Easedale 5 SE
Multi fuel burning stove.
Installation & user instructions.
(To be left with customer).
Edition 1
Reference: NS-21
Date: 5TH March 2020

2
Contents
Pre-installation checks & general safety notes.
The Clean Air Act 1993 and Smoke Control Areas.
Hetas Ltd approval.
Installation introduction including technical data.
1.0 Technical and emission data.
2.0 Installation introduction
2.1 Unpacking the stove
2.2 Installing the stove
2.2.1 The tertiary air control
2.2.2 Assembling the baffle and removeable internal stove parts
2.2.3 Stove data plate position
2.3 Stove placement / clearance requirements
2.4 The chimney
2.5 Stove pipe connection
2.6 Connecting to a masonry chimney
2.7 Connecting to a stainless-steel twin walled insulated flue system.
2.8 Ventilation (Fresh air supply)
2.9 Chimney Draft
2.92 Carbon Monoxide Alarm.
2.95 The handle
2.96 Commissioning and handover
3.0 User Manual
3.1 Maximum fuel loads and choice of fuel
3.2 Use
3.2.1 Use with wood
3.2.2 Use with approved smokeless fuel
3.2.3 Ash Removal
3.3 Maintenance
3.3.1 Glass panel fixings & fibre rope seal replacement
3.3.2 Door fibre rope seals
3.3.3 Cleaning and maintenance. (User)
3.3.4 Cleaning glass. (User)
3.3.5 Cleaning and checks inside the firebox. (User)
3.3.6 External surface cleaning. (User)
3.4 Operational problems – troubleshooting
3.5 Replacement parts
3.6 Product End-of- Life / Recycling
3.7 Exploded view of stove parts and identification.
3.8 Declaration of Performance
3.9 Energy label
4.0 Product fiche

3
Pre-installation checks & general safety notes
 Installation of this stove must be completed in accordance with current local codes and
regulations in each country. All local regulations & any rules in force, including those which
refer to National and European standards, must be observed when installing this product.
 Reference must be made to current issues of British Standard BS 8303, code of practice for
installation of domestic heating and cooking appliances burning solid mineral fuel and BS EN
15287-1:2007 design, installation, and commissioning of chimneys.
 Note: It is a legal requirement under England & Wales Building Regulations that the
installation of this stove is undertaken under Local Authority Building Control or is installed
by a competent person registered with a Government Approved Competent Persons Scheme.
Hetas Ltd operate such a scheme and a listing of their registered Competent Persons can be
found on their website at www.hetas.co.uk
 Should any conflict occur between these instructions and any regulations and rules in force
then the regulations and rules in force must apply.
 An approved Carbon Monoxide alarm conforming to the latest edition of BS EN 50291 must
be installed into the room into which the stove is installed. Installation and positioning must be
in accordance with current National laws, Building Regulations & any Rules in Force
including (Approved Document J England & Wales). Also refer to the alarm manufacturer's
instructions.
 This stove must not be installed into a flue that shares any other appliance.
 Extractions fans or units must not be installed into the room of stove installation.
 The installer has a responsibility to ensure that all requirements of Health & Safety at Work
Act are observed & implemented as stated on the date of installation.
 Due to the weight of this stove adequate facilities must be available for loading, unloading &
installation.
 Always ensure that there is an adequate air supply into the room containing the stove.
 It is very important that flue ways are regularly swept & checked by an approved person. It is
recommended that sweeping and checking should be done at least twice each year for
approved smokeless fuel use and quarterly each year for wood burning. The installer must
ensure that the chimney is examined for soundness and suitability before the appliance is
installed. Remedial action should be taken if required, seeking expert advice if necessary.
Where the chimney is believed to have previously served an open fire installation it is possible
that the higher flue gas temperatures from a closed appliance may loosen deposits that were
previously firmly adhered, with the consequent risk of flue blockage. It is therefore
recommended that the chimney be swept a second time within a month of regular use after
installation.
 All dampers or restrictors must be removed from the flue.
 This stove must be maintained to ensure safe operation & efficiency.
 Only use this appliance for domestic property heating in accordance with these instructions.
 Fire cement can be caustic & should not be allowed to come into contact with skin. Refer to
manufacturer’s instructions.
 This stove contains no asbestos. If there is any situation or possibility of disturbing any
asbestos during installation seek professional advice.
 An installation / user manual is enclosed with this product. The installation can only be used
after it has been inspected by a qualified inspector. A name plate of heat-resistant material is
affixed to this product. This contains information about identification and documentation for

4
the product.
The Clean Air Act 1993 and Smoke Control Areas
Under the Clean Air Act local authorities may declare the whole or part of the district of the
authority to be a smoke control area. It is an offence to emit smoke from a chimney of a
building, from a furnace or from any fixed boiler if located in a designated smoke control area.
It is also an offence to acquire an "unauthorised fuel" for use within a smoke control area
unless it is used in an "exempt" appliance ("exempted" from the controls which generally
apply in the smoke control area).
The Secretary of State for Environment, Food and Rural Affairs has powers under the Act to
authorise smokeless fuels or exempt appliances for use in smoke control areas in England. In
Scotland and Wales this power rests with Ministers in the devolved administrations for those
countries. Separate legislation, the Clean Air (Northern Ireland) Order 1981, applies in
Northern Ireland. Therefore it is a requirement that fuels burnt or obtained for use in smoke
control areas have been "authorised" in Regulations and that appliances used to burn solid fuel
in those areas (other than "authorized" fuels) have been exempted by an Order made and
signed by the Secretary of State or Minister in the devolved administrations.
Further information on the requirements of the Clean Air Act can be found here:
http://smokecontrol.defra.gov.uk/
Your local authority is responsible for implementing the Clean Air Act 1993 including
designation and supervision of smoke control areas and you can contact them for details of
Clean Air Act requirements"
To ensure smokeless operation opertate the stove in accordance with these instructions. (Please
see instructions within this manual).
The Easedale 5 SE have been recommended as suitable for use in smoke control areas when
burning wood.
The appliance is only exempt when used in accordance with these instructions.
HETAS LTD approval
The Easedale 5 SE appliance has been approved by HETAS Ltd as an intermittent
operating appliance for burning wood logs.

5
1.0 Technical and emission data.
Easedale 5 SE
Material: Steel and cast iron.
Finish: High-temp resistant paint.
Fuel: Wood (Approved wood logs)
Approved smokeless fuels
Log length: 25cm maximum
Flue outlet: Top or rear
Flue pipe dimension: Internal diameter 125mm / 122.7cm2 cross section
Approx. weight: 65kgs
Dimensions, distances etc: Figure 2 & 2A
Technical data according to EN 13240+A2:2004.
Nominal heat output: Wood: 5.0kw
Approved smokeless fuel: 5.0kw
Flue gas mass flow: Wood: 3.9 g/sec
Approved smokeless fuel: 3.6 g/sec
Recommended chimney draught: 12.5 Pa
Efficiency net: Wood: 80.7 %
Efficiency net: Approved smokeless fuel: 79%
CO emission (13% O2): Wood: 0.10%
Approved smokeless fuel: 0.07%
Mean flue gas temperature: Wood: 278 0C
Approved smokeless fuel: 290 0C
Operational mode: Intermittent

6
Emission data wood.
PM mg/m3 @ 13% 02: 11
OGC mg/m3 @ 13% 02: 79
CO emission mg/m3 @ 13% 02: 1250
NoX mg/m3 @ 13% 02: 109
Emission data Maxibrite smokeless fuel
PM mg/m3 @ 13% 02: 13
OGC mg/m3 @ 13% 02: 29
CO emission mg/m3 @ 13% 02: 875
NoX mg/m3 @ 13% 02: 114
2.0 Installation introduction
2.1 Unpacking the stove
After removing the outer packaging, remove the stove from the wooden pallet and place it on a
suitable floor. The cardboard packaging can be placed underneath to prevent marring. Note: There
are 4 lower bolts supplied for fitment into holes in the base of each leg, these are adjustable to
allow level adjustment of the stove to uneven surfaces.
We recommend that two people perform the assembly and installation procedure.
2.2 Installing this stove
The stove and chimney installations MUST comply with all current National and Local Building
Regulations and any Rules in Force including current issues of British Standard BS 8303 code of
practice for installation of domestic heating and cooking appliances approved solid mineral fuel
and British Standards BS EN 15287-1 design, installation and commissioning of chimneys; your
approved dealer or your local building control officer can advise regarding this. Ultimately, it is
you and your installer who is responsible to ensure that the installation complies with all relevant
regulations and any rules in force.
For installations within England and Wales also refer to Document J that gives guidance on
complying with the Building Regulations.
2.2.1 Tertiary air control.
The Tertiary air intake and control is a standard part for the Easedale 5 SE and as such is
assembled to the stove at manufacture. The tertiary air intake has been designed to leave the lower
air intake slider 3mm open when the tertiary air control is in the closed position. When burning
logs or approved smokeless fuel the tertiary air control was set at the closed position.

7
2.2.2 Assembling the baffle and removable internal parts.
See figures 1.1 to 1.10
All stove internal parts are assembled at manufacture, however with movements and handling
during stove delivery it is possible that some or all of the located parts inside the stove may have
moved, therefore it is important to check all these parts for correct position and fitment after the
stove is located. Check the baffles and all other parts are located into correct positions including
side bricks, bottom bricks, grate assembly, banking bar and ash pan. Before lighting the stove for
the first time, confirm the baffle and all parts are in correct location.
Location of non bolted stove internal parts.
Fig 1.1 Drawing of parts that are not bolt fixed to the inside of stove that may have
moved during transportation. These parts must be checked to ensure they are in
correct location before lighting the stove. Note. The top baffle and back brick are
screw fixed and not separate.
Fig 1.1

8
Figure 1.2 Bottom brick positioning
Fig 1.3 Grate positioning

9
Fig 1.4 Lower baffle positioning
Fig 1.5 Side view of stove showing lower baffle position.

10
Fig 1.6 Left & right-hand bricks. Note the right-hand brick has a cut out to clear
handle assembly.
Fig 1.7 Banking bar positioning

11
Fig 1.8 Ash pan positioning.

12
2.2.3 Data plate location. See figure 1.9
Figure 1.9 shows the position of the stove data plate which is located to the rear of the stove. This
shows important information, including:
a) Model
b) Standard number
c) Production date
d) Dimensions
e) Serial number
f) Weight
g) Recommended fuel
h) Co Emissions
j) Efficiency
k) Nominal heat output
L) Notice showing minimum distance to combustibles and other safety notes
m) Manufacturers details
Figure 1.9
Data plate

13
2.3 Stove placement / clearance requirements
This stove must only be installed onto floors with an adequate load-bearing capacity. If an existing
construction does not meet this requirement, suitable measures (e.g. load distributing plate) must
be taken. Must be in accordance with current National Laws, Building Regulations, & any
Rules in Force, including BS 8303 and BS EN 15287-1. Also refer to (Approved Document J
England & Wales)
Wooden floor protection. See: Figure 2 and 2A.
The Easedale 5 SE stove can only be used with a Constructional hearth and Superimposed
hearth. The dimension of the superimposed hearth in front of the stove must be a minimum of
300mm all other dimensions of the superimposed hearth and constructional hearth must be in
accordance with current National Laws, Building Regulations, & any Rules in Force,
including BS 8303 and BS EN 15287-1. Also refer to Approved Document J (England &
Wales)
Distance to wall made of combustible material
See: Figure 2. Also refer to current National laws, Building Regulations, & any Rules in
Force, including BS 8303 and BS EN 15287-1. Also refer to Approved Document J (England
& Wales)
Contact your local building authority regarding restrictions and installation requirements.
To the rear of stove. 850mm
To the side of stove: Left side 600mm / Right side 600mm

14
Distances between stove and a conventional brick Class 1 Chimney.
See: Figure 2A
Refer to current National laws, Building Regulations, & any Rules in Force, including BS
8303 and BS EN 15287-1. Also refer to Approved Document J (England & Wales)
When installing this stove into a conventional class 1 non-combustible brick chimney built to
current National laws, Building Regulations and any Rules in Force including BS 8303 and BS EN
15287-1 the clearances between the stove and a non-combustible brick chimney must comply with
current National laws, Building Regulations & any Rules in Force, however providing all
surrounding non combustible brick walls have a minimum thickness of 200mm the clearance
between the rear & sides of stove can be reduced to 50mm, refer to current National laws,
Building Regulations, & any other Rules in Force. However, it is recommended that the
measurement between the sides & rear of stove to be as large as possible above this dimension, as
the efficiency of this stove is dependent on the clearances as shown in figure 2A.
For all other clearances to a non-combustible brick wall and chimney refer to current National
laws, Building Regulations & any Rules in Force, including BS 8303 and BS EN 15287-1:2007.
Contact your local building authority regarding restrictions and installation requirements.
It is recommended that if a non-combustible fireplace manufactured from natural stone/marble

15
and other non-combustible fireplace types is being installed in conjunction with this stove that the
fireplace supplier is contacted to see what recommended clearances are required between the stove
and the fireplace, although most natural stone and marble is non-combustible there is a possibility
of the stone or marble being damaged such as cracking if the stone or marble material is heated
excessively.
Ceiling protection.
Refer to current National laws, Building Regulations, & any Rules in Force, including BS
8303 and BS EN 15287-1:2007. Also refer to Approved Document J (England & Wales)
Clearances to furniture and soft furnishings
Serious consideration should be given to positioning of furniture or soft furnishings that could be
adversely affected by heat. Newman Fireplaces Ltd recommend that any furniture or soft
furnishings should be a minimum distance of 2000 mm away from the stove. NEVER use or store
aerosol sprays or any other combustible products in the vicinity of the stove when it is in operation
or whenever the stove is hot. The stove will remain hot for some time even after the fire is
extinguished.
When lit, a wood-burning stove gets hot and therefore adequate protection must be provided,

16
particularly in situations where there is a safety risk to children or the infirm. When using this
stove in situations where children, aged and / or infirm persons are present a fireguard
manufactured in accordance with BS 8423:2010 + A1: 2016 must be used and such persons must
be supervised at all times.
It is also recommended that all other people should use a fireguard in accordance with BS
8423:2010 + A1: 2016 at all times when the stove is alight or hot.
2.4 The chimney.
Refer to current National laws, Building Regulations, & any Rules in Force, including
British standard BS EN 15287-1:2007 and BS 8303. Also refer to Approved Document J
(England & Wales)
The construction of the masonry chimneys, flue block chimneys and connecting flue pipe system
must meet the requirements of the current National laws, Building Regulations, and any Rules in
Force.
This stove must never be connected to any shared chimney.
An efficient modern stove places heavy demands on the chimney, and you should have the
chimney regularly swept and inspected at least twice a year for smokeless fuel use and quarterly
for wood fuel use by an approved chimney sweep.
The flue or chimney system must be in good condition. It must be inspected and swept by a
competent registered person and passed for use with the appliance before installation. The
National Association of Chimney sweeps (NACS) and for Northern Ireland (NIACS) Northern
Ireland Association of Chimney Sweeps offer a register of approved chimney sweeping and
inspection services who will issue certificates after inspection and sweeping.
Where the chimney is believed to have previously served an open fire installation it is possible that
the higher flue gas temperatures from a closed appliance may loosen deposits that were previously
firmly adhered, with the consequent risk of flue blockage. It is therefore recommended that the
chimney be swept a second time within a month of regular use after installation.
If it is necessary to fit a register plate it must conform to the current National laws, Building
Regulations, and any Rules in Force.
The minimum height of the flue or chimney must be 4.5m from the hearth to the top of the flue,
with no horizontal sections and a maximum of 4 bends. Bends must have angles of less than 45
degrees from the vertical. There should be at least 600mm of vertical flue pipe above the appliance
before any bends are introduced. Ensure the connecting flue pipe is kept a suitable distance from
any combustible material and does not form part of the supporting structure of the building.
The installer must ensure the flue pipe diameter is not less than the diameter of the outlet of the
appliance and does not narrow to less than the size of the outlet at any point in the system.
Make provision to remove the appliance without the need to dismantle the chimney.
Any existing flue must be confirmed as suitable for the new intended use as defined in the current
Building Regulations.
The flue or chimney systems must be inspected and swept to confirm the system is structurally
sound and free from obstructions by an approved and competent chimney sweep.
The flue exit from the building must comply with National laws, current local building control
rules, Building regulations and any Rules in Force.
Chimney heights and / or separations may need to be increased in particular cases where wind
exposure, surrounding tall buildings, high trees or high ground could have adverse effects on flue
draught

17
It is highly recommended that an approved and certified flexible flue liner that complies with
current National laws, Building Regulations and any Rules in Force of the correct internal
diameter be used to line the chimney, the liner must be approved for use with wood burning and
approved smokeless fuels. Flue liner installation must comply with current National laws,
Building Regulations, and any Rules in force, also refer to the flue liner manufacturer’s
instructions. The flue liner must be replaced when an appliance is replaced, unless proven to be
recently installed and in good condition.
The cross-sectional area of the chimney (at its narrowest point) must comply with current National
and Local Building Regulations and any Rules in Force. Generally, the area needed for a multi fuel
burning stove installation should measure at least 150 mm internal diameter. Please refer to current
National laws, Building Regulations and any Rules in Force.
Important note: The Easedale 5 SE has been tested for smoke exemption so a minimum internal
flue diameter of 125mm can normally be used. *(This must be confirmed with HETAS or Local
Authority Building Control and all current National laws, Building regulations and any Rules in
Force).
An over-sized chimney is generally hard to keep warm and results in poor draft. In cases where
there is an oversized masonry chimney, it is highly recommended that the chimney be lined using
an appropriate and approved chimney lining system with the correct internal diameter as stated
above.
With respect to the chimney termination, all chimneys should terminate in accordance with current
National and Local Building Regulations and any Rules in Force.
Note that current National and Local Regulations also apply regarding the placement of chimneys
and flues in connection with thatched roofs.
The chimney or flue system must be equipped with access doors for inspection and cleaning. The
size of the cleaning door in the chimney must at least equal to that of the cross-sectional area of
the chimney. In the event that a chimney fire occurs resulting from faulty operation or prolonged
use of damp wood fuel, if safely possible close the air vents of the stove completely, evacuate all
persons from the building and contact your local fire department immediately.
2.5 Stove Pipe connection .
Refer to current National laws, Building Regulations, and any Rules in Force including BS
8303 and BS EN 15287-1:2007. Also refer to Approved Document J (England & Wales)
There are two stove flue exits enabling either top or rear venting depending on installation
requirements.
Install the flue collar to the stove securely using the bolts supplied to the flue exit position required,
ensure the joint between the flue collar and stove is fully sealed using suitable stove sealer or
gasket. Install the blanking plate securely to blank the redundant stove flue exit using the fixing
bolts supplied, ensure the blanking plate is fully sealed to the stove using suitable stove sealer or
gasket See figures 3 and 3A.
A suitably gauged metal rigid stove flue pipe of the correct size complying with current National
laws, Building Regulations, and any Rules in Force (not supplied), is connected to the flue collar.
The joint between the stove collar and rigid stove pipe MUST BE fully sealed using suitable stove
rope / fire cement. When the rigid stove flue pipe is fully inserted into the stove flue collar drill
two suitably sized holes in a suitable position 180 apart through the stove flue collar and rigid
stove pipe and use either corrosion proof self-tapping screws or bolts, nut and washers of suitable
size to ensure the rigid stove pipe is unable to be pulled out of the stove collar. Ensure the

18
self-tapping screw or bolt nut and washers do not obstruct the stove collar flue way and ensure the
screws or bolts and locating holes are airtight.
The chimney or flue way that the stove pipe is connected must be of at least 125mm internal
diameter. (ii) rectangular or square flues having the same internal cross-sectional area and a
minimum dimension of 100mm for straight flues or 125mm for flues with bends or offsets. Refer
to current Building Regulations, any Rules in Force including BS 8303 and BS EN 15287-1
*(This must be confirmed with HETAS or Local Authority Building Control and all current
National laws, Building regulations and any Rules in Force).
Fig 3.
The left picture shows the flue collar and fixings if using the stove top flue exit.
The right picture shows the flue exit blanking plate and fixings if not using the stove top flue
exit, in this case you would have opted to use the rear flue exit of which the flue collar and
fixings would be installed.
Figure 3A
Showing the configuration if using the top flue exit.
The stove flue collar is installed to the top of the stove and the flue exit blanking plate is installed
to the rear of stove flue exit.

19
2.6 Connecting to a masonry chimney
Refer to current National laws, Building Regulations, & any Rules in Force, including BS
8303 and BS EN 15287-1:2007. Also refer to Approved Document J (England & Wales)
The stove with rigid stove pipe connection to the chimney and flue and any parts used for this
connection must be in accordance with current National laws, Building Regulations, and any Rules
in Force.
It is highly recommended that an approved flue liner that complies to current National laws,
Building Regulations and any Rules in Force of the correct internal diameter be used to line the
chimney, the liner must be approved for use with both wood burning and approved mineral
smokeless fuel. Flue liner installation must comply with current National laws, Building
Regulations, and any Rules in Force, also refer to the flue liner manufacturer’s instructions.
The chimney or flue system must be equipped with access doors for inspection and cleaning. The
size of the cleaning door in the chimney must at least equal to that of the cross-sectional area of
the chimney.
The chimney or flue way that the stove pipe is connected must be of at least 125mm internal
diameter. (ii) rectangular or square flues having the same internal cross-sectional area and a
minimum dimension of 100mm for straight flues or 125mm for flues with bends or offsets. Refer
to current Building Regulations, and any Rules in Force including BS 8303 and BS EN 15287-1
*(This must be confirmed with HETAS or Local Authority Building Control and all current
National laws, Building regulations and any Rules in Force).
2.7 Connecting to a stainless steel twin wall insulated flue system
Refer to current National laws, Building Regulations, & any Rules in Force, including BS
8303 and BS EN 15287-1:2007. Also refer to Approved Document J (England & Wales)
If the installation is to use a suitable and approved twin walled stainless steel insulated flue system
you must comply with current National laws, Building Regulations and any Rules in Force,
including referring to the flue manufacturer’s instructions concerning installation and clearances to
combustible materials such as walls, floor joists and ceilings etc.
It is important that the insulated flue system is properly supported both at ceiling level and at roof
level.
The Stove must not bear the weight of the chimney system (See chimney flue manufacturer’s
instructions). Excessive weight on the stove will inhibit expansion and could lead to damage of the
stove top. Damage caused to the stove in this way would not be covered by the manufacturers
guarantee.
The chimney or flue system must be equipped with access doors for inspection and cleaning. The
size of the cleaning door in the chimney must at least equal to that of the cross-sectional area of
the chimney.
The flue way that the stove is connected must be of at least 125mm internal diameter.
*(This must be confirmed with HETAS or Local Authority Building Control and all current
National laws, Building regulations and any Rules in Force).

20
2.8 Ventilation (Fresh air supply):
Refer to current National laws, Building Regulations, & any Rules in Force, including BS
8303 and BS EN 15287-1:2007. Also refer to Approved Document J (England & Wales)
The Easedale 5 SE, nominal heat output 5.0kw. Note: This is the nominal heat output not the
maximum heat output.
A Multi Fuel burning stove requires air for combustion and therefore you may need to install
additional ventilation to the room. An adequate air supply for ventilation & combustion is required
to the room into which the stove is installed. As this stove is CE tested to 5kw nominal heat output.
a purpose provided air vent is not normally required, (England and Wales).
 However, in certain circumstances a purpose provided air vent may be required such as
insufficient natural ventilation, a flue draught stabiliser is fitted and date of building
construction etc.
 Refer to current National laws, Building Regulations and any Rules in Force to any other
nation, country, or area outside of England for ventilation requirements.
 We suggest that it is advantageous to provide an air supply into the room that the stove is
installed.
 When determining the ventilation requirements account will need to be made for any other
combustion devices in the room.
 Purpose provided air vents must be of the correct size, be non-closable and unrestricted,
and must comply with current National laws, Building Regulation & any other Rules in
Force.
 Installation of purpose provided air vents must be installed to comply with current National
laws, Building Regulation & any other Rules in Force.
 Extractor fans or any other similar devices must not be installed in the room into which the
stove is installed.
 Air inlet vents should be positioned in the room at locations to avoid them becoming
blocked. If the air supply is inadequate the chimney draft may be too weak, with the
possible result that the stove will not burn properly leading to a potentially dangerous
situation. Smoke spillage may also occur especially during the refueling process.
 If there is an extraction fan fitted in adjacent rooms where this appliance is fitted,
additional air vents may be required to alleviate the possibility of spillage of products of
combustion from the appliance / flue while the fan is in operation. Refer to B.S. 8303 Part
1. Where such an installation exists, a test for spillage should be made with the fan or fans
and other appliances using air in operation at full rate, (i.e. extraction fans, tumble dryers)
with all external doors and windows closed. If spillage occurs following the above
operation, an additional air vent of sufficient size to prevent this occurrence should be
installed.
 This stove requires an adequate air supply in order for the stove to operate safely and
efficiently. The installer may have fitted a permanent air supply vent into the room in
which the stove is installed to provide combustion and / or ventilation air. This air vent
should not under any circumstances be shut off or sealed.
