Newhank MP103 MK2 USB User manual

USERMANUAL
103MK2USB
MP
www.newhank.com

BoxContent
Rulesforinstallation
ThankyouforbuyingthisNewHankproduct.Pleasereadtheoperating
instructions,soyouwillknowhowtooperateyourmodelproperly.Afteryouhave
finishedreadingtheinstructions,puttheminasafeplaceforfuturereference.
CDPlayer
IECPowerCord
RemoteControl
RCACable
Manual
MakesureallitemslistedintheBOXCONTENTSsectionareincludedinthebox.
Placemixerinanappropriatepositionforoperation.
Makesurealldevicesareturnedoffandallfadersandgainknobsaresetto“zero”.
Connectthestereooutputstopoweramplifiers),tapedecks,and/orotheraudiosources.
PlugalldevicesintoACpower.
Switcheverythingoninthefollowingorder:
1.Audioinputsources(i.e.turntables,CDplayers,etc.)
2.Mixer
3.Last,anyamplifiersoroutputdevices
Whenturningoff,alwaysreversethisoperationby:
1.Turningoffamplifers
2.Mixer
3.Last,anyinputdevices
www.newhank.com 103MK2USB
MP
12
Specifications
Powersupply：AC90v-260v(50hz/60hz)
Power：9w-16w
Headphone：200mv
Audiooutput：200mv
SNR：96db(a-wtd)
Frequency：20hz-20khz
Output：xlr,rca,phones,spdif
Source：cd,cd-r,cd-rw,wav,mp3,usb
Disc：12cm
Distortion：<0.01%(200hzlpf20khzlpf)
Dynamic：>98db(20khzlpfa-wtd)
Separation：>90db(at-1khz)
Distortion：>0.01%
Datadecoding：24bit
Frequency：44.1khz
Size：483mm×220mm×44mm
Weight：3.5kg
MP103Mk2USB,astheupdateversionhasMastertempo,meaningyoucan
changethepitchwithoutchangingthetone.Itistheperfectsolutionforthe
playbackofWAVandMP3filesfromCD,CDR,CDRWandMP3filesfromUSB
media.Pitchcontrolwithpitchbend,seamlessloopingandetc.
Introduction

www.newhank.com
FrontPanelFunctionDescription
1.Power:Pushthisbuttontoturnpoweronandoff,thebuttonlightsredwhenthe
2.Eject:Pushthisbuttontoloadorejectthedisc,thediscwillnotejectduring
playback. Stop playback before pushing the eject button.
3.Cue:PushingthisbuttonwillsetthecurrentsearchpointasanewCuepoint.(Cue).
4.Play/Pause:Pushoncetostartplayback,onceagaintopauseplayback,andonce
more to resume playback.
5.RewindbuttonPushthisbuttontorewindthesearch.
6.Fastforwardbutton:Pushthisbuttontofastforwardthesearch.
7.Skip.(TrackSelect):Turnthisknobtoselectatrack,bypushingthisknobdown
while turning, the tracks will change by 10 tracks at a time.
8.Backbutton:Showingexecutivefolderandsong’sname.Thefirststageisfolder
name, second stage is songs name, third stage is the state of play.
7-8.Additionalexplaination:Whenplaythecurrentsong,thesong’snameNo.and
the folder No. of LCD screen display normally.searching another folder or songs,
the folder No. or the song’s No. will flicker and the time state would not be
showed. press the confirm button, it will play next song. if it lasts 10 seconds
without searching for actiion, it will back to the curren state of play and will not
9.Disc/USB:PushthisbuttontoswitchbetweenCDinputoraUSBdevice.
10.Repeat:Usethisbuttontorepeattheselectedtrack(repeat1)ortorepeatallthe
tracks of the cd (repeat all).
12.Time:Pushthisbuttontotogglebetweenelapsedtimeremainingtimeortotal
remaining time.
Elapsed time: Showing the elapsed time of the current playing track.
Remaining time: Showing the remaining time of the current playing track.
Total remaining time: Showing how much time is remaining of the whole CD.
13.LoopIn:Pushthisbuttontosetastartlooppointduringplayback,whenno
loop point is set the loop button is flashing.
14.LoopOut:Pushthisbuttonforsettingtheendofthelooppointandreleasing
the loop action. To finish loop mode push this button again.
15.Reloop:Usedforrepeatingthelastsavedloop,Tofinishloopmodepushthis
button again.
16.Mastertempo:Presstostartthemastertempo.whenadj.thepitch.music
tone will not change.
17.Pitchbend-:WhilepushingPitchBend-theplayspeeddecreases,when
releasing this button playing speed returns to the previous speed.
18.Pitchbend+:WhilepushingPitchBend+theplayspeedincreases,when
releasing this button playing speed returns to the previous speed.
19.Pitch:Usethisknobtoincreaseordecreasethespeedofthetrack,thepitch
range hold +/-20%.
20.RemoteControl:Infraredremotecontrolreceiverunit.
21.USBMaster:ConnectyourUSBstoringdevicetothisdevicetoallowthe
MP103 MK2 USB to read and playback your music files. Via the USB master
input not only MP3 files but also WAV files can be read.
22.LargeLCDdisplay:Indicatesallthefunctions,astheyareoccurring,with
the CD.
11.S./C.(SingleandContinuousmode):Togglesbetweensingleandcontinuous
mode.
Single mode:Playback will stop when a track ends.
Continuous mode: When a tracks ends, the next track will play automatically
and the CD itself will stop when the last track has played.
power is on.
103MK2USB
MP
34
121 20 922 83 4 10 11 12 17 16 18

BackPanelFunctionDescription
1. Powerport: Accept ac90V-260V input.
2. RCAout:Stereounbalancedoutput.
3. Balancedout:Stereobalancedoutput.
4. Phonesout:Stereo6.35mmoutput.
5. Level: Adj.phoneslevel.
6. Faderstart:Supportconnectedmixertocontrolplaybutton.
7. Coaxialout:Supportdigitaloutput.
www.newhank.com 103MK2USB
MP
56
103MK2USB
MP
Safety
Thisequipmentisnotwaterproof.
Topreventafireorshockhazard,donotplaceanycontainerfilledwithliquidnear
thisequipment(suchasavaseorflowerpot)orexposeittodripping,splashing,
rainormoisture.
Topreventafirehazard,donotplaceanynakedfamesources(suchasalighted
candle)ontheequipment.
Topreventtheriskofelectricalshock,don’tremovecoverorback.Nouser
serviceablepartsinside.Referservicingtoqualifiedservicepersonnelonly.
