Nietzsche BT-868 User manual

BT-868
User’s Manual
NIETZSCHE

1
General Information BT –868
The Bluetooth headset BT-
868 is a most desirable cordless mobile solution that
complies with the Bluetooth™ profiles specification v1.1, a ne
w standard for
wireless short distance radio communications. The one touch button and the
voice activation on your Bluetooth enabled mobile phone, makes it facile for
making or receiving a call without holding or finding your phone when it is not
within y
our reach. Unlike current Bluetooth Headset available in the market place,
BT-
868 Bluetooth Headset adopts the unique design of changeable
Lithium-
Polymer Battery, which provides a longer talking time and a great
convenience when your Headset is running out of power. The BT-
868 can be used
with most of the mobile phone which supports the Bluetooth Headset profile.
BT-868 is compatible with the following phones:
Sony Ericsson
Sony Ericsson t39
Sony Ericsson t39mc
Sony Ericsson r520m
Sony Ericsson r520mc
Sony Ericsson t68
Sony Ericsson t68m
Sony Ericsson t68mc
Sony Ericsson t68i
Nokia
Nokia 6310 (*)
Nokia 6310i (*)
Nokia 8910 (*)
(*) For Nokia mobile phones, it won't be reconnected automatically if the
connection with Bluetooth is lost. You will have to m
anually approve the
re-
connection on the handset. The situation is the same with other Bluetooth
headsets

2
Operating Instruction
BT-868 Overview
Front View
Back View
EAR HOOK
MICROPHONE
SPEAKER
VOLUME CONTROL
SWITCH
• S1 : Power ON/OFF
• S2 : Increase Volume
• S3 : Decrease Volume
INDICATOR LIGHT
Blue LED
Flashing once every 3 sec
• Stand-by-mode
Flashing once every 5sec
•
Initiate a connection with
the phone
Flashing once every 10sec
• Mobile and BT-
868
Connected
Red LED
Flashing once every 3sec
• Hard-Reset-mode
• Ready for pairing
TALK/OFF BUTTON
• Making a call (by using voice
control)
• Answering a call
• Terminating a call
• Transferring sound from the
phone to the Headset
BATTERY
• Lithium-Polymer
Battery 220mAh
• Re-moveable
•Re-chargeable

3
Charging
The battery is not ful
ly charged when it is new. You must recharge it for
approximately 2 hours for the first time use.
When you hear a beep in your Headset at regular intervals, it indicates the low
power and you need to charge it. The charger LED turns RED when charging
the
battery and LED turns OFF when the battery is fully
charged. With a fully charged
battery, it has 200 hours of stand-by-
time and can support up to 6 hours talking
time.
NOTE:
Please use the charger provided with your product. The use of any other
charger will automatically suspend the warranty.
To remove the battery
Step 1. Push the battery backward away from
the “TALK” button until it is off the
hook.
Step 2. Lift it up from the
back of the battery as
shown in the picture.

4
To charge the battery
1.
Connect the adaptor into the desktop battery
charger as shown in the picture. Gently press
the connector until it clicks into place.
NOTE: The LED is off.
2.
Insert the battery by aligning the lock to the
hook on the battery charger, a
nd pushed it
towards the “TALK” button.
3.
When the battery is now in charging, the LED
turns Red.
4. When the battery is fully charged, the LED will
turn off.
How to put on battery
Step 1. Insert the battery by aligning the lock to
the hook on the battery charger
Step 2. Pushed the battery towards the “TALK”
button and lock it in position

5
Turning the Headset On or Off
Turning the Headset ON
If your Headset is switched off, press and hold S1 for 2 seconds.
The Headset
indicator light begin to flash blue once
in every 3 seconds. This indicates the
Headset is powered up, and it is at stand-by-mode.
NOTE:
The Headset will be turned ON automatically when a charged battery is
inserted onto the headset.
Turning the Headset OFF
Once you have finishe
d using the Headset, press and hold S1 for 2 seconds and the
headset will be powered down. The Headset indicator light will be switched
off
when the Headset is powered down.
NOTE: For Nokia mobile phones, you have to disconnect the connection between
BT-868 and your mobile phone first before you can turn the BT-868 off.
Pairing the Headset
Pairing
Before using the Headset with a Bluetooth-
enabled device for the first time, you
must pair the Headset with that device, for example, a mobile phone.
Pairing is the process of linking and creating a trusted relationship between
two
Bluetooth devices, so that they can communicate. To validate these two
Bluetooth devices to each other and create a trusted relationship between them, a
Bluetooth passkey (or PIN) is required. The default passkey stored in the BT-
868
internal memory is [1234].
You are usually required to enter the passkey on
that device during pairing.
The pairing only needs to be done once.
You do not need to pair it again until you
want to use it with another device.
Afterwards, every time you switch on your
Headset, it will automatically connect to your mobile phone. Please note,
however, Nokia Bluetooth mobile phones required you to reconnect to it manually.

6
To initial a pairing, i
t is recommended to put both the Headset and the mobile
phone within 1 meter to each other.
1. Turn the Headset on.
2.
Put the Headset into pairing mode by performing a
“Hard Reset”. Press and hold at the same time on the
button S2 and “TALK” button on
the Headset until the
indicator light on the Headset flashes Red. The
Headset is now in the pairing mode and is
ready for
pairing. (Note: Headset
will remain in pairing mode until
pairing is successfully)
3. Switch on your mobile phone and activate Blue
tooth
pairing in the device by following the instruction on your
mobile phone’s user guide. Select discovery or pairing
or sniff mode from the Bluetooth options of your mobile
phone.
4.
Once the mobile phone detects the Headset, a message
will be display
ed with the following information:
“BT-868”.
5. Follow the phone instructions to accept the Pairing;
Enter the Headset passkey [1234] and press “Yes”
key
to confirm.
6.
When the pairing is completed, the Headset indicator
light flashes blue and it is now
ready to use. However,
if there is failure in pairing, you may need to repeat
steps 3 to 5 until pairing succeeded.
Please Note:
1.
You can abort pairing any time by pressing and holding the S1 button for
about one second until the red light goes off an
d the Headset is now turned
off. Previous pairing (if any) is now revoked.

7
2.
Different device may require different pairing procedure. Please refer to
the manual of the other device(s) for specific pairing method.
Example 1: How to pair BT-868 with the Sony Ericsson T68i.
1. Turn the BT-868 on.
2. Put the BT-
868 into pairing mode by performing a “Hard Reset”. Press and
hold at the same time on the button S1 and the “TALK” button on the BT-
868
until the indicator light on the BT-868 flashes Red. The BT-868 is
now in
pairing mode and ready for pairing.
3.
Take your Sony Ericsson T68i and go to the main menu. From there select the
"CONNECT" option
4. Select option 4, "Bluetooth"
5.
Select option 2, "Paired devices" and if you had previously paired your phone
with anot
her headset, you will see it in the list. To cancel a pairing, highlight
the device and press on "C" to delete it.
6. Select "Add device" option.
7. Select option 1, “Phone initiates”.
8. Select option 2, “Hands free”. The T68i is now searching for the BT-868.
9. Once it has found it, press the "Yes" key to confirm it.
10. Press again the "Yes" key to confirm the option 1: "Add to paired".
11. Type your passkey: 1234 and then press "Yes" key to confirm.
12. The pairing is then in process and you should read under the title Nam
e tag:
BT-868.
13. Press "Yes" to confirm again.
14. Your mobile phone is now paired and ready to use
Example 2: How to pair BT-868 with the Nokia 8910i.
1. Turn the BT-868 on.
2. Put the BT-
868 into pairing mode by performing a “Hard Reset”. Press and
hold at the same time on the button S1 and the “TALK” button on the BT-
868
until the indicator light on the BT-868 flashes Red. The BT-
868 is now in
pairing mode and ready for pairing.
3.
Take your Nokia 8910i and go to the MENU. From there select option 10,
"Bluetooth".
4.
Select option 2, " Search for audio accessories ". The Nokia 8910i is now
searching for the BT-868 Headset. To end the inquiry, press “Stop”
5. Once it has found it, press the "Select" key to confirm it.
6. Type your passkey: 1234 and then press "Yes" key to confirm.
7.
The pairing is then in process and you should read under the title Name tag:
BT-868.
8. Press "Yes" to confirm again.
9. Your mobile phone is now paired and ready to use

8
Wearing your Headset
Step 1 Step 2 Step 3
Step 1. Press down the lever and adjust the ear hook.
Step 2. Put on the Headset with the ear hook behind your ear and turn.
Step 3. Ensure the microphone is pointing toward your mouth.
Right/Left Ear Usage
1.
Simply remove the ear hook from the Headset
by flipping towards the microphone.
2.
Flip the ear hook over and reinsert it to the
Headset.
3.
Attach the ear hook by aligning one side of the
lock into the hole on the Headset and gently
pressing it into position.

9
Making and answering calls
Once the Headset is succe
ssfully paired with your phone, you can make and
receive calls from your BT-868 Headset, or using the ke
ys on the mobile phone as
usual. When using the Headset, make sure it is ON
and within range of the
phone –up to 10m with no solid objects in between.
For best performance, use
the Headset and phone in the same room and
wear the Headset on the same side
to the phone to avoid directional interference occurred between wireless devices.
Making a Call
Using voice dialing to make a call
1. Make sure the ph
one and the Headset are on and voice dialing is activated on
your mobile phone.
2.
Press the “TALK” button on your mobile phone for one second until you hear
a beep.
3. Once a beep is heard,
speak out any of the names recorded in your voice
tags.
4. To end a call, press the “TALK” button or press the “NO” key on the phone.
NOTE:
As far as the voice recognition accuracy is concern, it is strongly
recommended that you save your names with the voice recognition function using
directly the headset.
Using mobile phone’s keypad to make a call (without voice dialing)
1. Make sure both the mobile phone and the Headset are on and
connected to
Bluetooth system.
2. Dial the phone number you wished to call.
3. Approximately 2 seconds after the call has been set up, the call should b
e
transferred to the Headset automatically, and you can hear short tones when
dialing.
4. To end a call, press the “TALK” button or press the “NO” key on the phone.
Answering a Call
To receive a call, press the “TALK” button on the Headset and you will the
n be
connected to the caller.
However, if a call is answered by your mobile phone, such as pressing “YES”
button, you will have to use your mobile for talking and listening.
