English-1
English
Declaration
Declaration of the Manufacturer
We hereby certify that the colour monitor
MultiSync LCD1830 (LA-18S02) and
MultiSync LCD1830 (LA-18S02-BK)
are in compliance with
Council Directive 73/23/EEC:
– EN 60950
Council Directive 89/336/EEC:
– EN 55022
– EN 61000-3-2
– EN 61000-3-3
– EN 55024
(IEC 61000-4-2)
(IEC 61000-4-3)
(IEC 61000-4-4)
(IEC 61000-4-5)
(IEC 61000-4-6)
(IEC 61000-4-8)
(IEC 61000-4-11)
and marked with
NEC-Mitsubishi Electric Visual Systems, Corp.
686-1, NISHIOI OI-MACHI
ASHIGARAKAMI-GUN
KANAGAWA 258-8533, JAPAN
Power consumption of the monitor
is less than 3 W when in power-
saving mode.
MultiSync LCD1830 white
Model (LA-18S02)
MultiSync LCD1830 Black
Model (LA-18S02-BK)
01b_English 13.12.2000, 11:50 Uhr1

English-2
Contents
Your new NEC MultiSync LCD monitor box* should contain the following:
• MultiSync LCD1830 monitor with tilt base
• Power Cord
• Video Signal Cable
• User’s Manual
• CD-ROM includes complete User‘s Manual in PDF format and
Windows related files (Inf file and color profile). To see the complete
User‘s Manual, Acrobat Reader 4.0 must be installed on your PC.
* Remember to save your original box and packing material to transport
or ship the monitor.
01b_English 13.12.2000, 11:50 Uhr2

English-3
English
Quick Start
To attach the MultiSync LCD monitor to your system, follow these
instructions:
1. Turn off the power to your computer.
2. For the PC: Connect the 15-pin mini D-SUB of the appropriate
signal cable to the connector of the display card in your system
(Figure A.1). Tighten all screws.
For the Mac: Connect the MultiSync LCD1830 Macintosh cable
adapter to the computer (Figure B.1). Attach the 15-pin mini D-SUB
end of the appropriate signal cable to the MultiSync LCD1830
Macintosh cable adapter (Figure B.1). Tighten all screws.
Remove connector cover and cable cover on back of monitor
(Figure E.1).
3. Connect the 15-pin mini D-SUB of the video signal cable to the
connector “INPUT 1” or “INPUT 2” on the back of the monitor
(Figure C.1).
NOTE: Incorrect cable connections may result in irregular operation,
damage display quality/components of LCD module and/or
shorten the module’s life.
4. Connect one end of the power cord to the MultiSync LCD Series
monitor and the other end to the power outlet. (Figure C.1)
Replace connector cover and cable cover. (Figure E.1)
NOTE: Please refer to Caution section of this manual for proper
selection of AC power cord.
5. Turn on the monitor (Figure D.1) and the computer.
6. To complete the setup of your MultiSync LCD monitor, use the
following OSM controls:
• Auto Adjust Contrast
• Auto Adjust
Refer to the Controls section of this User’s Manual for a full description
of these OSM controls.
NOTE: If you have any problems, please refer to the Troubleshooting
section of this User’s Manual.
NOTE: For easy removal of the cable cover or signal cable, place the
monitor face down. (Figure R.2)
01b_English 13.12.2000, 11:50 Uhr3

English-4
15-pin
mini D-SUB
15-pin
mini D-SUB
Mac Adapter
(not included)
Figure A.1 Figure B.1
Figure D.1
Power Switch
Figure C.1
Power Outlet
To Computer
AC Power
Cord
1. Cables pass through in this hole.
2. Connect each connector.
3. Replace connector cover with
cables passing through upper
opening.
Signal
Cable
INPUT2 INPUT1 AC-IN
01b_English 13.12.2000, 11:50 Uhr4

English-5
English
Push Push
Marking area
(1. Push)
Marking
Figure E.1
I. Cable Cover
How to remove this cover.
1. Push marking area
2. Slide to up side
3. Remove
II. Connector Cover
How to remove this cover.
1. Push under side
2. Remove
01b_English 13.12.2000, 11:50 Uhr5

English-6
Tilt
Grasp both sides of the monitor screen with
your hands and adjust the tilt as desired
(Figure TS.1).
Remove Monitor Stand
for Mounting
To prepare the monitor for alternate mounting
purposes:
1. Remove the connector
cover, hinge cover and
cable cover. (Figure R.1)
2. Disconnect all cables.
3. Place monitor face down
on a non-abrasive
surface.
(Place the screen on a
32 mm platform so that
hole of stand match to
screw location)
(Figure R.2).
4. Remove the 4 srcews
connecting the monitor to the
stand and lift off the stand
assembly (Figure R.2) the monitor
is now ready for mounting in an
alternate manner.
5. Connect the AC cord and signal
cable to the back of the monitor.
6. Reverse this process to reattach
stand.
Caution:To fulfil the safety requirements
the monitor must be mounted to
an arm which guaranties the
necessary stability under
consideration of the weight of the
monitor. The LCD monitor shall
only be used with an approved
arm (e.g. GS mark).
Figure TS.1
Figure R.1
Push
Push
Figure R.2
Screws
