Nematron LM9001 User manual

Analog Flat Panel Monitor
Regular and High Brightness
Installation and Operations Manual
For use with models:
LM9001 LM8001 LM6001
LM9006 LM8006 LM6006
LS9001 LS8001 LS6001
LS9006 LS8006 LS6006
DOC-I S-641
Nematron Corporation
5840 Interfa e Drive
Ann Arbor, MI 48103
Copyright © 2002 Nematron Corporation

Copyright Notice
This document and product is copyrighted, August 2002 by Nematron Corporation. All rights
are reserved. No part of this manual may be reproduced, copied, or translated without
permission from Nematron Corporation.
The information provided in this document is for reference only. We do not assume any
responsibility arising out of the application of the products. This manual is sub ect to change
without notice.

Analog Monitor User Guide
1
Table of Contents
Chapter 1: Product Information 3
1.1 General Product Specifications .................................................................... 3
1.2 LM9000 / LS9000 (17-inch) .......................................................................... 4
1.2.1 Dimensions.......................................................................................... 4
1.2.2 LM9000 Specifications........................................................................ 5
1.2.3 LS9000 Specifications ........................................................................ 5
1.2.4 Optional Touchscreen......................................................................... 6
1.2.5 Environmental ..................................................................................... 6
1.3 LM8000 / LS8000 (15-inch) .......................................................................... 7
1.3.1 Dimensions.......................................................................................... 7
1.3.2 LM8000 Specifications........................................................................ 8
1.3.3 LS8000 Specifications ........................................................................ 8
1.3.4 Optional Touchscreen......................................................................... 9
1.3.5 Environmental ..................................................................................... 9
1.4 LM6000 / LS6000 (12.1-inch) ..................................................................... 10
1.4.1 Dimensions........................................................................................ 10
1.4.2 LM6000 Specifications...................................................................... 11
1.4.3 LS6000 Specifications ...................................................................... 11
1.4.4 Optional Touchscreen....................................................................... 12
1.4.5 Environmental ................................................................................... 12
Chapter 2: Monitor Installation 13
2.1 Cable Connections...................................................................................... 13
2.1.1 LCD without Touch Screen............................................................... 13
2.1.2 LCD with Touch Screen.................................................................... 14
2.2 Panel Mounting ........................................................................................... 15
2.3 Arm Mounting .............................................................................................. 16
2.4 Wall Mounting.............................................................................................. 17
2.4.1 LM9000 / LS9000 (17-inch) Wallmount ........................................... 18
2.4.2 LM8000 / LS8000 (15-inch) Wallmount ........................................... 18
2.4.3 LM6000 / LS6000 (12.1-inch) Wallmount ........................................ 19
2.5 Rack Mounting............................................................................................. 20
2.5.1 LM9000 / LS9000 (17-inch) Rackmount .......................................... 20
LM8000 / LS8000 (15-inch) Rackmount ................................................... 20
2.5.3 LM6000 / LS6000 (12.1-inch) Rackmount....................................... 21
Chapter 3: User Mode OS Information 22
3.1 LM9000 / LS9000 and LM8000 / LS8000 .................................................. 22
3.1.1 Features ............................................................................................ 22
3.1.2 Button Functions ............................................................................... 23
3.1.3 User Mode OSD Structure................................................................ 24
3.1.4 User Mode OSD Item Description.................................................... 25
3.2 LM6000 / LS6000........................................................................................ 26
3.2.1 Features ............................................................................................ 26

Analog Monitor User Guide
2
3.2.2 Button Functions............................................................................... 27
3.2.3 User Mode OSD Structure ............................................................... 27
3.2.4 User Mode OSD Item Description.................................................... 29

Analog Monitor User Guide
3
Chapter 1: Product Information
1.1 General Product Specifications
Nematron Analog Flat Panel Industrial Monitors offer three different display sizes and resolutions, two
different brightness options and multiple mounting options to meet your needs. All of these flat panel
monitors are specially designed to meet the requirements of industrial en ironments.
• Suitable for panel mounting and 75/100mm interface pads for arm mounting (conform to the
proposed VESA standard)
• Panel Interface for 15” and 17” models: DVI and Analog VGA signal (by AV-0911 DVI and
Analog VGA to Digital LCD Interface Board)
• Panel Interface for 12.1” model: Analog VGA signal (by AV-9261 Analog VGA to Digital
LCD Interface Board)
• DVI (Digital Video Interface) input (optional for 15” and 17” models only)
o Sync Detect: for Plug & Display.
o Cable Distance Support: o er 3m with twisted-pair
o Compliant with DVI 1.0: DVI is backwards compatible with VESA® P&D™ and
DFP.
• Front On Screen Display (OSD) control keys to adjust for the best display quality.
• Side cabling design to reduce the LCD monitor’s total depth
• Aluminum front panel
• Ships with power adapter for 100-240 VAC input

Analog Monitor User Guide
4
1.2 LM9000 / LS9000 (17-inch)
1.2.1 imensions
The following diagrams indicate the dimensions of LM9000. The depth of the High Brightness LS9000
is 70.8 mm rather than the 50.8 mm shown for the LM9000.
Width Height Depth
Bezel 17.80 in (452.0 mm) 14.00 in (355.5 mm) 0.39 in (10.0 mm)
Chassis, LM9000 16.61 in (422.0 mm) 12.90 in (327.6 mm) 2.00 in (50.8 mm)
Chassis, LS9000 16.61 in (422.0 mm) 12.90 in (327.6 mm) 2.79 in (70.8 mm)
Cutout 16.69 in (424.0 mm) 12.97 in (329.5 mm) n/a

Analog Monitor User Guide
5
1.2.2 LM9000 Specifications
Display Model
17” LCD
Support digital input by DVI connector and
VGA connector
Resolution: 1280 x 1024
Max. Colors: 16.7 million
Brightness: 250cd/m2
Vertical iewing angle: 160°
Horizontal iewing angle: 160°
LCD MTBF: 50,000 hrs
Backlight MTBF: 25,000 hrs
Po er Supply
Input requirements:
Input Voltage range: 90 to 264 VAC
Line frequency: 47 to 63 HZ
Output:
Output Voltage range: +12V ±0.5V, 3.8A,
45 Watt
Ripple and Noise: Voltage 120 m P
EMI emissions:
The power supply meets the radiated and
conducted emission requirements for
CISPR22 CLASS B and FCC CLASS B.
MTBF:
When the power supply is operated within
any of the limits of this power supply’s
specification, the MTBF shall be at least
(50,000) hours at 25° C.
System Power Consumption: 12V / 1.8A
(not including touchscreen)
1.2.3 LS9000 Specifications
Display Model
17” High Brightness LCD
Support digital input by DVI connector and
VGA connector
Resolution: 1280 x 1024
Max. Colors: 16.7 million
Brightness: 725 cd/m2
Horizontal iewing angle: 160°
Vertical iewing angle: 160°
LCD MTBF: 50,000 hrs
Backlight MTBF: 20,000 hrs
Po er Supply
Input requirements:
Input Voltage range: 100 to 240 VAC
Line frequency: 47 to 63 HZ; 1.9A
Output:
Output Voltage range: +12V ±1.0V, 7.27A,
80 Watt
Ripple and Noise: Voltage 120 m P
EMI emissions:
The power supply meets the radiated and
conducted emission requirements for
CISPR22 CLASS B and FCC CLASS B.
MTBF:
When the power supply is operated within
any of the limits of this power supply’s
specification, the MTBF shall be at least
(50,000) hours at 25° C.
System Power Consumption: 12V / 4.8A
(not including touchscreen)

Analog Monitor User Guide
6
1.2.4 Optional Touchscreen
17” Touch Screen
Type: Analog Resisti e
Resolution: Continuous
Light transmission: Typical alue 75%
Surface Hardness: 4H or more (Test according to: ASTM D3363-92A)
8-wire touch screen
Touch screen interface: RS-232
Supported operating systems: Linux, MS-DOS, Windows 3.1, Windows 95/98/ME, Windows
NT/2000/XP, OS/2, Macintosh.
1.2.5 Environmental
LM9000 Operating Temperature: 0 to 50° C
LS9000 Operating Temperature: 0 to 40° C
Relati e Humidity: 10 to 95%, non-condensing
Storage Temperature: -20 to 60° C
Vibration: 5-17Hz, 0.1" double amplitude displacement; 17-640Hz, 1.5G acceleration peak to peak
Shock: 10G acceleration peak to peak

Analog Monitor User Guide
7
1.3 LM8000 / LS8000 (15-inch)
1.3.1 imensions
The following diagram indicates the dimensions of LM8000. The depth of the High Brightness
LS8000 is 56.1 mm rather than the 43.7 mm shown for the LM8000.
Width Height Depth
Bezel 16.14 in (410.0 mm) 12.17 in (309.0 mm) 0.35 in (9.0 mm)
Chassis, LM8000 15.10 in (383.6 mm) 11.13 in (282.6 mm) 1.84 in (46.7 mm)
Chassis, LS8000 15.10 in (383.6 mm) 11.13 in (282.6 mm) 2.21 in (56.1 mm)
Cutout 15.23 in (386.8 mm) 11.25 in (285.8 mm) n/a

Analog Monitor User Guide
8
1.3.2 LM8000 Specifications
Display Model
15” TFT LCD
Resolution: 1024 x 768
MAX. Colors: 16.7 M
Luminance: 200 cd/m2
Operating Temperature: 0 to 50° C
Storage Temperature: -20 to 60° C
Viewing Angle: R/L: 120°, U/D: 100°
LCD MTBF: 50,000 hrs
Backlight MTBF: 25,000 hrs
Po er Supply
Input requirements:
Input Voltage range: 90 to 264 VAC.
Line frequency: 47 to 63 HZ.
In-Rush current: 80 A max.
Input current: 1.4 A max.
Output:
Output Voltage range: +11.4V to +12.6V
(tolerance: ±5%) 3.8A 45 Watt
Ripple and Noise: Voltage +12V
Maximum peak to peak ripple and noise:
120mV
EMI emissions:
The power supply meets the radiated and
conducted emission requirements for a
(CISPR22 CLASS B) and a (FCC CLASS
B).
MTBF:
When the supply is operated within any of
the limits of this power supply’s
specification, the MTBF shall be at least
(50,000) hours at 25° C.
System Power Consumption: 12V / 1.2A
1.3.3 LS8000 Specifications
Display Model
15” high brightness TFT LCD
Resolution: 1024 x 768
MAX. Colors: 16.7 M
Luminance: 1750 cd/m2
Viewing Angle (degree): R/L:120 U/D:100
LCD MTBF: 50,000 hrs
Backlight MTBF: 30,000 hrs
Po er Supply
Input requirements:
Input Voltage range: 90 to 264 VAC.
Line frequency: 47 to 63 HZ.
In-Rush current: 30A max @ 115VAC, 60A
max@230VAC at 25° C.
Input current: 1.5 A max @ 115VAC, 0.8A
max@230VAC.
Output:
Output Voltage range: +12V ±0.5V 3.8A 45
Watt
Ripple and Noise: Voltage 120 m P
EMI emissions:
The power supply meets the radiated and
conducted emission requirements for
CISPR22 CLASS B and FCC CLASS B.
MTBF:
When the supply is operated within any of
the limits of this power supply’s
specification, the MTBF shall be at least
(50,000) hours at 25° C.
System Power Consumption: 12V / 4.3A

Analog Monitor User Guide
9
1.3.4 Optional Touchscreen
15” Touch Screen
Type: Analog Resisti e
Resolution: Continuous
Light transmission: Typical alue 75%
Surface Hardness: 4H (Test condition: ASTM D3363-92A)
8-wire touch screen
Touch screen controller: RS-232
Supported operating systems: Linux, MS-DOS, Windows 3.1, Windows 95/98/ME, Windows
NT/2000/XP, OS/2, Macintosh, etc.
1.3.5 Environmental
LM8000 Operating Temperature: 0 - 50° C
LS8000 Operating Temperature: 0 - 40° C
Relati e Humidity: 10 – 95%, non-condensing
Storage Temperature: -20 - 60° C
Vibration: 5-17Hz, 0.1" double amplitude displacement; 17-640Hz, 1.5G acceleration peak to peak
Shock: 10G acceleration peak to peak

Analog Monitor User Guide
10
1.4 LM6000 / LS6000 (12.1-inch)
1.4.1 imensions
The following diagrams indicate the dimensions of LM6000. The depth of the High Brightness LS6000
is 56.6 mm rather than the 43.7 mm shown for the LM6000.
Width Height Depth
Bezel 13.39 in (340.0 mm) 10.24 in (260.0 mm) 0.35 in (9.0 mm)
Chassis, LM6000 12.20 in (310.0 mm) 9.06 in (230.0 mm) 1.72 in (43.7 mm)
Chassis, LS6000 12.20 in (310.0 mm) 9.06 in (230.0 mm) 2.23 in (56.6 mm)
Cutout 12.28 in (312.0 mm) 9.13 in (232.0 mm) n/a

Analog Monitor User Guide
11
1.4.2 LM6000 Specifications
Display Model
12.1” TFT
Resolution: 800 x 600
MAX. Colors: 18 bits
Luminance: 250 cd/m2
Viewing Angle (degree): R/L:180 U/D:30
LCD MTBF: 50,000 hrs
Backlight MTBF: 30,000 hrs
Po er Supply
Input requirements:
Input Voltage range: 90 to 264 VAC.
Line frequency: 47 to 63 HZ.
In-Rush current: 80 A max.
Input current: 1.4 A max.
Output:
Output Voltage range: +11.4V to +12.6V
(tolerance: ±5%) 3.8A 45 Watt
Ripple and Noise: Voltage +12V
Maximum peak to peak ripple and noise:
120mV
EMI emissions:
The power supply meets the radiated and
conducted emission requirements for
CISPR22 CLASS B and FCC CLASS B.
MTBF:
When the supply is operated within any of
the limits of this power supply’s
specification, the MTBF shall be at least
(50,000) hours at 25° C.
System Power Consumption: 12V / 1.3A
1.4.3 LS6000 Specifications
Display Model
12.1” high brightness TFT LCD
Resolution: 800X600
MAX. Colors: 18 bits
Luminance: 1308 cd/m2
Viewing Angle (degree): R/L:180 U/D:30
LCD MTBF: 50,000 hrs
Backlight MTBF: 20,000 hrs
Po er Supply
Input requirements:
Input Voltage range: 90 to 264 VAC.
Line frequency: 47 to 63 HZ.
In-Rush current: 30A max @ 115VAC, 60A
max@230VAC at 25° C.
Input current: 1.5 A max @ 115VAC, 0.8A
max@230VAC.
Output:
Output Voltage range: +12V ±0.5V 3.8A 45
Watt
Ripple and Noise: Voltage 120 m P
EMI emissions:
The power supply meets the radiated and
conducted emission requirements for a
(CISPR22 CLASS B) and a (FCC CLASS
B).
MTBF:
When the supply is operated within any of
the limits of this power supply’s
specification, the MTBF shall be at least
(50,000) hours at 25° C.
System Power Consumption: 12V / 2.4A
(not including touchscreen)

Analog Monitor User Guide
12
1.4.4 Optional Touchscreen
12.1” Touch Screen
Type: Analog Resisti e
Resolution: Continuous
Light transmission: Typical alue 75%
Surface Hardness: 4H (Test condition: ASTM D3363-92A)
8-wire touch screen
Touch screen controller: RS-232
Supported operating systems: Linux, MS-DOS, Windows 3.1, Windows 95/98/ME, Windows
NT/2000/XP, OS/2, Macintosh, etc.
1.4.5 Environmental
LM6000 Operating Temperature: 0 to 50° C
LS6000 Operating Temperature: 0 to 40° C
Relati e Humidity: 10 to 95%, non-condensing
Storage Temperature: -20 to 60° C
Vibration: 5-17Hz, 0.1" double amplitude displacement; 17-640Hz, 1.5G acceleration peak to peak
Shock: 10G acceleration peak to peak

Analog Monitor User Guide
13
Chapter 2: Monitor Installation
Nematron Analog Monitors are ery easy to install. As you set up your system, please refer to the
following procedures.
2.1 Cable Connections
2.1.1 LC without Touch Screen
If you want to install LCD without Touch Screen, just connect the VGA cable from LCD connector to
the system VGA Signal Input port. The power connection you can choose to use the 12VDC jack (with
a 12VDC power adaptor that ship with each unit) or the terminal block. In the terminal block
connector, 12V or 24C DC inputs are a ailable.

Analog Monitor User Guide
14
2.1.2 LC with Touch Screen
If you want to install LCD with Touch Screen, please connect RS-232 connector from LCD to your
COM port on the PC. The dri er for the touchscreen is pro ided on the CD, which ships with the
Monitor.

Analog Monitor User Guide
15
2.2 Panel Mounting
Nematron Analog Monitors are suitable for panel mounting. As you mount this flat panel display,
please refer to the diagram below. Care should be taken in applying torque to the clips. An alternating
pattern of tightening the clips should be used so that e en compression of the perimeter gasket is
achie ed. Only about 50% compression is required on that gasket to achie e a NEMA 4 seal. Take care
not to apply too much torque as damage can be caused to the front panel.
Product Cutout Width Cutout Height
LM/LS9000 424.0 mm 329.5 mm
LM/LS8000 386.8 mm 285.8 mm
LM/LS6000 312.0 mm 232.0 mm

Analog Monitor User Guide
16
2.3 Arm Mounting
Nematron Analog Monitors are suitable for 75/100mm interface pads or for arm mounting and can be
pro ided with an optional Arm Mounting Kit. Arm mounting and the specification conform to the
proposed VESA standard.

Analog Monitor User Guide
17
2.4 Wall Mounting
Nematron Analog Monitors are suitable for wall mounting. The components required for this mounting
method are pro ided with each unit.
Step 1: Measure and mark placement of brackets based on display size.
Step 2: Drill and fasten wall-mount brackets.
Step 3: Mount monitor on wall-mount brackets.
Step 4: Install wall-mount ibration kit bracket.

Analog Monitor User Guide
18
2.4.1 LM9000 / LS9000 (17-inch) Wallmount
2.4.2 LM8000 / LS8000 (15-inch) Wallmount
