NF DP240S User manual

PROGRAMMABLE AC POWER SOURCE
DP240S/DP360S
INSTRUCTION MANUAL
NF Corporation

PROGRAMMABLE AC POWER SOURCE
DP240S/DP360S
INSTRUCTION MANUAL
DA00050449-002

DP240S/DP360S i
 Preface 
Thank you for purchasing our Programmable AC Power Source DP240S/DP360S.
For safe and correct use of the electrical product, please first read "Safety Precautions" on the next
page.
Alert symbols in this manual
This manual uses the following alert symbols. The instructions by these alert symbols shall be
carefully obeyed to ensure equipment operator's safety and prevent damage to equipment.
Equipment handling could result in death or serious injury. This symbol contains information
to avoid such risk.
Equipment handling could result in minor or moderate injury, or property damage. This
symbol contains information to avoid such risk.
This manual consists of the following chapters.
If it is the first time for you to use this product, start with "1. Outline."
1. Outline: Explains the overview, configuration, and features of this product.
2. Preparation before Use: Explains the preparations carried out before installation or operation.
3. Basic operation: Explains the component names and basic operations.
4. Advanced Operation: Explains the operations more extensively.
5. Description of Screen and Menu: Explains the screen configuration and menu composition.
6. Remote Control: Explains the remote control via communication interface.
7. Options: Explains the available options.
8. Troubleshooting: Explains the remedies when an error message is displayed, or when a failure
is suspected.
9. Maintenance: Explains the methods of storage, packaging, transportation and maintenance.
10. Specifications: Provides the list of specifications of functions and performance.
Scope of contents
In this manual DP240S and DP360S are covered.
The description of this manual applies to products with firmware version 1.20 and above.
For details on checking the firmware version, see Chapter 9.4.
CAUTION
WARNING

PROGRAMMABLE AC POWER SOURCE
ii
 Safety Precautions 
For safe use, ensure to obey the following warnings and considerations.
We are not responsible for damage resulting from failure to obey these warnings and considerations.
This product is an insulation Class I device (with a protective conductor terminal) complying with
the JIS and IEC standards.
Ensure you obey the instructions in this instruction manual.
This instruction manual contains instructions for safe operation and use of this product.
Before using the product, please read this manual first.
All the warning items contained in this instruction manual are intended for preventing risks that may
lead to serious accidents. Ensure to obey them.
Ensure to ground.
Ensure to connect the protective conductor terminal of the power input terminal of this product to an
earth ground so that ground resistance is 100 or less. If the product is not certainly grounded, an
electric shock might occur.
To prevent electric shock, ensure that the protective grounding conductor is connected before you
connect a cable to the power input terminals L1, L2 and L3.
For grounding, use a power cable of sufficient ampacity for the maximum input current (see Table
2-4).
Check the power supply voltage.
This product operates on the power supply voltage specified in "2.4 Grounding and Power
Connections". Before connecting the product to a power supply, make sure that the voltage of
distribution board conforms to the power supply voltage rating of the product.
If you notice anything strange
If this product produces smoke, unusual odor, or strange sound, immediately cut the power to the
product and stop using it.
Should you encounter any anomaly like above, immediately contact us or our agent. Never use it
until the repair is completed.
Do not use in a gaseous atmosphere.
This may pose a risk of explosion or other.
Do not remove the cover.
This product has high-voltage portions inside. Never remove the cover.
When inspection into the inside of the product is needed, never allow anybody to touch the innards
except our certified service engineers.

DP240S/DP360S iii
Do not modify the product.
Never modify the product. Modification to the product may pose a new risk. We may refuse the
repair of a modified product at fault.
Prevention of electric shock by output voltage
The maximum output of this product is ± 440 V. Be careful to avoid electric shock. Directly
touching the output or changing the cable connection while the output is on may cause electric
shock.
This product weights over 18 kg.
Do not carry it alone, or you may suffer physical injury.
Do not expose this product to water.
When this product is used in wet condition, it may cause an electric shock and a fire. If this product
is exposed to water, cut the power at the distribution board immediately, and contact NF Corporation
or one of our representatives.
If lightning occurs, power off this product and cut the power at the distribution board.
A lightning may cause an electric shock, a fire and a failure.
Safety symbols
The following shows the general definitions of the safety symbols used on the product main unit and
in the instruction manual.
Refer to the instruction manual
This notifies the user of potential hazards and indicates that he/she must refer to the
instruction manual.
Electric shock hazard
This indicates that an electric shock may occur under specific conditions.
Protection conductor terminal
This indicates that the terminal needs to be grounded in order to prevent electric shock
accidents.
Before operating the equipment, ensure to connect this terminal to an earth ground so
that ground resistance is 100 or less.
Warning
Equipment handling could result in death or serious injury. This symbol
contains information to avoid such risk.
Caution
Equipment handling could result in minor or moderate injury, or property
damage. This symbol contains information to avoid such risk.
CAUTION
WARNING

PROGRAMMABLE AC POWER SOURCE
iv
Other symbol
Chassis
This indicates that the terminal (or external conductor for a connector) is connected to
the chassis.
Request about disposal
For environmental preservation, this product shall be disposed of through an appropriate industrial
waste disposer.
This product does not include a battery.

DP240S/DP360S v
