REPAIR MANUAL
J:VAA12901 SV / BG
VAA12911 BK / BG
U:VAA12902 SV / GR
EP:VAA12903 SV / BG
VAA12913 BK / BG
EN:VAA12904 SV / BG
Body color/Grip color
SV(Silver),BK(Black)/BG(Bule-Gray),GR(Green)

VAA11801-R.3578.A
- E4300 -
SPECIFICATIONS ･････････････････････････････････････････････････････････････
DISASSEMBLING
WARNING / NOTES, REAR COVER/FRONT COVER ･･････････････････････････････････
DISCHARGE ELECTRICITY FROM THE MAIN CAPACITOR ･･････････････････････････
BATTERY HOLDER, LCD ････････････････････････････････････････････････････････
SY-1 PCB / TB-1 PCB, ST-1 PCB / MONITOR HOLDER ･･････････････････････････････
LENS UNIT, FINDER UNIT ･･････････････････････････････････････････････････････
ASSEMBLY
FINDER UNIT, LENS UNIT ･･････････････････････････････････････････････････････
LENS UNIT / CA-1 PCB, ST-1 PCB / MONITOR HOLDER ････････････････････････････
SY-1 PCB / TB-1 PCB, BATTERY HOLDER, LCD ･･･････････････････････････････････
Location where the Grease should be applied of the Card cover and Front cover ･････････････
REAR COVER/FRONT COVER ･･････････････････････････････････････････････････
Location of each board , Location of each lead wires part1 ･･････････････････････････････
Location of each lead wires part 2 ･･････････････････････････････････････････････････
ADJUSTMENT ･････････････････････････････････････････････････････････････
DISCRIPTION OF CIRCUIT ･････････････････････････････････････････････････････
ELECTRICITY
OVERALL WIRING ･･･････････････････････････････････････････････････････････
OVERALL BLOCK DIAGRAM ･･････････････････････････････････････････････････
CA-1(CCD)BLOCK DIAGRAM ･････････････････････････････････････････････････
CA-1(Lens)BLOCK DIAGRAM ･････････････････････････････････････････････････
CA-1BLOCK DIAGRAM ･･････････････････････････････････････････････････････
SY-1 BLOCK DIAGRAM ･･････････････････････････････････････････････････････
ST-1 BLOCK DIAGRAM ･･････････････････････････････････････････････････････
ST-1CIRCUIT DIAGRAM ･･･････････････････････････････････････････････････････
INSPECTION STANDARD ･･････････････････････････････････････････････････････
TOOL LIST ･･･････････････････････････････････････････････････････････････････
Ｍ１－Ｍ２
Ｄ１
Ｄ 2
Ｄ２
Ｄ 3
Ｄ 4
Ａ１
Ａ２
Ａ３
Ａ４
Ａ４
Ａ５
Ａ６
Ａ７－Ａ１６
Ｅ１－Ｅ７
Ｅ８
Ｅ９
Ｅ１０
Ｅ１１
Ｅ１２
Ｅ１３
Ｅ１４
Ｅ１５
Ｒ１－Ｒ５
Ｔ１－Ｔ３

VAA12901-R.3594.A
- M1 ･E4300 -
Specications
Type E4300 digital camera
Effective pixels 4.0 million
CCD 1/1.8-inch high-density CCD; total pixels: 4.13 million
Image size (pixels) • 2272 x 1704 • 1280 x 960
• 2048 x 1536 • 1024 x 768
• 1600 x 1200 • 640 x 480
Four Small Picture sizes selectable (640 x 480, 320 x 240, 160 x 120
or 96 x 72 pixels)
Lens
Focal length
f/-number
Construction
• 3x Zoom Nikkor
• F = 8-24 mm (35 mm [135] camera format equivalent: 38-114 mm)
• f/2.8-f/4.9
• Nine elements in eight groups
Digital zoom 4.0x
Autofocus (AF)
Focus range measured
from lens)
Focus-area selection
Contrast-detect through-the-lens (TTL) AF
• 30 cm (1 ft.)-∞ at widest angle (W), 60 cm (2 ft.)-∞ at telephoto (T)
• Macro mode (Autofocus): 4 cm (1.6 in.)-∞ at widest angle (W), 30 cm (1 ft.)-
∞ at telephoto (T)
Five-area multi AF and spot AF available
Viewfinder
Frame coverage
Real-image zoom optical viewfinder with LED indication
Approximately 80%
Monitor
Frame coverage
1.5-inch 110,000-dot, low-temperature polysilicon TFT LCD with brightness
adjustment
Approximately 97% vertical and 97% horizontal
Storage
Media
File system
File format
Type I CompactFlash™ (CF) cards
Compliant with Design rule for Camera File systems (DCF), Exif 2.2, Digital
Print-Order Format (DPOF)
Compressed: JPEG-baseline-compliant; (FINE-, NORMAL-, and BASIC-
quality images)
Uncompresses: TIFF-RGB (HI-quality images)
Movies: QuickTime
Exposure
Metering
Exposure control
Range
(ISO equivalent)
Four-mode through-the-lens (TTL) metering
• 256-segment Matrix • Center-Weighted
• Spot • AF Spot
Programmed auto, manual, exposure compensation (–2.0 - +2.0 EV in steps of
1/3 EV), autoexposure bracketing, AE lock
• W: EV –3 to +15
• T: EV –1.4 to +16.6
Shutter
Speed
Mechanical and charge-coupled electronic shutter
8-1/1000 sec.; Bulb (up to 60 sec. in M mode)

VAA12901-R.3594.A
- M2 ･E4300 -
Aperture
Range
Electronically controlled preset aperture
Two steps (f/2.8 and f/7.6 [W])
Sensitivity ISO equivalent approximately 100, 200, 400 or Auto
Self-timer Ten- or three-second duration
Built-in Speedlight
Range
Sync method
Equipped with automatic pop-up
W: 0.4 to 3.7 m (1.3 to 12.1 ft.)
T: 0.4 to 2.3 m (1.3 to 7.5 ft.)
Automatic sync control
Interface USB
Video output User can choose from NTSC and PAL
I/O terminals • DC input
• Data output (USB)
Power sources • Rechargeable Nikon EN-EL1 lithium-ion battery (supplied) or six-volt 2CR5
(DL245) lithium battery (available separately)
• EH-21 AC adapter/battery charger (available separately)
• EH-53 AC adapter (available separately)
Battery life
(EN-EL1)
Approximately 90 minutes (as measured at room temperature [20°C/68°F]
under standard Nikon test conditions: zoom adjusted with each shot, flash used
in approximately one third of photographs, image quality set to NORMAL,
image size 2272 x 1704)
Tripod socket 1/4 (ISO1222)
Dimensions
(W x H x D)
95 x 69 x 52 mm (3.7 x 2.7 x 2.0 in.)
Weight Approximately 225 g (7.9 oz.) without battery and memory card
Operating environment
Temperature
Humidity
0 - 40°C (32 – 104°F)
Under 85% (no condensation)

VAA12901-R.3594.A
- D1 ･E4300 -
DISASSEMBLY
REAR COVER, FRONT COVER
Battery cover
①①
①
②
②
④
FPC ③
FPC ⑤
Front cover
Back cover






Notes:
① Remove the battery prior to disassembly.
② During disassembly, make a note of the routing of the cords, which screws are
mounted in which parts, etc.
③ Electrical parts must be grounded since they are easily damaged by static.
• Open the battery cover.
• Remove the 6 pieces of the screws ①(M1.7×4).
• Remove the 5 pieces of the screws ②(M1.7×4.5).
• Lift up the front cover by setting up from the bottom side.
• Remove the hook as pushing the section shown in the diagram with your nger, and then remove the back
cover.
• Disconnect the FPC ③ connector.
• Remove the stand ④ while carefully removing the front cover.
Then disconnect the FPC ⑤ from the connector.

VAA12901-R.3594.A
- D2 ･E4300 -
• Remove the 2 pieces of screws ①(M1.7×4).
• Remove the 2 pieces of connectors ②, and then remove the battery holder.
• Remove the screw ③(M1.7×4), and then remove the TB-1 board ④.
• Disconnect the FPC ⑤ form the connector.
• Remove the connector ⑥.
• Remove the LCD .
DISCHARGE ELECTRICITY FROM THE MAIN CAPACITOR
BATTERY HOLDER , LCD
2KΩ/5W
Main
capacitor
①
②
③
⑤
⑥
LCD
Battery
holder







VAA12901-R.3594.A
- D3 ･E4300 -
• Remove the 3 pieces of the screws ①(M1.7×2.5), and then remove the ST-1 PCB.
• Remove the 2 pieces of the screws ②(M1.7×2.5) and the screws ③(M1.7×3)
to remove the monitor holder.
• Remove the 2 pieces of the screws ④(M1.7×2.5)
and the screws ⑤(M1.7×3) to remove
the main holder.
①
②
ST-1 PCB
③
Monitor holder
④
⑤
Main holder
④
①
②
③
④
SY-1 PCB
Card holder
TB-1 PCB
• Remove the 2 pieces of the screws ①(M1.7×2.5)
• Disconnect the FPC ② from the SY-1 PCB,
and then remove the control dial unit ③.
• Remove the 2 pieces of the screws ④(M1.7×4),
and them remove the SY-1 PCB.
• Remove the 2 pieces of the screws ⑤(M1.7×3),
and them remove the card holder.
• Remove the TB-1 PCB.
SY-1 PCB / TB-1 PCB
ST-1 PCB / MONITOR HOLDER
⑤

VAA12901-R.3594.A
- D4 ･E4300 -
• Remove the 3 pieces of the screws ①(M1.7×4).
• Remove the nder unit while carefully removing the lens unit.
LENS UNIT
• Disconnect the FPC ① from the connector.
• Remove the 2 pieces of the screws ②(M1.7×6) to
remove the lens assemble.
• Remove the soldering bridge of the CCD and
screw ③(M1.7×2.5)to remove the CCD from
the CA-1 PCB.
FPC ①
CA-1 PCB
②
③
FINDER UNIT
①
Finder unit
Lens unit

VAA12901-R.3594.A
- D5 ･E4300 -
LENS - BARREL
・ Remove the shutter FPC from the connector.
・ Remove the screw ①（Ｍ 1.7×4） and
the screw ②（Ｍ 1.7×3).
・ Uncover the zoom gear cover ③.
・Remove the 3 screws ①（Ｍ 1.7×4）.
・Lift up slowly the 1 and 2 lens group unit ②
to detach.
・Remove the gears ①②③④⑤ .
・Remove the spring of the 3rd
lens group frame ⑥.
・Insert the driver into the slot of
the AF motor shaft and turn it
clockwise to remove the 3rd
lens group frame ⑦ and the
AF nut ⑧.
Shutter FPC
①
②
①
③
AF motor shaft
⑥
⑤
④
③
①
②
⑧
⑦
②

VAA12901-R.3594.A
-A0-1 ･E4300 -
・Re-assemble the gears in the order
of ④,③,②,① and ⑤.
・Attach the AF nut ⑧ to the 3rd
lens frame ⑦. Then insert the
driver into the slot of the AF motor
shaft ⑩ and turn counterclockwise
and re-assemble the 3rd lens frame
⑦ to the master frame ⑨.
・Hook the spring ⑥ on the 3rd lens
group frame ⑦ and the master
frame ⑨.
To prevent the spring from coming
off, apply a little of the Screw Lock
to the hook (on both sides).
LENS - BARREL
２ｍｍ
Insert the driver into the slot of the AF motor shaft and turn it.
・Re-assemble the shutter FPC of the 1st and
2nd lens group unit ① by inserting it into
the hole of the master frame ②.
・Tighten the 3 screws ③ (M1.7×4).
⑥
⑤
④
③
①
②
⑧
⑦
⑨
・Set the 3rd lens group frame ⑦
in position as shown in the right.
⑩
②
③
①
ASSEMBLY

VAA12901-R.3594.A
-A0-2 ･E4300 -
・Cover the zoom gear cover ①.
・Screw the ② (M1.7×4）and ③ (M1.7×3) screws.
・Insert the shutter FPC into the connector.
When the lens-barrel is dissembled and repaired, the following should be checked after re-assembling the front
and back cover.
Refer to Page A7 for the method to inspect.
(1) Check the zoom driving and release performance
(2) Check the resolution by photographing the chart
In case either (1) or (2) of the above fails, it is necessary to replace the lens-barrel group unit with the new one.
③
②①
CHECK WHEN DISSEMBLE AND REPAIR THE LENS-BARREL
Shutter FPC

VAA12901-R.3594.A
- A1 ･E4300 -
Hole for a pin
Pin
Finder cam
Hole of the gear
ASSEMBLY
FINDER UNIT
LENS UNIT
• Set the lens unit to the reset position.
• Put the nder unit on the lens unit.
• Fix the nder unit by 3 pieces of the screws ① (M1.7×4).
• Remove the pin from the nder unit.
Note: When mounting the nder lens unit, be careful about dust.
• Rotate the nder cam in an arrow direction until it touches
the limit (Wide end), and rotate it back a little to align a hole of
the gear and a hole for a pin. Then insert the pin
(approx. φ0.5) into the holes.
Note: When mounting the nder lens unit, be careful about dust.
①

VAA12901-R.3594.A
- A2 ･E4300 -
LENS UNIT / CA-1 PCB
A
C
D
CA-1 PCB
• Put the CCD on the CA-1 PCB, and then
attach them by the soldering bridge and
the screw ① (M1.7×2.5).
• Attach the lens unit by 2 pieces of the screws
② (M1.7×6).
• Insert the FPC ③ in the connector.
③
Lens side CCD side
①
Optical lter
②
ST-1 PCB / MONITOR HOLDER
• Attach the main holder by 2 pieces of the screws
①(M1.7×2.5) and the screw ② (M1.7×3).
• Attach the monitor holder by 2 pieces of the
screws ③(M1.7×2.5) and the screw ④ (M1.7×3).
• Attach the ST-1 PCB by 3 pieces of the screws ⑤
(M1.7×2.5).
B
CD
Monitor
holder
Main holder
ST-1PCB
⑤
④
①
①
③
②

VAA12901-R.3594.A
- A3 ･E4300 -
A
B
SY-1 PCB
④
⑤
Card holder
TB-1 PCB
①
③
②
• Attach the TB-1 PCB.
• Attach the card holder by the 2 pieces of the
screws ① (M1.7×3).
• Attach the SY-1 PCB by the 2 pieces of the screws
②(M1.7×4).
• Insert the FPC ③ in the connector.
• Attach the control dial unit ⑤ by the 2 pieces of
the screws ④(M1.7×2.5).
BATTERY HOLDER , LCD
• Attach the monitor LCD unit.
• Insert the FPC ① in the connector.
• Insert the connector ② in the connector.
• Attach the TB-2 PCB by the screws ③(M1.7×4）.
• Insert the 2 pieces of the connector ④
in the connector.
• Attach thebattery holder by the 2 pieces
of the screws ⑤(M1.7×4).
Battery
holder
Monitor LCD unit
②
③
TB-2
④
④
SY-1 PCB / TB-1 PCB
⑤
①

VAA12901-R.3594.A
- A4 ･E4300 -
Rear cover
FPC ①
FPC ③
Front cover
Battery cover
②
④④
④
⑤
⑤
LOCATION WHERE THE GREASE SHOULD BE APPLIED OF THE CARD COVER AND FRONT COVER
Grease: MZ-800S
To the sliding part
with the rear cover
To the sliding part
with the battery
(Rib x 4 places)
Grease: MZ-800S
REAR COVER, FRONT COVER
• Insert the FPC ① in the connector, and then attach the rear cover while inserting the stand ②.
• Insert the FPC ③ in the connector, and then attach the front cover.
• Attach the 6 pieces of the screws ④ (M1.7×4).
• Attach the 5 pieces of the screws ⑤(M1.7×4.5).

VAA12901-R.3594.A
- A5 ･E4300 -







LOCATION OF EACH BOARD
ST1 board
TB2 board TB1 board
SY1 board
CA1 board
SY1 board
TB1 board
CA1 board
ST1 board
TB2 board
LOCATION OF EACH LEAD WIRES
Part 1

VAA12901-R.3594.A
- A6 ･E4300 -
Part 2
A
B
D
C
B
B
C

VAA12901-R.3594.A
-A6-1 ･E4300 -
Be sure to check when dissemble and repair the lens-barrel
(1) Check the performance
Repeat the following performance several times: After tuning the power switch ON and driving the zoom,
turn it OFF.
Conrm that there is no abnormal operation by repeating to check the release performance several times.
(2) Check the resolution
By photographying the high-denition resolution chart (J63079), conrm that the TV lines are within the standard.
Standard for the TV lines: more than 1100 TV lines in the Center; more than 750 TVs in the 4 corners.
(ref.：The resolution is based on the unit of TV lines that are black-and-white strips distinguished in the TV screen.)
(a) The camera is set as follows to take photos: Shooting-mode: Auto, Image quality mode: FINE, Image
size: 2272, Flash mode: Flash cancel
(b) The uneven pattern in luminance of the chart does not affect, but photograph with the luminance
(ISO100, 1/15-1/250) by which the aperture is open.
(c) Check the zoom position in the order of WIDE, MIDDLE (press the button 6 times starting from WIDE)
and TELE.
The object distance is WIDE: approx.65cm, MIDDLE: approx.115cm, TELE: approx.185cm. Set the
chart fully screened in the LCD of the camera, and x on a tripod.
(d) Open the photographed image by Photoshop, and conrm it by the magnied display, e.g. 100%, etc.
(e) Regarding the resolution of the frame center and the 4 corners, check if it is clear in black and white in
the position circled in red as shown in the below.
In case either (1) or (2) of the above fails, it is necessary to replace the lens-barrel group unit with the new one.
CHECK THE PERFORMANCE AND RESOLUTION
High-denition resolution chart (J63079)

VAA12901-R.3594.A
- A7 ･E4300 -
ADJUSTMENT
1. Equipment
IBM compatible PC • AC adapter EH-21 • USB cable ( UC-E1) • Oscilloscope
2. Servicing Tools
• Pattern Box •Color Meter •Luminance Meter • Siemens star chart • Calibration software
3. Adjustment Items and Order
1. Lens Adjustment
2. AWB Adjustment
3. CCD White Point Defect Detect Adjustment
4. CCD Black Point Defect Detect Adjustment
5. USB Storage information registration
6 LCD Panel Adjustment
7-1. LCD H AFC Adjustment
7-2. LCD RGB Offset Adjustment
7-3. LCD Gain Adjustment
7-4. LCD Blue Brightness Adjustment
7-5. LCD Red Brightness Adjustment
Note) If replacing the lens, CCD, optical lter, CA-1 or CP-1 board, it is necessary to perform the above 1-5
adjustments. 2-5 adjustments other than these should be carried out in sequence.
4. Setup
1) System requirements
• Windows98® , Me, 2000 or XP
• IBM-compatible PC with Pentium processor
• CD-ROM drive
• 3.5-inch high-density diskette drive
• USB port
• 40 MB RAM
• Hard disk drive with at least 15 MB available
• VGA or SVGA monitor with at least 256-color display
2) Installing calibration software
• Insert the calibration software installation diskette into your diskette drive.
• Open Explorer.
• Copy the DscCalDI_128 folder on the oppy disk in the FD drive to a folder on the hard disk.

VAA12901-R.3594.A
- A8 ･E4300 -
5. Installing USB drive
Install the USB drive with camera or connection kit for PC.
6. Pattern box
Turn on the switch and wait for 30 minutes for aging to take place before using Color Pure. It is used after
adjusting the chroma meter (VJ8-0192) adjust color temperature to 3100 ± 20 K and luminosity to
900 ± 20 cd/m2. Be careful of handling the lump and its circumference are high temperature during use and
after power off for a while.
・Procedure for correcting Pattern Box
Note: Be sure to perform the aging correction.
1) Measure the center of screen with the Color Meter (J63081).
2) Adjust the pattern box so that the color temperature would be 3100±20K by using "VR for adjustment of
the color temperature".
3) Measure the center of screen with the Luminance Meter BM-300 (J63068).
4) Adjust the pattern box so that the brightness would be 900±20cd/  by using "Knob forbrightness
adjustment".
5) Repeat process 1) to 4) until the color temperature would be 3100±20k and brightness
would be 900±20cd/ .
Power switch
VR for adjustment of
the color temperature
Knob for brightness
adjustment
Iris unit
Screen
Area to be measured
