Netkrom AIR-PT900L User manual

Quick Installation Guide
AIRNET 54 Mb CPE Bridge Point to Point Kit
Series
Package Contents:
•2 Netkrom CPE units
•Two Mounting bracket include: 2 stainless steel U-Bolt, 2 mounting brackets, 2
pipe Brackets and 4 screw nuts
•Two PoE Injectors
•Two Power Cables
•Two RJ45 Waterproof Connector System
•CD-ROM
•Two 75’ Outdoor Rated Cat5e shielded cables

1.
H
Ha ar rd dw wa ar re e
I
In ns st ta al ll la at ti io on n
Warnings
•Do not work on the system or connect or disconnect cables during periods of lightning activity.
•NETKROM shall not be liable for incidental or consequential damages resulting from the furnishing,
performance, or use of this manual.
•Do not locate the antenna near overhead power lines or other electric light or power circuits, or where it
can come into contact with such circuits. When installing the antenna, take extreme care not to come
into contact with such circuits, as they may cause serious injury or death.
•Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
•To meet regulatory restrictions, the radio and the external antenna must be professionally installed. The
network administrator or other IT professional responsible for installing and configuring the unit must
be a suitable professional installer. Following installation, access to the unit should be password
protected by the network administrator to maintain regulatory compliance.
•The AIRNET CPE PtP Kit and PoE injector can be damaged by incorrect power application. Read and
carefully follow the installation instructions before connecting the system to its power source.

Package contents
Kit Point to Point
Take a moment to ensure you
have all of the following parts
in your Outdoor Waterproof
Unit installation kit before you
begin installing the product. If
any parts are missing, please
contact your local vendor or
contact us, please see the
contact information in Section
6.

Setup Requirements
Before starting, please verify that the
following is available:
•CAT5/5e or FTP Outdoor Ethernet
cable (from the CPE to PoE Injector)
•At least one computer is installed with
a Web browser and a wired or wireless
network interface adapter
•TCP/IP protocol is installed and IP
address parameters are properly
configured on all your network’s nodes
Important!
•Configure and verify the CPE
operations first before you mount the
unit in a remote location.
•You may need to install a lightning
arrestor to protect your CPE from
lightning.
•For choosing the best location for your
CPE choose an elevated location
where trees, buildings and large steel
structures will not obstruct the antenna
signals and which offers maximum
line-of-sight propagation with the
users.

AIRNET CPE
Installation
Step 1:
Connect one end of your UTP or FTP
Outdoor cat.5 Ethernet cable with
waterproof connector to the RJ-45
connector located in the CPE. Then connect
the other end of the cable to the PoE
injector.
For the Netkrom PoE, the recommended
length of the Category 5 cable is up to 260
feet or 80 meters.
1.- Remove the thin enclosure nut
from the feedthru assembly. This
can be discarded. Loosen the
compression nut completely
2.- Insert the RJ45 connector thru
the feedthru assembly
3.- Tighten the compression nut
loosely to the feedthru assembly
enclosure nut
feedthru assembly
compression nut

4.- Screw the entire feedthru assembly into
the RJ45-ECS housing which is already
mounted in the CPE. There should be a
rubber gasket between the two assemblies.
Tighten the feedthru assembly to create a
seal.
5.- The final step is to tighten the
compression nut until the gaskets are tight
around the Cat5 cable. Always push the
cable toward the connector while tightening
to ensure good strain relief of cable to
connector.
Step 2
From the PoE injector connect one cat.5
Ethernet cable to the radio and another cat.5
cable to a switch or PC.
Step 3
Connect the power cable supplied in the
Netkrom PoE kit to the mainelectrical supply
and the power plug into the socket of the
injector. Now, turn on your power supply.
Notice that the POWER LED has lighted up.
This indicates that the CPE is receiving
power through the NetkromPoE Injector and
that connection between your CPE and your
network has been established.
Note: Please use the PoE injector provided in
the package. Using a PoE with a different
voltage rating will damage this product.
RJ45-ECS housing

Mounting the Outdoor
CPE in a Pole or Tower
Netkrom CPE device can be mounted on the
pole or tower as shown in following:
1.-Attach the mounting bracket to the back
of the CPE using the three hex screws
provided. (Do not over tighten the screws.)
Note:The bracket in the illustration side
shows the normal orientation which allows
the CPE to be pointed up towards the base
station antenna. However, if you live
somewhere that would require you pointing
the CPE down towards the base station
antenna (for example, you are on the side of
a mountain in view of the base station
antenna below), reverse the bracket so the
Netkrom CPE Unit can be “tilted”
downward when you aim the CPE in a later
step.
bolts are
approximately 1/4" from the end.
to adjust the CPE
direction in a later step.
a, then hand-tighten the nuts on the U-
bolt.
3.-Remove the U-bolt and pipe bracket
assembly from the plastic bag. Place the
washer, lock nut to each side of the U-bolt,
and then tighten until the U-
Note: Do not tighten the screws all the way
because you will need
4.-Mount the CPE to the top of the pipe or
other support and point the CPE in the
approximate direction of the base station
antenn

2.
u uC Co on nf fi ig g U Ut ti il li it ty y
uConfig is a feature that provides the ability to directly access the CPE without the need to know absolutely its
IP address. It may be run directly from the product CD or installed on the user’s PC for later access.
Using uConfig
When you execute the uConfig file you
should see a window as it is shown on the
right side. Click yes to continue
The screen is divided into three sections. The
top section shows the Ethernet adapter that is
accessing the network device and the middle
portion shows the routing table associated
with the Ethernet adapter. In the lower
window, a list of all uConfig compatible
devices on the network is shown.
Highlight the device you desire to configure.
Then click on the “Open web” button

K button to continue
The default browser will be loaded using the
correct IP address of the CPE (regardless of
how the computer’s TCP/IP properties are
set),
Default Password: password
Click on L LO OG GI IN N! !, and start configuring the
.
Click the O
radio.

3.
P PC C C Co on nf fi ig gu ur ra at ti io on n
If you don’t use the uConfig Utility you need to establish Ethernet connection between your PC and the CPE,
by default the CPE has the IP address 192.168.168.1. Therefore, your PC must be in the same network segment
as the CPE is to get Ethernet connectivity.
tep 1
o to Start button, then go to My Network
laces and finally click on Network
onnections.
ight-Click over your network adapter and
elect Properties.
Properties.
tep 3
ow configure the IP Address of your
etwork adapter with an IP in the same
etwork segment as your CPE is as it is
hown in the picture, you don’t need to
ssign any gateway address.
Press OK and then press the Close button.
S
G
P
C
R
s
Step 2
Select the Internet Protocol Option and then
click in
S
N
n
N
s
a

4.
C
Co om mm mo on n
C
Co on nf fi ig gu ur ra at ti io on ns s
Find below typical and basic configurations using the CPE. For advanced features please refer to the user
manual.
Getting Started
Address bar, enter
You can start configuring your CPE using
either your Web Browser or the uConfig
utility.
At the
http://192.168.168.1 and press Enter on your
LOGIN!
en reach the home page of your
keyboard.
At the login page, click on the
button to enter the configuration page.
Default Password: password
You will th
pe’s Web interface.c

Wireless Point to Point
Setup
The CPE Bridge Point to Point Kit is
commonly used in Point-to-Point
Applications.
ou caY
cn implement a Point-to-Point onnection by simply setting one access point
RootAP in Access Point mode and setting
parent Client
as
the other access point in Trans
mode or in Client Mode.
NOTE
•Client Mode does not provide transparent
bridging.
•Transparent Client Mode does provide
transparent bridging.
Follow these steps to setup RootAP
Click on WLAN Setup from the
CONFIGURATION menu. You will see the
sub-menus expanded under WLAN Setup.
Click on Basic.
Ensure that The Current Mode is set to
Access Point.
Select Act as RootAP, click on the Apply
button and reboot your device to let your
changes take effect.

Follow these steps to setup Transparent
Client/s.
elect the Remote AP MAC checkbox.
Step 2
Select the Remote AP MAC checkbox.
Enter the Remote AP MAC. Check the MAC
address of your Remote AP under About
system >> Wireless MAC
Note:
When using Remote AP MAC, the ESSID
name must also match the AP’s ESSID name,
especially when Closed System is enabled on
the AP.
Repeat the Transparent Client steps to add
more Clients to the Point-to-MultiPoint
Step 1
S
Enter the Remote AP MAC. Check the MAC
address of your Remote AP under About
system >> Wireless MAC.
Ensure that The Current Mode is set to
Transparent Client.
connection.

900 MHz Channel
Conversion
(AIR-PTP900L )
have to
900
In order to use your 900 MHz CPE, you
select in Wireless Profile any of the following
options:
802.11b only
802.11g only
802.11b/g mixed (recommended)
Channel conversion from 2.4 GHz to
MHz:
Channel 10 or 11 must be used in an
Operational Mode when using a 900 MHz CPE.
y
802.11 b/g 900 MHz
Channel 10 (2457) 913 MHz
Channel 11 (2462) 918 MHz

5.
A
Ad dv va an nc ce ed d C Co on nf fi ig gu ur ra at ti io on n
1. - Advanced Routing Configuration: Please go to page 85 of User Manual.
2 th Control: Please go to page 95 of User Manual.
3. – Remote Management: Please go to page 99 of User Manual.
4. – Advanced Wireless Configuration: Please go to page 114 of User Manual.
5. – Wireless Security Setup: Please go to page 135 of User Manual.
6. – Security Configuration: Please go to page 143 of Us
7go to page
. – Bandwid
er Manual.
. – Wireless Operation Modes: Please 3 of User Manual.

6.
C
Co on ng gr ra at tu ul la at ti io on ns s
With these basics steps you can enjoy your wireless link without problems, please for more information about
the capabilities and advanced configuration of our product please see the user manual.
