IEI Technology AFL-W19A User manual

AFL-W19A/W19B/17D/W15A-N270 Panel PC
Page i
IEI Technology Corp.
User Manual
MODEL:
AFL-W19A/W19B/17D/W15A-N270
Panel PC with Touch Screen Intel
®
CPU
Gigabit Ethernet, USB, Audio, RS-232/422/485, SATA
RoHS Compliant, IP 64 Protection
Rev. 1.04 – 19 November 2009

AFL-W19A/W19B/17D/W15A-N270 Panel PC
Page ii
Revision
Date Version Changes
19 November 2009 1.04 Updated I/O diagrams
3 November 2009 1.03 Changed jumper settings section
26 May 2009 1.02 Minor updates
8 April 2009 1.01 Added 15"
18 March 2009 1.00 Initial release
