1Product overview
The Wideband Optical Couplers (WOC) in the Flashlink range are all-optical power splitters
or combiners. One or multiple wavelengths can be used on the fibres. Today the product
offering consists of WOC-2-xx-xx which is a 1:2 optical coupler available with different
coupling ratios. The WOC-4-25 is a 1:4 optical coupler, where the optical power is divided
and distributed equally to the four output ports.
Figure 1: Block diagram of the WOC-2 module operation.
The Flashlink 1:2 Wideband Optical Coupler is a fibre optical splitter/combiner module for
use together with the W03-C1 connector module.
A typical application for these units is multiple distribution and linear, tapped fibre optic bus
structures. The unit is passive and there is no need for power or control.
The WOC-2 optical coupler is made for the 2nd and 3rd optical window (1310nm and
1550nm) and is available with three different split ratios:
−WOC-2-50-5050%-50% split ratio
−WOC-2-90-1090%-10% split ratio
−WOC-2-95-0595%-05% split ratio
The WOC-2 has two input/output ports and one common port. The product is also available
with multi mode fibre on request.
Figure 2: Block diagram of the WOC-4-25 module operation.
A typical application for the WOC-4-25 is distribution to multiple locations of single or
multiple signals using WDM.
The WOC-4-25 optical coupler is made for wavelengths from 1260 up to 1620nm thus
covering the whole CWDM band.
network-electronics.com | 4

WOC-2-50-50/-90-10/-95-05 WOC-4-25 Rev. 3
2Specifications
2.1 WOC-2-xx-xx
2.1.1 Single mode fibre (9/125 um)
Optical wavelength: 2nd & 3rd opt. window (1310 nm & 1550 nm)
Optical bandpass: 1270-1350 nm & 1510-1590 nm
Return loss: Better than 40 dB w/SM fibre
Directivity: Better than 55 dB
Transmission circuit fibre: Single Mode
Connector: SC/UPC
Split ratios and corresponding maximum insertion loss (incl. connectors):
WOC-2-50-50: 50 % / 50 % 4.3 dB / 4.3 dB
WOC-2-90-10: 90 % / 10 % 1.33 dB / 11.7 dB
WOC-2-95-05: 95 % / 05 % 1.1 dB / 15.3 dB
2.1.2 Multi mode fibre (62.5/125um)
Optical wavelength: 2nd opt. window (1310nm)
Directivity: better than 40dB
Transmission circuit fibre: Multi Mode
Connector: SC/UPC
Split ratios and corresponding maximum insertion loss (incl. connectors):
WOC-2-50-50: 50 % / 50 % 4.8 dB / 4.8 dB
2.2 WOC-4-25
2.2.1 Single mode fibre (9/125um)
Optical passband: 1260-1620 nm
Return loss: Better than 40 dB typ w/SM fibre
Directivity: Better than 55 dB typ
Transmission circuit fibre: Single Mode
Connector: SC/UPC
Split ratio: 25%/25%/25%/25%
Insertion loss with connectors: Max 9dB over passband.
network-electronics.com | 5

WOC-2-50-50/-90-10/-95-05 WOC-4-25 Rev. 3
3Connections
The WOC-2 has the same connector module as theWDM-2: W03-C1. This module is
mounted at the rear of the sub-rack. The module is shown in Figure 3.
Figure 3: Overview of the W03-C1 connector module.
Figure 4: Overview of the WOC-4-25 connector module
network-electronics.com | 6

WOC-2-50-50/-90-10/-95-05 WOC-4-25 Rev. 3
The WOC-4-25 is a self contained box similar to the CWDM filters that is mounted
permanently in the Flashlink FR-2RU-10-2 from the rear.
Figure 5: The WOC-4-25
The WOC-4-25 can also be delivered in the N-BOX, which is used for stand alone
applications.
3.1 Mounting the connector module
This section only applies to the WOC-2-xx-xx if the module is not purchased pre-mounted in
a sub-rack.
The details of how the connector module is mounted, is found in the user manual for the
sub-rack frame FR-2RU-10-2.
This manual is also available from our web site: http://www.network-electronics.com/
3.2 Preparation of module
Just before the module and the connector module are put together, the dust caps should be
removed and stored in the enclosed plastic bag. The dust caps are removed from the
connector module and the module card as we see in Figure 6 and Figure 7.
Figure 6: Removal of the dust caps from the WOC connector module.
network-electronics.com | 7

WOC-2-50-50/-90-10/-95-05 WOC-4-25 Rev. 3
Figure 7: Removal of plastic dust caps from WOC module.
3.3 Applying signals to the WOC-2-xx-xx connector module
Optical 1 is always the common port (orange lead).
Optical 2 has largest1coupling ratio (blue lead)
Optical 3 has lowest coupling ratio (natural lead).
3.4 Application examples
We show some examples of how a WOC can be used for different applications.
Tx
Rx 1
Rx 2
WO C
50 / 50
Figure 8: Redundant solution – Same signal on two different fibres.
In Figure 8 we have a solution where the signal path from transmitter (Tx) to the receiver
(Rx) is redundant. Since both Rx1 and Rx2 are located at the same place, the signal is
divided into two equal parts and transmitted over two different fibres. At the receiver end
the same signal is present from different receiver cards, a redundant solution. This solution is
also suitable for transmitting the same signal to two different locations; each located
approximately the same distance from the transmitter.
If the distances from the two different receiver-locations to the transmitter are very different
a WOC-2-90-10 or a WOC-2-95-05 is more suitable. Which WOC to use in which case can
be found by calculating the optical transmission budgets for the involved links, or by calling
your Network Electronics representative. More information on transmission budgets can be
1A WOC-2-50-50 has the same coupling ratio for both Optical 2 and Optical 3.
network-electronics.com | 8

WOC-2-50-50/-90-10/-95-05 WOC-4-25 Rev. 3
found in the user manual for the sub-rack frame, and on our web site http://www.network-
electronics.com/
Tx
Rx 1
Rx 2
WO C
90 / 10
90
10
Figure 9: Signal tapping / monitoring / distribution with a WOC-2-90-10.
If one of the Rxs for some reason is not connected, we recommend bypassing the
WOC module until the Rx is in operation again. This is to avoid back-reflections
degrading the signal.
network-electronics.com | 9

WOC-2-50-50/-90-10/-95-05 WOC-4-25 Rev. 3
4Module status
The WOC-2-xx-xx and the WOC-4-25 are all-optical modules with no electrical connections;
hence there will be no on-board processing or monitoring. If the module is faulty this can be
monitored on the receiver end. The only possibilities for the module to fail are if either te
fibre is broken, or the fibre connections at the rear are bad. Then no signal will pass the
module.
4.1 Front Panel - Status Monitoring
The WOC-2-xx-xx and the WOC-4-25 are all-optical modules, so there are no LEDs on the
module.
network-electronics.com | 10

WOC-2-50-50/-90-10/-95-05 WOC-4-25 Rev. 3
5Laser safety precautions
These are guidelines to limit hazards from laser exposure.
All the available EO units in the Flashlink range include a laser.
Therefore this note on laser safety should be read thoroughly even though there is no laser
onboard this product.
The lasers emit light at 1310 nm or 1550 nm. This means that the human eye cannot see the
beam, and the blink reflex cannot protect the eye. (The human eye can see light between
400 nm to 700 nm).
A laser beam can be harmful to the human eye (depending on laser power and exposure
time). Therefore:
Be careful when connecting / disconnecting fibre pigtails (ends).
Never look directly into the pigtail of the laser/fibre.
Never use microscopes, magnifying glasses or eye loupes to look into a fibre end.
Use laser safety goggles blocking light at 1310 nm and at 1550 nm
Instruments exist to verify light output power: Power meters, IR-cards etc.
Flashlink features:
The FR-2RU-10-2 is classified as Class 1 laser product according to EN 60 825-1:94/A11:96,
and CFR Ch1 (1997) Part 1040.10.
If the front panel is removed, the FR-2RU-10-2 is classified as Class 1 laser product according
to EN 60 825-1:94/A11:96, and class IIIb according to CFR Ch1 (1997) Part 1040.10.
Maximum output power2: 5 mW
Operating wavelengths: > 1260 nm
2Max power is for safety analysis only and does not represent device performance.
network-electronics.com | 11

WOC-2-50-50/-90-10/-95-05 WOC-4-25 Rev. 3
General environmental requirements for Network Electronics
equipment
1. The equipment will meet the guaranteed performance specification under the
following environmental conditions:
- Operating room temperature range: 0°C to 50°C
- Operating relative humidity range: Up to 90 % (non-condensing)
2. The equipment will operate without damage under the following environmental
conditions:
- Temperature range: -10°C to 55°C
- Relative humidity range: Up to 95 % (non-condensing)
network-electronics.com | 12

WOC-2-50-50/-90-10/-95-05 WOC-4-25 Rev. 3
Product Warranty
The warranty terms and conditions for the product(s) covered by this manual follow the
General Sales Conditions by Network Electronics ASA. These conditions are available on the
company web site of Network Electronics ASA:
www.network-electronics.com
network-electronics.com | 13

WOC-2-50-50/-90-10/-95-05 WOC-4-25 Rev. 3
Appendix A Materials declaration and recycling information
A.1 Materials declaration
For product sold into China after 1st March 2007, we comply with the “Administrative
Measure on the Control of Pollution by Electronic Information Products”. In the first stage of
this legislation, content of six hazardous materials has to be declared. The table below
shows the required information.
Toxic or hazardous substances and elements
組成名稱
Part Name
鉛
Lead
(Pb)
汞
Mercury
(Hg)
镉
Cadmium
(Cd)
六价铬
Hexavalent
Chromium
(Cr(VI))
多溴联苯
Polybrominated
biphenyls
(PBB)
多溴二苯醚
Polybrominated
diphenyl ethers
(PBDE)
WOC-2-50-50/-
90-10/-95-05
WOC-4-25
O O O O O O
O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for
this part is below the limit requirement in SJ/T11363-2006.
X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous
materials used for this part is above the limit requirement in SJ/T11363-2006.
This is indicated by the product marking:
A.2 Recycling information
Network Electronics provides assistance to customers and recyclers through our web site
http://www.network-electronics.com. Please contact Network Electronics’ Customer Support
for assistance with recycling if this site does not show the information you require.
Where it is not possible to return the product to Network Electronics or its agents for
recycling, the following general information may be of assistance:
−Before attempting disassembly, ensure the product is completely disconnected from
power and signal connections.
−All major parts are marked or labelled to show their material content.
−Depending on the date of manufacture, this product may contain lead in solder.
−Some circuit boards may contain battery-backed memory devices.
network-electronics.com | 14

WOC-2-50-50/-90-10/-95-05 WOC-4-25 Rev. 3
EC Declaration of Conformity
Network Electronics ASA
P.B. 1020, N-3204 SANDEFJORD, Norway
MANUFACTURER
AUTHORISED REPRESENTATIVE
(Established within the EEA) Not applicable
WOC-2-50-50/-90-10/-95-05 WOC-4-25
MODEL NUMBER(S)
Wideband Optical Coupler
DESCRIPTION
LVD 73/23/EEC
EMC 89/336/EEC
DIRECTIVES this equipment complies with
EN 55103-1:1996
EN 55103-2:1996
EN 60950-1:2006
HARMONISED STANDARDS applied in order to
verify compliance with Directive(s)
TEST REPORTS ISSUED BY Notified/Competent Body Report no:
Nemko 200013115
Not applicable
TECHNICAL CONSTRUCTION FILE NO
2000
YEAR WHICH THE CE-MARK WAS AFFIXED
TEST AUTHORIZED SIGNATORY
MANUFACTURER AUTHORISED REPRESENTATIVE
(Established within EEA) Date of Issue
2007-06-07
Place of Issue
Not applicable Sandefjord,
Norway
Nils B. Sannes
Name
Quality Manager
(authorised signature)
Position
network-electronics.com | 15
