Ninebot miniPRO Instruction manual

PRO
Quick Start Manual
About this manual
Thanks for choosing Ninebot™ Personal Transportation Robot. This manual relates to the instructions for Ninebot™ Mini series which may help
you to:
●Practice safely starting from scratch, grasp basic operation steps, riding methods of Mini gradually.
●Get familiar with the safe riding methods and the riding techniques that must be followed so as to gain safe and pleasant riding experiences.
●Understand the structures and operation modes of Mini as well as methods for its regular maintenance. Enjoy the Ninebot to the fullest in a
safe manner.
For more information, please visit www.ninebot.com. You can also scan two-dimension code on the cover of this manual, subscribing official
microblog and wechat public account of Ninebot.
Warning!
●Get off Mini and charge it for safety in the case of low power, successive warning and limit speed. If
keeping riding forcibly in low battery, danger may be caused by decline of motor and shorten battery
life.
●If Mini is starting up and in autobalance mode during transportation, power output would be cut off
automatically when tires are hung to protect you; balance mode would be recovered automatically
when placing Mini to the ground. Do not lift the Ninebot by the fender, because your finger may be
clipped between the wheel and the fender or damage fender. Please do as follows:
●Please check before every riding, do not ride if there are any looseness, damage or tire pressure lacking. Use Ninebot App to connect with
Mini and check if mainframe buzzing alarms continuously after starting or ask support staff for help. Do not ride before removal of fault.
●Please be sure the power is off when dismounting battery pack or rinse the mainframe, or you will get electric shock and cause severe
damage, or lead to internal short and fire.
●Understand and comply with local traffic rules. Do not use it in any place that is not allowed access by the laws of the relevant country/
region or by the related management units. Do not ride it on the motorway in any area. It is a very dangerous kind of riding behaviors which
may cause severe injury or even death.
1. Introduction to Mini
Ninebot™ Mini Personal Transportation Robot is a new form of electrical balancing vehicle with intelligence and robot function. The rider
can stand on the robot to operate it by moving his/her body. Ninebot boasts the following features:
1. Being eudipleural, the wheels turn with zero radius, making the robot moving more flexibly. Apply to short-distance transportation, for its
excellent maneuvering characteristic, riding Ninebot is more like walking than driving a vehicle.
2. Having small volume of mainframe, so it has access to most of the places where walking is possible, including paths, sidewalks, corridors,
rooms and lift/elevators.
3. Portable mainframe can be easily placed in trunk or other smaller storing space.
4. During riding, the rider controls the robot with his/her body posture instead of an accelerator or a brake, thus making it comfortable in
riding and sensitive in reaction.
Notice
●Please read and reserve this manual carefully. Do not use product arbitrarily before understanding performance detailedly.
●Respect the pedestrians’ right of using road without scaring them. When you are behind someone, remind him and pass
him by the left side with decelerating speed; and when you are in front of someone, keep at the right side with decelerating
speed.
●Please wear safety helmet (bicycle helmet or roller skating helmet) to avoid severe head injury when falling; Knee, elbow
and wrist protectors are recommended to lower probability of accidents and injury.
●Do not lend Ninebot™ Mini to anyone who cannot control it to avoid damage. Please be responsible for your friends’ safety
before giving Ninebot™ Mini to them; Safe riding instruction video can be found in Ninebot App for your teaching and
watching with your friends.
●Form good riding manner with concentrated attention and without making any prompt accelerating start or any prompt
decelerating braking. Achieve civilized riding without colliding with the persons or objects around.
●Scheduled maintenance is basically unnecessary for your Mini; Please conduct basic check to Mini before every riding. If
finding abnormalities like obvious loose parts, obvious reduced battery life, slowly flat tire or excessive wear, abnormal
sound or malfunction of steering, please stop immediately and call service hotline [phone] for assistance. Or visit
Ninebot App, consult online support staff.
4. Safe Riding Mini
Apart from an entertainment robot, Ninebot is also a transportation vehicle which may have the risks similar to those of all other commuting
tools. However, if you follow the safe riding instruction in this manual, it may maximize the safety of you yourself and others. By so doing, it will
not cause heavy injury to you even if unrecoverable faults happen to Ninebot or something unexpected happens to your body.
There is one thing you should remember. Once you ride Mini on road or other public occasions, although you ride Ninebot on the road or in a
public occasion in compliance with the Guide for Safe Riding, you may be subject to the risks resulted from improper driving or operation by
other people or of other transportation means. It is just as you may be injured by other transportation means when you are walking or riding a
bike. Like all vehicles, faster speed causes longer brake stopping distance. Emergency brake on smooth earth may lead to wheelslip, losing
balance and even falling. It’s significant to be cautious and keep a reasonable and safe distance with other people and transportation means
during riding. Keep cautious and slow before entering unfamiliar area.
Note: Basic status needs to be checked before every riding, like if there is any loosening, falling or damage. If continuous
abnormal sound or alarms of vehicle occurring during riding, please slow down and get off immediately to check the tire
pressure and if there any obvious loose parts, install Ninebot App with smartphone and check safety status of Mini.
THIS CHAPTER IS VERY IMPORTANT. PLEASE READ CAREFULLY AND UNDERSTAND ALL THE
INSTRUCTIONS. PLEASE STRICTLY COMLY WITH SAFETY REQUIREMENTS FOR RIDERS OF THIS MANUAL IN
COUNTRIES AND AREAS WITHOUT LAWS AND REGULATIONS OF SELF-BALANCING ELECTRIC VEHICLE LIKE
CHINA. WE WILL NOT BE RESPONSIBLE FOR ANY PROPERTY LOSS, CASUALTIES, ACCIDENTS, LEGAL
DISPUTES CAUSED BY VIOLATION OF THE SAFETY INSTRUCTIONS ON CHAPTER.
2. Assemble Mini
2.1 Check of articles in the package
After unpacking,take out foot control and mainframe carefully.
When take out the mainframe, please check whether the articles included in the package are as above, and contact your reseller or call service
hotline [phone] for assistance immediately in case of absence of any.
You can assemble your new Ninebot by the following steps after confirming that all the parts are complete and in good condition.
Open foor-control quick release Quick release links mainframe Fasten quick release
MainframeFoot control
Extended air tap
Charger
Instruction/Warranty Sheet
Height setting knob
Charger port
Riding lamp
Tire air tap
Screen
Foot-control mat
Lock hole
Pull bar
Foot-control bar
Fender
Remember to switch off the power of Mini and unplug the charging cable before handling and
mounting of any accessory or cleaning of the mainframe.
Safety lock Quick charger
Mini 240 Mini 320
Rim blade（detachable）Protect the steering bar and mainframe from scratches with soft cloth and polyfoam when laying the
mainframe flatwise.Then check whether your Ninebot can be switched on/off(you will hear a sequence of sound)
and whether the dashboard on the upper side of the operation bar can be lighted up.
1.1 Model of Ninebot Mini Series
1.2 Ninebot Mini Sketch
Ninebot™ and the shape icon are the registered trademark of Ninebot (Beijing) Technology Co., Ltd. (Ninebot Inc.); iPhone,
iOS, that of Apple Inc. Android, that of Google Inc. . The owners shall reserve all the rights of their trademarks referred to in
this manual, and Ninebot Inc. shall reserve all the rights of Ninebot™ and the shape icon.
Ninebot Inc. is the owner of various patents relating to Ninebot personal transportation robot, and some other patents
pending. This manual is prepared by Ninebot Inc. who shall reserve all its copyrights. No institute or individual shall copy or
disseminate this manual as a whole or in part, or take use of the aforesaid patents without the consent of Ninebot Inc. in
writing.
We have tried as much as possible to include the description and instruction for all the functions of Ninebot at the time of
printing, but there may still be discrepancies with the Ninebot that you have bought because of improvement and change in
design of functions. Please use IOS or Android device, like smartphone or pad to scan two-dimension code of this page, visit
www.ninebot.com and enter “support & service” channel to download and check the latest electronic user manual for Ninebot.
Or scan another two-dimension code and download Ninebot App using on ISO or Android system, read latest electronic
version of manual. Please note that there are various Ninebot models with different functions, and some of the functions
mentioned herein may not be achieved by your Ninebot. Ninebot Inc. shall reserve the right to explain any deviation of the
actual products from those described in the manual in terms of color and appearance.
纳恩博公司 NinebotInc.
快速使用指南
Quick start manual
手册版本号：V1.1.1
3. Accessory(Purchase on selection)
Rotate height setting knob anticlockwise
Lift foot control to needed height
Tighten up height setting knob clockwise Pull bar can be lifted if needed
2.3 Height setting of foot control
Ninebot Inc.
Version：V1.1.1
Scan and Download Hint:
Factory default of Mini is nonactivated status. It can only keep
anterior-posterior balance and cannot steer. Please download Ninebot App
and activate Mini directing by instructions and activate steering function by
watching safe riding instruction video. The first 2km of Mini shall keep
beginner mode after activation, rate-limiting is 7km/h and steering sensitivity
is low. After accumulating mileage reaching 2km, App can be used for
switching to normal mode.
保修手册
产品序列号标签粘贴处
本产品经质检合格，准予出厂。
此保修卡（制造商盖章、粘贴序列
号标签后有效），或正规销售发票
均是享受售后服务的凭证，并且请
妥善保管本卡，以此作为全球联保
凭据。保修政策及方式以本手册
“有限保修条款”部分说明为准。
合格证
质检签章
纳恩博公司
NinebotInc.
手册版本号：V1.1.1
序列号
粘贴处
After taking out foot control and mainframe, please assemble as follows：
2.2 Assemble Mainframe
Wheel
Foot-control
quick release
Foot rest

10. Daily maintenance
You can use a soft cloth (one used for wiping your glasses) dipped with small amount of water to wipe the mainframe of Ninebot to
remove dirt on the surface of mainframe. The dirt that is hard to wipe out on the plastic surface can be scrubbed with toothbrush
after coating it with toothpaste, and then clean it with wet cloth. Do not wash Ninebot with alcohol, gas, diesel, acetone or other
corrosive and volatile chemical solvent. These substances may damage the appearance and internal structure of Ninebot. Scratches
on plastic parts of vehicle can be polished by abrasive paper or other abrasive substances.
Please dry Ninebot in the room and place it in a cool place. Do not store it in the open air for a long time. Exposure to sunshine and
hot/cold outdoor environment will accelerate the aging of the appearance. Mini possesses water resistant function and can be used
in light rain, but spray cleaning of pressure water gun is forbidden.
Hint: When cleaning Ninebot, make sure that Ninebot is powered off, the charging cable is plugged out and the rubber cap on
the charging port is tightly sealed. Or you may suffer electric shock or Ninebot may goes into trouble.
Maintenance of battery pack
Do not place battery in high-temperature or low-temperature environment which is over 50℃or below -20℃. Do not throw battery pack into fire.
Other items for attention in maintenance of battery refer to nameplate of battery pack which is below vehicle.
Battery of Mini can be used for riding over 20,000 km and still keeps excellent performance with great maintenance. Please try to use along with
charge, do not exhaust all the power in the battery and then charge it in daily use. In addition, when using in high-temperature summer, battery
pack can play high distance mileage and performance; and when using in environment below 0℃, endurance and performance of battery would
decline. Typically, when temperature is -20℃, distance mileage may be half of normal temperature 25℃. Distance mileage of battery will recover
when temperature rises.
Hint: Typically, the fully charged battery, if mounted on the Ninebot Mini, will be exhausted within 120 to 180 days in the stand-by mode; And a
low-power battery, if mounted on the Ninebot Mini, will be exhausted within 30 to 60 days in the stand-by mode. Remember to charge the battery
after each riding. Or over draining of power may cause un-recoverable damage to the battery. Intelligent chips inside battery shall record
charge-discharge condition of battery, damage causing by long-time discharge will not be covered under warranty. (Non-specialized person are
forbidden to dismount battery pack randomly!)
Must wear helmet when riding,
recommend putting on kneecap,
elbow guard and cuff.
6. Warning
Watch out for slipping when climbing slope.
Watch out for space above
your head/door frame.
Avoid riding forcibly under low
power (battery level indicator
twinkles and buzzing alarms. )
7. Prohibited
Prohibit waggling back
and forth substantially
during riding.
Prohibit multiplayer to ride one
Mini meanwhile or ride holding children.
Prohibit riding in ponding
that exceeds 2cm.
Prohibit riding into motorway.
Switch
Turn power on or off. Mini will automatically shut if not be used in 10
minutes after starting or mainframe is put down over 5 seconds.
After starting lock mode with APP, mainframe will shake fiercely and buzzing
alarm if anyone moves it. User’s smartphone will vibration alarm if Ninebot
App operates on user’s smartphone meanwhile.
Flicker of Bluetooth icon means Bluetooth is opened but not connect to
smartphone; Bluetooth icon normally on means Ninebot App has connected with Mini.
Mini will be restricted to low speed when rate-limiting icon is on. Foot rest
will raise when accelerate. Default speed of rate-limiting mode is 7km/h and
can be relieved or adjusted by App.
Rate-limiting
LED battery
indictor
Lock
Bluetooth
Every power grid means 20% dumb energy. Please stop and charge immediately
if power is totally empty and flicker. You can see more accurate dumb energy
and estimated riding mileage by App, when power is below 30%, Mini will
decelerate gradually; when power is below 10%, speed will be limited to 7km/h.
Pull the bar on power assistance mode (enter into power assistance mode when start up), push Mini flatly, this may help you push
Mini easily under non-riding mode.
Watch out for slipping on
roads, do not accelerate or
decelerate rapidly on slippery
roads.
Please keep proper speed (little quicker
than walking) when pass deceleration strip
or elevator threshold, do not try to pass
deceleration strip with zero velocity, or
you will fall due to slip or stuck of tires.
Try to avoid passing step that is greater than
1cm or potholes pavement, please keep
low-speed riding on rough pavement (3km/h~10km/h),
bend your knees slightly makes you adapt rough
pavement riding better.
Prohibit trying riding to ascend
and descend stairs.
Prohibit riding on gradient that exceeds 15°;
Especially rider’s weight is over 80kg, please
be cautious and decelerate when climbing
or descending.
Over 15°
Foot rest would uplift gradually if
exceeds safety speed and mainframe
would alarm. Please do not accelerate,
or falling or severe damage may occur.
0
11. Specifications Data and parameter labelled * differ with different models. No further notice if any alteration.
Performance index Item Ninebot Mini-240 Ninebot Mini-320
Size
Weight
Major
parameter
of mainframe
Parameter of
battery pack
Parameter of
electromotor
Parameter of
standard
charger
262x546
611～866
85
About 12.5
About 20
About 15°
About 28
About 12.5
100
55.5
63
240
300x2
900x2
400x2
1200x2
320
Break automatically under status like balance/over charge/
undervoltage/temperature alarm. Connect App to test battery status.
100~240VAC/50~60Hz
About 63
About 1.1 About 1.9
70 120
CCC，CE
LxW (mm)
Mainframe height[1] (mm)
Maximum load (kg)
Net weight(kg)
Maximum speed(km/h)
Typical endurance[2](km)
Maximum gradeability
Beginner mode Be relieved after 2-km accumulative riding.
Applicative terrian
Max. charging voltage (VDC)
Nominal capacity (Wh)
Intelligent BMS
Safety certification
Nominal input voltage(VAC)
Nominal output voltage(VDC)
Nominal current(A)
Safety certification
Nominal voltage(VDC)
Nominal power(W)
Nominal power(W)
Maximum power(W)
Harden pavement, flat dirt pavement, ramp that is below 15°,
stair that is shorter than 1cm, channel that is narrower than 3cm.
About 17 About 20
CCC,CB,CE,FCC,PSE,UL
Charging time(h）About 4.5 About 3.5
(1) Mainframe height: refer to distance from ground to the highest end of mainframe. Since height of foot control is adjustable,
mainframe height refers to height range from the lowest and highest point of adjusted foot control.
(2) Typical endurance refers to: test under riding in full power, 70kg load, 25°C environmental temperature, 15km/h average speed
on flat pavement.
9. Application method of battery charger
Middle deck Open middle deck cap Open rubber cap
of charger port
Charger cable hole
12. After-sales and Warranty
You can contact us by the following ways if you want to consult the issues relating to riding, maintenance and safety, or
report the faults of your product to the manufacturer in the process of using Ninebot; we are at your service.
There are the two-dimension codes for the official Wechat account and official microblog of Ninebot, you can subscribe
by scanning them with your phone. We will provide value-base gifts and colorful activities irregularly for users who
subscribe the official Wechat account and pay attention to the latest trends and activities of Ninebot, stay tuned!
Official Microblog Official Website
QQ Group of Ninebot Club: 389793470
Wechat Service Number
Ninebot Inc.
Head office: F1, Building A-1, Northern Territory of Zhongguancun Science Park, Xixiaokou Road No.66, Haidian District, Beijing, China
Tel ：[phone] Fax：[phone]-800
Toll Free (China only): 400-607-0001(consultation, purchase and after-sales service)
E-mail：[email protected] （Consultation）[email protected] （After-sales service）
Address of Manufacturer：
Ninebot (Changzhou) Tech Co., Ltd. 16F-17F, 3th Bldg., 18 Changwu Road, Wujin Disct, Changzhou, Jiangsu, China
Ninebot (Tianjin) Tech Co., Ltd. 11 Tianrui Rd. Auto Industrial Park,Wuqing disct., Tianjin, China.
Product Standard：Q/320412NCZ001-2015
Other safety certifications we have passed：
UN38.3 Cell and battery pack have passed UN38.3 test and certification
2014/30/EU EN 61000-6-3:2007+A1:2011, EN 60950-1:2006+A12:2011
2014/35/EU EN 60204-1:2006/AC:2010, EN 60950-1:2006/AC:2011, EN 60034-1:2010/AC:2010
2006/42/EC EN ISO 12100:2010, EN ISO 13849-1:2008/AC:2009, EN 62061:2005/AC:2010
EMC ETSI EN 301 489-1 V1.9.2 (2011-09)；ETSI EN 301 489-17 V2.2.1 (2012-09)
RF ETSI EN 300 328 V1.8.1 (2012-06)
Safety EN 60950-1: 2006+A11: 2009+A1: 2010+A12: 2011+A2: 2013
SAR EN 62479: 2010
FCC PART15C FCC Rules Part15.247
REACH 2012/19/EU
www.ninebot.cn
Step on foot rest with both feet meanwhile.
Be relaxed, stand erectly and look straight
ahead, avoid severe ooching.
Touch foot control left and right
to swerve.
Step on foot rest with both feet, move center
of gravity forward or backward slowly to
control back and forth.
Please get in with other’s assistance
for your first ride.
Step on foot rest with one foot, avoid touching foot
control with your shank or knees and cause steering.
Keep your feet and move your center
of gravity to left foot slowly.
1 2 3
5.Learn to ride (Do not touch foot control with your shank or knees when you get in, in case of rapid
rotation or forwarding of mainframe may cause damage. )
4
8. Icons on the dashboard
Switch
Lock
Bluetooth
Rate-limiting
LED battery indictor

IC Radiation Exposure Statement for Canada
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
Under Industry Canada regulations, this radio transmitter may only operate using an
antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry
Canada. To reduce potential radio interference to other users, the antenna type and its gain
should be so chosen that the equivalent is otropically radiated power (e.i.r.p.) is not more
than that necessary for successful communication.
Conformément àla réglementation d'Industrie Canada, le présent émetteur radio peut
fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvépour
l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique àl'intention des autres utilisateurs, il faut choisir le type d'antenne et son
gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas
l'intensiténécessaire àl'établissement d'une communication satisfaisante.
User manuals for transmitters equipped with detachable antennas shall also contain the
following notice in a conspicuous location:
This radio transmitter (identify the device by certification number, or model number if
Category II) has been approved by Industry Canada to operate with the antenna types
listed below with the maximum permissible gain and required antenna impedance for each
antenna type indicated. Antenna types not included in this list, having a gain greater than
the maximum gain indicated for that type, are strictly prohibited for use with this device.
Le présent émetteur radio (identifier le dispositif par son numéro de certification ou son
numéro de modèle s'il fait partie du matériel de catégorie I) a étéapprouvépar Industrie
Canada pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain
admissible maximal et l'impédance requise pour chaque type d'antenne. Les types
d'antenne non inclus dans cette liste,ou dont le gain est supérieur au gain maximal indiqué,
sont strictement interdits pour l'exploitation de l'émetteur.
IMPORTANT NOTE:
Radiation Exposure Statement:

This equipment complies with “Industry Canada RSS-102 for radiation exposure limits set
forth for an uncontrolled environment”.
This equipment should be installed and operated with minimum distance 20cm between the
radiator and your body.

Federal Communications Commission (FCC) Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generate, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate this equipment.
RF exposure warning
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
