IP CAMERAS

IP CAMERAS
YOUR EYE, ONLINE ALL THE TIME
Technology developments such as Broadband and the rise of digital
have lead to unprecedented demand for net orked video solutions.
Net orked video is made possible through IP cameras, hich allo
remote vie ing or recording of images from a Web bro ser any here,
at any time. IP Cameras use existing IP net ork infrastructure, hich
reduces installation time and costs normally associated ith the
implementation of traditional CCTV surveillance systems.
NetComm is playing a key role in the uptake of net orked video
surveillance as an alternative to traditional Closed Circuit Television
(CCTV) Systems.
A NetComm IP Camera is like any other network de ice
With its o n IP address, a NetComm IP Camera connects directly to a
standard net ork s itch or to a ireless net ork. This enables
vie ing of real time digital video over the Internet from any location.
NetComm IP Cameras use existing Network (IP) technology
By using existing IP net ork infrastructure, additional costs related to
the installation and deployment of traditional analog CCTV
surveillance systems (such as coax cabling, monitors and video
recorders) are eliminated. The flexibility of NetComm’s IP cameras
also makes it economically possible to digitally enable existing
analog CCTV systems.

PC with
Surveillance
Software Hard disk
storage
Host
Analogue cameras Motion detector
Video motion
detection #
Device Activation
Network
cameras
Switch
NAT
router
DSL
modem
Security
company
Security
manager
Police
Internet
IP Sur eillance system
NetComm IP Cameras are designed around a robust
camera platform. Under the hood is an
ingeniously embedded eb and ftp server
ith a robust UNIX-like operating system
to ensure guaranteed 24/7 operation in the
most demanding of environments.
NetComm IP Cameras are rich in features and include the following:
A state of the art on-board image processor
An inbuilt eb and FTP server
JPEG and MJPEG video compression
Real time video at maximum resolution (single vie )
Motion detection capability
3 layer pass ord protection for the camera, providing
additional security
4 external inputs and 1 output trigger to attach devices such as
motion sensors or gate control
FTP/Email/HTTP notification of alarm and event triggers
Tensile Aluminium Case for superior protection against vandals
Easy script izard to set up triggered recording and
external alarms
Interchangeable lens option to any standard CS mount lens
Easy Net ork Camera IP Installer tool & quick install guide
An extensive range of soft are options for different applications
IP CAMERA RANGE

The NS4000 is an inexpensive solution for remote monitoring of
indoor areas such as foyers, hall ays, reception areas, retail
stores or hotel lobbies. The camera features 640 x 480
resolution, real-time video at maximum resolution, a CMOS VGA
image sensor, an interchangeable cs mount lens, a COM port for
dial-up or ADSL modem connection and a GPIO port (4 input/ 1
output) to control devices such as opening doors and gates. It
also provides basic video control functions of hite balance, auto
gain control and electronic shutter.
NS4000
NS4100
The NS4100 is an indoor or outdoor remote monitoring solution.
It features a superior CCD image sensor that enables a maximum
resolution of 704 x 576, superior video control features such as
manual electronic shutter and line lock, a DC Auto Iris vari-focal
lens offering a flexible field of vie , full-motion video at
maximum resolution, a COM port for dial up or ADSL modem
connection and a GPIO port (4 input/1 relay output).

GPIO allows
connection of 1
CCTV camera or 1
pan tilt zoom
camera
The NS4120 is a true surveillance grade camera that can be used
for indoor or outdoor monitoring purposes. This camera
incorporates all the features of the NS4100 plus a video output
port to connect an additional analogue device such as a VCR or
monitor. The camera also includes an External Video input (via
GPIO block) to connect an analog CCTV camera to the device.
Video output
ports for
connecting
CCTV
cameras
The NS4240 is the most feature-rich surveillance solution in the
IP Camera range. The 4240 has all the capabilities of the NS4120
plus 3 additional video input ports to connect any legacy CCTV
cameras to the device. This IP Camera is a cost-effective
4 camera security monitoring and surveillance solution for
any organisation.
Video output
port for
recording to a
VCR
GPIO allows
connection
of 1pan tilt
zoom
camera
Video output
port for
recording to a
VCR
NS4240
NS4120

NetComm IP cameras can be used for
a wide range of sur eillance applications
EDUCATION
Besides capturing acts of vandalism and theft, high schools and
tertiary institutions are adopting NetComm IP Cameras for innovative
ne educational applications such as allo ing students access to
vie science experiments from home via the internet.
RETAIL
Retail businesses can install NetComm IP cameras to remotely
monitor staff, customer activity and customer interaction ith staff
and in-store traffic flo . To provide a complete retail monitoring
solution, NetComm has also partnered ith various soft are
providers to complement the camera range.
CONSTRUCTION
Building companies can effectively utilise NetComm IP Cameras to
remotely monitor site construction as ell as employee and material
movements. Key managers can also visually confirm construction
progress ithout being onsite.
HEALTH
Hospitals can use NetComm IP Cameras to monitor patients and
vie ing medical equipment from remote areas in an instant. Aged
care units can also install NetComm IP Cameras to ensure the safety
of the elderly.
WAREHOUSING/LOGISTICS
Warehouses can monitor loading and dispatch operations, entrances
and exits (including fire exits), shipping and storage areas, entry
points and parking areas. Combining a NetComm Smart IP Camera
ith 11g ireless eliminates the need for costly cabling in sites ith
large floor areas such as arehouses and campuses, here the cost
of camera cabling is prohibitive.
Warehousing / Logisitics
Health
APPLICATIONS

IP CAMERA OUTDOOR HOUSING
An IP Camera requires protection from the elements or any harsh
environment hen installed for outdoor applications.
That is hy NetComm has designed a eatherproof camera housing
to suit any environment. The housing is solid, coated aluminium
ith a thick 5mm glass indo . The in-built cooling system also
ensures that your IP Camera stays cool hen in direct sunlight.
Anti-corrosive coated aluminium case
Break resistant 5mm glass screen
In-built cooling fan
L 435mm x W 110mm x H 128mm
Weight 2.5kg
This option allo s the mounting of camera housing to a all.
Anti-corrosive coated aluminium
S ivel angle – 360 degrees
Tilt angle – 90 degrees
Scre size 25.4mm
285mm (L) x 76mm (W ) x 97mm (H)
Weight 0.8kg
In-built Cooling System
IP CAMERA OPTIONS
MSHTH-S3
IP CAMERA MOUNTING BRACKET MS1010-1
SOFTWARE
NetComm has partnered ith various key soft are developers to
provide enhanced soft are capability and complete the IP
Surveillance solution. Soft are options currently available offer
the follo ing functionality:
Enhanced net ork digital recording ith multiple camera
vie ing and recording capabilities
Advanced motion detection and stationary object detection
Scheduling of recording.

NetComm Limited, ABN 85 002 490 486 • PO Box 1200, Lane Cove NSW 2066 Australia
PHONE [phone] • FAX [phone] • EMAIL [email protected]
www.netcomm.com. u
Trademarks and registered trademarks are the property of NetComm Limited or their respective o ners.
Specifications are subject to change ithout notice. Images sho n may vary slightly from the product.
Camera Specifications NS4000 NS4100 NS4120 NS4240
Web and FTP server Yes Yes Ye s Ye s
Frames/second 25 fps 25 fps 25 fps 25fps
Screen display Single camera 1 camera 1-2 cameras 1-4 cameras
Network interface 10/100 RJ-45 10/100 RJ-45 10/100 RJ-45 10/100 RJ-45
Lens zoom Manual Manual Manual Manual
Pan, tilt, zoom support --11
requires external requires external
PTZ camera PTZ camera
Indoor/outdoor use Indoor only Indoor/Outdoor Indoor/Outdoor Indoor/Outdoor
Video Motion detection Ye s Ye s Ye s Ye s
On/Off selectable Yes Yes Ye s Ye s
Max video resolution 640 x 480 704 x 576 704 x 576 704 x 576
Image sensor CMOS Sony HAD CCD Sony HAD CCD Sony HAD CCD
Lens type Standard DC-Iris DC-Iris DC-Iris
F1.8 6mm Vari-focal Vari-focal Vari-focal
3.2-10mm F1.4 3.2-10mm F1.4 3.2-10mm F1.4
Memory buffer 16Mb SDRAM 16Mb SDRAM 16Mb SDRAM 16Mb SDRAM
Light sensitivity 2.5-10,000 0.5-200,000 0.5-200,000 0.5-200,000
in colour (Lux)
Modem support Dial-up/ADSL Dial-up/ADSL Dial-up/ADSL Dial-up/ADSL
Power supply 14/13.8V AC 1A 14/13.8V AC 1A 12V DC 1A 14/13.8V AC 1A
Alarm activation 4 alarm inputs 4 alarm inputs 4 alarm inputs 4 alarm inputs
+ video motion + video motion + video motion + video motion
detection detection detection detection
Alarm notification Alarm output/ Alarm output/ Alarm output/ Alarm output/
email email email email
Alarm recording Single frame Single frame Single frame Single frame
snapshot to snapshot to snapshot to snapshot to
full-motion full-motion full-motion full-motion
video video video video
Video input port - - 1 (GPIO) 3 (BNC)
Video output port PAL - - 1 (BNC) 1 (BNC)
Dimensions 77(w) x 54(h) 77(w) x 54(h) 77(w) x 54(h) 77(w) x 54(h)
with lens (mm) x 194(l) x 194(l) x 194(l) x 194(l
Weight (kg) 1.1kg 1.1kg 1.1kg 1.1kg
Operating temperature 5 – 50 C 5 - 50 C 5 - 50 C 5 - 50 C
IP CAMERA SPECIFICATIONS
