Nidek Medical NT-510 User manual

NON CONTACT TONOMETER
Model
OPERATOR’S MANUAL

NIDEK CO., LTD. : 34-14, Maehama, Hiroishi-cho, Gamagori, Aichi 443-0038, Japan
(Manufacturer) Telephone: [phone]
Facsimile: 81-533-67-6610
NIDEK CO., LTD : 3F Sumitomo Fudosan Hongo Bldg., 3-22-5, Hongo,
(Tokyo Office) Bunkyo-Ku, Tokyo 113-0033, Japan
Telephone: [phone]
Facsimile: 81-3-5844-2642
NIDEK INCORPORATED : 47651 Westinghouse Drive, Fremont, California 94539, U. S. A.
(United States Agent) Telephone: [phone]
Facsimile: 1-510-226-5750
NIDEK SOCIETE ANONYME : Europarc 13, rue Auguste Perret, 94042 CRETEIL, France
(EU Authorized Representative) Telephone: [phone]
Facsimile: 33-1-49 80 32 08
August 2008
18536-P902A
Printed in JAPAN

I

Use this device properly and safely.
"CAUTION! Federal Law (US) restricts this device to sale by or on the order of a properly
licensed practitioner."
Safety precautions
BEFORE USE, READ THIS MANUAL.
This operator’s manual contains information necessary for the operation of the NIDEK
NON CONTACT TONOMETER Model NT-510. This manual includes the operating
procedures, safety precautions, and specifications.
This manual is necessary for proper use. Especially, the safety precautions and
operating procedures must be thoroughly understood prior to operation of the device.
Keep this manual handy to verify use whenever necessary.
The device complies with ISO 8612:2001 (Ophthalmic instruments-Tonometers).
There are no user-serviceable parts inside the device except printer paper.
If you encounter any problems or have questions about the device, please contact NIDEK
or your authorized distributor.
In this manual, signal words are used to designate the degree or level of safety alerting. The defini-
tions are as follows.
WARNING
• Indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION
• Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury or property damage accident.
Even situations indicated by “ CAUTION” may result in serious injury under certain conditions.
Safety precautions must be strictly followed at all times.

II

Use precautions
Before Use
CAUTION
• Do not use the device for other than the intended purpose.
NIDEK is not responsible for accidents or malfunctions caused by misuse.
• Be sure to read the manual prior to operation of the device to understand the safety
precautions and operating procedures thoroughly.
Using the device for purposes other than specified in this manual may cause unex-
pected malfunctions and/or adverse events.
• Never modify nor touch the internal structure of the device.
Electric shock or malfunction may result.
• Install the device in an environment that meets the following conditions. The
following conditions must be maintained during use.
Use conditions
Temperature: 10 to 35qC (50 to 95qF)
Humidity: 30 to 90% (Non-condensing)
Pressure: 800 to 1060 hPa
A place not exposed to the water
A dust-free location
A place with little external light
A level and stable surface free from vibration and shock
If the device is not installed and used under the above conditions, the reliability of
measured results is impaired, and malfunction may result. In addition, there is a possi-
bility of injury if the device receives shock and falls down.
• Install the device in an environment where no contaminants such as corrosive gas,
acid, and salt are contained in the air.
Corrosion or malfunction of the device may result.
• Avoid installing the device where it is exposed to direct air-conditioning flow.
Changes in temperature may result in condensation inside the device or adversely
affect measurements.
• Be sure to use a wall outlet which meets the power specification requirements.
If the line voltage is too high or too low, the device may not perform properly. Malfunc-
tion or fire may occur.
• Connect the power plug to a ground outlet. Or connect a grounding wire to a ground
terminal.
Electric shock or fire may occur in the event of device malfunction or power leakage.
• Completely insert the power plug into the outlet as far as the prongs will go.
Fire may occur if the device is used with a loose connection.
• Never use a table tap or extension cable to supply the device with power.
The electrical safety may be lowered.

III

CAUTION
• Do not use a power cord other than the one supplied. Also do not connect the
supplied power cord to any other device.
Failure or fire may result.
• Do not place heavy objects on the power cord.
The damaged power cord may cause fire or electric shock.
• Before connecting cables to the device, turn the device off and disconnect the
power cord from an outlet.
Malfunction may result.
• Before carrying the device, put the device into the packing mode and lock the main
body to the base with the locking lever.
An accidental movement of the measuring unit during transportation may result in mal-
function.
• When the device is carried, avoid holding
the forehead rest and the main body; hold
the bottom of the base.
If areas other than the base are held and
the device falls, there is a fear of injury
or malfunction.
• Install the device in a place that is not
exposed to high electromagnetic wave
when in use.
• In installation and operation of the device, observe the following instructions about
EMC (electromagnetic compatibility):
- Do not use the device simultaneously with other electronic equipment to avoid elec-
tromagnetic interference with the operation of the device.
- Do not use the device near, on, or under other electronic equipment to avoid electro-
magnetic interference with the operation of the device.
- Do not use the device in the same room with other equipment such as life-support
equipment, other equipment that has major affects on the life of the patient and
results of treatment, or other measurement or treatment equipment that involves
small electric current.
- Do not use the device simultaneously with portable and mobile radio frequency com-
munication systems because it may have an adverse effect on operation of the
device.
- Do not use cables and accessories that are not specified for the device because that
may increase the emission of electromagnetic waves from the device or the system
and decrease the immunity of the device to electromagnetic disturbance.
• The Electromagnetic Compatibility Directive sets the essential requirements for
electrical and electronic equipment that may disturb, or be disturbed by, other
equipment. The NT-510 complies with these requirements as tabled on pages 79 to
82. Follow the guidance in the tables for use of the device in an electromagnetic
environment.
