Nemo GO AVA01 User manual

AVA01
handsfree flushing

What's inside
the box ?
1. Sensor/push button
2. The battery box
3. Controller / Air pump
4. Overflow pipe
5. Flush body
6. Rubber washer
7. Nut
8. Air tubes
9. 4 AA batteries (weren't
included with the sample)
1
2
3
4
9
5
6
7
8
8

Prep work
1. Turn off the water suply to the toilet
2. Decouple the flexible
3. Look inside the cistern and measure how
high the water is (you'll need this later when
adjusting the overflow pipe)
4. Flush, do that until all the water is gone from
the cistern
5. Use a cloth to remove the remaining water that
sits at the bottom of the cistern

First step
Unscrew the lid of the battery
box (1 screw) using a screw driver

Second step
Look for the yellow stickers
inside the battery box and
insert the 4 batteries as
depicted on each sticker.

Second step TIP
When closing the lid of the
battery box make sure the
springs in the lid match the "+"
and "-" of the batteries, then
screw shut.

Third step
Dismount the cistern from the
toilet.

Fourth step
Dismount the old flushing
mechanism from the cistern,
old mechanism can be hard to
dismount.

Fifth step
Unscrew the nut and detach
the transparant ring from the
flush body, leave the rubber
washer on the flush body.

Sixth step
Mount the controller with the
battery box on the overflow
pipe and insert it into the
cistern.

Seventh step
Mount the nut
together with the
transparant ring
on the outside
of the cistern.

Eighth step
Place the o-ring from the old
flushing mechanism (if it is
still usable) over the nut on the
bottom of the cistern.

Ninth step
Mount the cistern back on the
toilet.

Tenth step
Remove the controller with the
battery box from the overflow
pipe and adjust the overflow
pipe by rotating it.
Match the height of the
overflow pipe with the height
of the water inside the cistern
and put the controller with the
battery box back in place.

Eleventh step
Carefully remove the nut from
the sensor/push button.

Twelveth step
Place the sensor/push button
on top of the lid, screw the nut
back on.

Thirteenth step
Slide the transparant tube over
the protrusion found on the
button piece.

Fourteenth step
Connect the electrical wires
(black with black and red with
red).
From this point on the sensor/
push button is active.

Fifteenth step
Peel of the plastic cover on top
of the button.
READY TO GO !

Using the sensor
Move your hand over the sensor
You should see a blue ring
appear when the sensor is
activated.
Cover short time = long flush
Cover longer time = short flush
