NEFF S353ITX02G User manual

Dishwasher
[en] User manual
S353ITX02G

en
2
Table of contents
Safety...............................................4
General information..........................4
Intended use.....................................4
Restriction on user group.................4
Safe installation ................................4
Safe use ...........................................6
Damaged appliance.........................7
Risk to children ................................8
Preventing material damage ........10
Safe installation ..............................10
Safe use .........................................10
Environmental protection and
saving energy................................11
Disposing of packaging .................11
Saving energy.................................11
AquaSensor....................................11
Installation and connection..........11
Scope of supply .............................11
Installing and connecting the ap-
pliance............................................11
Drainage connection ......................12
Drinking water connection .............12
Electrical connection ......................12
Familiarising yourself with
your appliance...............................14
Appliance .......................................14
Controls ..........................................15
Programmes ..................................17
Information for test institutes ..........18
Additional functions .....................18
Features.........................................19
Top basket......................................19
Bottom basket................................19
Cutlery basket ................................20
Etagere ...........................................20
Baking sheet spray head ...............20
Before using for the first time ......21
Performing the initial configura-
tion..................................................21
Water softening system................21
Overview of water hardness set-
tings................................................21
Setting the water softening sys-
tem .................................................22
Special salt.....................................22
Switching off the water softening
system ............................................23
Regeneration of the water
softening system ............................23
Rinse aid system...........................24
Rinse aid ........................................24
Setting the amount of rinse aid......24
Switching the rinse aid system
off ...................................................25
Detergent .......................................25
Suitable detergents ........................25
Unsuitable detergents ....................26
Information on detergents ..............26
Adding detergent ...........................27
Tableware ......................................27
Damage to glass and tableware ....28
Arrange tableware..........................28
Removing tableware.......................29
Basic operation .............................29
Opening appliance door ................29
Switching on the appliance ............29
Setting a programme .....................30
Setting additional functions ............30
Setting timer programming1...........30
Starting the programme .................30
1Depending on the appliance specifications

en
3
Interrupting programme .................30
Terminate programme....................31
Switching off appliance ..................31
Basic settings................................32
Overview of basic settings .............32
Cleaning and servicing.................33
Cleaning the tub.............................33
Cleaning products..........................33
Tips on appliance care...................33
Easy Clean ................................34
Filter system ...................................35
Cleaning spray arms ......................36
Troubleshooting............................37
Error code / Fault display / Sig-
nal...................................................37
Washing results..............................38
Information on display panel..........45
Malfunctions ...................................45
Mechanical damage.......................46
Noise ..............................................46
Clean wastewater pump.................48
Transportation, storage and
disposal .........................................48
Removing the appliance ................48
Protect appliance from frost...........49
Transporting the appliance ............49
Disposing of old appliance ............49
Customer Service..........................49
Product number (E-Nr.), produc-
tion number (FD) and consecut-
ive numbering (Z-Nr.) .....................50
AQUA-STOP guarantee ..................50
Technical specifications...............50
Information regarding Free and
Open Source Software ...................51

en Safety
4
Safety
Observe the following safety instructions.
General information
¡Read this instruction manual carefully.
¡Keep the instruction manual and the product information safe
for future reference or for the next owner.
¡Do not connect the appliance if it has been damaged in transit.
Intended use
Only use this appliance:
¡For cleaning household tableware.
¡In private households and in enclosed spaces in a domestic en-
vironment.
¡Up to an altitude of 4000 m above sea level.
Restriction on user group
This appliance may be used by children aged 8 or over and by
people who have reduced physical, sensory or mental abilities or
inadequate experience and/or knowledge, provided that they are
supervised or have been instructed on how to use the appliance
safely and have understood the resulting dangers.
Children must not play with the appliance.
Cleaning and user maintenance must not be performed by chil-
dren unless they are being supervised.
Keep children under the age of 8 years away from the appliance
and power cable.
Safe installation
WARNING‒Risk of injury!
Improper installation may cause injury.
▶When installing and connecting the appliance, follow the in-
structions in the manual and installation instructions.

Safety en
5
WARNING‒Risk of electric shock!
¡Incorrect installation is dangerous.
▶Connect and operate the appliance only in accordance with
the specifications on the rating plate.
▶Always use the supplied power cable for the new appliance.
▶Connect the appliance to a power supply with alternating
current only via a properly installed socket with earthing.
▶The protective conductor system of the domestic electrical
installation must be properly installed.
▶Never equip the appliance with an external switching
device, e.g. a timer or remote control.
▶When the appliance is installed, the mains plug of the
power cord must be freely accessible. If free access is not
possible, an all-pole isolating switch must be installed in the
permanent electrical installation according to the installation
regulations.
▶When installing the appliance, check that the power cable is
not trapped or damaged.
¡Cutting through the supply hose or immersing the Aqua-Stop
valve in water is dangerous.
▶Never immerse the plastic housing in water. The plastic
housing on the supply hose contains an electric valve.
▶Never cut through the supply hose. The supply hose con-
tains electric power cables.
WARNING‒Risk of fire!
It is dangerous to use an extended power cord and non-ap-
proved adapters.
▶Do not use extension cables or multiple socket strips.
▶If the power cord is too short, contact Customer Service.
▶Only use adapters approved by the manufacturer.

en Safety
6
WARNING‒Risk of injury!
Hinges move when opening and closing the appliance door
and can cause injury.
▶If built-under or integrable appliances are not in a cavity so
that one side is accessible, the hinge area must be covered
at the side. Covers are available from Customer Service or
specialist outlets.
WARNING‒Risk of tipping!
Improper installation may cause the appliance to tip up.
▶Only install built-under or integrable appliances under a
continuous worktop that is securely connected to adjacent
cabinets.
Safe use
WARNING‒Risk of serious harm to health!
Failure to comply with safety instructions and directions for
use on packagings of detergent and rinse aid products may
cause serious harm to health.
▶Follow the safety instructions and directions for use on the
packagings of detergent and rinse aid products.
WARNING‒Risk of explosion!
¡Adding solvents to the interior of the appliance may cause ex-
plosions.
▶Never add solvents to the interior of the appliance.
¡Highly caustic alkaline or highly acidic cleaning agents in con-
junction with aluminium parts in the interior of the appliance
may cause explosions.
▶Never use highly caustic alkaline or highly acidic cleaning
agents, in particular commercial or industrial products, in
conjunction with aluminium parts (e.g. grease filters of ex-
tractor hoods or aluminium pans), e.g. for the Machine Care
programme.

Safety en
7
WARNING‒Risk of injury!
¡Leaving the appliance door open may result in injury.
▶Only open the appliance door to load or unload tableware
in order to prevent accidents, e.g. through tripping.
▶Do not sit or stand on the appliance door when open.
¡Knives and utensils with sharp points can cause injuries.
▶Arrange knives and utensils with sharp points in the cutlery
basket with the points downwards, on the knife shelf or in
the cutlery drawer.
WARNING‒Risk of scalding!
If you open the appliance door while the programme is run-
ning, hot water may splash out of the appliance.
▶Open the appliance door carefully if the programme is still
running.
WARNING‒Risk of electric shock!
¡An ingress of moisture can cause an electric shock.
▶Only use the appliance in enclosed spaces.
▶Never expose the appliance to intense heat or humidity.
▶Do not use steam- or high-pressure cleaners to clean the
appliance.
¡If the insulation of the power cord is damaged, this is danger-
ous.
▶Never let the power cord come into contact with hot appli-
ance parts or heat sources.
▶Never let the power cord come into contact with sharp
points or edges.
▶Never kink, crush or modify the power cord.
Damaged appliance
WARNING‒Risk of electric shock!
¡If the appliance or the power cord is damaged, this is danger-
ous.
▶Never operate a damaged appliance.
▶Never operate an appliance with a cracked or fractured sur-
face.

en Safety
8
▶Never pull on the power cord to unplug the appliance. Al-
ways unplug the appliance at the mains.
▶If the appliance or the power cord is damaged, immediately
unplug the power cord or switch off the fuse in the fuse box
and turn off the water tap.
▶"Call customer services." →Page49
¡Incorrect repairs are dangerous.
▶Repairs to the appliance should only be carried out by
trained specialist staff.
▶Only use genuine spare parts when repairing the appliance.
▶If the power cord of this appliance is damaged, it must be
replaced with a special connection cable, which is available
from the manufacturer or his Customer Service.
Risk to children
WARNING‒Risk of suffocation!
¡Children may put packaging material over their heads or wrap
themselves up in it and suffocate.
▶Keep packaging material away from children.
▶Do not let children play with packaging material.
¡Children may breathe in or swallow small parts, causing them
to suffocate.
▶Keep small parts away from children.
▶Do not let children play with small parts.
¡Children may become trapped in the appliance and suffocate.
▶Use the childproof lock if fitted.
▶Never let children play with or operate the appliance.
WARNING‒Risk of harm to health!
Children can lock themselves in the appliance, thereby putting
their lives at risk.
▶With redundant appliances, unplug the power cord. Then
cut through the cord and damage the lock on the appliance
door beyond repair so that the appliance door will no longer
close.

Safety en
9
WARNING‒Risk of crushing!
With higher-level appliances, children can become crushed
between the appliance door and cabinet doors underneath.
▶Keep an eye on children when opening and closing the ap-
pliance door.
WARNING‒Risk of chemical burns!
Rinse aid and detergent may cause chemical burns to the
mouth, throat and eyes.
▶Keep children away from detergent and rinse aid products.
▶Keep children away from the appliance when open. The wa-
ter in the interior of the dishwasher is not drinking water. It
may contain residues of detergents and rinse aid.
WARNING‒Risk of injury!
Children may get their fingers caught in the slots of the tablet
collecting tray and injure themselves.
▶Keep children away from the appliance when open.

en Preventing material damage
10
Preventing material damage
Preventing material dam-
age
Preventing material damage
Safe installation
ATTENTION!
¡Improper installation of the appli-
ance may cause damage.
▶If the dishwasher is installed
above or below other domestic
appliances, follow the informa-
tion on installation in combina-
tion with a dishwasher in the in-
stallation instructions for the in-
dividual appliances.
▶If there is no information or if the
installation instructions do not in-
clude the relevant information,
contact the manufacturer of
these appliances to check that
the dishwasher can be installed
above or below these appli-
ances.
▶If no information is available
from the manufacturer, the dish-
washer should not be installed
above or below such appli-
ances.
▶To ensure the safe operation of
all domestic appliances, con-
tinue following the installation in-
structions for the dishwasher.
▶Do not install the dishwasher un-
der a hob.
▶Do not install the dishwasher
near heat sources, e.g. radiat-
ors, heat storage tanks, ovens
or other appliances that gener-
ate heat.
¡Modified or damaged water hoses
may result in material damage and
damage to the appliance.
▶Never kink, crush, modify or cut
through water hoses.
▶Only use the water hoses sup-
plied with the appliance or genu-
ine spare hoses.
▶Never re-use water hoses that
have been used before.
¡If the water pressure is too high or
too low, the appliance may not be
able to operate properly.
▶Make sure that the water pres-
sure in the water supply system
is min. 50kPa (0.5bar) and
max. 1000kPa (10bar).
▶If the water pressure exceeds
the maximum value specified, a
pressure-reducing valve must be
installed between the drinking
water connection and the hose
set of the appliance.
Safe use
ATTENTION!
¡Escaping water vapour can dam-
age fitted units.
▶When the programme ends,
leave the appliance to cool
down for a while before opening
the door.
¡Special salt for dishwashers can
damage the tub due to corrosion.
▶To make sure that any special
salt that escapes is washed out
of the tub, add the special salt
to the dispenser for special salt
immediately before the pro-
gramme starts.
¡Detergent may damage the water
softening system.
▶Only fill the dispenser of the wa-
ter softening system with special
dishwasher salt.
¡Unsuitable cleaning agents may
damage the appliance.
▶Do not use a steam cleaner.
▶So as not to scratch the finish
on the appliance, do not use
sponges with a rough surface or
abrasive cleaning agents.

Environmental protection and saving energy en
11
▶To prevent corrosion, do not use
sponge cloths on dishwashers
with a stainless steel front or
rinse such cloths thoroughly
several times before using them
for the first time.
Environmental protection and saving energy
Environmental protection
and saving energy
Environmental protection and saving energy
Disposing of packaging
The packaging materials are environ-
mentally compatible and can be re-
cycled.
▶Sort the individual components by
type and dispose of them separ-
ately.
Saving energy
If you follow these instructions, your
appliance will use less electricity and
less water.
Use the Eco50° programme.
The Eco50° programme is en-
ergy-efficient and environmentally
friendly.
→"Programmes", Page17
AquaSensor
The AquaSensor is an optical meas-
uring device (light barrier) which
measures the turbidity of the rinsing
water. You can save water with the
AquaSensor.
Use of the AquaSensor depends on
the programme. If the soiling level is
high, the rinsing water is drained off
and replaced with fresh water. If the
soiling level is lower, the rinsing wa-
ter is used in the next wash cycle, so
reducing water consumption by 3-6
litres. In the automatic programmes
the temperature and run time are ad-
ditionally adjusted to the level of soil-
ing.
Installation and connection
Installation and connec-
tion
Installation and connection
To ensure proper operation, connect
the appliance to the power and water
supply correctly. Observe the spe-
cified criteria and the installation in-
structions.
Scope of supply
After unpacking all parts, check for
any damage in transit and complete-
ness of the delivery.
If you have any complaints, contact
the dealer who sold you the appli-
ance or our Customer Service.
Note:The appliance has been tested
at the factory to check it is in working
order. It is possible that water has left
marks on the appliance. These
marks will disappear after the first
wash cycle.
The delivery consists of the following:
¡Dishwasher
¡Operating instructions
¡Installation Instructions
¡Further information documents
¡Installation material
¡Steam guard plate
¡Mains cable
¡Quick reference guide
Installing and connecting the
appliance
You can position your built-under or
integrable appliance in a fitted kit-
chen between wooden and plastic
walls. If you subsequently install your
dishwasher as a free-standing appli-

en Installation and connection
12
ance, you must stop it from tipping
over, e.g. by screwing it to the wall or
installing it under a continuous work-
top that is securely connected to ad-
jacent cabinets.
1. "Follow the safety instructions."
→Page4
2. "Follow the instructions for elec-
trical connection." →Page12
3. Check the Scope of supply and
the condition of the appliance.
4. Consult the installation instructions
for the installation dimensions re-
quired.
5. Make the appliance level using the
height-adjustable feet.
Make sure that the appliance is
standing on the floor securely.
6. "Install the drainage connection."
→Page12
7. "Install the drinking water connec-
tion." →Page12
8. Connect the appliance to the
power supply.
Drainage connection
Connect your appliance to drainage
connection so dirty water is dis-
charged via the wash cycle.
Installing the drainage connection
1. Consult the installation instructions
supplied for the steps required
here.
2. Connect the wastewater hose to
the outlet connection of the siphon
using the enclosed parts.
3. When doing so, check that the
wastewater hose is not kinked,
crushed or twisted.
4. Also check that there is no cover
in the drainage system preventing
the wastewater from being dis-
charged.
Drinking water connection
Connect your appliance to a drinking
water connection.
Installing the drinking water
connection
Note
¡If you are replacing the appliance,
you must use a new water supply
hose.
1. Consult the installation instructions
supplied for the steps required
here.
2. Connect the appliance to the drink-
ing water connection using the en-
closed parts.
Observe the "Technical data"
→Page50.
3. When doing so, check that the
drinking water connection is not
kinked, crushed or twisted.
Electrical connection
Connect your appliance to the power
supply.
Connecting the appliance to the
electricity supply
Notes
¡Please follow the "Safety instruc-
tions" →Page4.
¡Connect the appliance to alternat-
ing current only, in the range of
220 - 240V and 50Hz or 60Hz.
¡Please note that the water safety
system is only functional if there is
a power supply.
1. Insert the non-heating appliance
plug of the power cable into the
appliance.
2. Insert the mains plug of the appli-
ance into a nearby socket.

Installation and connection en
13
The connection data for the appli-
ance can be found on the rating
plate.
3. Check that the mains plug is inser-
ted properly.

en Familiarising yourself with your appliance
14
Familiarising yourself with your appliance
Familiarising yourself with your appliance
Familiarising yourself with your appliance
Appliance
You can find an overview of the parts of your appliance here.
1
2
3
4
5
6
7 8
9
10
11
12
1
Rating plate Rating plate with "E number and FD number"
→Page50.
The data you need for "Customer Service"
→Page49.
1Depending on the appliance specifications

Familiarising yourself with your appliance en
15
2
Detergent dispenser "Detergent" →Page25 is added to the detergent
dispenser.
3
Bottom basket "Bottom basket" →Page19
4
Dispenser for special salt Add the special salt to the dispenser for special salt.
→"Water softening system", Page21
5
Lower spray arm The lower spray arm washes the tableware in the bot-
tom basket.
If the tableware has not been washed properly, clean
the spray arms.
→"Cleaning spray arms", Page36
6
Tablet collecting tray During the wash cycle tablets automatically fall out of
the detergent dispenser into the tablet collecting tray
where they can fully dissolve.
7
Top basket Top basket
8
Cutlery shelf1"Cutlery shelf" →Page20
9
Upper spray arm The upper spray arm washes the tableware in the top
basket.
If the tableware has not been washed properly, clean
the spray arms.
→"Cleaning spray arms", Page36
10
Filter system "Filter system" →Page35
11
Cutlery basket "Cutlery basket" →Page20
12
Dispenser for rinse aid Add rinse aid to the dispenser for rinse aid.
→"Rinse aid system", Page24
1Depending on the appliance specifications
Controls
You can use the control panel to configure all functions of your appliance and
to obtain information about the operating status.
With some buttons you can perform different functions.

en Familiarising yourself with your appliance
16
1 3 4
CBA
2 5 6 7
89101112
1
ON/OFF button and reset button "Switching on the appliance" →Page29
"Switching off the appliance" →Page31
"Terminating the programme" →Page31
2
Programme button "Programmes" →Page17
3
Programmes "Programmes" →Page17
4
Water supply display Display for water supply
5
Timer programming1"Setting timer programming" →Page30
6
button If you press for approx. 3 seconds,
you can open the basic settings.
7
Start button "Starting the programme" →Page30
8
Programme buttons and additional
functions
"Programmes" →Page17
"Additional functions" →Page18
9
Door opener1"Opening the appliance door" →Page29
10
Programme sequence display The programme sequence display shows the cur-
rent cycle of the appliance, e.g. washing.
11
Rinse aid refill indicator "Rinse aid system" →Page24
12
Special salt refill indicator "Water softening system" →Page21
1Depending on the appliance specifications

Programmes en
17
Programmes
Programmes
Programmes
You can find an overview of the pro-
grammes that can be selected here.
Different programmes, which can be
found on the control panel of your
appliance, are available depending
on the appliance configuration.
The running time may vary depend-
ing on the programme selected. The
running time depends on the water
temperature, the quantity of table-
ware, the level of soiling and the ad-
ditional function selected. The
runtime will change if the rinse aid
system is switched off or rinse aid
needs to be added.
The consumption values can be
found in the quick reference guide.
The consumption values relate to
normal conditions and a water hard-
ness of 9-20°E. Different influen-
cing factors such as water temperat-
ure or pipe pressure may result in
deviations.
Programme: Use Programme sequence Additional func-
tions
Chef 70
Tableware:
¡Washing pots and pans,
non-fragile tableware and
cutlery.
Level of soiling:
¡Removing stubborn
burned or dried-on food
remnants containing
starch and protein.
Intensive:
¡Pre-Rinse
¡Cleaning 70°C
¡Intermediate rinse
¡Final rinse 72°C
¡Extra Dry
Speed
→"Additional
functions",
Page18
Auto 45-65°
Tableware:
¡Cleaning mixed table-
ware and cutlery.
Level of soiling:
¡Removing common
household food remnants
lightly dried-on.
Sensor-controlled:
¡Optimised by sensors de-
pending on the soiling of
the rinsing water.
All
→"Additional
functions",
Page18
Eco 50°
Tableware:
¡Cleaning mixed table-
ware and cutlery.
Level of soiling:
¡Removing common
household food remnants
lightly dried-on.
Most economical pro-
gramme:
¡Pre-Rinse
¡Cleaning 50°C
¡Intermediate rinse
¡Final rinse 68°C
¡Drying
All
→"Additional
functions",
Page18

en Additional functions
18
Programme: Use Programme sequence Additional func-
tions
1 hr Programme
Tableware:
¡Cleaning mixed table-
ware and cutlery.
Level of soiling:
¡Removing common
household food remnants
lightly dried-on.
Time-optimised:
¡Cleaning 65°C
¡Intermediate rinse
¡Final rinse 69°C
¡Drying
Extra Dry
→"Additional
functions",
Page18
Easy Clean
Only when using unloaded
appliance.
Machine Care 70°C None
Note:The relatively long running time
in the Eco50° programme is due to
longer soaking and drying times. This
results in optimal consumption val-
ues.
Information for test institutes
Test institutes are provided with in-
formation for comparability tests, e.g.
according to EN60436.
These are the conditions for conduct-
ing the tests, however they are not
the results or consumption values.
E-mail enquiries to: dishwasher@test-
appliances.com
The product number (E-Nr.) and the
production number (FD) are required
here. They can be found on the rat-
ing plate on the appliance door.
Additional functions
Additional functions
Additional functions
You can find an overview of the addi-
tional functions that can be selected
here. Different additional functions,
which can be found on the control
panel of your appliance, are available
depending on the appliance configur-
ation.
Additional func-
tion
Use
Speed
¡The run time is
shortened by 15% to
75% depending on the
rinse programme.
¡The additional function
can be activated before
the start of the pro-
gramme and at any
time when the pro-
gramme is running.
¡Energy and water con-
sumption are increased.
Power Zone
¡Switch on with mixed
loads containing table-
ware with different soil-
ing levels, e.g. place
very soiled pots and
pans in the bottom bas-
ket and normally soiled
tableware in the upper
basket.
¡The spray pressure in
the bottom basket is in-
creased and the max-
imum programme tem-
perature held longer.
This will increase the
run time and energy
consumption.

Features en
19
Additional func-
tion
Use
Extra Dry
¡For a better drying res-
ult the final rinse tem-
perature is increased
and the drying phase
extended.
¡Especially suitable for
drying plastic parts.
¡There is a slight in-
crease in energy con-
sumption and the run
time is extended.
Features
Features
Features
You can find an overview of the pos-
sible features of your appliance and
how to use them here.
These features depend on the model
of your appliance.
Top basket
Arrange cups, glasses and small
items of tableware in the top basket.
Bottom basket
Arrange pans and plates in the bot-
tom basket.
a
Cutlery basket 1
Large plates up to a diameter of
31cm can be arranged in the bottom
basket as shown.
1Depending on the appliance specifications

en Features
20
Cutlery basket
Arrange cutlery in the cutlery basket,
always without sorting it and with the
sharp points downwards.
Etagere
Use the cutlery shelf and space un-
derneath for small cups and glasses
or for large items of cutlery, e.g.
cooking spoons or serving cutlery.
If you do not need the cutlery shelf,
you can fold it up.
Baking sheet spray head
Use the baking sheet spray head to
clean large items of tableware, e.g.
trays, grilles and plates.
Arrange max. 2baking sheets and
2grilles as shown to ensure that the
spray jet can reach all parts.
Note:Check that the appliance is al-
ways operated with the top basket or
the baking sheet spray head.
Inserting baking sheet spray head
Use the baking sheet spray head in-
stead of the top basket to clean large
trays, grilles and plates.
1. Remove top basket.
2. Insert the baking sheet spray head
in the holder and turn to the
right ⁠.
aThe baking sheet spray head
clicks into position.
