NENKO MOD02 User manual

Module Installation General
1. For mounting we recommend the following tools: Impact drill with possibly drill 6 mm for drilling holes
for supplied wall plugs. Please note that this applies to stone walls in particular. With other types of
walls, plugs can either be omitted to screw directly into the wall and with plaster walls, for example,
plugs must be purchased suitable for wall on site. From an aesthetic point of view, you can also choose
to omit the included installation kits and attach the mirrors as well as wall mats with mounting kit and
caulking gun. Furthermore, you will need, a hammer for entering the dowels/plugs into the wall, a
tape measure with pencil for marking the holes in the wall and a screwdriver for fixing the screws in
both wall and on the back of the mirrors or wall mats.

2. When purchasing optional fiber optics with light source, take this base, remove the bubble
unit lid and tilt it for easy access from the bottom. Position the light source with fiber optics
(first mount the fiber optics in the light source as described in the manual of this product)
into the base against the top side a few centimeters from the recess of the bubble unit lid
and slide fibers through half round recess so that you can be sure that the lid can be placed
on the base and the fiber optics strands can pass through the half roundness. Screw the light
source using 4 screws (max. 20 mm length) (not included)

3. Place the bubble unit base in the corner against the wall and remove the lid to place the
bubble unit as centrally as possible in the base on the floor. PLEASE NOTE: the bubble unit is
fragile especially at the attachment of the tube to the foot. Moving, bumping or lifting while
it is filled can lead to breakage which is not covered by warranty conditions.
Connect the supplied adapter to the bubble unit. If applicable, also attach the adapter of the
optional fiber optics light source. If desired, place an approved junction box inthe platform
where you can insert both adapters. The cable of this junction box can be passed under the
platform. Now place the lid and gently slide it down over the tube. Make sure that the lid is
easily placed in the open. Optionally, you can reposition some fiberoptic wires or do not pass
through some wires and leave them as a spare at the bottom.

4. Mount the supplied mirrors against the wall 1 by 1 with the supplied mounting brackets
and/or use a mounting kit suitable for the wall in question. First position the mirrors exactly
on the correct height so that the base (height of which is 46 cm) fits well under it. Keep in
mind that the mirrors and wall mats are the same level on the bases/platforms and
therefore have to be placed at the same height to create a continue level. Placing them too
low can cause problems placing the other platforms/bases. When using mountingkit, please
take into account that due to the weight of mirrors / mats they can drop slightly. Support or
intermediate pressing is advised when attaching with mountingkit.

5. Now mount any adjacent wall mats, in the same way as the mirrors. As described above, it is
advisable to check that the wall mats do not lower when using sealant (this depends on the
amount of type and amount of sealant used)
