DIGITAL CAMERA
Quick Start Guide
Quick Start Guide
pg. 3
pg. 13
pg. 2
Bundled software
Taking Pictures
Package Contents
PictureProject

Check that you have all the items listed below.
Check that you have all the items listed below.
NOTE: A memory card is not included with the camera.
Package Contents
2
COOLPIX S3
digital camera
En
The Nikon Guide to Digital Photography
with the
DIGITAL CAMERA
Guide to Digital
Photography with
the COOLPIX S3
PictureProject
installer CD
(yellow)
PictureProject
reference manual
CD (silver)
Warranty
Warranty
EN-EL8 rechargeable battery
(with terminal cover)
MV-11 / MV-11B
COOL-STATION*
EG-E5000
audio/video cable
UC-E10 USB
interface cable
Camera strap
EH-63 AC adapter†
(with power cable)
Quick Start Guide
(this guide)
En
DIGITAL CAMERA
Quick Start Guide
Quick Start Guide
* An MV-11 or MV-11B is provided, depending on the color of the camera body.
† Shape of cord depends on country of use.
Use Only Nikon Brand Electronic Accessories
Use Only Nikon Brand Electronic Accessories
Nikon COOLPIX cameras are designed to the highest standards and include complex
electronic circuitry. Only Nikon brand electronic accessories (including battery char-
gers, batteries, and AC adapters) certified by Nikon specifically for use with this Nikon
digital camera are engineered and proven to operate within the operational and safety
requirements of this electronic circuitry.
THE USE OF NON-NIKON ELECTRONIC ACCESSORIES COULD DAMAGE THE CAMERA AND MAY VOID YOUR NIKON
WARRANTY. The use of third-party rechargeable Li-ion batteries not bearing the Nikon
holographic seal*could interfere with normal operation of the camera or result in the
batteries overheating, igniting, rupturing, or leaking.
For more information about Nikon brand accessories, contact a local authorized Nikon
dealer.
* Holographic seal: Identifies this device as an authentic Nikon product.

Taking Pictures
3
Attach the camera strap
Attach the camera strap
Attach the strap as shown.
Charge the battery
Charge the battery
Afterinsertingthebattery, place the camera in the supplied MV-11 / MV-11B
COOL-STATION for charging.
Connect the EH-63 AC adapter to the COOL-STATION
Connect the AC power cord to the AC adapter.
Plug the DC cord into the COOL-STATION’s DC-IN connector.
Plug the AC power cord into a wall outlet. The power lamp on
the AC adapter will light ().
DC-IN
connector
MV-11 / MV-11B
COOL-STATION
Power cord
3
4
Power lamp
1
AC adapter
Attach the camera strap/Charge the battery
1
2

Taking Pictures
4
Close the battery-chamber cover
Close the cover () and slide it in
until it latches ().
Open the battery-chamber cover
Slide the battery-chamber cover in
the direction shown (), stopping
when the cover opens ().
21
2
Insert the battery
Insert the battery as shown in the
label at the entrance to the battery
chamber, making sure that the posi-
tive (“+”) and negative (“–”) termi-
nals are in the correct orientation.
Inserting the battery upside down
or backwards could damage the
camera. Be sure that the battery
is in the correct orientation.
When the battery is fully inserted,
the orange battery latch will pop
up, locking the battery in place.
3
4
1
2
Charge the battery
battery latch

5
Taking Pictures
5Place the camera in the COOL-STATION
Power lamp
Camera connector
Charge the battery
The indicator next to the camera
monitor will blink green while the
battery charges.
Charging is complete when the in-
dicator stops blinking. Remove the
camera from the COOL-STATION
and unplug the AC adapter.
6
1
2
2
1
Charge the battery
An exhausted battery will re-
charge in about two hours.
Place the camera in the COOL-STATION with the monitor to-
wards you, making sure that the connector is fully inserted in
the matching connector on the COOL-STATION.
Confirm that the camera power-on lamp is off. The battery
will not charge while the camera is on.

Taking Pictures
6
Turn the camera on
Press the power switch until the
power-on lamp lights.
Turn the camera on
Turn the camera on
Select mode
Slide the mode selector to (auto
mode).
1
Auto Power off (Stand-by Mode)
Auto Power off (Stand-by Mode)
If no operations are performed for about five seconds in shooting mode, the
monitor will gradually dim to save power. Full brightness can be restored by
pressing the shutter-release button or operating any of the controls next to the
monitor. If no operations are performed for about a minute, the monitor will
turn off altogether and the camera will enter stand-by mode, further reducing
the drain on the battery. The display can be reactivated by pressing the shutter-
release button halfway. The camera will turn off automatically if no operations
are performed for another three minutes.
See the Guide to Digital Photography for more information on the options
available for auto power off.
2
Turn the camera on

7
Taking Pictures
Use the multi selector to navigate the menus.
The first time the camera is turned on, a language-selection dialog will
be displayed in the monitor. Follow the steps below to choose a lan-
guage and set the time and date.
Choose a language and set the clock
Choose a language and set the clock
Display sub-menu,
move cursor right,
or make selection
Move cursor up
Move cursor down
Cancel and return
to previous menu,
or move cursor left
Press center ( )
to make selection
2DATE
DATE
DATE
Confirm
Confirm
Confirm
Set time and date?
Yes
No
No
3DATE
DATE
DATE
Confirm
Confirm
Confirm
Set time and date?
No
Ye
s
4TIME ZONE
TIME ZONE
TIME ZONE
Confirm
Confirm
Confirm
DaylightSaving
London
,
Casablanc
a
1
Cancel
Cancel
Confirm
Confirm
Cancel Confirm
* To turn daylight saving time on or off, press multi selector down to highlight
DaylightSaving and press button of multi selector. When DaylightSaving is
checked, time will automatically be advanced one hour. To return to Step 4, press
multi selector up to highlight current time zone.
Choose a language and set the clock
Confirmation dialog displayed.
Highlight Yes. TIME ZONE menu displayed.*
Highlight language.

Taking Pictures
8
Display map of world time zones.
5HOME TIME ZONEHOME TIME ZONE
Back
Back
Confirm
Confirm
Back Confirm
London, Casablanca
Edit Day (order of Day, Month, and
Year may differ in some areas).
Display DATE menu.
7DATE
DATE
DATE
YDM
2005..01
00 00:
01
8DATE
DATE
DATE
YDM
2005..01
00 00:
01
Select home time zone.
6HOME TIME ZONEHOME TIME ZONE
Back
Back
Confirm
Confirm
Back Confirm
London, Casablanca
Select Month. Repeat 8– 9to edit
Month, Year, hour, and minute.
9DATE
DATE
DATE
YDM
200501 . .
00 00:
10
1
0
10
Highlight D M Y.
DATE
DATE
DATE
Confirm
Confirm
Confirm
200501 . .10
15 10:
Y
D
M
Choose order in which Day, Month,
and Year will be displayed.
11
DATE
DATE
DATE
Confirm
Confirm
Confirm
200510 . .01
15 10:
Y
M
M
D
Exit to shooting mode.
12
AUTO
AUTO
AUTO 9
9
Choose a language and set the clock

9
Taking Pictures
Take pictures
Take pictures
Picture Storage
Picture Storage
Pictures are stored either in the camera’s 12 MB internal memory or on remov-
able memory cards. In the description that follows, pictures are stored in internal
memory. For information on using memory cards, see page 10 of the Guide to
Digital Photography.
AUTOAUTOAUTO 9
9
1Check indicators in the monitor
AUTO 99
Battery level indicator: Battery level is shown as follows:
Display Description
NO ICON Battery fully charged.
Low battery. If flash fires, monitor will turn off while
flash recharges. Prepare to recharge or change battery.
WARNING!!
BATTERY
EXHAUSTED
Battery exhausted. No pictures can be taken until bat-
tery has been recharged or replaced with fully-charged
spare battery.
Number of expo-
sures remaining
Take pictures

Taking Pictures
10
AUTO
AUTO
AUTO 9
9
Frame the subject
Position the subject in the center of the frame and use the zoom
buttons to compose the picture.
Zoom buttons: Press Tto zoom
in on the subject so that it fills
a larger area of the frame. Press
Wto zoom out, increasing the
area visible in the frame.
Ready the camera
Hold the camera steadily in both hands.
Important
Take pictures
2
3
Don’t Block the Shot
Don’t Block the Shot
To avoid dark or partially obscured pictures, keep your fingers and other
objects away from the lens and flash window.

11
Taking Pictures
Take the picture
Press the shutter-release button
the rest of the way down to take
the picture. To prevent blur, press
the shutter-release button down
smoothly.
AUTO 9
5
Focus
Press the shutter-release button
halfway to set focus and exposure.
In mode, the camera will auto-
matically focus on the subject at
the center of the frame. Focus and
exposure will lock while the shutter-
release button is pressed halfway.
With the shutter-release button
pressed halfway, check the focus
and flash indicators:
AUTO
AUTO
AUTO 9
9
4
Focus indicator On (green) Subject in focus.
Blinks red Camera unable to focus. Change compo-
sition and try again.
Indicator lamp
(flash lamp)
On (red) Flash will fire when picture is taken.
Blinks red Flash charging.
Off Flash off or not required.
Take pictures
The COOLPIX S3 has a two-stage shutter-release button. Pressing the shut-
ter-release button halfway focuses the camera. Pressing it the rest of the way
down releases the shutter to record a picture.

12
Taking Pictures
100NIKON
100NIKON
1
/
11
/
1
15:30
15:30
15:30
100NIKON
01.10.2005
01.10.2005
01.10.2005
View pictures
View pictures
Press the button
A picture will be displayed in the
monitor.
1
When the camera is off, press-
ing the button for about one
second will turn the camera on
with a picture displayed in the
monitor.
(playback) button
View additional pictures
Press the multi selector down or
right to view pictures in the order
recorded, up or left to view pictures
in reverse order. Keep the multi
selector pressed to scroll quickly to
the desired frame.
To return to shooting mode, press
the button again.
2View previous picture
View next picture
Turn the camera off
Press the power switch. The camera
is off when the power-on lamp is
off.
3
Now that you’ve taken a few pictures, you can install PictureProject and
transfer (copy) them to your computer as described on the following
pages.
View pictures

13
PictureProject
OS Mac OS X version 10.1.5 or later (version 10.2.8 or later
required for Burn Disc option)
Hard disk space 60 MB required for installation
RAM Minimum 64 MB
Video resolution 800 ×600 or more with 16-bit color (thousands of colors)
or better
Miscellaneous Only computers with built-in USB ports supported
Once the supplied PictureProject software has been installed, pictures can
be transferred to a computer for easy viewing and storage.
System Requirements for PictureProject
CPU 300 MHz Pentium or better recommended (550 MHz
Pentium III or better for muvee option)
OS
Preinstalled versions of Windows XP Home Edition, Windows
XP Professional, Windows 2000 Professional, Windows
Millennium Edition (Me), or Windows 98 Second Edition (SE)
Hard disk space 60 MB required for installation
RAM
Minimum 64 MB (128 MB with muvee option)
Video resolution 800 ×600 or more with 16-bit color (High Color) or better
Miscellaneous Only computers with built-in USB ports supported
pg. 14
Windows
pg. 18
Macintosh
For the latest information on supported operating systems, visit:
• http://www.europe-nikon.com/support (for users in Europe and Africa)
• http://www.nikon-asia.com/ (for users in Asia, Oceania, and the Middle East)
System Requirements for PictureProject
Bundled software
Important
Other Nikon Software (Nikon View/Nikon Capture)
Other Nikon Software (Nikon View/Nikon Capture)
Uninstall Nikon View before installing PictureProject. For information on
using PictureProject with Nikon Capture, see the PictureProject Reference
Manual (on CD).

Bundled software
Windows
PictureProject
14
A language selection dialog will be
displayed. Select a language and click
Next.
Insert the PictureProject installer CD into
the CD-ROM drive. The Install Center
program will launch automatically and a
“Select Region” dialog will be displayed.
Select a region and click Next. (The “Select Region” dialog is
not displayed in the European release of PictureProject. European
users can proceed directly to Step 3.)
Windows
Install PictureProject Windows
If the “Select Region” or “Select Language” Dialog Is Not Displayed
If the “Select Region” or “Select Language” Dialog Is Not Displayed
Open the “My Computer” window by selecting My Computer from the Start
menu (Windows XP Home Edition/Windows XP Professional) or by double-
clicking the My Computer icon on the desktop (other versions of Windows) and
then double-click the CD (PictureProject) icon.
3
2
1Turn the computer on and wait for Windows to start up.
Before proceeding to the next step, turn off any virus-checking
software and exit any other applications that may be running.
Important
Install PictureProject
Windows XP/Windows 2000
Windows XP/Windows 2000
Log on to an account with administrator privileges when installing or
uninstalling PictureProject under Windows XP Home Edition, Windows XP
Professional, or Windows 2000 Professional.

Bundled software
Windows
PictureProject
15
Click Easy Install to begin installation of
the following software:
• PTP drivers for COOLPIX-series cameras
(Windows XP only)
• Nikon Mass Storage Camera Drivers
(Windows 98SE only)
• Panorama Maker
• Apple QuickTime 6 • Nikon FotoShare (Europe only)
• PictureProject • Microsoft DirectX 9
The first components to be installed are the camera drivers.
The drivers installed depend on the computer’s operating system:
• Windows XP: Follow the on-screen
instructions to install the PTP driver
(on some systems the driver may be
installed by a wizard).
5
• Windows 2000/Windows Me: No drivers are installed.
Proceed to Step 6.
• Windows 98SE: Follow the on-screen
instructions to install the Mass Storage
Drivers.
The Panorama Maker install wizard will
start. Follow the on-screen instructions
to complete installation.
6
7
4
Install PictureProject
Click Yes to install QuickTime.

Bundled software
Windows
PictureProject
16
Panorama Maker and muvee options
require DirectX version 9 or later. If an
earlier version is installed, the dialog
shown at right will be displayed. Follow
the on-screen instructions to install
DirectX 9.
Click Next to install PictureProject to
the location shown under “Destination
Folder,” or click Browse… to choose a
different folder. Complete the following
steps:
The PictureProject setup program will now
start. After reading the license agreement,
click Yes to accept the agreement and
proceed with installation.
The Nikon FotoShare setup program will
start (Europe only). Follow the on-screen
instructions to complete installation.
8
9
2
1
3
10
11
Click Yes when prompted to create a new folder.
To create a shortcut to PictureProject on the desktop, click
Yes when prompted.
Click Finish to exit the PictureProject installer.
Install PictureProject

Bundled software
Windows
PictureProject
17
When the computer restarts, the
PictureProject Import Assistant will be
displayed.
The Import Assistant is used to catalog
pictures already on the computer for dis-
play in PictureProject. To proceed without
cataloging existing pictures, click Close (existing pictures can be
cataloged manually at any time; see the PictureProject reference
manual for details).
For more information on importing pictures into PictureProject,
see the PictureProject Reference Manual (on CD).
This completes installation of PictureProject. The next step is to transfer
pictures to your computer as described on page 22.
Software updates
Software updates
If the computer is connected to the Internet, PictureProject will periodically
check for updates. If an update is detected when PictureProject starts, an up-
date dialog will be displayed. Follow the on-screen instructions to update to
the latest version of PictureProject.
Remove the PictureProject installer CD from the CD-ROM drive.
14
13
Click Finish or Yes to restart the computer.
12
Displayed if DirectX is installed Displayed if DirectX is not installed
Install PictureProject

Bundled software
PictureProject
Macintosh
18
Click Easy Install to begin installation of
the following software:
• Panorama Maker
• PictureProject
• Apple QuickTime 6 (if required)
Once installation is complete, Euro-
pean users can install Nikon FotoShare by
copying the “FotoShare” icon to the hard disk (Step
12
).
A language selection dialog will be
displayed. Select a language and click
Next.
Insert the PictureProject installer CD into
the CD-ROM drive. Double-click the
PictureProject installer CD icon on the
desktop, then double-click the Welcome
icon. The “Select Region” dialog will be displayed. Select a region
and click Next. (The “Select Region” dialog is not displayed in the
European release of PictureProject. European users can proceed
directly to Step 3.)
Important
Windows
Macintosh
Install PictureProject
Turn the computer on and wait for it to start up.
Before proceeding to the next step, turn off any virus-checking
software and exit any other applications that may be running.
1
2
3
4
Install PictureProject
Installing or Uninstalling PictureProject
Installing or Uninstalling PictureProject
Log on to an account with administrator privileges when installing or
uninstalling PictureProject.

Bundled software PictureProject
Macintosh
19
The Panorama Maker installer will start. Fol-
low the on-screen instructions to complete
installation.
5
6
7
8
Install PictureProject
The message shown at right will be
displayed (Europe only; users in other
areas can proceed directly to Step 7).
Click OK.
Enter your administrator name and pass-
word and click OK.
The PictureProject license agreement will
be displayed. After reading the license
agreement, click Accept to accept the
terms and conditions of the agreement
and view the ReadMe file. Take a few
moments to read this file, which may
contain important information that could not be included in this
manual. After viewing the ReadMe file, click Continue to pro-
ceed with installation.

Bundled software
PictureProject
Macintosh
20
The PictureProject installer will start. Click
Install and follow the steps below:
9
2
3
1
Apple QuickTime 6
Apple QuickTime 6
If an earlier version of QuickTime is installed, the
QuickTime 6 installer will start automatically. Follow
the on-screen instructions to complete installation.
When the dialog shown at right is displayed, click
Continue. Do not complete the “Registered To,”
“Organization,” and “Registration Number” fields.
On some systems, the QuickTime installer may require
considerable time to complete installation.
Click Restart to restart the computer.
10
Displayed if QuickTime 6
is not installed
Displayed if QuickTime 6
is installed
Install PictureProject
Click Yes to add PictureProject to the Dock.
Click Quit to exit the PictureProject installer.
To have PictureProject Transfer start automatically when the
camera is connected, click Yes when prompted.
