NexAIoT NISE 109 User manual

NexAIoT Co., Ltd.
NexAIoT Co., Ltd.
Published January 2022 www.nexaiot.com
IoT Automation Solutions Business Group
Fan-less Computer
NISE 109
User Manual

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. ii NISE 109 User Manual
Contents
Contents
Preface
Copyright ............................................................................................. iv
Disclaimer.............................................................................................. iv
Acknowledgements ............................................................................... iv
Regulatory Compliance Statements........................................................ iv
Declaration of Conformity...................................................................... iv
RoHS Compliance ................................................................................... v
Warranty and RMA ................................................................................ vi
Installation Recommendations................................................................vii
Safety Information ................................................................................viii
Safety Precautions.................................................................................. ix
Technical Support and Assistance............................................................ x
Conventions Used in this Manual............................................................ x
Global Service Contact Information........................................................ xi
Package Contents.................................................................................xiii
Ordering Information ............................................................................xiv
Chapter 1: Product Introduction
Overview ................................................................................................1
Hardware Specifications..........................................................................2
Knowing Your NISE 109..........................................................................4
Front Panel..........................................................................................4
Rear Panel ...........................................................................................5
Mechanical Dimensions...........................................................................6
Chapter 2: Jumpers and Connectors
Before You Begin ....................................................................................7
Precautions ............................................................................................7
Jumper Settings ......................................................................................8
Locations of the Jumpers and Connectors for NISB 109...........................9
NISB 109 .............................................................................................9
Top View..........................................................................................9
Bottom View..................................................................................10
DIP Switches .........................................................................................11
Clear CMOS Switch...........................................................................11
ATX/AT Mode Selection .....................................................................11
Connector Pin Definitions .....................................................................12
External I/O Interfaces .......................................................................12
USB2.0 Ports x2 .............................................................................12
Connector location: CN1................................................................12
USB3.0 + USB2.0 Ports...................................................................12
USB3.0 Ports x2 ................................................................................13
HDMI Connector ...............................................................................13
DisplayPort Connector.......................................................................14
LAN Ports x2......................................................................................14
Internal Connectors...........................................................................15
SATA Connector.............................................................................15
GPIO Connector.............................................................................15
COM1 Connector ..........................................................................16
COM2 Connector ..........................................................................16
COM3 Connector ..........................................................................17

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. iii NISE 109 User Manual
Contents
COM4 Connector ..........................................................................17
DE1 Connector ..............................................................................18
Power Button.................................................................................18
Audio Line In Connector ................................................................19
Audio Line Out Connector .............................................................19
Audio MIC In Connector ................................................................20
Vin Power Terminal Block ...............................................................20
LCD Backlight Connector ...............................................................21
SATA Power Connector..................................................................21
Flash BIOS Pin Header ....................................................................22
Remote Power On/Off THR.............................................................22
Panel LED Pin Header .....................................................................23
Reset Pin Header............................................................................23
LCD Backlight Control Voltage Select Pin Header............................24
LCD Voltage Select Pin Header .......................................................24
USB2.0 Port Pin Header..................................................................25
COM2 Pin9 R#/5V Select Pin Header ..............................................25
Remote Power On/Off & S3 Pin Header..........................................26
Nano SIM Connector......................................................................26
LVDS Connector 1 of 2 (Reserved for APPC/IPPC project)................27
LVDS Connector 2 of 2 (Reserved for APPC/IPPC project)................27
RTC Battery....................................................................................28
M.2 Key B Connector.....................................................................29
Mini PCIe Connector......................................................................30
DDR4 SO-DIMM.............................................................................31
Chapter 3: System Setup
Removing the Chassis Cover ................................................................34
Installing a SO-DIMM Memory Module .................................................35
Installing a SIM Card.............................................................................37
Installing a Mini-PCIe Module................................................................39
Installing an M.2 Module (2242) ...........................................................41
Wall Mounting Instructions ...................................................................43
Chapter 4: BIOS Setup
About BIOS Setup.................................................................................44
When to Configure the BIOS.................................................................44
Default Configuration...........................................................................45
Entering Setup......................................................................................45
Legends................................................................................................45
BIOS Setup Utility..................................................................................47
Main .................................................................................................47
Advanced .........................................................................................48
Chipset..............................................................................................56
Security .............................................................................................57
Boot..................................................................................................58
Save & Exit ........................................................................................59
Appendix A: LED Status.........................................60

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. iv NISE 109 User Manual
Preface
PrefaCe
Copyright
This publication, including all photographs, illustrations and software, is
protected under international copyright laws, with all rights reserved. No
part of this manual may be reproduced, copied, translated or transmitted in
any form or by any means without the prior written consent from NexAIoT
Co., Ltd.
Disclaimer
The information in this document is subject to change without prior notice and
does not represent commitment from NexAIoT Co., Ltd. However, users may
update their knowledge of any product in use by constantly checking its manual
posted on our website: http://www.nexaiot.com. NexAIoT shall not be liable for
direct, indirect, special, incidental, or consequential damages arising out of the
use of any product, nor for any infringements upon the rights of third parties,
which may result from such use. Any implied warranties of merchantability or
fitness for any particular purpose is also disclaimed.
Acknowledgements
NISE 109 is a trademark of NexAIoT Co., Ltd. All other product names
mentioned herein are registered trademarks of their respective owners.
Regulatory Compliance Statements
This section provides the FCC compliance statement for Class A devices and
describes how to keep the system CE compliant.
Declaration of Conformity
FCC
This equipment has been tested and verified to comply with the limits for
a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference
to radio communications. Operation of this equipment in a residential area
(domestic environment) is likely to cause harmful interference, in which
case the user will be required to correct the interference (take adequate
measures) at their own expense.
CE
The product(s) described in this manual complies with all applicable
European Union (CE) directives if it has a CE marking. For computer systems
to remain CE compliant, only CE-compliant parts may be used. Maintaining
CE compliance also requires proper cable and cabling techniques.

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. vNISE 109 User Manual
Preface
RoHS Compliance
NexAIoT RoHS Environmental Policy and Status
Update
NexAIoT is a global citizen for building the digital
infrastructure. We are committed to providing green
products and services, which are compliant with
European Union RoHS (Restriction on Use of Hazardous Substance in
Electronic Equipment) directive 2011/65/EU, to be your trusted green
partner and to protect our environment.
RoHS restricts the use of Lead (Pb) < 0.1% or 1,000ppm, Mercury (Hg) < 0.1%
or 1,000ppm, Cadmium (Cd) < 0.01% or 100ppm, Hexavalent Chromium
(Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or
1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm.
In order to meet the RoHS compliant directives, NexAIoT has established an
engineering and manufacturing task force to implement the introduction
of green products. The task force will ensure that we follow the standard
NexAIoT development procedure and that all the new RoHS components
and new manufacturing processes maintain the highest industry quality
levels for which NexAIoT are renowned.
The model selection criteria will be based on market demand. Vendors and
suppliers will ensure that all designed components will be RoHS compliant.
How to recognize NexAIoT RoHS Products?
For existing products where there are non-RoHS and RoHS versions, the
suffix “(LF)” will be added to the compliant product name.
All new product models launched after January 2013 will be RoHS compliant.
They will use the usual NexAIoT naming convention.

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. vi NISE 109 User Manual
Preface
Warranty and RMA
NexAIoT Warranty Period
NexAIoT manufactures products that are new or equivalent to new in
accordance with industry standard. NexAIoT warrants that products will be
free from defect in material and workmanship for 2 years, beginning on the
date of invoice by NexAIoT.
NexAIoT Return Merchandise Authorization (RMA)
▪Customers shall enclose the “NexAIoT RMA Service Form” with the
returned packages.
▪Customers must collect all the information about the problems
encountered and note anything abnormal or, print out any on-screen
messages, and describe the problems on the “NexAIoT RMA Service
Form” for the RMA number apply process.
▪Customers can send back the faulty products with or without accessories
(manuals, cable, etc.) and any components from the card, such as CPU
and RAM. If the components were suspected as part of the problems,
please note clearly which components are included. Otherwise, NexAIoT
is not responsible for the devices/parts.
▪Customers are responsible for the safe packaging of defective products,
making sure it is durable enough to be resistant against further damage
and deterioration during transportation. In case of damages occurred
during transportation, the repair is treated as “Out of Warranty.”
▪Any products returned by NexAIoT to other locations besides the
customers’ site will bear an extra charge and will be billed to the customer.
Repair Service Charges for Out-of-Warranty Products
NexAIoT will charge for out-of-warranty products in two categories, one is
basic diagnostic fee and another is component (product) fee.
System Level
▪Component fee: NexAIoT will only charge for main components such as
SMD chip, BGA chip, etc. Passive components will be repaired for free,
ex: resistor, capacitor.
▪Items will be replaced with NexAIoT products if the original one cannot
be repaired. Ex: motherboard, power supply, etc.
▪Replace with 3rd party products if needed.
▪If RMA goods can not be repaired, NexAIoT will return it to the customer
without any charge.
Board Level
▪Component fee: NexAIoT will only charge for main components, such as
SMD chip, BGA chip, etc. Passive components will be repaired for free,
ex: resistors, capacitors.
▪If RMA goods can not be repaired, NexAIoT will return it to the customer
without any charge.

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. vii NISE 109 User Manual
Preface
Warnings
Read and adhere to all warnings, cautions, and notices in this guide and
the documentation supplied with the chassis, power supply, and accessory
modules. If the instructions for the chassis and power supply are inconsistent
with these instructions or the instructions for accessory modules, contact
the supplier to find out how you can ensure that your computer meets
safety and regulatory requirements.
Cautions
Electrostatic discharge (ESD) can damage system components. Do the
described procedures only at an ESD workstation. If no such station is
available, you can provide some ESD protection by wearing an antistatic
wrist strap and attaching it to a metal part of the computer chassis.
Installation Recommendations
Ensure you have a stable, clean working environment. Dust and dirt can get
into components and cause a malfunction. Use containers to keep small
components separated.
Adequate lighting and proper tools can prevent you from accidentally
damaging the internal components. Most of the procedures that follow
require only a few simple tools, including the following:
▪A Philips screwdriver
▪A flat-tipped screwdriver
▪A grounding strap
▪An anti-static pad
Using your fingers can disconnect most of the connections. It is recommended
that you do not use needle-nose pliers to disconnect connections as these
can damage the soft metal or plastic parts of the connectors.

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. viii NISE 109 User Manual
Preface
Safety Information
Before installing and using the device, note the following precautions:
▪Read all instructions carefully.
▪Do not place the unit on an unstable surface, cart, or stand.
▪Follow all warnings and cautions in this manual.
▪When replacing parts, ensure that your service technician uses parts
specified by the manufacturer.
▪Avoid using the system near water, in direct sunlight, or near a heating
device.
▪The load of the system unit does not solely rely for support from the
rackmounts located on the sides. Firm support from the bottom is highly
necessary in order to provide balance stability.
▪The computer is provided with a battery-powered real-time clock circuit.
There is a danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the manufacturer.
Discard used batteries according to the manufacturer’s instructions.
▪This product is intended to be supplied by an approved power adapter,
rated 12Vdc, 5A or 24Vdc, 2.5A minimum and Tma 55 degree Celsius.
If further assistance is needed, please contact NexAIoT for further
information.
CAUTION!
CAUTION!CAUTION!
Danger of explosion if battery is incorrectly replaced.
Replace with the same or equivalent type recommended by
the manufacturer. Discard used batteries according to the
manufacturer’s instructions.
CAUTION!
CAUTION!CAUTION!
ATTENTION
IL Y A RISQUE D’EXPLOSION SI LA BATTERIE EST REMPLACÉE
PAR UNE BATTERIE DE TYPE INCORRECT.
METTRE AU REBUT LES BATTERIES USAGÉES
CONFORMÉMENT AUX INSTRUCTIONS.

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. ix NISE 109 User Manual
Preface
Safety Precautions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a
damp cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the
equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a stable surface during installation. Dropping it or
letting it fall may cause damage.
7. The openings on the enclosure are for air convection to protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting
the equipment to the power outlet.
9. Place the power cord in a way so that people will not step on it. Do not
place anything on top of the power cord. Use a power cord that has been
approved for use with the product and that it matches the voltage and
current marked on the product’s electrical range label. The voltage and
current rating of the cord must be greater than the voltage and current
rating marked on the product.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical
shock.
13. This equipment is not suitable for use in locations where children are
likely to be present.
14. Ensure to connect the power cord to a socket-outlet with earthing
connection.
15. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
16. If one of the following situations arises, get the equipment checked by
service personnel:
a. The power cord or plug is damaged.
b.Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d.The equipment does not work well, or you cannot get it to work
according to the user’s manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
17. Do not place heavy objects on the equipment.
18. The unit uses a three-wire ground cable which is equipped with a third
pin to ground the unit and prevent electric shock. Do not defeat the
purpose of this pin. If your outlet does not support this kind of plug,
contact your electrician to replace your obsolete outlet.
19. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. xNISE 109 User Manual
Preface
Technical Support and Assistance
1. For the most updated information of NexAIoT products, visit NexAIoT’s
website at www.nexaiot.com.
2. For technical issues that require contacting our technical support team or
sales representative, please have the following information ready before
calling:
– Product name and serial number
– Detailed information of the peripheral devices
– Detailed information of the installed software (operating system,
version, application software, etc.)
– A complete description of the problem
– The exact wordings of the error messages
Warning!
1. Handling the unit: carry the unit with both hands and handle it with care.
2. Maintenance: to keep the unit clean, use only approved cleaning products
or clean with a dry cloth.
Conventions Used in this Manual
Warning:
Information about certain situations, which if not observed,
can cause personal injury. This will prevent injury to yourself
when performing a task.
CAUTION!
CAUTION!CAUTION! Caution:
Information to avoid damaging components or losing data.
Note:
Provides additional information to complete a task easily.

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. xi NISE 109 User Manual
Preface
Global Service Contact Information
Headquarters
NEXCOM International Co., Ltd.
9F, No. 920, Chung-Cheng Rd.,
Zhonghe District, New Taipei City, 23586,
Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
www.nexcom.com
Asia
Taiwan
NexAIoT Headquarters
Industry 4.0 and Cloud Services
13F, No.916, Zhongzheng Rd.,
Zhonghe District, New Taipei City,
23586, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexaiot.com
NexAIoT Co., Ltd.
Taichung Office
16F, No.250, Sec. 2, Chongde Rd.,
Beitun District,
Taichung City, 406, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexaiot.com
NexCOBOT Taiwan Co., Ltd.
13F, No.916, Chung-Cheng Rd.,
Zhonghe District,
New Taipei City, 23586, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcobot.com
GreenBase Technology Corp.
13F, No.922, Chung-Cheng Rd.,
Zhonghe District,
New Taipei City, 23586, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com.tw
EMBUX Technology Co., Ltd.
13F, No.916, Chung-Cheng Rd.,
Zhonghe District,
New Taipei City, 23586, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com.tw
TMR Technology Corp.
13F, No.916, Chung-Cheng Rd.,
Zhonghe District,
New Taipei City, 23586, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com.tw
China
NEXSEC Incorporated
5F, No.4, No.7 Fengxian Middle Rd.,
(Beike Industrial Park), Haidian District,
Beijing, 100094, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexsec.cn
NEXCOM Shanghai
No.4, 16 Building,
Shanghai OMNI Tech & Science Park
No. 1699, Douhui Rd.,
Shanghai, 201108, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. xii NISE 109 User Manual
Preface
NexCOBOT China
Room 501, Building 1, Haichuang Building,
No.7 Qingyi Road, Guicheng Street,
Nanhai District, Foshan City,
Guangdong Province, 528314, China
Tel: [phone]
Email: [email protected]
www.nexcobot.com.cn
Beijing NexGemo Technology Co.,Ltd.
5F, Gemotech Building, No.1, Development Rd.,
Changping International Information Industry Base,
Changping District,
Beijing, 102206, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexgemo.cn
Japan
NEXCOM Japan
9F, Tamachi Hara Bldg.,
4-11-5, Shiba Minato-ku,
Tokyo, 108-0014, Japan
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom-jp.com
NEXCOM Surveillance Technology Corp.
5F, Building C, ZhenHan Industrial Zone,
GanKeng Community, Buji Street,
LongGang District,
ShenZhen, 518112, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
NEXCOM United System Service
Room 603/604, Huiyinmingzun Plaza Bldg. 1,
No. 609, Yunlin East Rd.,
Shanghai, 200062, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
NEXGOL Chongqing
1F, Building B4, Electronic 2nd Area,
(Phoenix Lake Industrial Park), Yongchuan Dist.,
Chongqing City, 402160, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcobot.com/NexGOL
America
USA
NEXCOM USA
46665 Fremont Blvd.,
Fremont CA 94538, USA
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcomusa.com
Europe
United Kingdom
NEXCOM EUROPE
10 Vincent Avenue,
Crownhill Business Centre,
Milton Keynes, Buckinghamshire
MK8 0AB, United Kingdom
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.co.uk

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. xiii NISE 109 User Manual
Preface
Package Contents
Before continuing, verify that the package that you received is complete.
Your NISE 109 package should have all the items listed in the following table.
Item Part Number Description Qty
1 4NCPM00302X00 (T)Terminal Blocks 3P Phoenix Contact:1777992 5.08mm MALE DIP GREEN 1
2 4NCPM00203X00 Terminal Blocks 2P Phoenix Contact:1803578 3.81mm MALE ASSY GREEN 1
3 5050900008X00 Mini PCI-e Bracket Ver:A MP 30x29x2.1mm SPCC T=1.0mm 1
4 5060900226X00 Mini PCI-e Bracket CHYUAN-JYH 29x30x2.1mm SPCC T=1.0mm NI 1
5 5061600245X00 Washer Kangyang:TW-320-01 10.4x6.4mm T=1mm NYLON BLACK 4
6 5060200437X00 Thermal Pad E-Lin 30x20x12mm PK404SHC With Back Glue 2
7 50311F0144X00 I Head Screw Long Fei: M3x4mm NI NYLOK 5
8 50311F0295X00 Flat Head Screw Long Fei:F2x4 NYLOK NIGP F2x4 NIGP NYLOK 1
9 50311F0330X00 Round Head Screw Long Fei:P2x3 ISO+NYLON P2x3 NI NYLOK 2
10 50311P0014X00 P Head Screw Kang Yang:M3-5 5.5x2.1x5mm PLASTICS 4

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. xiv NISE 109 User Manual
Preface
Ordering Information
The following information below provides ordering information for
NISE 109.
NISE 109-E01 system (P/N: 10J00010900X0)
▪Intel®Atom®processor x6211E 1.3Ghz
NISE 109-E02 system (P/N: 10J00010901X0)
▪Intel®Celeron®processor J6412 2.0Ghz
▪24V, 60W AC to DC power adapter w/o power cord
(P/N: 7400060054X00)
▪24V, 120W AC /DC power adapter w/o power cord
(P/N: 7400120029X00)

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. 1NISE 109 User Manual
Chapter 1: Product Introduction
ChaPter 1: ProduCt IntroduCtIon
Key Features
▪Onboard Intel®Celeron®630SE Processor J6412 2.0Ghz or Atom®
Processor x6211E 1.3Ghz
▪Dual display port: 1 x HDMI & 1 x DP
▪2 x Intel® I210-IT GbE LAN ports; support WoL, teaming, PXE and
Ethercat
▪3 x USB3.0 & 3 x USB2.0
▪2 x RS232 & 2 x RS232/422/485
▪Support 1 x 2.5” SSD & 1 x M.2 Key B storage
▪Support 9~30V DC input; support ATX power mode
▪Operation temperature
- Intel®Celeron®J6412: -5~55°C
- Intel Atom®x6211E: -20~70°C
▪Support 1 x M.2 & 1 x mini-PCIe expansion slot
Overview

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. 2NISE 109 User Manual
Chapter 1: Product Introduction
Hardware Specifications
CPU Support
▪Onboard Intel®Celeron®processor J6412 2.0Ghz
▪Onboard Intel Atom®processor x6211E 1.3 Ghz
Main Memory
▪1 x SO-DIMM DDR4 non ECC up to 2666 MT/s, 16G max., support
IBECC, non-ECC, and un-buffered memory
Display Option
▪1 x DP 1.4
▪1 x HDMI 1.4
I/O Interface - Front
▪ATX power on/off switch
▪Status LEDs: storage, battery, and COM1/2 TX/RX.
▪3 x USB 3.0 (900mA per each)
▪1 x USB 2.0 (500mA per each)
▪2 x Intel® I210-IT GbE LAN ports; support WoL, teaming and PXE
▪1 x DP
▪1 x HDMI
▪1 x DB9 for COM3, it supports RS232/422/485 with auto flow control
- Jumper-free setting on RS232/422/485 by BIOS
▪1 x Line-out and 1 x Mic-in
▪1 x Optional I/F window
▪3-pin DC input, support 9~30V DC
I/O Interface - Rear
▪3 x DB9 for COM2, COM3 & COM4
- COM2: RS232/422/485 auto flow control
- COM3 & COM4: RS232
▪2 x USB 2.0 (500mA per each)
▪1 x 2-pin remote power on/off switch
▪2 x Antenna hole for optional Wi-Fi/4G/LTE antenna
Storage Device
▪1 x M.2 (SATA/PCIe x 1, 2242, Key B & B+M)
▪1 x 2.5“ SATAIII SSD
Expansion Slot
▪1 x mini-PCIe socket for optional Wi-Fi/3.5G/4G/LTE module (for
3.5G/4G/LTE function, support SIM card holder onboard)
Power Requirements
▪Power input: +9 to +30V DC
▪1 x Optional 24V, 60W power adapter
Supported OS
▪Windows 10 64-bit
▪Linux Kernel
Dimensions
▪185mm (W) x 131mm (D) x 54mm (H) without wall mount bracket

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. 3NISE 109 User Manual
Chapter 1: Product Introduction
Construction
▪Aluminum and metal chassis with fanless design
Environment
▪Operating temperature
(according to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14):
– NISE 109-E01 ambient with air flow: -20°C to 70°C
– NISE 109-E02 ambient with air flow: -5°C to 55°C
▪Storage temperature: -20°C to 80°C
▪Relative humidity: 10% to 90% (non-condensing)
▪Shock protection:
– HDD: 20G, half sine, 11ms, IEC60068-2-27
– M.2: 50G, half sine, 11ms, IEC60068-2-27
▪Vibration protection with SSD & M.2 condition:
– Random: 2Grms @ 5~500 Hz, IEC60068-2-64
– Sinusoidal: 2Grms @ 5~500 Hz, IEC60068-2-6
Certifications
▪CE approval
– EN61000-6-2
– EN61000-6-4
▪FCC Class A
OS Support
▪Linux Kernel version 4.1
▪Windows 10 IoT Enterprise, 64-bit

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. 4NISE 109 User Manual
Chapter 1: Product Introduction
Knowing Your NISE 109
Front Panel
HDMI
MIC-In
Line-Out
Power
Switch
Power Switch
Press to power-on or power-off the system.
System status LED
Indicates the power status, RTC battery status, storage activity, serial port
send (Tx), and transmit (Rx) activity of the system.
USB 2.0
USB 2.0 ports to connect the system with USB 2.0/1.1 devices.
USB 3.0
USB 3.0 ports to connect the system with USB 3.0/2.0 devices.
DisplayPort
A DisplayPort port used to connect DisplayPort interface displays.
HDMI
A HDMI port used to connect HDMI interface displays.
LAN
Two RJ45 ports used to connect the system to a local area network.
DC Input
Used to plug a DC power cord.
COM
– COM1: RS232/422/485 with auto flow control
Mic-In/Line-Out
Mic-In: Used to connect an external microphone
Line-Out: Used to connect a headphone or a speaker.
DisplayPort
USB3.0
USB2.0
USB3.0
LAN
3pin 9~30V
DC input
System
status LED
COM1: RS232/422/485

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. 5NISE 109 User Manual
Chapter 1: Product Introduction
Remote On/Off Switch
Used to connect a remote to power on/off the system.
USB 2.0
USB 2.0 ports to connect the system with USB 2.0/1.1 devices.
COM
– COM2: RS232/422/485 with auto flow control
– COM3&4: RS232
Rear Panel
USB2.0 2-pin remote
power on/off
switch
COM3&4: RS232
COM2: RS232/422/485

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. 6NISE 109 User Manual
Chapter 1: Product Introduction
Mechanical Dimensions
206
184.85 54
115
131
