Next 780455 User manual

Tools Needed
Helpline
If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: [phone]
held liable for any charges arising from future decorative or re-installation costs should the fire require to be
exchanged at a future date.
• Avoid the use of an extension power cord because this may overheat and become a fire hazard. If an
extension cord must be used it should be a 13A extension cord.
• The appliance must be positioned so that the plug is accessible. If you choose to chase the wire into the wall
for cosmetic reasons and or to install the fire using a fuse spur connection then the manufacturer cannot be
• Do not use the heater in areas where gasoline, paint, or flammable liquids are used or stored.
• Use this heater only as described in this manual. Any other use not recommended by the manufacturer may
cause fire, electric shock, or injury to persons.
• Connect to properly earthed sockets only. The earth should comply with current IEE regulations.
• Do not insert or allow foreign objects to enter the ventilation opening as this may cause an electric shock
or fire, or damage the heater.
• To prevent a possible fire, do not block air intakes or ventilation grid in any manner.
• Do not use this heater in bathrooms.
• Do not run the power cord under carpeting. Do not cover the power cord with throw rugs, runners, or other
like.
• Do not operate a heater with a damaged power cord or plug or after a heater malfunctions, has been
dropped or damaged in any manner. Return heater to authorised service facility for examination, electrical or
mechanical adjustment, or repair.
• Do not use this heater outdoors.
and unattended. The guard is to reduce the risk of fire or injury from burns and no part of it should be
permanently removed. It does not give full protection for children.
• Always unplug the heater when not in use. To disconnect heater, turn controls to off, then remove the plug
from the socket.
• This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. Keep combustible
materials such as furniture, pillows, bedding, papers, clothes, and curtains at least 1 metre from the front of
the heater and keep them away from the sides and rear.
• Extreme caution is necessary when any heater is used near children whenever the heater is left operating
Suites are designed to be freestanding and should not be permanently secured or sealed to the wall.
Read all instructions before using this heater. When using an electrical heating appliance basic precautions
should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the
following:
ASSEMBLY INSTRUCTIONS.
IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is
found to be faulty. Should you need to return the unassembled product, please repack in the original packaging.
Please see instructions guide for reference.
IMPORTANT
7 0455 ASHDOWN STOVE SUITE

M6 x 30mm
• Always use a non-silicone based furniture polish. Silicone in furniture polishes can break down the lacquer
finish.
1-MANTLE 2- HEARTH 3-ENGINE 4-CHIMMEY
FITTINGS
A x 4
PARTS
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if
necessary.
• Wood will mellow and change colour over time; we recommend that ornaments are moved regularly to prevent
uneven mellowing.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent
scratching or damage.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration
or warping.
CARE INSTRUCTIONS
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
only be done by a qualified electrician.
PRODUCT INFORMATION
• Made from soild wood and MDF with black paint finish.
• Made in China
risk exists when the heater is accidentally covered or displaced.
• If the molded plug is removed it should be disposed of with the fuse removed, as there is a risk of electrical
shock if inserted into another socket outlet.
If the power cord needs to be changed, it can be accessed through the mains access cover. This work should
• The appliance MUST be earthed.
• The appliances MUST NOT be situated directly below a fixed socket outlet.
• Check the voltage requirement of the fire accords with the local supply voltage.
• Do not use this heater in series with any device which would switch the heater on automatically, since a fire
Electrical – Before plugging into the mains, ensure the following:
• This heater should not be used in a dusty environment.
• “Warning “in order to avoid over heating do not cover the heater.

NOTE: 1 person is required to hold it in position
1. Place the engine 3 on the hearth 2 as shown.
2. Slot the power cord through the hole
whilst another person actions step three.
STEP FOUR
on back panel.
1. Insert the chimmey 4 into the groove in top panel of
engine as shown in the diagram.
1. Insert the chimmey 4 into the hole located at
underside bottom of mantel as shown.
1. Attach mantel 1 to hearth 2 with 4 x bolts (A) using a
screwdriver to tighten.
STEP TWO
STEP THREE
STEP ONE
1
2

1.The fire is ready for use through controlling the
switches.
NOTE:
The switches will look like the diagram as show. It is
important to be aware that switches must be turned on
in the correct sequenceas below:
‘A’ must be on prior to switching on ‘B’ to get cool
wind.
‘A & B’ must be on prior to switching on ‘C’ to operate
at 1Kw.
‘A & B & C’ must be on prior to switching on ‘D’ to
operate at 2Kw.
Switching off ‘A’ will disable ‘B & C & D’& "Brightness"
• Heating Appliance Settings
NOTE:
CAUTION:
1. Open the door of the engine.
• Before undertaking any maintenance or cleaning, unplug or disconnect fire from the socket outlet.
STEP ONE
ILLUMINATED PEBBLE BED BULB REPLACEMENT
Bulbs have a limited life span and will require replacing as they expire.
• Bulbs can be very hot, handle with care. Allow bulbs to cool before attempting to replace.
Timber Dust with a soft, dry cloth. If necessary, polish with furniture wax. Avoid silicone based spray polishes.
Note: sunlight affects timber, giving a natural deepening colour. This ‘mellowing’ is traditionally
add to the beauty of wooden furniture
MDF Clean with a lightly dampened cloth or a non-abrasive domestic cleanser.
To reduce dust build up, the fan area must be regularly vacuum cleaned through the grill, with a soft brush nozzle,
the fire has been switched off and is cool.
• CARE
Metal The surfaces should be cleaned with a lightly dampened cloth. Abrasive creams should not be used.
FAN UNIT (HEATER)
The fan heater has a thermostatic cut-out to prevent overheating. It should reset automatically after the appliance
switched off and on again at the mains. Allow 15 minutes to cool.
When in use, the fan will emit a faintly audible ‘hum’. This is a normal feature of fan assisted air movement.
STEP FIVE
MAINTENANCE

1. Release the log by unscrewing 1 × screw.
1. Slightly pull the log forward and lift it up, then you
can see the bulb inside.
1. Plug out the bulb and replace with a new one. Re-fit
the log with the screw and close the door.
STEP THREE
STEP FOUR
TROUBLESHOOTING
STEP TWO

ENVIRONMENTAL PROTECTION
European Fires (CE approved)
EARTH: GREEN and YELLOW
NEUTRAL: BLUE
LIVE: BROWN
Next Retail Ltd, Desford Road, Leicester, LE19 4AT
Heating Elements: 2000 W
IMPORTANT
The wiring in this mains lead is colored in accordance with the following code:
Replacement fuse must conform to British Standards and be rated at 13A.
CUSTOMER SERVICES.
RATING INFORMATION
Volts: 220-240V~50Hz
Lamp: G9 25W/240V
Where facilities exist. Check with your Local Authority or retailer for recycling advice.
YOUR APPLIANCE IS GUARANTEED FOR ONE YEAR FROM THE DATE OF PURCHASE AGAINST ANY
MANUFACTURING DEFECT (BULBS HAVE A LIMITED LIFE-SPAN AND WILL REQUIRE REPLACEMENT
EVENTUALLY. THIS IS NOT REGARDED AS A DEFECT). IF YOU ENCOUNTER A PROBLEM, PLEASE CONTACT
Waste electrical products should not be disposed of with household waste. Please recycle
