NTCS Series Full-automatic
Computer Wire Stripping Machine
Operation Manual
(FOR NTCS 16)

1. Straightening frame: wire straightening effect
2. Pressure adjusting knob of the cable-in wheel:adjust the pressure
between the two wheels of the cable-in wheel, pull out the knob to rotate

OPERATION MANUAL
3
5. Inlet hole seat: fixed catheter, move up and down to adjust the center
position of the catheter and blade.
6. Feeder wheel lift function: rotate the feeder wheel counterclockwise,
and rotate the feeder wheel clockwise.
7. Wire feed wheel: The motor drives the wire feed wheel to rotate so that
the wire material moves forward and backward, and cooperates with the
function of the wire feed and stripping head of the knife holder.
8. Pipe seat: fixed catheter function, can be adjusted up and down so that
the front and rear rollers and catheter become a center line.
9. Pipe: The wire penetrates into the catheter and enters the knife edge to
fix the wire, at the center of the upper and lower knife edges.
10. Knife holder assembly cover: protect debris from entering the knife
holder assembly.
11. Blade: It is divided into upper and lower pieces, the upper part of the
short device and the lower part of the long device. The two pieces are one
piece. The upper and lower blades are vertical when the device isinstalled.
12. Outgoing wheel: The motor drives the outgoing wheel to rotate to
make the wire harness move forward and backward, and cooperates with
the function of exiting and stripping the knife holder.
13. The outlet wheel lifting function: rotate the outlet wheel clockwise,
and rotate the outlet wheel counterclockwise.
14. Outlet wheel clearance adjustment knob: The clearance of the outlet

OPERATION MANUAL
4
wheel increases when it is rotated upward, and decreases when it is
rotated downward.
15. Outlet wheel pressure adjustment knob: adjust the pressure between
the two wheels of the outlet wheel, pull out the knob to rotate
counterclockwise to increase the pressure, turn clockwise to decrease the
pressure, adjust the appropriate pressure and push it inward to fix it.
16. Display: adjust the parameters of the wire to be processed.
17. Start: When the data input is completed without error, press [Start] to
make the machine work.
18. Stop: Press [Stop] to stop the machine.
19. Emergency stop: When the machine is in working state, press
[Emergency Stop], the machine will stop working urgently.
▼ Note that before the power is turned off, no matter the machine is
working or stopped, the blade cannot be approached by hand.

OPERATION MANUAL
5
Part 2: Operation of the
computer
Picture 1
1.1. Program: store parameters from 0-99 program serial numbers.
1.2 UPH: to wait.
1.3. FORWARD: Thread the thread into the cable entry hole until the
cable entry roller. Press the [Thread entry] roller to automatically feed the
thread forward.
1.4 REVERSE: Press [Return] wheel to automatically retreat the line
backward.
1.5. SINGLE STEP / SINGLE CYCLE / Full automatic: Press the start
button to run a single action in the case of inching, press the start button
to run a complete action in the test machine, and press the start button to
continue the operation in the fully automatic case.
1.6. Start: When the data input is completed without error, press [Start] to

OPERATION MANUAL
6
make the machine work.
1.7. Stop: Press [Stop] to stop the machine.
1.8. Reset: Make each part of the machine return to the origin.
1.9 Emergency stop: When the machine is in working state, press
[Emergency Stop], the machine will stop working urgently.
1.10. Length: The total length of the cutting wire, the unit is mm.
1.11. Strip Len: The required length of the wire end.
1.12. Strip Off: The length of the stripping of the wire at the tip of
the wire. If the stripping parameter is less than the threading parameter, it
is called half stripping. If the stripping parameter is greater than the
threading parameter, it is called full stripping.
1.13. Strip Len: the required length of the end of the wire.
1.14. Strip Off: The length of the stripping of the rubber at the end of the
wire. If the tail stripping parameter is less than the wire tail parameter,it is
called half stripping.
1.15. Cutter dia: refers to the cutting section of the number of steps
transmitted by the knife holder drive motor, and controls the cutting depth
of the wire end and the tail. Then, the smaller the upper and lower knife
openings, the deeper the cutting depth. The opening distance of the upper
and lower knife edges is calculated in millimeters. The diameter of the
core wire of the wire is mm, and the diameter of the wire is entered as
much as mm.

OPERATION MANUAL
7
1.16. Cutter Back: Refers to the blade cutting into a certain depth and
retreating to a certain size to avoid the core wire being scratched. The size
of the retreat is determined according to the thickness of the wire rubber.
The thicker the rubber is, the larger the retreat is. ~ 5.0mm.
1.17. Set Count: refers to the total output of set work. The input data
cannot be less than the quantitative input data. If the data is less than the
quantitative data, the machine will not work.
1.18. Finished: cumulative production quantity.
1.19. Set Batch: how many parameters the machine operates and how
many times the machine automatically stops. If you enter 100 machines
to 100 times, it will automatically stop. Enter 0 for no quantitative data,
the machine will not automatically stop, and the data will reach the set
total amount. Downtime.
1.20. Batch Delay: When the machine reaches the specified amount, how
many seconds will it delay, and it will start automatically and continue to
run.

2.1. Cutter: Press the forward button to close the upper and lower blades

OPERATION MANUAL
9
Parameter settings:
Picture 3
3.1 Roller speed: refers to the motor feed roller speed of 00-99, 00 is the
slowest and 99 is the fastest.
3.2. Cutter speed: refers to the cutting speed of the knife holder driven by
the motor, the speed is 00-99, 00 is the slowest and 99 is the fastest.
3.3 Strip speed: refers to the speed at which the rubber peels off. The
slower the speed, the greater the peeling force, and the faster the speed,
the smaller the peeling force.
3.3. Cut Down SPD: Refers to the speed at which the upper and lower
blades touch the wire until cutting, the speed is 00-99, 00 is the fastest,
and 99 is the slowest.
3.4 Air Blow time: Each blowing time is adjustable.

OPERATION MANUAL
11
MIDDLE STRIP
Picture 5
MIDCUT: on / off
5.1. DIA MODIFY: when the middle stripping wire and the copper
wire are too tight to be stripped, the cutting depth of the middle
stripping can be slightly increased.
For example, 0.1 means 0.1+ 【Picture 1】wire diameter.
5.2. LENGTH MODIFY: the last end is provided with a liner on the
top, and the total length can be finely adjusted to remove the liner.
5.3. POS 01: The length of the cut wire from the wire to the first
place in the middle; Stripping: The peeling distance from the first
place in the middle.
5.4, POS 02: The length of the skin cut from the top of the wire to
the second place in the middle; Stripping: The stripping distance
from the second place in the middle.
By analogy ...
