Neuro Beat Puck User manual

PUCK
USER MANUAL
NB-PS-00B-10

What’s included? ………… 1
Components ……………… 2
Charging ……………………… 3
Powering On/Off ………………… 4
Bluetooth Connection ………… 4
Appendix …………………………… 5
TABLE OF CONTENTS
󱁿Solutions for Troubleshooting of Puck
󱂀Solutions for Troubleshooting
of Wired Earphones
󱂁Warnings and Cautions
󱂂Handling and Storage
󱁿Puck
󱂀Wired Earphones
󱁿Puck
󱂀Wired Earphones
Please follow the rules depicted in this manual closely to ensure your safety. Before
using this Puck, we would strongly encourage to you read through this user manual.

1
What’s included?
• Puck 1ea
• Wired Earphones 1ea
• USB-Micro 5 Pin Charging Cable 1ea
• 2 sets of Spare Earbuds

2
Components / Specifications
8
9
1
5
2
6
7
4
3
• Buttons and parts
1
2
3
4
5
6
7
8
9
RBS
Power
Volume (+)
Volume (–)
AUX IN
HP OUT
Charger Port
LED Ring
Reset
RBS ON / OFF
Power ON / OFF (Press for approximately 3 seconds)
Increase volume while playback.
Decrease volume while playback.
3.5Ø aux in for input.
Wired Earphones for output.
Micro 5 Pin Charging Cable
Red = Charging / Blue = Charged
Red = RBS On
Blue = Bluetooth connected to mobile phone
Reset
󱁿 Puck

• Specifications
1
2
3
4
5
6
7
Speaker
Output
HP Output
Bluetooth
Playback
Time
Charge Type
Weight
Size
2W
1mW
Bluetooth 4.2
4+ hours
Micro USB B type
170g
92(L) * 92(W) * 39(H) mm

4
Charging
Before using Puck for the very first time, you must first charge the battery. Use the
Micro 5 Pin charging cable included in the box.
Make sure to use a charger of 5V 500mA or greater.
For safety, keep the maximum charge time of 4 hours.
Please check the correct direction of the charger before connecting. Improper
connection may cause damage to the device.
•
•
•
•
Using a power source other than the charger, such as PC or a battery bank may
result in slower charging speed due to a lower electric current.
While charging, Puck may heat up. This is normal and should not affect the
product’s lifespan nor performance. If the battery gets hotter than usual, you
may stop charging for awhile.
Charging while in use may slow down the charging process.
To save energy, remove the charger when not in use. Since most chargers do
not have a power switch, you must disconnect the charger and the outlet to
prevent power consumption.
Only use certified charging adapters. Charging with unapproved charger may
cause malfunction of the battery or Puck itself.
Charging time may vary depending on the charging specification.
•
•
•
•
•
•

5
Press the Power button
to turn the device On /
Off.
Once power is On, the LED ring
will flash in Red and Blue for
approximately 3 seconds.
Bluetooth Connection
Power On / Off
1. 2.
Where wireless use is restricted, follow the warnings and instructions of the area.
NB-Station-V1
My Devices
Bluetooth ON
For Further instructions and/or compatibility of your mobile phone in use, please
see the manual provided by the manufacturer.
Please read the appendix for the cautions when Bluetooth connecting.
•
•
Turn on Bluetooth on
your mobile phone
and search for devices
available to connect.
Select NB-Station-V1
from the device list to
connect.
Once connected, Puck
will remember your
mobile phone and
automatically connect
to it when you turn the
device on. (Bluetooth
must be On)
1. 2. 3.

6
Appendix
󱁿 Solutions for Troubleshooting of Puck
Puck does not turn on.
Sound quality is poor in Bluetooth speaker mode.
Distortion at max volume via mobile phone.
Unable to find Puck on the list of Bluetooth Device List.
Puck does not make any sound.
Check the battery status then please check the charging instructions on page 3.
Reconnect the mobile phone and Puck.
Various wireless devices can generate noise and disturb the music playing. Place
Puck away from the devices that use or generate radio waves.
The sensitivity of sound input may differ by manufacturer and model. Set proper
volume within the range where the sound quality is not distorted.
Excessive volume output can cause device failure.
Restart Puck and re-search via mobile phone.
Make sure to place Puck and your mobile phone within the maximum connection
range of 10m.
The maximum connection range may differ by manufacturer and model. Try
connecting by locating Puck and your mobile phone as close as possible.
Check the manufacturer’s manual for information on Bluetooth function of your
mobile phone.
Once Puck is connected to Wired earphones, earphone output will be prioritized.
If you want to use Puck in Bluetooth speaker mode, disconnect the Wired
Earphones.
•
•
•
•
•
-
-
-
-
-
-
-
-
-
-

7
The battery depletes faster than when first purchased.
Cannot feel any difference in RBS mode.
How do I control the device connected via audio cable?
When exposed to extreme temperatures, the charging efficiency may decrease.
The battery is consumable and the usage time will gradually shorten depending
on usage and frequency.
The efficiency of RBS and the time it takes to experience its effects may differ.
Check connection between Puck and Earphones.
Speaker output does not support RBS mode.
When the device is connected via audio cable, controls such as Play / Pause,
Previous / Next and etc. should be done with the connected device. Control
methods may differ depending on the manufacturer or model of the device.
(Volume and RBS control is possible with Puck.)
•
•
•
•
The music stops when incoming call. (When in Bluetooth Speaker mode)
Depending on mobile phone model and streaming service, music may stop at times
with incoming calls.
Speakerphone mode is not supported with Puck.
-
-
-
-
-
-
-
-

8
󱂀 Solutions for Troubleshooting of Wired Earphones
Wired Earphones do not play any sound.
Sound quality is bad in RBS mode.
Check connection between Puck and wired earphones.
Compared to original sound source, RBS may degrade in sound quality. However,
this is due to its conversion to Mono from Stereo.
Check Bluetooth connection between Puck and mobile phone.
-
-
-
•
•
󱂁 Cautions
Keep the devices close to each other. Otherwise, abnormal operation or noise
may occur depending on the environment.
Ensure that Compact and other Bluetooth devices are within the connection
range of 10m. The distance may vary depending on devices.
Ensure that there are no obstacles between Compact and connected device
including human body, walls, corners, or fences.
Bluetooth uses the same frequency band as industrial, scientific, medical and
electronic devices, and small output such as wireless LANs may cause radio
interference between devices.
Follow warnings and directions as directed by the authorized personnel in areas
where wireless devices are restricted.
•
•
•
•
•
1) Bluetooth

9
Puck is a Bluetooth Healthcare Speaker that induces Frequency Modulation
utilizing RBS Technology. It helps shorten sleep latency and improve quality of
sleep. Puck is not a medical or therapeutic device.
The images and specs in the user manual may differ from the actual product.
Contents of the user manual may change without prior notice.
Services related to personal safety are not available via Puck due to its possibility
of radio interference while in use.
Since the Wired Earphones provided contain magnets in its earbuds, there are
several things to keep to prevent vital problems on users and devices.
Therefore, please note and be cautious about the followings:
Do not put or store your Earphones near magnetic fields.
Magnetic cards such as credit cards, phone cards, passbooks, and
boarding passes may be damaged by magnetic fields.
If the magnets are swallowed, it can be fatal.
If swallowed, seek medical attention immediately.
Use with extreme caution to prevent from the reach of children or pets.
•
•
•
•
-
-
-
•
3) The Others
2) Wired Earphones

10
󱂂 Handling and Storage
Please carefully read the user manual before use.
As the devices are not waterproof or water resistant, be very careful not to expose to
water or high humidity.
Avoid using and/or storing the devices at temperature below 41℉or over 86 ℉.
Avoid using and/or storing the devices in a place exposed to direct sunlight, or in a
heat generating environment such as near a heating equipment or near flammable
substances.
Avoid using and/or storing the devices in an environment with vibration or
magnetism.
Avoid using and/or storing the devices in a place where the temperature can rise due
to insufficient ventilation, such as a bookcase or closet, and other enclosed spaces.
Avoid using and/or storing the devices in unstable places such as a high shelf.
Avoid using and/or storing the devices near the equipment which uses high voltage
electricity or where there are electromagnetic interferences.
Avoid any large impacts such as throwing or dropping. It may cause malfunction.
Do not disassemble and/or modify the devices. It may cause malfunction.
Do not use the devices at an excessively high volume for a long time. It may cause
malfunction.
If you see and/or smell smoke, stop using or charging the devices immediately. Turn
off the power and remove the charger.
Gently wipe with a soft cloth when cleaning. Do not use chemicals or strong
detergents. Doing so may discolor or corrode.
If the battery is damaged, there may be a danger of an explosion. Always use with
caution.
Neuro Beat Puck is a Healthcare Bluetooth speaker that induces Frequency
Modulation utilizing RBS technology to reduce fall asleep time, Not a medical or
therapeutic device.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
