Assembly instructions
299836 / M01028
HELSINKI LIV 5PC
CHAIR X2
SIZE: (H)86X(W)73(REAR LEGS)/70(ARMRESTS)X(D)80CM
2-SEAT SOFA X1
SIZE: (H)86X(W)136X(D)80CM
BIG COFFEE TABLE X1
SIZE: (H)35XDIA71CM
SMALL COFFEE TABLE X1
SIZE: (H)43XDIA51CM
IMPORTANT RETAIN FOR FUTURE REFERENCE
Actual product size
Need Help?
With: Assembly instructions
Missing or damaged parts
CALL: 0333 777 8999

1
299836 / M01028
HELSINKI LIV 5PC
Don’ts
Do not stand on your chair.
BEFORE YOU START
You can write to us at
Home Customer Services
Next Retail Ltd,
Desford Road,
Leicester,
LE19 4AT
Home service technicians
If you have a fault with your product please contact our
customer service team on 0333 777 8999. If you have had the
product for 28 days or less you may be offered a replacement,
refund or for a fully trained home service technician to visit your
home to assess the fault and repair the product where possible.
If you have had the product for more than 28 days we will send
an independant home service technician to review and repair
the product where possible and recommend further action.
Missing parts
If you are missing any fixtures and fittings for your product
please contact our customer service team on 0333 777 8999
and they will be happy to arrange for a replacement to be sent
to you free of charge.
Time to assemble
Number of people required to assemble
Two persons are required to assemble this item.
45 Mins
Assembly instructions
Warnings
For domestic and outdoor use only.
We suggest you retain these instructions for future reference.
Keep fittings out of children’s reach and keep children well
away from construction area.
Please periodically check all fittings and re-tighten as necessary.
Please do not sit or stand on your table.
Unwrap all packaging materials and place the components on
top of the carton box or on a clean floor to protect it from
damage.
This product should only be used on firm, level ground.
Make sure the legs remain in contact with the ground.
Do’s
We suggest you retain these instructions for future reference.
When you are ready to start, make sure that you have the right
tools and plenty of space.
We suggest you spend a short time reading through this leaflet
before you start.
Produced in China for Next Retail Ltd.
299836/M01028-2020-V1
Unwrap all packaging materials and place the components on
a clean surface to protect it from damage, We recommend that
the packaging is used to protect the surfaces during assembly.
Carefully check that you have all the parts before beginning
assembly.
Please retain the assembly tools. You will need them in the
future to re-tighten the bolts, or if you want to dismantle the
furniture for storage.
Please make sure that the product is clean and dry before
putting it into storage.
We recommended the use of furniture covers to protect your
furniture when not in use.
During severe weather conditions, please move your furniture
inside.
To clean your items, please use mild detergent in warm water.
Rinse with clean water and dry thoroughly.
Do not use abrasive cleaners, strong detergents, bleach, acid
or solvents on the frame parts.
When cleaning glass panels use a damp cloth with washing up
liquid or soft soap if necessary.
Do not use washing powders or any other substances containing
abrasives since these substances scratch glass panel.
The glass used in this product is toughened and complies with
BS EN 12150-1:2009.
Do not sit on the arms of your chair. (Note: arm chair only).
When moving furniture never drag the pieces across the floor,
as this will cause damage to the joints.
Please do not leave your product outside when not in use.
During bad weather and winter months the product should be
dismantled and stored in a cool dry place.
Do not use silicone based furniture polish.
If the glass is chipped or broken, stop using the product and
consult Next.
Do not place very hot or very cold items on the glass surface,
unless adequately thick table mats are used to prevent such
items from coming into contact with the glass.
Do not use glass as a chopping surface.
Do not strike the glass with hard or pointed items.
To View our full furniture range please visit www.next.co.uk

2
299836 / M01028
HELSINKI LIV 5PC
Assembly instructions
GETTING TO KNOW YOUR PRODUCT
Produced in China for Next Retail Ltd.
299836/M01028-2020-V1
.
Components supplied. Please use this guide if you require replacement parts.
Qty
Visual n Ctn t
