www.necdisplay.com
Entertainment Desktop
NEC AccuSyncTM GX/CX LCD Series
19", 22" & 24" widescreen flat-panel monitors
ideal for home users
Turn your desktop into the ultimate entertainment center. With the NEC AccuSync GX/CX LCD
Series, there are no limits to what you can enjoy on your desktop. The 19” NEC AccuSync LCD-
19WMGX, 22” NEC AccuSync LCD22WMGX and 24” NEC AccuSync LCD24WMCX feature bright,
colorful screen performance, a variety of digital connections and technologies that promote high-
speed video. In addition, their wide-format screens provide a viewable area that’s significantly larger
than standard aspect ratio screens, allowing you to simultaneously view multiple/side-by-side applica-
tion windows. All of these benefits make the AccuSync GX/CX LCD Series ideal for techno-savvy
users looking for an enhanced visual experience with video games, streaming video, photo viewing
and other applications that require jaw-dropping color and contrast or wide connectivity.
Enhanced screen performance. With dynamic contrast ratios up to 2000:1 (dynamic) and brightness
up to 400 cd/m2, outstanding LCD monitor front-of-screen visual performance is NEC’s #1 goal. The
AccuSync GX/CX LCD Series delivers vibrant colors and flicker-free images that make your time in
front of the monitor more comfortable and engaging. OptiClear® screen technology (featured on the
LCD19WMGX and LCD22WMGX) delivers true-to-life images with remarkable clarity and color, while
NEC’s Rapid ResponseTM technology provides for uninterrupted display of full-motion video with
lightning-fast response times of 5ms. This remarkably seamless motion makes these models better
than ever for gaming and video applications such as streaming web video.
Connect to the latest components. With the advanced screen capabilities of AccuSync GX/CX LCD
Series displays, it is only fitting that they be compatible with the most cutting-edge peripherals. Com-
ponent (featured on the LCD22WMGX and LCD24WMCX), HDMI and DVI inputs with HDCP support
allow you to hook up to the most recently unveiled video consoles, computers, DVD players and other
high-definition components for an optimal visual performance.
Series Features and Benefits
Super-bright OptiClear screen technology pro-
vides rich color saturation, remarkable clarity
and true-to-life contrast to enhance the user’s
overall visual perception (LCD19WMGX &
LCD22WMGX)
Remarkable brightness makes images and
video jump off the screen with vivid realism
HDMI connectivity w/ HDCP support links you
to the latest, most advanced peripherals
Rapid Response technology delivers virtually
uninterrupted, undistorted viewing of high-
speed, full-motion video
Wide-format screen increases productivity by
expanding your working area to view multiple
application windows
Dynamic Video Mode enhances video and im-
ages with real-time optimization of brightness,
color and contrast
Built-in, multimedia speakers provide quality
sound
Piano black glossy bezel adds a stylish appeal
to your desktop
Windows® Vista certification maximizes the
monitor’s resolution capabilities
Ambix dual-input technology allows for digi-
tal/analog compatibility with upgraded video
cards and software as well as connection to
two systems
No Touch Auto AdjustTM reduces setup time
and provides optimal image settings upon
initial power-on
Wall/arm mounting capability adds flexibility
and comfort, while freeing up valuable desktop
space (using third-party product)
RoHS compliance ensures the displays are free
of hex-chrome, cadmium, PBDE and PBB, with
reduced mercury and lead
NEC Display Solutions’ quality and reliability
provide peace of mind with a 3-year limited
parts and labor warranty (including backlight)
and 24/7 customer service and technical support

Model
Display
Viewable Image Size
Pixel Pitch
Pixels Per Inch
Brightness (typical)
Contrast Ratio (typical)
Viewing Angle (typical)
Response Time (typical)
Display Colors
Synchronization Range
Horizontal
Vertical
Input Signal
Video
Sync
Input
Resolutions Supported
Native Resolution
Additional Features
Touch-Capable
Voltage Rating
Power Consumption (typical)
On
Power Savings Mode
Dimensions (W x H x D)
Net (with stand)
Net (without stand)
Weight
Net (with stand)
Net (without stand)
VESA Hole Configuration
Specifications
Environmental Conditions
Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude
Limited Warranty
Technical Support
AccuSync LCD24WMCX
24”
0.270mm
90 @ native resolution
400 cd/m2
2000:1 (dynamic)
178 Vert., 178 Hor. (89U/89D/89L/89R)
(CR>5)
Rapid Response (5ms)
More than 16.7 million
31.5-92 kHz (Analog), 31.5-91.1 KHz (Digital)
60 - 75 Hz
Analog 0.7 Vp-p/75 Ohms
Separate Sync: TTL Level (Positive/Negative)
DVI-D, VGA 15 pin D-sub, Component Video and
Audio (RCA), HDMI, coaxial digital audio (output)
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 75 Hz
1152 x 870 @ 75 Hz
1280 x 720 @ 60 Hz
1280 x 768 @ 60-75Hz
1280 x 960 @ 60-75 Hz
1280 x 1024 @ 60-75 Hz
1360 x 768 @ 60 Hz
1440 x 900 @ 60 Hz
1680 x 1050 @ 60 Hz
1600 x 1200 @ 60 Hz
1920 x 1200 @ 60 Hz
480i, 480p, 576p, 720p, 1080p, 1080i
1920 x 1200 @ 60 Hz
Glossy bezel, widescreen format, tilt,
integrated speakers, No Touch Auto Adjust,
cable management, digital smoothing, digital
controls, AccuColor color control, On Screen
Display (OSD) user controls, NaViSet software,
DDC/CI, Plug and Play (VESA DDC2B), VESA
DPMS power management, ISO 13406-2 Class
II, TCO ‘06, Dynamic Video Mode, headphone
jack, Windows Vista Premium-certified
No
AC 100-120V / AC 220-240V
98W
<2W
22.1 x 18.1 x 10.2 in. / 561.8 x 460 x 260mm
22.1 x 15.5 x 3.4 in. / 561.8 x 392.7 x 86mm
15.4 lbs. / 7 kg
14.3 lbs. / 6.5 kg
100 x 100mm
5-35 C / 41-95 F
30-80%
4572m / 15,000 ft.
-10-60 C / 14-140 F
10-85%
12,192m / 40,000 ft.
3 years parts and labor, including backlight
24 hours / 7 days
AccuSync LCD22WMGX
22”
0.282mm
90 @ native resolution
300 cd/m2
2000:1 (dynamic)
160 Vert., 170 Hor. (80U/80D/85L/85R)
(CR>10)
Rapid Response (5ms)
More than 16.7 million
30 - 83 kHz (Analog/Digital)
60 - 75 Hz
Analog 0.7 Vp-p/75 Ohms
Separate Sync: TTL Level (Positive/Negative)
DVI-D, VGA 15 pin D-sub, Component Video and
Audio (RCA), HDMI, coaxial digital audio (output)
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 75 Hz
1152 x 870 @ 75 Hz
1280 x 720 @ 60 Hz
1280 x 768 @ 60-75Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60-75 Hz
1360 x 768 @ 60 Hz
1440 x 900 @ 60 Hz
1680 x 1050 @ 60 Hz
480i, 480p, 576p, 720p, 1080p, 1080i
1680 x 1050 @ 60 Hz
OptiClear, glossy bezel, widescreen format,
tilt, integrated speakers, No Touch Auto
Adjust, cable management, digital smoothing,
digital controls, AccuColor color control, On
Screen Display (OSD) user controls, NaViSet
software, DDC/CI, Plug and Play (VESA
DDC2B), VESA DPMS power management, ISO
13406-2 Class II, Dynamic Video Mode, head-
phone jack, Windows Vista Premium-certified
No
AC 100-120V / AC 220-240V
48W
<2W
19.9 x 16 x 8.3 in. / 505.8 x 407.5 x 210mm
19.9 x 14.1 x 2.1 in. / 505.8 x 358 x 60.8mm
12 lbs. / 5.5 kg
11 lbs. 5 kg
100 x 100mm
5-35 C / 41-95 F
30-80%
4572m / 15,000 ft.
-10-60 C / 14-140 F
10-85%
12,192m / 40,000 ft.
3 years parts and labor, including backlight
24 hours / 7 days
AccuSync LCD19WMGX
19”
0.285mm
89 @ native resolution
400 cd/m2
1000:1
160 Vert., 170 Hor. (80U/80D/85L/85R)
(CR>10)
Rapid Response (5ms)
More than 16.7 million
30 - 83 kHz (Analog/Digital)
55 - 75 Hz
Analog 0.7 Vp-p/75 Ohms
Separate Sync: TTL Level (Positive/Negative)
DVI-D and VGA 15 pin D-sub, HDMI (via
DVI-D adapter)
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 75 Hz
1280 x 768 @ 60 Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60-76 Hz
1440 x 900 @ 60 Hz
480p, 576p, 720p, 1080p, 1080i
1440 x 900 @ 60-75 Hz
OptiClear, glossy bezel, widescreen format,
tilt, integrated speakers, No Touch Auto
Adjust, cable management, digital smoothing,
digital controls, AccuColor color control, On
Screen Display (OSD) user controls, NaViSet
software, DDC/CI, Plug and Play (VESA
DDC2B), VESA DPMS power management,
ISO 13406-2 Class II, Dynamic Video Mode,
Windows Vista Premium-certified
No
AC 100-120V / AC 220-240V
40W
<2W
17.3 x 14.3 x 8.3 in. / 440 x 363 x 210mm
17.3 x 12.2 x 2.4 in. / 440 x 310.4 x 60.8mm
9.9 lbs./ 4.5 kg
9.3 lbs./ 4.2 kg
100 x 100mm
5-35 C / 41-95 F
30-80%
4572m / 15,000 ft.
-10-60 C / 14-140 F
10-85%
12,192m / 40,000 ft.
3 years parts and labor, including backlight
24 hours/7 days
NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
Ambix, OptiClear and OSD are registered trademarks,
and AccuSync, NaViSet, No Touch Auto Adjust
and Rapid Response are trademarks of NEC Display
Solutions. All other brand or product names are
trademarks or registered trademarks of their respec-
tive holders.
Product specifications subject to change. 8/07 ver. 1.
©2007 NEC Display Solutions of America, Inc.
