Nemco 7030A User manual

NEMCO Cone Baker
Model Series: 7030A, 7030A-208, 7030A-2, 7030A-2208, 7030A-240, 7030A-2240
OPERAT NG NSTRUCT ONS
NTRODUCT ON
1. Please read instructions before using this appliance.
2. When using electrical appliances, always followed basic precautions to reduce the risk of fire, electric shock and injury to persons.
3. Clean machine thoroughly before and after all uses using cleaning instructions below.
SAFETY NSTRUCT ONS
1. Plug electrical cord into a certified electrical outlet with a corresponding oltage rating as listed on the machine model labels.
2. Always unplug the electric cord when appliance is not in use and before cleaning, adjusting or maintaining this machine. Do not
operate with a damaged cord or plug or after the machine malfunctions, has been dropped or damaged. Use authorized ser ice for
examination, electrical or mechanical adjustment or repair.
3. This machine will be HOT during use and for a short time after it is turned off – BE CAREFUL. To a oid burns, do not let bare skin
touch hot surfaces. If pro ided, use handles when mo ing this appliance. Keep combustible materials away from appliance.
4. Use extreme caution when any appliance is used by or near children and whene er the appliance is left operating and unattended.
5. This appliance is not intended for use near or around water. Ne er locate appliance where it may fall into a water container.
ELECTR CAL REQU REMENTS
Refer to the product tag (serial plate) on the back of the unit for oltage and wattage requirements. Be sure to plug unit into grounded
outlet with sufficient power.
PREPARAT ON AND PROGRAMM NG T ME AND TEMPERATURE
1. Set unit on a flat surface.
2. Position unit near the power outlet. A oid the use of extension cords. Do not run cord under carpeting or co er with runners or the
like. Arrange cord where it will not be tripped o er.
3. This appliance has hot and li e electrical parts. Do not use it in areas where gasoline, paint or flammable liquids are used or stored
4. Clean unit thoroughly before use.
5. If unit fails to work properly when first operated call NEMCO customer ser ice at 1-800-782-6761.
NOTE: The unit is factory set at 385 degrees Fahrenheit for 1 minute.
6. The following steps may be taken to alter factory pre-programmed settings for both time and temperature.
7. A cycle may be cancelled by depressing and holding the “ start/stop “ button for 3 seconds.
8. To change the pre-programmed time; simply press and hold the “ minute” button until colon disappears; roughly 10 seconds. The
“ minutes” button will scroll settings up, and the “ seconds” button will scroll settings down. By holding the buttons down, the
settings will scroll quickly.
9. To change the pre-programmed temperature setting; press and hold the “ start/stop” button until colon disappears; roughly 10
seconds. NOTE: Temperature is displayed in degrees Fahrenheit.
10. When changes are done, press the “ start/stop” button and the changes will be stored. Any and all changes will be stored in the
unit and will not be affected by power supply.
NOTE: On 7030-2 units both sides are independent.
STARTUP AND SEASON NG THE GR DS
1. Wash the machine before using.
2. For best results and to eliminate sticking on aluminum grids, the grids should be seasoned following the steps below. Any good
nonstick agent will work. It will be necessary to re-coat from time to time.
3. Coat only new or clean grids.
4. Spray the grid surface and allow to “ dry” for at least 30 minutes.
5. Turn baker on for at least 30 minutes.
6. Baker is now ready to use.
OPERAT ON
1. Push on-off switch to the “ ON” position.
2. L.E.D. display will read “ LO”, indicating the grids ha e not reached the set point temperature.
3. Time cycle will be displayed once temperature has been reached, approximately 15 minutes.
4. Open grids and pour batter on lower grid.
5. When timer reaches 0:00, the alarm will sound for 10 seconds. Pushing the “ Start/Stop” button will stop the beeping.
6. Open grids and remo e waffle.
7. To disconnect appliance, turn controls to off and remo e plug from outlet.
MPORTANT:
1. Frequent use of egetable oil or non-stick agents on grids will contribute to carbon build up.
2. Keep grids clean as an abundance of oil coating and carbon build up has an insulating effect and will increase preheat and cooking
time.
3. When the baker is not in use, keep grids closed to pre ent heat loss.

2
CLEAN NG
NOTE: Proper maintenance plays an important part in the life span and functioning of the unit
1. CAUT ON: Unplug the power cord from electrical source before cleaning.
2. Do not immerse in water or other liquid.
3. Wash grids with soft brush.
4. Wipe down unit using a damp cloth or sponge and hot detergent water.
5. Rinse by wiping with a damp cloth.
6. Wipe dry.
7. HEAV LY CARBONED GR DS – may need to use a carbon build-up cleaner, such as Sok- Off. CAUT ON: - USE ONLY “SAFE
FOR ALUM NUM” CLEANERS OR PERMANENT DAMAGE MAY RESULT. CONSULT SPEC F C NSTRUCT ON FOR EACH
CLEANER FOR PROPER USE.
8. Grids will need to be re-seasoned.
9. Be careful to not allow case to get wet, doing so will damage digital control circuit.
10. For seasoning – see abo e.
Waffle Baker 7030 Series
Service Parts List
45063 2 Acorn Nut
45375 1 Strain Relief
45741 2 Cotter Pin
45966 4 Leg, Le eling
46060 5 Unlock Nut
46303 2 Compression Spring
46380 2 Terminal Adapter
46390 1 Power Cord 240 Volt
47420 1 Rocker Switch
77020 1 Spring Handle Assembly
1 Power Cord Assembly 120 Volt (77096)
77112 1 Spring Handle Insulating Washer
48265-1 1 Digital Control Board
48265-1240 1 Digital Control Board
77415 1 Thermistor with Bracket
77257 1 Hinge Pin
77258 2 Waffle Grid Top
77036-1 1 Heating Element 120 Volt/400 Watt
77036-2 1 Heating Element 120 Volt/490 Watt
77122-1 1 Heating Element 240 Volt/400 Watt
77122-2 1 Heating Element 240 V/490 Watt
77204-1 1 Heating Element 208 Volt/400 Watt
77204-2 1 Heating Element 208 V/490 Watt
W7000A 1 Wire Set
NEMCO FOOD EQU PMENT 301 Meuse Argonne, Hicks ille, OH 43526
1-800-782-6761 Toll Free 419-542-6690 Fax 46033
www.nemcofoodequip.com 10-23-13
