NEUTRIK opticalCON FOCD-STC Configuration guide

CLEANING INSTRUCTION
®
opticalCON Chassis Connector
Cleaning Adapter FOCD-STC & FOID-STQC
R
Cassis Cleaning / Inspection
CAUTION:
Laser radiation, do not look directly into beam of light!
Intervall: every 500 matings recommended
®
Tools: Neutrik Chassis Cleaning Adapter: FOCD-STC / FOID-STQC
Dry Cleaner: FOCD-DC125, FOCD-DCM
Optical fiber video probe
®
opticalCON DUO Chassis Cleaning
®
Insert the FOCD-STC in to the Neutrik opticalCON
NO2-4FDW-A-* chassis.
Use the appropriate tip for the video probe
according to the matrix on the last page.
Then inspect the LC surface.
After inspection clean the LC surface with the Dry
Cleaner 1.25 mm.
Check the condition of the LC ferrule surface again
and if necessary, repeat step A and B .
Page 1BDA 636 V1
LASER
1
The sealing shutter mechanism of the opticalCON avoids contamination of the LC ferrule locked inside.
®
The dust-proof design reduces maintenance intervals to a minimum; if nevertheless necessary,
follows the maintenance procedure below to avoid damages on the due to inpropes cleaning.
1.
Video probe tip
Dry Cleaner
A
B
A
B

opticalCON Chassis Cleaning Instruction
Page 2BDA 636 V1
®
opticalCON QUAD Chassis Cleaning
Insert the Inspection Adapter into the FOCD-STC.
®
Insert the unit into the Neutrik opticalCON chassis
NO4-FDW-A
Use the appropriate tip for the video probe
according to the matrix on the last page.
Then inspect the LC surface.
After inspection remove the inspection adapter and
clean the LC surface with the Dry Cleaner 1.25 mm
Check the condition of the LC ferrule surface again
and if necessary, repeat step C and D.
®
opticalCON MTP Chassis Cleaning
®
®
Insert the FOCD-STC in to the Neutrik opticalCON
NO12FDW-A or NO24FDW-A chassis.
Use the appropriate tip for the video probe
according to the matrix on the last page.
Attention:
®
Due to the 8-degree angled MTP singlemode
ferrule. It is not possible to inspect singlemode
®
MTP ferrules.
®
Currently only MTP Multimode ferrules can be
inspected.
C
D
E
2.
Dry Cleaner
F
3.
G
Video probe tip
C
D
E
F
G

Page 2
Draft. Nr.: BDA 636 V1 Update: 2021-11-17
I I
www.neutrik.com
Neutrik AG LI T: +423 / 237 24 24 F: +423 / 232 53 93
Neutrik USA Inc. USA T: +1 704 / 972 3050 F: +1 704 / 438 9202
( )
Neutrik UK Ltd. UK T: +44 1983 / 811 441 F: +44 1983 / 811 439
Neutrik Vertriebs GmbH DE / NL / AT/DK T: +49 8131 / 280 890 F: +49 8131 / 280 830
Neutrik France FR T: +33 1 / 4131 6750 F: +33 1 / 4131 0511
Neutrik Tokyo Ltd. JP T: +81 3 / 3663 4733 F: +81 3 / 3663 4796
Neutrik Hong Kong Ltd. HK T: +852 / 2687 6055 F: +852 / 2687 6052
R
Data subject to change without prior notice. 2021 NEUTRIK . NEUTRIK and opticalCON are registered trademark of Neutrik AG. ALL RIGHTS
® ® ®
©
opticalCON Chassis Cleaning Instruction
®
After inspection clean the MTP surface with the
®
Dry Cleaner MPO / MTP .
®
Check the condition of the MTP surface again and
if necessary, repeat step G and H.
H
H
CLEANING MATRIX
Service Chassis Video Appropriate Brand Dry Cleaning
Tool Probe Tip Tool
FOCD-STC
NO2-4FDW-A
NO2-4FDW-1-A
PT2-LC/PC/F-1
FBPT-LC
LIGHTEL
VIAVI/JDSU
FOCD-DC125
FOID-STQC
FOCD-STC
NO4FDW-A
NO12FDW-A
NO24FDW-A
PT-WO/ADAPT-3/N
FBPP-BAP3
LIGHTEL
VIAVI/JDSU
PT-WO/ADAPT-3/N
only MULTIMODE
FBPP-BAP3
only MULTIMODE
LIGHTEL
VIAVI/JDSU
FOCD-DCM
DI-1000-B2-NT
DI-1000-WIFI
DI-2000-B2-*
CI-1100-A2
FBP-5000
FBPP5000i
FIT-FC-KIT1
FBP-5000
FBPP5000i
FIT-FC-KIT1
DI-1000-B2-NT
DI-1000-WIFI
DI-2000-B2-*
CI-1100-A2
FBP-5000
FBPP5000i
FIT-FC-KIT1
DI-1000-B2-NT
DI-1000-WIFI
DI-2000-B2-*
CI-1100-A2
