USER MANUAL
30L / 40L Thermoelectric Refrigerator
Model No: 7440301 (30L), 7440401 (40L)
·Indication of parts............................................................2-3
·Instruction for use…...........................................................4
·Installation instructions...................................................... 5
·Change the swing hinge .....................................................6
· Trouble shooting guides..................................................... 6
·Electric diagram ................................................................7
·Energy saving tips .............................................................7
·Specification tables ...........................................................8
Thank you very much for buying this product. Before using your
new refrigerator, please read this user manual to ensure that
you gain the maximum benefit from it.
Backed by the Nero 3 Year Warranty

2
Up Hinge
Cabinet
Heat Pump
Heat Pump
FootLow Hinge
Door
Handle
Door Gasket
Door Inner
Shelf
Thermoelectric RefrigeratorThermoelectric Refrigerator
•Indication of Parts (7440301)
•Warning
1. •WARNING: Keep ventilation opening in the appliance enclosure or in the
built-in structure, clear of obstruction.
•WARNING: Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
•WARNING: Do not damage the refrigerant circuit.
•WARNING: Do not use electrical appliances inside the food storage compartments of
the appliance, unless they are of the type recommended by the manufacturer.
2. This appliance is intended to be used in household and similar applications such as
•staff kitchen areas in shops, offices and other working environments;
•farm houses and by clients in hotels, motels and other residential type environments;
•bed and breakfast type environments;
•catering and similar non-retail applications.
3.Please keep the products away from the fire or similar glowing substance before
you dispose the refrigerator.
4.Please remove the door before you dispose your refrigerator.
5. The appliance shall not be installed in the laundry.
6. The appliance must be positioned so that the plug is accessible.
7. The appliance shall be installed in accordance with national wiring regulations.
8. Do not store explosive substances such as aerosol cans with a flammable propellant
in this appliance.
9.This appliance can be used by children aged from 8 years and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning
and use maintenance shall not be made by children without supervision.
10. If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
11. DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of
such waste separately for special treatment is necessary.
12. This appliance including flammable refrigerant and foaming agent, you should send
it to the particular disposal station when you need.
9

3
Plastic
Shelves
Leveling Legs
Light Switch
Upper Hinge
Door Handle
Door Racks
Door Gasket
Cabinet
Heat Pump
Door
Cooling
Sheet
8
Thermoelectric RefrigeratorThermoelectric Refrigerator
•Specification Table
Model No. 7440301
220-240
CCC/ CB/ CE/ EMC & LVD
50
7440401
3040
65 65
10.1 12
11.5 13.6
380x445x475 402x445x546
430x510x520 455x495x590
Net capacity
(litres)
Voltage (V)
Frequency (Hz)
Input Power (W)
Dimension (mm)
Packing (mm)
Net Weight (kg)
Gross Weight
(kg)
Approval
•Indication of Parts (7440401)

4
•Instruction foruse•Electric Diagram
•Energy Saving Tips
§Note
§Very important
§Power supply
§Warning
•Position your refrigerator so that the plug is accessible.
•Keep your refrigerator out of direct sunlight.
•Do not place next to heat generating appliance.
•Do not place directly on the ground. Provide suitable stand
•The refrigerator willhavebetter performance at ambientof20-25degree;
we suggestthe refrigerator to be powered off if the ambient temperature is lower than
10 degree.
•Afterplugging the appliance, allow the unit to cool down for 2-3 hours before
placing beverage into the refrigerator compartment.
•Ventilation is veryimportantforthiskindof thermoelectric refrigerator.Theinside of
PCB will be broken easily if the ventilation is bad. It will also reduce the life of the
refrigerator.
•The refrigerator applies automatic defrosting system, so there is no need to defrost it
manually.
•The refrigeratormust be connected toaproperlyearthedsocketinline with
relevantvalid country regulations before operating.
•Checkthe datalabel(which is on the sideoftherefrigerator)forvoltageand
frequency corresponds to your local one, if not don't plug your cable into the socket.
•If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
•This appliance is not intended for use by persons (including children) with reduced
physical,sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
•Children should be supervised to ensure that they do not play with the appliance.
•WARNING: To avoid a hazard due to instability of the appliance, it must be fixed in
accordance with the instruction.
•The refrigerator should be located in thecoolestareaoftheroom,awayfromheat
producing appliances, and out of the direct sunlight.
•Overloading the refrigerator forces the thermoelectric cooling system to run longer.
•Reduce door openings and extended searches, remove as many item as needed
at one time.
•Onecharacteristic of thermoelectric units is thelength of timeitrequires to recover
fromhavingthe door opened and shut frequently. It may be necessary to wait longer
for the temperature to return to its former level once the door has been opened for too
long. This is normal for the type of unit.
•Thermoelectric technologycostsjust pennies to operate. It is environmentally
friendlyduetothe lack of CFC's.
7
FF
Cooling
unit
P
C
B
K
220-240V~
100-120V~
Thermoelectric RefrigeratorThermoelectric Refrigerator

65
Thermoelectric RefrigeratorThermoelectric Refrigerator
•Changing the Swing Hinge
•Trouble Shooting Guide
•Installation Instructions
This refrigerator has the capability of the door opening from either the left or right side.
The unit is delivered to you with the door opening from the left side. Should you desire to
reverse the opening direction, please follow the below instructions.
All thehinges can be used for leftorrightswing, except for model7440401, please
find an additional left upper hinge in the bag of the user manual for installation as below.
•Pull out the three screws from right hinge.
•Remove the hinge (upper and lower) away.
•Install the door in suitable position with hinges, use three self-screws to fix them.
When install a Thermoelectric Refrigerator, ventilation should be considered seriously,
please refer to the following:
•There should be left at least 200 cm³ for ventilation
•The distance between wall and refrigerator side should be at least 20mm
•The bottom should be left at least 50mm for air flowing air passing through
must not be preheated
•Entire cooling system should be considered in the ventilation
•The following four pictures show four installation ways:
Refrigerator does not operate
The light does not work
•Not plugged in.
•The circuit breaker tripped or a
blown fuse.
•The room temperature is hotter
than normal.
•The door is opened too often.
•The door is not closed completely.
•The temperature control is not
set correctly.
•The door gasket does not
seal properly.
•The refrigerator does not have the
correct clearances.
•Abnormal voltage.
•Not plugged in.
•The circuit breaker tripped or
a blown fuse.
•The LED light has burned out.
Vibrations •Check to assure that the refrigerator
is levelled
The door will not close properly •The refrigerator is not levelled.
•The door was reversed and not
properly installed.
•The gasket is dirty.
•The shelves, bins, or baskets are
out of positions.
PROBLEM POSSIBLE CAUSE
