NetComm NP3680 User manual

User Guide
NP3680
2-Port USB Print - Scanner - Storage Server

2 NP3680 User Guide
YML838 Rev 2
Contents
Chapter1 Introduction ....................................................................................................................... 4
1.1 About this Manual...................................................................................................... 4
1.2 Customer Support...................................................................................................... 4
Chapter2 Product Overview............................................................................................................... 5
2.1 Package Contents...................................................................................................... 5
2.2 Product CD................................................................................................................ 5
2.3 Physical Description................................................................................................... 6
2.4 Installation Procedures .............................................................................................. 7
2.5 Features and Benefits ............................................................................................... 8
Chapter3 Basic Installation................................................................................................................ 9
3.1 Connecting the Hardware .......................................................................................... 9
3.2 Assigning an IP Address to the Server ...................................................................... 10
Chapter4 Installing the Print Server in Windows ............................................................................... 15
4.1 Overview of Installation Methods ............................................................................. 15
4.2 Connecting the Server ............................................................................................. 16
4.3 Setting up Local Windows Printer Driver .................................................................... 17
4.4 Adding Network Printers in Windows ........................................................................ 18
Chapter5 Installing the Print Server in Unix/Linux.............................................................................. 28
5.1 Configuring Host File ............................................................................................... 28
5.2 Printing by LPD/LPR................................................................................................. 28
5.3 Using the Server on BSD UNIX/Linux ......................................................................... 29
5.4 Using the Server on RedHat Linux (Fedora Core) ...................................................... 30
Chapter6 Connecting a File Server................................................................................................... 35
6.1 Preliminary.............................................................................................................. 35
6.2 Storage Names........................................................................................................ 35
6.3 Connecting USB Mass Storage to the Server ............................................................. 35
6.4 Supported Codepages.............................................................................................. 36
6.5 Adding Your USB Mass Storages to Network with Security .......................................... 38
Chapter7 Connecting a Scanner ...................................................................................................... 43
7.1 Connecting HP All-In-One to the Server..................................................................... 43
7.2 Using the Shared Scanner in Windows ...................................................................... 43
7.3 Using the Shared Scanner in Linux............................................................................ 46
Chapter8 The Control Center .......................................................................................................... 47
8.1 Installing Control Center .......................................................................................... 47
8.2 Using the Control Center .......................................................................................... 47
8.3 Quitting the Control Center ....................................................................................... 54

NP3680 User Guide 3
YML838 Rev 2
Chapter9 The NetUSB Technology.................................................................................................... 55
9.1 Introduction............................................................................................................. 55
9.2 Link & Unlink........................................................................................................... 56
9.3 How to Use.............................................................................................................. 57
9.4 Limitations .............................................................................................................. 61
Chapter10 The Server’s Web Pages .................................................................................................. 62
10.1 Introduction............................................................................................................. 62
10.2 Using the Server’s Web Pages .................................................................................. 62
Chapter11 Email Alerting................................................................................................................... 71
Chapter12 SNMP.............................................................................................................................. 72
Chapter13 Troubleshooting ............................................................................................................... 73
13.1 LED Indicators ......................................................................................................... 73
Chapter14 Restore Factory Defaults................................................................................................... 74
14.1 Using the Control Center .......................................................................................... 74
14.2 Using the Server’s Web Pages .................................................................................. 74
14.3 Using Init Button ...................................................................................................... 74
14.4 Default Parameters List............................................................................................ 75
Chapter15 Upgrade Firmware............................................................................................................ 77
Chapter16 The Init Button ................................................................................................................. 79
APPENDIX A Cable Information............................................................................................................. 80
RJ-45 Network Ports ....................................................................................................... 80
Straight and crossover cable configuration ........................................................................ 80
Straight-Through Cabling.................................................................................................. 81
Cross-Over Cabling .......................................................................................................... 81
APPENDIX B Registration and Warranty Information............................................................................... 82
Contact Information.......................................................................................................... 82
Copyright Information ....................................................................................................... 82
Customer Information ....................................................................................................... 83

4 NP3680 User Guide
YML838 Rev 2
Chapter1 Introduction
Thank you for purchasing this NP3680 USB MFP Server (in the following referred to as “Server”). This Server
is designed to connect your AIO/MFPs (All-In-One/Multifunction Peripheral), printers, USB mass storages
(hard drives, flash drives, and memory card readers), and scanners, to your network, allowing all network
users access to these shared USB devices resources.
1.1 About this Manual
This manual provides introductory information as well as detailed instructions on how to set up and manage
NP3680 in various network environments.
To fully benefit from this document, you should be familiar with basic networking principles. The instructions
described in this manual are based on the settings in a new Server. To reload the Factory Parameters, you
can reset this Server back to Factory Default, which will restore most of the settings. For details, please refer
to the chapter “Restore Factory Defaults”.
1.2 Customer Support
Should you require any technical assistance, please contact your product reseller. Or you can visit our
website at http://www.netcomm.com.au for latest product information. This document is subject to
changes without prior notice.

NP3680 User Guide 5
YML838 Rev 2
Chapter2 Product Overview
2.1 Package Contents
Verify that nothing is missing from the package by using the check list below. Please contact your dealer
if anything is missing or damaged. All packing materials are recyclable. Please confirm the items in the
package below:
• One NetComm MFP Server
• One CD (Control Center Utility and User Documentation)
• One Power Adaptor
• One USB Cable
• One Ethernet Cable
• One Package Contents Note
2.2 Product CD
This CD provides easy-to-use Control Center software, and the User’s Manual and Quick Installation Guide.
If your computer is configured to auto start CDs, this CD will start automatically when inserted. You can also
navigate to the CD and start the autorun.exe file from within the Windows file manager.

6 NP3680 User Guide
YML838 Rev 2
2.3 Physical Description
Rear Panel
Power Adaptor Port: DC IN 5V/2A adaptor
Init Button: Print the configuration page and initialize this Server
Ethernet Port: A twisted pair category 5 cable
USB Host Ports: USB 1.1/2.0 low, full, and Hi-Speed compliant
Front Panel Indicators
Power Indicator: is lit while power is applied. If it is not lit, or if it blinks, there is a problem with this
Server or power adapter.
Link Indicator: is lit while network is applied. If it is not lit, it indicates that this server does not
connect to the network.
Status Indicator: blinks to indicate network activity.
USB1 Indicator: is lit while a USB device connects to USB1 Port of this Server. If it is not lit, or if it
blinks, there is a problem with the USB device or this Server.
USB2 Indicator: is lit while a USB device connects to USB2 Port of this Server. If it is not lit, or if it
blinks, there is a problem with the USB device or this Server.

NP3680 User Guide 7
YML838 Rev 2
2.4 Installation Procedures
2.4.1 Installation and Integration
Please refer to the table below to select the appropriate installation method. The Control Center is available
on the CD or from NetComm’ website.
Function OS Method Description
Print Server Windows Standard Windows Add
Printer Wizard
Installation of LPR, Raw
TCP (JetDirect), Local
Port Using SMB, and IPP
Control Center Tool Installation of LPR, Raw
TCP, Local Port Using
SMB
Apple MAC OS X Printer Setup Tool LPR, Raw TCP
(JetDirect) SMB, IPP
Unix/Linux Edit /etc/printcap File Using vi or other editors
to edit the printcap file
RedHat Linux Printer
System Manager
Using X-Windows
Interface to operate
File Server Windows None Don’t need installation
Apple MAC OS X None
Unix/Linux Samba Use smbclient in Samba
Scan Server Windows The Control Center Installation of SANE
Client and SANE-Twain
Driver
Apple MAC OS X Download and install
SANE
Use terminal
Unix/Linux Download and install
SANE Frontends
Use SANE Applications
such as XSANE
2.4.2 Configuration and Management
This Server can be configured and managed from its internal web pages or from the Control Center. These
web pages or PC tools offer you a management tool suitable for all supported network environments.

8 NP3680 User Guide
YML838 Rev 2
2.5 Features and Benefits
This Server provides the following features and benefits:
Reliability: The Server provides high performance and reliability combined with low power
consumption.
Flexibility: The Server supports Print/File/Scan sharing in all major computer systems and
environments.
Easy to Install: The Server installs, operates, and is managed in a reliable and easy fashion.
Security: You can assign administrator name and password to restrict login.
Monitoring: The Server’s web pages and user software allow you to continuously monitor the
status of connected USB devices.
Future Proof: The firmware stored in the Server’s Flash memory can be upgraded over the
network. This allows you to quickly update and enhance its operational features
when new Server software becomes available.

NP3680 User Guide 9
YML838 Rev 2
Chapter3 Basic Installation
3.1 Connecting the Hardware
1. Make sure that your USB devices are switched off and that the Server’s Power Adapter is disconnected.
2. Connect the USB devices to the USB ports with the USB cables.
3. Connect the Server to the network with a twisted-pair category 5 cable, 10baseT or 100baseTX.
4. Turn on the USB devices and make sure they are ready for use.
5. Connect the Power Adapter to the Server. The power indicator will light up and USB1 and USB2
indicators will flash in turn. When the Link indicator lights up, the Server is correctly connected to the
network. When the USB1 and USB2 indicators stop flashing, the Server is ready to work.
6. If you connect USB HP printers to the Server, please press the Init button for 3 seconds on the Server
once to print a page of Server configuration report.

10 NP3680 User Guide
YML838 Rev 2
3.2 Assigning an IP Address to the Server
3.2.1 Preliminary
• If you have a DHCP server on your network, your Server will receive an IP address automatically. The IP
address will then appear on the Control Center or on the page of configuration report that you printed
earlier. If your DHCP server does not give an IP address to the Server, the Server will use the Factory IP
address: 192.168.1.100.
• If you are not working in a DHCP network, you need to manually set the Server’s IP address.
• If you are connecting multiple MFP Servers, and not using a DHCP server on your network, you will need
to disconnect the other MFP Servers if they are using the default IP Address (192.168.1.100) to avoid IP
conflicts and configure the server.
3.2.2 Ethernet Address
You do not need to know the Ethernet address of your Server to assign an IP address to it. The Control Center
will automatically search for Servers and list their Ethernet addresses.
3.2.3 IP Address
Unless you are assigning an IP address using DHCP, you must obtain an unused IP address from your
network administrator.
3.2.4 Methods for Setting the IP Address
You can set the IP address of your Server using one of the following methods, depending on your network
operating environment:
• Automatic IP Address Assignment
• Manual IP Address Assignment
3.2.5 Host Names and Host Name Rules
The Host Name of the Server defaults to be “NP3680” (for NP3680). If you put two or more Servers in your
local area network, to avoid using the same Host Names you have to change the Host Names by using the
Control Center or the Server’s web pages. If your Host Name is longer than 15 characters, the Server uses
only the first 15 characters.

NP3680 User Guide 11
YML838 Rev 2
3.2.6 Setting the IP Address Using DHCP
Follow the instructions below to get an IP address using DHCP:
1. Edit or create a scope in the DHCP manager of the DHCP daemon. The entries included in this scope
should contain the following parameters:
• range of IP addresses
• subnet mask
• default router IP address
• DNS server IP address
• lease duration
2. Activate the scope. The Server automatically gets the DHCP parameters. If you are using DNS, you may
include at least one DNS server IP address in the DHCP scope or manually set the DNS server IP address
using Server’s web pages or the Control Center.
3.2.7 Setting the IP Address Using the Control Center
1. Install the Control Center. The Control Center is available on the Product CD.
2. Start the Control Center and Auto-searching Server window will appear.

12 NP3680 User Guide
YML838 Rev 2
3. If the tool finds multiple Servers in your local area network, then you have to select one Server from the
Server List.
4. Double click the server in the list and enter the Server’s administrator (default: admin) and password
(default: admin).
5. After you have logged in successfully, select the TCP/IP tab. The Set IP Address dialog appears.
6. Click the button corresponding to your choice of IP setting method (static or dynamic using DHCP). When
assigning a static IP address you also have to define Subnet Mask and Default Gateway. If you choose
Automatically get IP by DHCP, you can use desired DNS by clicking the Manual DNS button and manually
assigning a DNS.
7. Click Apply to save your settings and the Server will reboot.
8. You have now finished the procedure of setting the IP address.

NP3680 User Guide 13
YML838 Rev 2
3.2.8 Setting the IP Address Using the Server’s Web Pages
1. If you don’t know the current IP of you Server, follow Step1~Step4 of Set the IP Address Using the
Control Center.
2. You can see the IP address of you Server in the Server List. Open a Web Browser and enter the Server’s
IP address or click the Home Icon of the Control Center.
3. Go to the web page and click the CONFIG menu icon.
4. Enter administrator (default: admin) and password (default: admin).
5. Click the TCP/IP menu icon.

14 NP3680 User Guide
YML838 Rev 2
6. Click the button corresponding to your choice of IP setting methods (static or dynamic using DHCP).
When assigning a static IP address you also have to define Subnet Mask and Default Gateway.
7. Click Submit to save your settings. And the Server will reboot. You have now finished the procedure of
setting the IP address.

NP3680 User Guide 15
YML838 Rev 2
Chapter4 Installing the Print Server in Windows
4.1 Overview of Installation Methods
This chapter describes how to add network printers.
Table List for Installing Network Printer
Windows Platform Printing Protocols Method
Windows 98, ME, 2000,
XP and 2003
SMB/CIFS Printing Standard Windows Add Printer Wizard
The Control Center’s Add Printer
IPP Printing Standard Windows Add Printer Wizard
Windows 2000, XP and
2003
LPR Printing Standard Windows Add Printer Wizard
The Control Center’s Add Printer
Raw TCP/JetDirect
Printing
Standard Windows Add Printer Wizard
The Control Center’s Add Printer
Steps for Installing Network Printer
Step 1
Set up / Install the Local
Windows Printer Driver
Step 2
Connect Your Printer to the
MFP Server and Connect the
MFP Server to the Network
Step 3
Turn on Your Printer
and MFP Server
Step 4
Configure Your
MFP Server
Step 5
Add Network Printer by
Windows Standard Method
or Control Center Utility
Step 6
Turn on “Online Use Printer”
in Installed Windows
Printer Driver

16 NP3680 User Guide
YML838 Rev 2
4.2 Connecting the Server
To configure your Server correctly, you should know which type of network topology that your Server is
connecting to.
4.2.1 The Server and Windows PC on Same LAN
4.2.2 The Server and Windows PC on Different LANs
Example: Wired Windows PC across Internet
Internet

NP3680 User Guide 17
YML838 Rev 2
4.3 Setting up Local Windows Printer Driver
You are advised to install your Windows printer driver in advance. For most printers, you can install the printer
drivers with the following procedure:
1. Click Start, click Control Panel, click Printers and Other Hardware, and then click Printers and Faxes.
2. Double click Add Printer to start the Add Printer Wizard, and then click Next.
3. Click Local printer, clear the Automatically detect and install my Plug-n-Play printer check box to
avoid having to wait for the completion of another printer search, and then click Next. If you leave this
option selected, Windows will attempt to find the printer itself and figure out what kind it is. If Windows
does not find the printer, the wizard will continue as described in this task.
4. Select a Windows driver for your printer. Click Next.
5. Choose whether you want to share the printer with other network users. Do you want to print a test
page? Select the appropriate radio button and click Next and Finish.

18 NP3680 User Guide
YML838 Rev 2
4.4 Adding Network Printers in Windows
Follow the instructions below to use the standard Windows Add Printer Wizard and the Control Center for
adding a network printer in Windows 98 SE, ME, 2000, XP and 2003.
Note:
1. Before adding a network printer, you are advised to install the local Windows printer driver in
advance.
2. Before using network printer, you have to turn on “Use Printer Online” in installed network
printer driver and then you can use the printer.
4.4.1 Using Standard Windows Methods for LPR Printing Protocol
Windows Platform: Windows 2000, XP and 2003
1. Open Printers and Faxes.
2. Right-click the printer for which you want to change settings, and then click Properties/ports.
3. Clear Enable bidirectional support and click Add port, and then click Standard TCP/IP Port from the
dropdown and click New port.
4. The Add Standard TCP/IP Printer Port Wizard will pop up and click Next.
5. In the Printer Name or IP Address box, enter the Host Name of the Server (default: NP3680) or IP
address of the Server. In the Port Name box, enter your desired names or USB1_LPR or USB2_LPR for
printer connected to USB1 port and USB2 port, respectively.

NP3680 User Guide 19
YML838 Rev 2
@If your Server is running on a different LAN than your Windows PC such as Internet PC,
you must enter Server’s IP address in Printer Name or IP Address box.
6. Click Next.

20 NP3680 User Guide
YML838 Rev 2
7. Click Custom/settings.
8. Click Settings and confirm that the settings are as below. The queue names are USB1_LQ, USB2_LQ
for USB1 port 1 and USB2 port, respectively. Click OK.
9. Click Finish.
