MultiSync XV17+
User’s Manual

Declaration of the Importer
We hereby certify that the color monitors
MultiSync XV17+ JC-1745UMB
are in compliance with
Council Directive 73/23/EEC:
- EN 60950
Council Directive 89/336/EEC:
- EN 55022
- EN 60555-2
- EN 60555-3
- EN 50082-1
(IEC 801-2)
(IEC 801-3)
(IEC 801-4)
and marked with
NEC Europe Ltd. Ismaning Office
Steinheilstraße 4-6
D-85737 Ismaning, Germany

Safety Instruction
Caution:
When operating the JC-1745UMB with a 220-240V AC power source
in Europe except UK, use the power cord provided with the monitor.
In UK, a BS approved power cord with moulded plug has a Black (five
Amps) fuse installed for use with this equipment. If a power cord is not
supplied with this equipment please contact your supplier.
When operating the JC-1745UMR with a 220-240V AC Power source
in Australia, use the power cord provided with the monitor.
For all other cases, use a power cord that matches the AC voltage of the
power outlet and has been approved by and complies with the safety
standard of your particular country.
IBM PC/XT/AT, PS/2, MCGA, VGA, 8514/A and XGA are registered trademarks of
International Business Machines Corporation.
Apple and Macintosh are registered trademarks of Apple Computer Inc.
Microsoft and Windows are registered trademarks of the Microsoft Corporation.
NEC is a registered trademark of NEC Corporation. ErgoDesign, IPM, OSM, ColorControl,
OptiClear, CROMACLEAR and Advanced Digital Control System are trademarks of NEC Home
Electronics, Ltd.
MultiSync is a registered trademark of NEC Technologies, Inc in U.S., and of NEC Home
Electronics, Ltd in Canada, U.K., Germany, France, Spain, Italy, Austria, Benelux,
Switzerland, Denmark, Finland, Norway and Saudi Arabia.
All other trademarks or registered trademarks are property of their respective owners.

English
Deutsch
Français
Italiano
Español
Appendix

English

Introduction
Congratulations on your purchase of the MultiSync XV17+ colour
Monitor!
The MultiSync XV17+ monitor includes Microsoft’s Plug and Play,
NEC’s ErgoDesign properties, the On Screen Manager (OSM), as well
as all the unique features you expect from MultiSync Monitors.
The MultiSync technology provides you with automatic compatibility
with multiple operating platforms and a vast array of graphics standards
allowing resolution upgrades without upgrading the monitor.
The MultiSync XV17+ monitor strictly follows ErgoDesign guidelines
featuring enhanced human ergonomics (human and earth condition).
The goal of ErgoDesign is to maximise the comfort and productivity of
the end user. ErgoDesign parallels the strict European standards of
power management and reduced emissions. In addition our monitor is
designed to be recyclable.
Screen Technology
The OptiClear Surface of the XV17+ CRT dramatically reduces the
reflection of ambient illumination and glare resulting in greatly
improved user comfort and productivity. This multilayered screen
coating increases the contrast without sacrificing the focus level, clarity
or brightness.
A 0.28 mm dot pitch in conjunction with the Invar Shadow Mask
increases the clarity and displays greater detail. Good clarity allows
your eyes to flow over the screen image and more easily view the
on-screen information.
The flat square CRT technology reduces image distortion and glare.
Plug and Play
Plug and Play is the new Microsoft®solution with Windows®95 to
provide automatic peripheral connections without confusing and
time-consuming setup. When used with a Plug and Play compatible system
and video card, the MultiSync XV17+ monitor automatically tells the
Introduction E - 1

system its identification and capabilities. The system will then select its
highest resolution and refresh rate to take advantage of your MultiSync
monitor.
ErgoDesign
The MultiSync ErgoDesign features enhance human ergonomics
(human and earth conditions). MultiSync monitor’s ErgoDesign will
improve the working environment, protect the health of the user and
save money. ErgoDesign parallels the strict European standards of
power management and reduced emissions:
–automatic display power-down (also known as NUTEK
specification 803299)
–emission characteristics (stricter than those referred to as
reduced electromagnetic fields as recommended by MPR II
and, for JC-1745UMB, also by TCO)
–safety (EN 60950)
MultiSync monitors comply with these standards by offering IPM
System power management and Reduced Magnetic Field technology.
Power Manager
IPM (Intelligent Power Manager) System is an innovative power-saving
utility that complies with both the EPA’s Energy Star requirements and
Europe’s TCO NUTEK’s power management requirements. Energy Star
products use less than 30 watts when in the main power saving mode. The
NUTEK specification 803299 requires automatic power down to less than
30 watts in the suspend mode and less than 8 watts in the off mode.
When in the maximum power-down mode, the MultiSync XV17+
monitor will consume approximately 10% of the total power drawn
under normal operation. This innovation adds up to 90% energy savings,
longer monitor life, environmental protection, reduced emissions and
reduced air conditioning costs of the work environment. The IPM
System increases the monitor’s life and saves energy and costs by
powering down when not in use.
E - 2 Introduction

MultiSync monitors follow the Video Electronics Standard Association
(VESA) approved DPMS power-down signalling method. VESA’s
Display Power Management Signalling (DPMS) method, which is
endorsed by the EPA, is the power-down process a system should use to
communicate to the monitor to save power. Power-down functions can
be utilised only with an Energy Star system or video card which adheres
to the VESA DPMS standard. By using the monitor’s horizontal and
vertical SYNC signals, the monitor can be prompted into the different
IPM modes. The following is the description of the LED indicator for
the IPM power-saving modes:
Mode LED Indicator Power Saving
On Green None
Stand By Green Minimum (Quickest Recovery)
Suspend Yellow Moderate (< 20 Watts, Moderate
Recovery)
Off (IPM Mode) Orange Maximum (< 8 Watts, Slow Recovery)
Off (Power
Switch, Off) No Light No Power Used (Fully Off)
Reduced Emissions
The XV17+ monitor incorporates Reduced Magnetic Field technology
designed to reduce magnetic and alternating electric field emissions and static
electricity. NEC’s monitors follow the strictest magnetic field, alternating
electric field, and electrostatic recommendations of the Swedish Board for
Technical Accreditation, or SWEDAC (previously known as MPR, National
Board for Measurement and Testing). The JC-1745UMB follows the
recommendations of the TCO which specify maximum recommended values
of electric and magnetic fields.
Multiple Frequency Technology
Multiple Frequency Technology automatically adjusts the monitor to the
video card’s scanning frequency, displaying the resolution you desire.
The MultiSync XV17+ color monitor also supports multiple operating
platforms such as PC compatible, Macintosh family and workstation
systems.
Introduction E - 3

Increased refresh rates at all resolutions provide a flicker-free image.
The clearer image is easier on your eyes and extends your viewing time.
A wide range of graphics standards, including VESA standards, is
supported by the MultiSync XV17+ color monitor including:
–640 x 480: 55 - 100 Hz vertical refresh
–800 x 600: 55 - 100 Hz vertical refresh
–1024 x 768: 55 - 100 Hz vertical refresh (non-interlaced, 75 Hz
recommended)*
–1280 x 1024: 55 - 75 Hz vertical refresh (non-interlaced)**
* NEC cites recommended resolutions for optimal display performance
** Maximum resolution based on horizontal and vertical frequencies only.
And Macintosh resolutions, such as:
–MAC II 640 x 480 at 67 Hz ***
–Macintosh 832 x 624 at 75 Hz
–Macintosh 1024 x 768 at 75 Hz
–Macintosh 1152 x 870 at 75 Hz
*** For ergonomical reasons we recommend using non-interlaced
signals with a vertical refresh rate between 75 and 100 Hz.
Horizontal and vertical FullScan capability can increase the display size
of a variety of video modes to the edges of the monitor bezel. The
FullScan capability allows you to use the entire screen area in most
resolutions, significantly expanding image size.
E - 4 Introduction

Contents of the Package
Included with your MultiSync XV17+ color monitor are the following
items:
–MultiSync XV17+ (JC-1745UMB/R) with removable tilt/
swivel stand
–Power cord
–User’s manual
Recommended use
For optimum performance when setting up and using the MultiSync
XV17+ colour monitor, please note the following:
–The optimum monitor position is away from direct sunlight.
–Place the monitor just below eye level for the ideal viewing
angle.
–Allow adequate ventilation around the monitor so that heat can
properly dissipate.
–Do not place any heavy objects on the power cord. Damage of
the cable may cause shock or fire.
Contents of the Package E - 5

–Keep the monitor away from high capacity transformers,
electric motors and other devices which may create strong
magnetic fields.
–Use the monitor in a clean, dry area.
–Handle with care when transporting.
–We recommend to adjust the brightness in a way that the
background raster disappears.
–For ergonomical reasons we recommend not to use the
position of the maximum contrast control.
–For ergonomical reasons the preset size and position is
recommended with the standard signals.
–For ergonomical reasons preset side-pincushion setting is
recommended.
–For ergonomical reasons we recommend using
non-interlaced signals with a vertical refresh rate between
75 and 100 Hz.
–For ergonomical reasons we recommend not to use the primary
colour blue on dark background ( it is difficult to recognise and
produces eye fatigue due to insufficient contrast).
–To separate the equipment from the power source you have
to remove the plug from the inlet socket.
–The power outlet socket should be installed as near to the
equipment as possible, and should be easily accessible.
–We recommend using the power cord supplied with the
monitor. However, if another type of power cord is
required, power cord H05VV-F should be used except in
U.K.
–To clean the CRT surface use a lint-free, non-abrasive cloth
and a neutral cleaner based, non-abrasive cleaning solution
or glass cleaner for best results.
E - 6 Recommended use

Quick Start
The following chart summarises the connection process for the
MultiSync XV17+.
For more details please turn to the following pages if you are connecting
to an IBM compatible, Macintosh compatible or other systems.
Is the computer a Macintosh
Computer? Use the optional MultiSync Mac adapter to attach the
monitors signal cable to the
Macintosh video output.
Attach the signal cable of the moni-
tor to the video board/Mac adapter.
Connect the power cord of the
monitor to the power outlet and to
the monitor itself.
Turn monitor and computer on.
If necessary, use the OSM controls
for personal preference of the image.
Is the image correct?
Enjoy your monitor.
Problem solved?
Call your NEC-Dealer
Yes
No
Yes No
No
Yes
See the Trouble Shooting section
Quick Start E - 7

Connection to Your Personal Computer
The MultiSync XV17+ color monitor complements NEC computers, PC
compatibles, Macintosh and Macintosh compatibles.
For the PC:
Your system has one of two configurations:
–the video controller is built into the computer
–the video controller is in the form of a display card (sometimes
referred to as the graphics card, video adapter or graphics board)
Both configurations have a video connector (or a CRT PORT on laptop
computers). If you are not sure which port is the video connector, please
consult your computer or display card manual.
For the Mac:
With the optional MultiSync XV17+ Macintosh Cable Adapter, the
MultiSync XV17+ color monitor is compatible with Macintosh
computers, as well as Macintosh clones.
NOTE: Power Macintosh 6100/60 users need to use the Apple HDI-45
cable adapter in conjunction with the appropriate MultiSync Cable
Adapter when connecting a MultiSync monitor.
The MultiSync XV17+ Macintosh Cable Adapter allows you to change
between 640 x 480, 832 x 624, 1024 x 768 and 1152 x 870 screen
resolutions without restarting your system, if the video port supports
these modes. You will connect your MultiSync XV17+ monitor one of
two ways to your Macintosh computer:
–On-board video port
–NuBus, PDS or PCI display card
Both configurations should have the same style video connector. If you
are not sure which port is the video connector, please consult your
computer or display card manual.
Please contact your local dealer for information about the Mac Adapter.
E - 8 Connection to Your Personal Computer

To attach the MultiSync XV17+ monitor to your system, follow these
instructions:
1. Turn off the power to your computer and MultiSync monitor.
2. If necessary, install the display card. For more information,
refer to the display card manual.
3. For the PC: Connect the MultiSync XV17+ monitor’s video
cable to the display card’s connector on the computer.
Tighten screws on all connectors.
For the Mac: Connect the MultiSync XV17+ Macintosh
Cable Adapter to the monitor’s connector on your computer.
Connect the MultiSync XV17+ monitor’s signal cable to the
other end of the cable adapter. Tighten screws on all
connectors.
4. Connect one end of the power cable to the MultiSync XV17+
monitor and the other end to the power outlet.
5. Turn on your MultiSync monitor and computer.
6. This completes the installation.
NOTE: If you have any problems, please refer to the
Troubleshooting section of this manual.
On-Screen Manager (OSM )
Now, On-Screen Manager (OSM ) Controls have made the MultiSync
monitor’s Advanced Digital Control System easier to use by providing
menus on screen. A touch of the up front controls turns on OSM,
allowing you to easily navigate through menus and adjust controls.
OSM allows you to control the Brightness, Contrast, Size, Position,
Geometry and other OSM Utilities. User adjustments are saved
automatically when you change menus. Controls can be reset to factory
settings by pressing the reset button.
On-Screen Manager (OSM ) E - 9

OSM buttons on the front of the monitor function as follows:
Main Menu Sub-Menu
EXIT Exits the OSM Controls. Exits to the OSM main
menu.
CONTROL ▼/▲Moves the highlighted
area up/down to select
one of the controls
Moves the highlighted
area up/down to select
one of the controls.
CONTROL+/- Moves highlighted area
left/right to select
direction one of the
controls
Moves the bar in the +
or – direction to increase
or decrease the
adjustment.
PROCEED Has no function Only executes control or
enters sub, sub-menu
RESET Resets all the controls
within the highlighted
menu to the factory
setting
Resets the highlighted
control to the factory
setting.
NOTE: When RESET is pressed in the main and sub-menu, a warning
window will appear allowing you to cancel the reset function.
E - 10 On-Screen Manager (OSM )

OSM Elements:
On-Screen Manager windows typically have the following elements:
Highlight: Indicates the selected menu or control in green. Inactive tab
is indicated in yellow.
Scroll Bar: Indicates direction of adjustment.
Accessing OSM: Press any of the control buttons +/-,▼/▲or the
PROCEED or EXIT button to view the current settings.
Turning off OSM:
–When in the main menu: Press the EXIT button.
–When in the sub-menu: Press the EXIT button twice.
–When in the sub, sub-menu: Press the EXIT button three times.
OSM Menus
Main Menu
OSM’s main menu of control icons gives you an overview of the
selection of controls available. When OSM is activated, icons are
displayed at the top of the menu.
If an arrow button is displayed (⇒), it indicates further choices are
available. Use the ▼/▲control buttons to scroll through all of the options.
BRIGHTNESS
CONTRAST
DEGAUSS
OSM Menus E - 11

The icons control the following:
Brightness/Contrast Control
Brightness: Adjusts the overall image and background screen
brightness.
Contrast: Adjusts the image brightness in relation to the background.
Degauss: Eliminates the build-up of stray magnetic fields which alter
the correct scan of the electron beams and affect the purity of the screen
colours, focus, and convergence. When activated, your screen image
will jump and waver a bit as the screen is demagnetised.
Caution: Please allow a minimum of 20 minutes to elapse between uses
of the Degauss function.
Size and Position
Left/Right: Moves the image horizontally (left or right).
Up/Down: Moves the image vertically (up or down).
Narrow/Wide: Increases or decreases the horizontal size of the image.
Tall/Short: Increases or decreases the vertical size of the image.
Geometry Controls
Geometry Controls Menu
The Geometry controls allow you to adjust the curvature or angle of the
sides of your display.
Sides ln/Out (pincushion): increases or decreases the curvature of the
sides either inward or outward.
Sides Left/Right (pincushion balance): increases or decreases the
curvature of the sides either to the left or right.
Sides Tilt (parallelogram): increases or decreases the tilt of the sides
either to the left or right.
Sides Align (trapezoidal): increases or decreases the bottom of the
screen to be the same as the top.
E - 12 OSM Menus

Note on Controls in the Geometry Controls Menu:
EXIT: exits to the main menu.
Cursor ▼/▲:moves the highlighted area up/down to select one of the
choices.
Cursor +/-: moves the bar in the + or – direction to increase or decrease
the adjustment.
RESET: resets the current highlighted control to the factory setting.
Tools
Provides a list of optional adjustments which include the following:
Language: OSM menus are available in 6 languages.
OSM Position: You can choose where you would like the OSM image
to appear on your screen. Selecting OSM location allows you to
manually adjust the OSM menu left, right, up, or down.
OSM Turn Off: The OSM menu will stay on as long as it is in use. In
the OSM Turn Off sub-menu, you can select how long the monitor waits
after the last touch of a button to shut off the OSM menu. The preset
choices are 10, 20, 30, 60, 120 seconds.
OSM Lockout: This control completely locks out access to all OSM
functions. When attempting to activate OSM while in the lockout mode,
a screen will appear indicating that OSM is locked out. To activate the
OSM Lockout function, press PROCEED, then “▲” and hold down
simultanously. To de-activate the OSM Lockout, press PROCEED,
then “▲” and hold down simultanously.
Linearity: The Linearity selection allows you to adjust the spacing of
the areas on the screen. The purpose of this control is to ensure that a 2
cm circle is a true 2 cm circle wherever it is drawn on the screen. The
best way to determine the vertical linearityis as follows:
–Draw equally spaced horizontal lines using a drawing
application that has a ruler.
–Use the Vertical control to adjust the spacing between the lines
near the centre of your screen.
OSM Menus E - 13

Factory Preset: Selecting Factory Preset allows you to reset all OSM
settings back to the factory settings. A warning statement will appear to
confirm that you do want to reset ALL settings. Individual settings can be
reset by highlighting the control to be reset and pressing the RESET button.
Information
Provides you with additional information which includes the following:
Fitness Tips: The Fitness Tips provide you with helpful reminders to
periodically rest your eyes. You may select how frequently the reminders
are displayed based upon your individual needs. Select an interval from
15, 30, 45, 60, 90, 120 minutes for the tips to appear. When the tips
appear, follow the advise of the tips and press EXIT to clear.
Additional information: Adjust the monitor height so that the top of
the screen is at or slightly below eye level.
Position your monitor no closer than 30 cm and no further away than 60
cm from your eyes. The optimal distance is 45 cm.
Set up your work area to promote a natural and relaxing position.
Rest your eyes periodically by focussing on an object at least 6 m away.
Blink often.
Stretch and walk during frequent short breaks. Relax muscles and joints.
Have regular eye checkups.
Display Mode: Indicates the current mode and frequency setting of the
monitor.
MODE
FREQUENCY
HORIZONTAL
VERTICAL
POLARITY
HORIZONTAL
VERTICAL
03
31.60 KHZ
60.00 HZ
POS.
NEG.
E - 14 OSM Menus

Troubleshooting/Support
Problem Check These Items
No Picture: The video card should be completely
seated in its slot. Power Switch and
computer power switch should be in
the ON position. The signal cable
should be completely connected to
the video card/computer. Check the
connector for bent or pushed-in pins.
Image is scrolling or unstable Signal cable should be completely
attached to the computer. Check the
pin assignment and signal timing of
your video card with respect to the
frequency range and pin assignment
of the monitor MAC adapter is used,
check for proper connection or make
sure the video card is PC or MAC
compatible and that the card is
properly seated in the computer.
LED on the monitor is not lit (no
green, orange or yellow color can be
seen)
Power Switch should be in the ON
position and the power cord should
be connected.
Picture is fuzzy: Adjust the Brightness, then Contrast
Controls. Access the Degauss Control
through OSM. Activate the Degauss
Control. CAUTION: A minimum
interval of 20 minutes should exist
before the Degauss Function is used a
second time.
Picture bounces or a waving pattern.
is present in the picture Move electrical devices that may be causing electrical interference away
from the monitor.
Edges of the display image are not
square Use the OSM Geometry Controls to straighten the edges.
Troubleshooting/Support E - 15
