vista-certified
Designed for integration
AC 100-120V / AC 220-240V
30W
2W
14.5 x 14.1-16.1 x 9.1 in. /
368 x 358.5-408.5 x 230mm
14.5 x 12.6 x 2.4 in. /
368 x 320.5 x 61mm
10.6 lbs. /4.8 kg
8.4 lbs. /3.8 kg
100 x 100mm
5-35°C / 41-95°F
10-80%
3048m / 10,000 ft.
-10-60°C / 14-140°F
10-85%
12,192m / 40,000 ft.
3 years parts and labor,
including backlight
24 hours / 7 days
MultiSync LCD195VX+
19”
0.294mm
86 @ native resolution
270 cd/m2
600:1
170° Vert., 170° Hor.
(85U/85D/85L/85R) (CR>5)
Rapid Response (5ms)
More than 16 million
31.5-81.1 kHz (Analog/
Digital)
56-76 Hz
Analog 0.7 Vp-p / 75 Ohms
Separate Sync: TTL Level
(positive/negative)
DVI-D and VGA 15 pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 70-75 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60-75 Hz
1280 x 1024 @ 60-75 Hz
1280 x 1024 @ 60 Hz
Thin-frame (bezel), height-
adjustable stand, tilt, No
Touch Auto Adjust, cable
management, touchscreen-
compatible, AccuColor color
control, digital smoothing,
digital controls, DDC/CI,
NaViSet software, Plug and
Play (VESA DDC 1/2B), VESA
DPMS power management,
OSD user controls, ISO
13406-2 Class II, Windows
Vista-certified
Designed for integration
AC 100-120V / AC 220-240V
37W
2W
16 x 15.2-17.2 x 9.4 in. /
405.5 x 385.8-435.8 x 240mm
16 x 13.6 x 2.6 in. /
405.5 x 345.5 x 66.5mm
13.2 lbs. /6 kg
11 lbs. /5 kg
100 x 100mm
5-35°C / 41-95°F
10-80%
3048m / 10,000 ft.
-10-60°C / 14-140°F
10-85%
12,192m / 40,000 ft.
3 years parts and labor,
including backlight
24 hours / 7 days
MultiSync LCD195WXM
19”
0.284mm
89 @ native resolution
300 cd/m2
700:1
160° Vert., 170° Hor.
(85U/75D/85L/85R) (CR>5)
Rapid Response (5ms)
More than 16 million
31.5-81.1 kHz
(Analog/Digital)
56-76 Hz
Analog 0.7 Vp-p / 75 Ohms
Separate Sync: TTL Level
(positive/negative)
DVI-D and VGA 15 pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-76 Hz
1152 x 864 @ 60-75 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60-75 Hz
1280 x 1024 @ 60-76 Hz
1360 x 768 @ 60-75 Hz
1440 x 900 @ 60-75 Hz
1440 x 900 @ 60 Hz
Thin-frame (bezel), wide-
screen format, integrated
speakers, height-adjust-
able stand, tilt, swivel, No
Touch Auto Adjust, cable
management, touchscreen-
compatible, AccuColor color
control, digital smoothing,
digital controls, DDC/CI,
NaViSet software, Plug and
Play (VESA DDC 1/2B),
VESA DPMS power manage-
ment, OSM user controls, ISO
13406-2 Class II, Windows
Vista-certified
Designed for integration
AC 100-120V / AC 220-240V
42W
2W
17.3 x 13.4-15.4 x 9.4 in. /
440 x 340-390 x 240mm
17.3 x 11.9 x 2.6 in. /
440 x 302 x 65.5mm
12.8 lbs. /5.8 kg
10.1 lbs. /4.6 kg
100 x 100mm
5-35°C / 41-95°F
10-80%
3048m / 10,000 ft.
-10-60°C / 14-140°F
10-85%
12,192m / 40,000 ft.
3 years parts and labor,
including backlight
24 hours / 7 days
Model
Display
Viewable Image Size
Pixel Pitch
Pixels Per Inch
Brightness (typical)
Contrast Ratio (typical)
Viewing Angle (typical)
Response Time (typical)
Display Colors
Synchronization Range
Horizontal
Vertical
Input Signal
Video
Sync
Inputs
Resolutions Supported
Native Resolution
Additional Features
Touch-Capable
Voltage Rating
Power Consumption (typical)
On
Power Savings Mode
Dimensions (W x H x D)
Net (with stand)
Net (without stand)
Weight
Net (with stand)
Net (without stand)
VESA Hole Configuration
Specifications
Environmental Conditions
Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude
Limited Warranty
Technical Support
* Aside from integrated speakers, LCD175VXM+ specs are identical to those of the LCD175VX+
