Nibe AG-AA10 Series User guide

Installer manual
AG-AA10-30
AG-AA10-40/50
AG-AA10
Air/air heat pump
IHB GB 1516-1
331554

Table of Contents
21 Important information
2Safety information
3Read before starting the installation
3Electrical requirements
42 Delivery and handling
4Transport
4Assembly
4Supplied components
53 Pipe connections
5General
5Connecting the cooling circuit
64 Electrical connections
6General
6Connecting indoor and outdoor unit
6Connecting accessories
75 Installation
7Model combinations
7Installation instructions
11Pump down
126 The main functions of the valves
137 Disturbances in comfort
13Troubleshooting
148 Accessories
159 Technical data
15Dimensions
16Technical specifications
18Index
1Table of Contents |AG-AA10

Safety information
This manual describes installation and service proced-
ures for implementation by specialists.
This appliance can be used by children
aged from 8 years and above and per-
sons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved. Chil-
dren shall not play with the appliance.
Cleaning and user maintenance shall
not be made by children without super-
vision.
Rights to make any design or technical
modifications are reserved.
©NIBE 2015.
Symbols
NOTE
This symbol indicates danger to machine or
person.
Caution
This symbol indicates important information
about what you should observe when main-
taining your installation.
TIP
This symbol indicates tips on how to facilitate
using the product.
Marking
AG-AA10 is CE marked and fulfills IPX4.
The CE marking means that NIBE ensures that the
product meets all regulations that are placed on it
based on relevant EU directives. The CE mark is obligat-
ory for most products sold in the EU, regardless where
they are made.
IPX4 means that the product is protected against drops
of water from all angles.
Environmental information
This unit contains a fluorinated greenhouse gas that is
covered by the Kyoto agreement.
F-Gas Regulation (EU) No. 517/2014
The equipment contains R410A, a fluorinated green-
house gas with a GWP value (Global Warming Poten-
tial) of 2087.50. DO not release R410A into the atmo-
sphere.
Safety precautions
NOTE
■Avoid the use and storage of flammable li-
quids near the climate unit.
■Never install electric equipment that does
not have IPX1 protection (protection against
vertical water drops), under the unit.
The manufacturer assumes no liability, if safety the
standards or protection preventive measures are not
complied with.
Special safety measures
During installation the cooling circuit must be connec-
ted first and then the electrical circuit. Perform in re-
verse order when removing the unit.
During repair
■Disconnect the voltage (via the main switch) before
opening the unit to check or repair the electrical
parts.
■Keep hands and clothing away from moving parts.
■Clean after completing the work, and check that no
metal residue or cable parts have been left inside the
unit.
■Vent the premises during the installation and the
cooling circuit test. Ensure that no refrigerant gas
has leaked out during the installation, as contact with
naked flames or heat sources can be toxic or danger-
ous.
AG-AA10Chapter 1 | Important information2
1 Important information

Read before starting the install-
ation
This heat pump complies with strict safety and function
standards.
It is very important that the installer or the service
technicians install or repair the system so that it works
safely and efficiently.
For a safe installation and good function the
following is required:
■Read this instruction manual carefully before starting
installation.
■Follow the installation and safety instructions exactly
as described and shown.
■Comply with local and national electrical regulations.
■Note all the warning and safety messages indicated
in this manual.
■The unit must be connected to a separate supply.
These instructions are sufficient for installation and
maintenance. If assistance is required for a particular
problem, contact our dealer for further information.
NIBE does not accept any responsibility for damage
that occurs in the event of incorrect installation or im-
proper maintenance.
Electrical requirements
NOTE
The electrical discharge can cause serious
personal injury or death. Only qualified electri-
cians may handle the electrical system.
■Before installation ensure that the mains supply for
the power supply is the same as that indicated on
the climate unit's rating plate.
■Each unit must be connected with approved groun-
ded cable.
■The electrical connections must be performed by a
specially trained and qualified electrician.
■Ensure a ground connection before the unit is
powered.
■Hazardous electrical voltage is used in this electrical
circuit. See electrical wiring diagram and its instruc-
tions below the connection. Incorrect connections
or unsuitable ground connection can cause accidents
or death.
■The yellow/green cable must not be used for connec-
tions other than ground.
■Tighten the cables securely. Incorrect connections
can cause overheating and fire.
■Electrical cables must not come into contact with the
cooling pipes, the compressor or fan's moving parts.
■Use separate cables for each type of cable.
3Chapter 1 | Important informationAG-AA10

Transport
Take care when lifting and moving the indoor and
outdoor unit. We recommend that you ask for assist-
ance and bend your knees when you lift to avoid injur-
ing your back. There is a risk of cutting yourself on the
sharp edges of the climate unit.
Assembly
We recommend that this climate unit be installed by
an authorised technician in accordance with the sup-
plied installation instructions.
NOTE
■Do not install this climate unit where there
are flue gases, flammable gases or a lot of
moisture, e.g. in a greenhouse.
■Do not install this climate unit where there
is equipment that generates too much heat.
■Do not install the unit in premises where it
may be subjected to water splashes (e.g.
laundry rooms).
■To protect the climate unit from corrosion,
the unit must not be installed where it can
be directly exposed to seawater splashes or
sulphur fumes.
Selection of installation location for outdoor
unit
During installation...
■...in damp or uneven locations:
Use a base that is stable and raised above the ground
to prevent damage and abnormal vibrations.
■...in locations exposed to strong winds:
Secure the unit with bolts and metal frame. Ensure
that there is suitable wind protection.
■...in locations susceptible to snowfall (for climate units
with heat pump):
The concrete foundation or slabs must be positioned
so that the lower edge of the evaporator is at the
level of the average local snow depth, however a
minimum of 300 mm.
Prevent the following:
■proximity to heat sources or to areas where hot air
is blown out.
■Installation on wooden wall, because there is a risk
of resonance.
■damp areas or easily flooded areas and uneven sur-
faces.
■to drill holes in the areas where there are electrical
parts or units.
The following is recommended:
■If possible, select well-ventilated, shaded areas.
■Secure the unit securely at the base to prevent vibra-
tions.
Installation area
Minimum working and maintenance range (measured
in mm):
2000
100 500
2000
400
100
100
400
100
300
100 500
2000 2000
Supplied components
AG-AA10-30/40/50:
1 x Communication cable (8.5 m)
AG-AA10Chapter 2 | Delivery and handling4
2 Delivery and handling

General
Pipe installation must be carried out in accordance with
current norms and directives.
Only use refrigerant pipes that are seamless, degreased,
deoxidized and suitable for a pressure of at least 42
bar. The pipes must be supplied with at least 8 mm
vapour-proof insulation.
Max 10 m
Max 10 m
Max 10 m
Max 10 m
Pipe length
1.5 mThe refrigerant pipes' minimum length
7.5 mThe refrigerant pipes' total length with
standard filling
15 mThe refrigerant pipes' total length with
additional filling1
11. Additional filling of refrigerant can be done when the unit runs in cooling
operation:
For refrigerant pipe 1/4" - 3/8" = 15 g/m
For refrigerant pipe 1/4" - 1/2" = 20 g/m
For information about pipe dimensions, see section
"Technical Specifications" on page 16.
Condensation drain
For condensation removal, the AG-CH10 accessory of
suffient length is required to transport the condensa-
tion to an external drain. See section "Accessories" on
page 14 for further information about AG-CH10.
Connecting the cooling circuit
■Use the flare method to connect the pipes.
■Lubricate the contact surfaces and hand tighten, then
tighten the connections using a torque wrench to
obtain a good and secure connection, see installation
instructions on page 8.
■Check carefully that there is no risk of any leakage
prior to the function test.
5Chapter 3 | Pipe connectionsAG-AA10
3 Pipe connections

General
■A heat pump must not be connected without the
permission of the electricity supplier and must be
connected under the supervision of a qualified elec-
trician.
■Electrical installation and wiring must be carried out
in accordance with the stipulations in force.
■If a miniature circuit-breaker is used this should have
motor characteristic “C” (compressor operation). For
other fuse sizes, see section "Technical Specifications"
on page 16.
■AG-AA10 does not include an omnipolar circuit
breaker on the incoming power supply. The heat
pump’s supply cable must be connected to a circuit
breaker with a breaking gap of at least 3 mm. When
the building is equipped with an earth-fault breaker
the heat pump should be equipped with a separate
one. Incoming supply must be 230 V ~ 50 Hz via
electrical distribution units with fuses.
■If an insulation test is to be carried out in the building,
disconnect the heat pump.
Connecting indoor and out-
door unit
L
N
C2
C1
L
N
C2
C1
L
N
Indoor unit Outdoor unit
Rated voltage
230V ~ 50Hz
A
B
C
Explanation
Power supply cableA
Communication cable1 B
Connection cableC
1The communication cable must always be screened. 8.5 m
screened cable supplied.
Connecting accessories
The outdoor unit is equipped for connection of a con-
densation water pipe (AG-CH10).. Connect the power
supply to AG-CH10 as illustrated:
GREY
WHITE
GREEN/YELLOW
AG-CH10
Caution
Also see the Installer manual for AG-CH10.
AG-AA10Chapter 4 | Electrical connections6
4 Electrical connections

Model combinations
See product catalogue for further information about
model combinations.
Indoor unitOutdoor unit
AG-WT10-4AG-AA10-30
AG-WT10-4AG-AA10-40
AG-WT10-7AG-AA10-50
Installation instructions
1. Place the outdoor unit on a stable base raised
above the ground and secure it.
TIP
When installing stand, install screws
downward to facilitate removal of the
front panel.
400 mm
300 mm
100 mm
2. Hole for connecting the accessory AG-CH10.
7Chapter 5 | InstallationAG-AA10
5 Installation

3. Remove the side panel, then connect the supply
and communication cables to the outdoor unit and
secure them with load relief.
N.O
4. Use insulated copper cooling pipes. Cut a length
of 30 – 50 cm in addition to the distance between
the units.
min. 8 mmmin. 8 mm
Insulation
5. Remove burrs from the pipe ends. Turn the pipe
ends downwards to prevent residue entering the
pipe.
6. Thread the flange nuts (which are removed from
the outdoor unit) on the pipes and bend up the
ends of the pipes.
NOTE
Only use tools intended for R410A
AG-AA10Chapter 5 | Installation8

7. A good upward bend must have the following
properties:
■a smooth and even inner surface
■a uniform and even outer edge
■a conical upward bend of uniform length.
Lubricate the contact surfaces with compressor oil
before connecting the pipes.
3 mm 45 °
Lubricate!
8. Tighten the connections using a wrench and torque
wrench according to the tightening torque values
in the table.
Tightening torquePipe diameter
Approx. 15 – 20 Nm6.35 mm (1/4")
Approx. 30 – 40 Nm9.52 mm (3/8")
Approx. 50 – 55 Nm12.7 mm (1/2")
Approx. 60 – 65 Nm15.88 mm (5/8")
9. Insulate the pipes thoroughly and keep the pipe
connections free for leak testing.
Before vacuuming, leak trace the system. Fill with
nitrogen to approx. 3 bar. Leak trace all connec-
tions using leak spray (soapy water) to ensure that
the system is sealed.
10. For vacuuming of the indoor unit and refrigerant
pipe, connect the vacuum pump to the outdoor
unit as illustrated.
NOTE
Remaining air or damp affects the heat
pump's function negatively and can dam-
age the product.
9Chapter 5 | InstallationAG-AA10

11. Remove the valve caps from both valves. Now start
the vacuum pump. If damp air has entered the
cooling pipes, flush through with dry nitrogen.
Low pressure
High pressure
12. With the vacuum pump in operation, close the tap
on the manometer unit when you have reached a
vacuum less than 2 mbar (absolute pressure,
standing vacuum min. 30 minutes). Stop the vacu-
um pump.
13. Open the service valves fully (anti-clockwise direc-
tion). Disconnect the vacuum pump. Reinstall the
caps on the valves, tighten to a torque of 20 Nm.
Leak trace caps and connections using a sniffer or
leak spray. See page 12 for the valves' main func-
tions.
14. Complete insulation, protect against mechanical
impacts, secure and hang up. If necessary, seal the
valve opening in the wall.
AG-AA10Chapter 5 | Installation10

Pump down
Pump down means retrieving all refrigerant in the
outdoor unit without losing the system's filling. This is
done when the climate unit is to be moved or during
repair of the cooling circuit.
Procedure for "Pump down":
1. Connect a manometer assembly to the low pres-
sure valve, open partially (1/4 turns). Extract air
from the manometer. Then close the high pressure
valve fully.
2. Start the climate unit in cooling mode. When the
pressure that is read out from the manometer has
dropped to a value less than 0.6 bar (absolute
pressure), the low pressure valve must be closed
fully and the climate unit switched off.
1
0,5
0
3. Remove the manometer assembly. The action
"Pump down" is now complete and all refrigerant
has been collected in the outdoor unit.
11Chapter 5 | InstallationAG-AA10

3-way valve (service valve)2-way valve (service valve)Action
Valve cap
Cone
O-ring
CLOSED
Delivery
OPEN
Function and test of the climate unit
*
OPEN
Pressure measurement and gas filling
*
CLOSED
Vacuuming with vacuum pump
*
The service valve on the outdoor unit that gives access
to the refrigerant system is of the "Schrader" type. Use
hoses that have a Schrader opener in the connection.
AG-AA10Chapter 6 | The main functions of the valves12
6 The main functions of the valves

Troubleshooting
NOTE
Work behind covers secured by screws may
only be carried out by, or under the supervision
of, a qualified installation engineer.
NOTE
As AG-AA10 can be connected to several dif-
ferent indoor units, these should also be
checked.
NOTE
In the event of action to rectify malfunctions
that require work within screwed hatches the
incoming electricity must isolated at the safety
switch.
Basic actions
Start by checking the following possible fault sources:
■That the climate unit is running or that the supply
cable to AG-AA10 is connected.
■Group and main fuses of the accommodation.
■The property's earth circuit breaker.
Fault codes
Caution
Remove the side panel that protects the ter-
minal blocks to read off the LEDs. See page
8.
Key to symbols
The LED is off.
The LED flashes.
CauseDL7DL6DL5DL4DL3
Compressor sensor defective or not connected.
Outdoor temperature sensor defective or not connected.
Evaporator sensor defective or not connected.
Overcurrent on compressor.
The compressor's control electronics have overheated.
Overcurrent on fan.
The fan's control electronics have overheated.
Fault in indoor unit.
Communication error.
Phase monitor tripped.
When the unit functions correctly DL3 lights with a
steady light. DL4 lights with a steady light if the indoor
unit is running, otherwise the lamp is out.
13Chapter 7 | Disturbances in comfortAG-AA10
7 Disturbances in comfort

Condensation water pipe
Condensation water pipe for leading condensation to
external drain.
AG-CH10-10
Length: 1000 mm
Part no. 067 466
AG-CH10-30
Length: 3000 mm
Part no. 067 467
AG-CH10-60
Length: 6000 mm
Part no. 067 468
Ground stand
Ground stand AG-GS10-1
Part no. 067 460
Wall mounting
Wall mounting AG-WS10-1
Part no. 067 462
AG-AA10Chapter 8 | Accessories14
8 Accessories

Dimensions
AG-AA10-30
1/4"
3/8"
AG-AA10-40/50
1/4"
3/8" (AA10-40)
1/2" (AA10-50)
15Chapter 9 | Technical dataAG-AA10
9 Technical data

Technical specifications
AG-AA10-50AG-AA10-40AG-AA10-30
Output data
900/5650 W1010/4060 W1370/3650 WCooling capacity +35°C1) / 27°C2), min/max
1030/5290 W910/4870 W930/3880 WHeat capacity +7 °C1) / +20 °C2), min/max
3900 W3510 W2650 WHeat capacity -7 °C1) / +20 °C2), max
3040 W2980 W2150 WHeat capacity -20 °C1) / +20 °C2), max
5215 W/6.7/A++3670 W/6.0/A++2680 W/6.1/A++Pdesignc/SEER/Energy class (cooling +35 °C)3)
4470 W/4.16/A+4020 W/4.01/A+3030 W/3.82/APdesignh/SCOP/Energy class (heat -10 °C)3)
Electrical data
230 V ~ 50 HzRated voltage
1790 W/7.80 A1550 W/6.90 A1550 W/6.90 AMax. specified power/operating current
10 AFuse
Refrigerant circuit
R410AType of refrigerant
Twin rotarySingle rotarySingle rotaryType of compressor
1.3 kg1.1 kg0.81 kgVolume
Pipe connections
6.35 mm (1/4")6.35 mm (1/4")6.35 mm (1/4")Pipe connection (liquid)
12.77 mm (1/2")9.52 mm (3/8")9.52 mm (3/8")Pipe connection (gas)
0.8 mm0.8 mm0.8 mmMin. thickness refrigerant pipe
Dimensions and weight
57 kg57 kg35 kgWeight
895 mm895 mm765 mmWidth
345 mm345 mm315 mmDepth
630 mm630 mm544 mmHeight
AG-AA10Chapter 9 | Technical data16

AG-AA10-50AG-AA10-40AG-AA10-30
Recommended working range 4)
-20/50 °CMin/max outdoor temp. during cooling
10/32 °CMin/max indoor temp. during cooling
-20/24 °CMin/max outdoor temp. during heating
0/27 °CMin/max indoor temp. during heating
Miscellaneous
41 dB(A)44 dB(A)40 dB(A)Max. sound pressure level at 2 m, according to ISO
9614
IPX4Enclosure class
064 163064 162064 061Part No.
1) Refers to the outdoor temperature.
2) Refers to the indoor temperature.
3) According to EN 14825
4) Access to full capacity is guaranteed within the heat
pumps' recommended working range. Operation out-
side the recommended working range is possible as
the internal protective functions ensure that the heat
pump will not be damaged.
17Chapter 9 | Technical dataAG-AA10

Item register
A
Accessories, 14
D
Delivery and handling, 4
Assembly, 4
Transport, 4
E
Electrical connection, 6
I
Important information, 2
Electrical requirements, 3
Safety information, 2
Installation, 7
Installation instructions, 7
Model combinations, 7
Pump down, 11
M
Marking, 2
P
Pipe connections, 5
Condensation removal, 5
Connecting the cooling circuit, 5
S
Safety information
Marking, 2
Symbols, 2
Safety precautions, 2
Supplied components, 4
Symbols, 2
T
Technical data, 15
Dimensions, 15
Technical specifications, 16
The main function of the valves, 12
AG-AA10Chapter 10 | Item register18
10 Item register
