2 Product Description
Using these accessories allows for flexible mobile use of all VIDA M speaker types. You can set
them up for different applications on a regular and recurring basis.
2.1 Intended Use
To be operated by qualified personnel only.
Unless otherwise stated, use only KLING & FREITAG original parts for mounting.
2.1.1 VIDA M Mounting Adapter
The VIDA M mounting adapter is provided for use with VIDA M 110 / 110 S and VIDA M 220
/ 220 S speakers. It is designed for permanent attachment to the speaker and allows for
mounting other accessories, thus ensuring flexible mobile use of the speaker.
The VIDA M mounting adapter is not designed for regularly attaching/removing it to/from the
speaker. Once installed, be sure to leave the accessory attached to the speaker.
The installation on one side of the speaker allows for recurrent use of the following:
•Eyelets
•Spigot adapter
•Stand adapter (only for the VIDA M 110 / 110 S)
With the above accessories, be sure to use the VIDA M mounting adapter indoors only.
Outdoor use is permitted only after taking appropriate steps (for example additional horizontal
bracing at the speaker bottom and providing a structural certification specifically for the appli-
cation at hand).
When installing mounting adapters on both sides of the speaker, this provides a second handle
for safer handling. It also allows the use of a VIDA M Truss Adapter Set.
Any other use as well as any use not described in this User’s Guide is not an intended use.
2.1.2 VIDA M Truss Adapter Set
For using the Truss Adapter Set, you need two VIDA M mounting adapters (sold sep-
arately).
Using the VIDA M Truss Adapter Set, you can attach a VIDA M 110 / 110 S or VIDA M 220 /
220 S speaker either vertically or horizontally to a truss or tube with a diameter of approx.
50 mm.
A speaker system installed using this set can be exposed to certain wind loads and therefore
be installed outdoors.
Prerequisite is a peak velocity pressure of q = 0.97 kN/m² acting on the speaker. According to
the German DIN EN 1991-1-4 standard, this corresponds to wind zone 2 (inland) and a maxi-
mum operating height of 25 m above the ground.
Any other use as well as any use not described in this User’s Guide is not an intended use.
2.1.3 VIDA M Connector Panel
The VIDA M connector panel provides ports for power supply, audio, and network signals. It
can be mounted to any VIDA M speaker. The panel makes establishing and separating connec-
tions simple and is particularly useful in mobile use (for example, with rental applications).
Note that the requirements of the IP65 specifications are met only when using Neutrik True
Outdoor Protection (TOP) series connectors.
The installation of the connector panel must be performed by a qualified electrician. We there-
fore recommend permanent installations.
Any other use as well as any use not described in this User’s Guide is not an intended use.
Page 6 of 30 Version 1.3 © KLING & FREITAG GMBH
User's Manual K&F VIDA M Accessories for Mobile Use
2.2 Items included
2.2.1 VIDA M Mounting Adapter
[A] 6 x M6x10 countersunk screw,
stainless steel, strength class A2-
70, for permanent installation to
the speaker
[B] 1 x VIDA M mounting-adapter
plate
[C] 2 x Locktix® M10 lock washer
for eyebolt
[D] 2 x M10 eyebolt, stainless steel,
DIN 580,
When using 20-mm spigot
adapter (optional) with
M10 × 20 mm external thread:
[E] 1 x Locktix® M14 lock washer
[F] 1 x O-ring 10 × 2.5, for center-
ing M14 lock washer
When using stand a sleeve with
M10 external thread:
[G] 1 x Sicherungsscheibe ‚Locktix®‘
für M20
[H] 1 x Rubber washer for centering
M20 lock washer
•1 x User’s Manual
Note:
The M10 spigot adapter and the
M10 stand sleeve (in gray) are shown
for illustration purposes only and are
not included.
© KLING & FREITAG GMBH Version 1.3 Page 7 of 30
User's Manual K&F VIDA M Accessories for Mobile Use
2.2.2 VIDA M Truss Adapter Set
•2 x VIDA M mounting adapter
(for details on items included
with each mounting adapter, re-
fer to chapter »Items included«
on page 6)
[A] 2 x Truss-Adapter Bracket
[B] 4 x M10 x 25 Pan-head screw
with flange, grade A2-70
[C] 4 x Locktix® M10 lock washer
[D] 2 x M10 nut, self-locking,
grade 8
[E] 2 x M10 spring washer
[F] 2 x M10 washer, large
[G] 2 x M10 x 35 countersunk screw,
grade 8.8
[H] 2 x half coupler, 48–51 mm
[I] 2 x M12 nut, grade 5
[J] 2 x M12 butterfly nut, grade 5
Page 8 of 30 Version 1.3 © KLING & FREITAG GMBH
User's Manual K&F VIDA M Accessories for Mobile Use
2.2.3 VIDA M Connector Panel
[A] Connector panel (all external
ports equipped with protective
caps)
[B] Analog-audio connector
(ANALOG IN / AUX OUT)
[C] Network cable (Dante)
[D] Dante/Remote Secondary, Neu-
trik etherCon TOP (RJ45)
[E] Dante/Remote Primary, Neutrik
etherCon TOP (RJ45)
[F] ANALOG IN (analog-audio input,
Neutrik XLR female TOP)
[G] AUX OUT (analog-audio output,
Neutrik XLR male TOP)
[H] Grommet
[I] Phoenix power connector
[J] POWER IN (power port, 100–
240 VAC; Neutrik PowerCon
True1 TOP)
•1 x mains power cable
(EU, Schuko) 3m, Neutrik power-
CON TRUE1 TOP
lockable device connector, han-
dles up to 16A, supports inser-
tion / removal on load and volt-
age
Page 12 of 30 Version 1.3 © KLING & FREITAG GMBH
User's Manual K&F VIDA M Accessories for Mobile Use
3 General Safety Instructions
The information described here does not relieve the user of the duty to follow the given safety
requirements and legal regulations.
The technicians responsible for installing the system on site are responsible for and guarantee
safe setup and use.
To prevent injury and damage, be sure to securely mount, suspend, or place the product as
specified in the DGUV regulations 17 (BGV C1) or similar locally applicable accident-control
standards.
WARNING
Risks imposed by falling or overturning parts
•The VIDA M mounting adapter is not designed for frequent attachment to/removal from
the speaker. Therefore, leave the accessory attached to the speaker once mounted!
Throughout its entire lifecycle, a Vida M mounting adapter must be installed/un-
installed (i.e. attached using screws) no more than 5 times!
However, using an installed VIDA M mounting adapter allows for attaching and removing
appropriate accessories at will.
•Be sure to tighten all bolts and screws to the specified torque.
•Only qualified technicians are permitted to perform the installation steps. Be sure to use
personal protective equipment at all times.
•Be sure to use the accessories as specified in this document only.
•Unless otherwise stated, use only KLING & FREITAG original parts for mounting.
•Be sure to perform visual inspections and function checks before each use and at regular
intervals. Never use the system if it shows signs of malfunction or wear, cracks, deforma-
tion, etc.
© KLING & FREITAG GMBH Version 1.3 Page 13 of 30
User's Manual K&F VIDA M Accessories for Mobile Use
4 Installing the VIDA M Mounting Adapter
Required Tools Required mounting material
IH4 torque wrench with hexagon-socket drive
and 3 Nm torque
Loctite 2400 (supplied with the speaker)
1. Apply Loctite 2400 to the
threads of screws [A].
2. Slide the tabs of mounting
adapter [B] into the correspond-
ing inlets of speaker [C].
3. Screw in all M6x10 screws [A]
using an IH4 hexagon socket
wrench. Do not tighten yet!
4. Once all screws are loosely
screwed in, tighten them to a
torque of 3 Nm.
5. For installation on both sides, in-
stall the second mounting
adapter [D] accordingly.
Page 14 of 30 Version 1.3 © KLING & FREITAG GMBH
User's Manual K&F VIDA M Accessories for Mobile Use
4.1 VIDA M Mounting-Adapter Use Cases
An installed VIDA M mounting adapter provides for various use cases:
1. Single-side use-cases:
•Vertical speaker suspension
•Two-strand suspension
•One-strand suspension with safety
•Suspension with optional spigot adapter and safety
•Speaker-stand use (requires optional stand sleeve M10)
2. Dual-side use cases:
•Allows for conveniently carrying the speaker
•Horizontal, two-strand speaker suspension
© KLING & FREITAG GMBH Version 1.3 Page 15 of 30
User's Manual K&F VIDA M Accessories for Mobile Use
4.2 Suspending a Speaker with One Mounting Adapter
Installed
WARNING
Risks imposed by falling parts
•Be sure not to suspend more than one VIDA M 110 / 110 S or VIDA M 220 / 220 S speaker
from a mounting adapter.
•Note that speakers suspended using a single installed mounting adapter must be placed
vertically and must never be mechanically down-tilted.
•Make sure all fittings used are suitable for the task at hand and meet all relevant safety
requirements.
•Ensure that all connections are secured against coming loose and that only authorized,
statically tested and correctly sized supports, mounting equipment, wire ropes, and chains
are used.
•Note that the suspension points on the hall ceiling (i.e. shackles, attachment points, or
chain hoists) must comply with the DGUV regulations 17 (BGV C1) or similar locally appli-
cable accident-control standards. The maximum load must have been certified by an
authorized expert.
•Also follow the operating and safety instructions supplied with the product you intend to
suspend the VIDA M mounting adapter from (e.g. a truss). Never attach the mounting
adapter to a product if there is no information on safe use and maximum load.
•Even with two-fall suspension, each chain and motor must be capable of carrying the en-
tire mass! Make sure that the motor chains hang down vertically and are not twisted, and
that the motors are located at the required positions.
•Make sure no persons stand in the danger zone below the speakers during setup and
mounting/dismounting.
•Never use signal cables or power cords for suspending, aligning, or securing the systems.
Risk imposed by swinging loads
•Remember that speakers being lifted may swing out!
•Ensure there is sufficient clear space for assembling and suspending the speakers on-site.
•Permit only personnel directly involved with assembly or disassembly to access the working
area. The person in charge must announce all mounting-adapter lifting and lowering ac-
tivities beforehand and make sure all people attending are aware. In this case, all persons
present must leave the swing and lifting range immediately.
Hazard of falling
•Never use the VIDA M mounting adapter for lifting or securing persons or objects other
than the above speakers.
•Implement safeties with not drop distance!
Page 16 of 30 Version 1.3 © KLING & FREITAG GMBH
User's Manual K&F VIDA M Accessories for Mobile Use
4.2.1 Vertical Two-Strand Suspension
4.2.2 Vertical One-Strand Suspension with Safety
1. Screw eyebolts [A] with lock
washers [B] to the outer M10
thread holes of mounting adapt-
er [C].
2. Hang the speaker in two strands
using the eyelets.
1. Screw eyebolts [A] with lock
washers [B] to the middle and to
one outer M10 thread hole of
mounting adapter [C].
2. Suspend the speaker on the mid-
dle eyebolt and secure it using a
safety on the outer eyebolt.
© KLING & FREITAG GMBH Version 1.3 Page 17 of 30
User's Manual K&F VIDA M Accessories for Mobile Use
4.2.3 Vertical Suspension Using Spigot Adapter with
Safety
1. Screw eyebolt [B] with M10 lock
washer [A] to one of the outer
M10 thread holes of mounting
adapter [C] and tighten it.
2. Screw spigot adapter [D] (op-
tional) with O-ring [E] and M14
lock washer [F] to the middle
M10 thread hole of mounting
adapter [C] and tighten it.
3. Mount the spigot-adapter acces-
sories, then install the speaker.
4. Attach a safety to the eyebolt.
Page 18 of 30 Version 1.3 © KLING & FREITAG GMBH
User's Manual K&F VIDA M Accessories for Mobile Use
4.3 Using the M10 Stand Sleeve for Speaker-Stand
Placement
WARNING
Risks imposed by falling parts
•This use case is suitable for VIDA M 110 / 110 S speakers only.
The VIDA M 220 / 220 S is not approved for use on a stand as that would overload the
configuration.
1. Screw stand sleeve [A] with cen-
tering disk [B] and M20 lock
washer [C] to the middle M10
thread hole of mounting adapter
[C] and tighten it.
2. Place the speaker onto a stand of
adequate size and stability. (This
must be done by two persons.)
3. Fasten the speaker using the
hand wheel of stand-sleeve [A].
© KLING & FREITAG GMBH Version 1.3 Page 19 of 30
User's Manual K&F VIDA M Accessories for Mobile Use
5 Mounting the Truss Adapter Set
Required Tools
IS6 hexagon socket wrench
Spanner (size 17)
1. Attach two mounting adapters
to your speaker (refer to
chapter »Installing the VIDA M
Mounting Adapter« on page
13).
2. Mount half coupler [A] to the
truss adapter [E] using M10 x 35
countersunk screw [B], washer
[C] and spring washer [D].
3. Repeat the procedure for the
second truss adapter.
4. Screw truss adapter [A] using
two M10 x 25 pan-head screws
[B] and two M10 lock washers
[C] to the outer thread holes of
mounting adapter [D].
5. Repeat the procedure for the
second truss adapter.
Other manuals for VIDA M
1
Table of contents
Other KLING & FREITAG Adapter manuals
