Operator’s Manual
Model 2500C
Charger Stand
English

.
Nonin®reserves the right to make changes and improvements to this manual and the products it
describes at any time, without notice or obligation.
Nonin Medical, Inc.
13700 1st Avenue North
Plymouth, Minnesota 55441 USA
[phone]
[phone] (USA and Canada)
Fax [phone]
E-mail: [email protected]
Nonin Medical B.V.
Prins Hendriklaan 26
1075 BD Amsterdam, Netherlands
+31 (0)13 - 79 99 040 (Europe)
Fax: +31 (0)13 - 79 99 042
E-mail: [email protected]
www.nonin.com
MPS, Medical Product Service GmbH
Borngasse 20
D-35619 Braunfels, Germany
References to “Nonin” in this manual shall imply Nonin Medical, Inc.
Nonin and PalmSAT are registered trademarks or trademarks of Nonin Medical, Inc.
© 2020 Nonin Medical, Inc.
7923-201-05
Consult Instructions for Use.
EC
REP

i
Contents
Intended Use.................................................................................................. 1
Warnings ................................................................................................................1
Cautions .................................................................................................................1
Guide to Symbols.......................................................................................... 3
Using the Model 2500C ................................................................................. 4
General Description................................................................................................4
Unpacking the Model 2500C..................................................................................5
Operation........................................................................................................ 6
To Charge the Battery Pack Using the Charger Stand...........................................6
Cleaning.......................................................................................................... 8
To Clean the Charger Stand...................................................................................8
Service............................................................................................................ 9
Warranty....................................................................................................... 10
Accessories.................................................................................................. 11
Troubleshooting Guide............................................................................... 12
Technical Information ................................................................................. 13
Manufacturer’s Declaration...................................................................................13
Specifications .......................................................................................................15

ii
Figures
Figure 1. Charger Stand and Pulse Oximeter............................................................. 4
Figure 2. Bottom View Showing the Serial Number, Power Supply Connection, and
Symbols .................................................................................................... 4
Figure 3. Using the PalmSAT Pulse Oximeter while Charging the Battery Pack........ 7

iii
Tables
Table 1. Labeling Symbols........................................................................................ 3
Table 2. Charging Conditions.................................................................................... 6
Table 3. Electromagnetic Emissions....................................................................... 13
Table 4. Electromagnetic Immunity......................................................................... 14

1
Intended Use
Intended Use
The Nonin Model 2500C Charger Stand is intended for use with the PalmSAT Models 2500 and
2500A Pulse Oximeters and the Model 2500B Rechargeable NiMH (Nickel Metal Hydride)
Battery Pack.
Warnings
Do not use this product in an MR environment.
Do not use this product in an explosive atmosphere.
This product is not defibrillation proof per IEC 60601-1.
As with all medical equipment, carefully route patient cabling to reduce the possibility of patient entanglement,
strangulation, or injury to the patient.
This product should not be used adjacent to or stacked with other equipment. If adjacent or stacked use is
necessary, the product should be observed carefully to verify normal operation.
The use of accessories, sensors, cables, and power supplies other than those listed in the Parts and
Accessories List may result in increased electromagnetic emission and/or decreased immunity of this product.
To prevent improper performance and/or patient injury, verify compatibility of the monitor, sensor(s), and
accessories before use.
No modifications to this device are allowed as it may affect device performance.
Portable RF communications equipment such as cell phones or radios (including peripherals such as antenna
cables and external antennas) should be used no closer than 30 cm (12 inches) to any part of the ME system,
including cables specified by the manufacturer. Otherwise, degradation of the performance of this equipment
could result.
Cautions
This equipment complies with International Standard 60601-1-2 for electromagnetic compatibility for medical
electrical equipment and/or systems. This standard is designed to provide reasonable protection against
harmful interference in a typical medical installation. However, because of the proliferation of radio-frequency
transmitting equipment and other sources of electrical noise in healthcare and other environments, it is
possible that high levels of such interference due to close proximity or strength of a source might disrupt the
performance of this product. Medical electrical equipment needs special precautions regarding EMC, and all
equipment must be installed and put into service according to the EMC information specified in this manual.
Do not connect this product to an AC outlet controlled by a wall switch. If the switch is accidentally turned off
before the battery pack is recharged, the pulse oximeter may not function.
Grounding reliability can only be achieved when the equipment is connected to an equivalent receptacle
marked “Hospital Only” or “Hospital Grade”.
This product contains sensitive electronic components and must be repaired by trained Nonin personnel only.
Do not immerse this product in liquid.
!

2
Intended Use
Do not place liquids on top of this product.
Do not use caustic or abrasive cleaning agents on this product.
Do not remove any covers from the product. There are no user-serviceable parts inside the unit.
Do not attempt to charge disposable batteries. Disposable batteries may leak or explode if used improperly.
Follow local, state and national governing ordinances and recycling instructions regarding disposal or recycling
of the product and product components, including batteries. Use only Nonin-approved battery packs.
In compliance with the European Directive on Waste Electrical and Electronic Equipment (WEEE) 2002/96/EC,
do not dispose of this product as unsorted municipal waste. This product contains WEEE materials; please
contact your distributor regarding take-back or recycling of the product. If you are unsure how to reach your
distributor, please call Nonin for your distributor’s contact information.
Cautions (Continued)
!

3
Guide to Symbols
Guide to Symbols
This table describes the symbols that are found on the Model 2500C and in this manual.
Table 1: Labeling Symbols
Symbol Description
Caution!
Consult Instructions for Use.
Follow Instructions for Use.
UL Mark for Canada and the United States with respect to electric shock,
fire, and mechanical hazards only in accordance with UL 60601-1 and
CAN/CSA-C22.2 No. 601.1.
MR Unsafe
Type BFApplied Part (Patient isolation from electrical shock).
Direct Current
Serial Number
CE Marking indicating conformance to EC directive No. 93/42/EEC
concerning medical products.
Indicates separate collection for electrical and electronic equipment
(WEEE).
Authorized Representative in the European Community.
Manufacturer
Class II, double insulated
Keep dry
!
C
L
A
S
S
I
F
I
E
D
US
CU
L
MRMR
SN
EC
REP

4
Using the Model 2500C
Using the Model 2500C
General Description
To use, place a PalmSAT Pulse Oximeter containing a rechargeable battery pack into the charger
stand. Next, connect the charger power supply to the charger, then plug the power supply into an
appropriate AC power source (wall outlet).
The fast charge feature will fully charge a depleted battery pack in approximately 180 minutes.
The charge indicator shows a steady green light when charging, and a flashing green light when
the battery pack is fully charged.
Figure 1: Charger Stand and Pulse Oximeter
Figure 2: Bottom View Showing the Serial Number, Power Supply Connection, and
Symbols
Charger Stand
Pulse Oximeter
Charge Indicator
Serial
Number
Power Supply
Connection

5
Using the Model 2500C
Unpacking the Model 2500C
The complete package includes the following items:
• 1 Model 2500C Charger Stand
• 1 Model 2500B Rechargeable NiMH Battery Pack
• 1 Power Supply*
• 1 Model 2500C-INS Operator’s Manual (on CD)
Confirm that the items listed are included in the package. If any item on this list is missing or
damaged, contact your distributor. Contact the carrier immediately if the shipping carton is
damaged.
*Certain power supply models will be provided with a separate power cord.

6
Operation
Operation
Follow the steps below to recharge the Model 2500B NiMH Battery Pack.
NOTES:
• The NiMH battery pack must be fully charged before the first use.
• Various Nonin-specified power cords are available for use with certain power supplies. See
“Accessories” on page 11 or contact your distributor.
• It is normal for the battery pack and charger to become warm during the charge cycle.
To Charge the Battery Pack Using the Charger Stand
1. Insert the battery pack into the PalmSAT Pulse Oximeter. (See the PalmSAT
Operator’s Manual for battery pack placement instructions.)
2. Place the pulse oximeter into the charger stand.
3. Plug the power supply into the back of the charger stand.
4. Connect the appropriate power cord into the power supply, when necessary.
5. Plug the power cord assembly into an appropriate AC power outlet.
6. The battery pack will be fully charged in approximately 90 minutes. Refer to Table 2
for a description of the charging conditions.
NOTES:
• You can maintain a full charge in the battery pack by charging the PalmSAT Pulse Oximeter
in the charger stand until needed. (NiMH battery packs will self-discharge approximately
20% over a 30-day period when removed from the charger.)
• You can use the PalmSAT Pulse Oximeter while it is charging in the stand. For added
stability, route the sensor cable under the charger stand as shown in Figure 3.
Table 2: Charging Conditions
Charge Indicator Status
GREEN constant Charging up to full capacity.
GREEN alternating
ON 1/8 sec, OFF 1/8 sec Fully charged (and trickle charging to prevent battery pack self-discharge).
GREEN alternating
ON 1/8 sec, OFF 1 3/8 sec Preparing for charge (adjusting the minimum voltage).
AMBER ON 1 3/8 sec alternating
with AMBER/GREEN ON 1/8 sec ERROR. See “Troubleshooting Guide” on page 12.
OFF (not illuminated) Not in use.

7
Operation
Figure 3: Using the PalmSAT Pulse Oximeter while Charging the Battery Pack

8
Cleaning
Cleaning
To Clean the Charger Stand
1. Unplug the power supply from theAC power outlet.
2. Clean the product with a soft cloth dampened with isopropyl alcohol. Do not pour or
spray any liquids onto the product, and do not allow any liquid to enter any openings
in the product.Allow the product to dry thoroughly before reusing.
CAUTION: Do not immerse this product in liquid.
CAUTION: Do not use caustic or abrasive cleaning agents on this product.
CAUTION: Do not place liquids on top of this product.
!
!
!

9
Service
Service
NOTE: Any sign or evidence of opening the system, field service by non-Nonin personnel,
tampering, or any kind of misuse or abuse of the system, shall void the warranty in its
entirety.
Nonin does not recommend field repair of this product. The circuit board in the Model 2500C
isa multi-layerboardusing verynarrowtraces.Duetotheverysmalltracesize,extremecaremust
be used when replacing components to prevent permanent, non-repairable damage to the circuit
board. Most components are surface-mounted and require special hot-air jet soldering and
desoldering equipment.After any repairs are made, the product must be tested to ensure correct
operation. The device’s expected service life is 3 years.
For additional technical information, contact Nonin’s Technical Service department at:
Nonin Medical, Inc.
13700 1st Avenue North
Plymouth, Minnesota 55441 USA
[phone] (USA and Canada)
[phone]
Fax: [phone]
E-mail: [email protected]
Nonin Medical B.V.
Prins Hendriklaan 26
1075 BD Amsterdam, Netherlands
+31 (0)13 - 79 99 040 (Europe)
Fax: +31 (0)13 - 79 99 042
E-mail: [e-mail]
www.nonin.com
All non-warranty work shall be done according to Nonin standard rates and charges in effect at the
time of delivery to Nonin. All repairs include a complete retest of the Model 2500C using factory
test fixtures.
CAUTION: This product contains sensitive electronic components and must be
repaired by trained Nonin personnel only.
CAUTION: Do not remove any covers from the product. There are no user-
serviceable parts inside the unit.
!
!

10
Warranty
Warranty
For warranty information go to: http://www.nonin.com/warranty/

11
Accessories
Accessories
For more information about Nonin parts and accessories:
• See the Parts and Accessories List on the Operator’s Manual CD.
• Contact your distributor or Nonin at [phone] (USA and Canada),
[phone], or +31 (0)13 - 79 99 040 (Europe).
• Visit www.nonin.com

12
Troubleshooting Guide
Troubleshooting Guide
Problem Possible Cause Possible Solution
The product will not
turn on.
The power supply/power cord
assembly is not properly
connected to the chargerand an
appropriate AC outlet.
Check all connections. Check
that theAC outlet is not turned off
via a wall switch.
Thepulse oximeteris improperly
inserted into the charger. Insert the pulse oximeter into the charger correctly.
The battery pack is improperly
inserted into the pulse oximeter. Insert the battery pack into the pulse oximeter correctly.
The charge indicator
is flashing amber
alternating with
amber/green (an
error condition).
The battery pack is stored or
used outside of specified
environmental conditions.
Warm the battery pack to room
temperature, place it into the
pulse oximeter, and then reinsert
into the charger.
Either disposable batteries, a
faulty battery pack, or a non-
specified pack is in the pulse
oximeter.
Place a new Nonin-specified
rechargeable battery pack into
the pulse oximeter and then
reinsert into the charger.
The charge connections are
faulty.
Check all connections and
reinsert the pulse oximeter into
the charger, or contact Nonin
Technical Service.
If these solutions do not correct the problem with your product, please contact Nonin
Technical Service at [phone] (USA and Canada), [phone], or
+31 (0)13 - 79 99 040 (Europe).

13
Technical Information
Technical Information
NOTE: This product complies with ISO 10993-1, Biological Evaluation of Medical Devices
Part 1: Evaluation and Testing.
Manufacturer’s Declaration
Essential Performance
Essential performance of the 2500C, when used in conjunction with the Model 2500 or Model
2500A, is defined as SpO2 accuracy and pulse rate accuracy or an indication of abnormal
operation.Accuraciesmay beaffectedasaresultofexposureto electromagneticdisturbances
that are outside of the environments listed in the Indications For Use. If issues are
experienced, move the Nonin system away from the source of electromagnetic disturbances.
Refer to the following table for specific information regarding this device’s compliance to
IEC 60601-1-2.
WARNING: Portable RF communications equipment such as cell phones or radios
(including peripherals such as antenna cables and external antennas) should be used
no closer than 30 cm (12 inches) to any part of the ME system, including cables
specified by the manufacturer. Otherwise, degradation of the performance of this
equipment could result.
Table 3. Electromagnetic Emissions
Emissions Test Compliance
This device is intended for use in the electromagnetic environment specified in the Indications For Use.
RF Emissions
CISPR 11 Group 1, Class B
Harmonic Emissions
IEC 61000-3-2 Class A
Voltage Fluctuations/Flicker Emissions
IEC 61000-3-3 Within limits of IEC 61000-3-3

14
Technical Information
Table 4. Electromagnetic Immunity
Immunity Test Compliance Level
This device is intended for use in the electromagnetic environment specified in the Indications For Use.
Electrostatic Discharge (ESD)
IEC 61000-4-2 ±8 kV contact ±15 kV air
Electrical Fast Transient/Burst
IEC 61000-4-4 ±2 kV for power supply lines ±2 kV for input/output lines
Surge
IEC 61000-4-5 ±0.5kV, ±1kV, ±2kV for Line-to-Ground
±0.5kV, ±1kV for Line-to-Line
Voltage dips, short interruptions, and
voltage variations on power supply
input lines
IEC 61000-4-11
0% UTfor 0.5 Cycles at 50 Hz at 0, 45, 90, 135, 180, 225,
and 315° Phase
0% UTfor 1 Cycle at 50 at 0°Phase
70% UTfor 25 Cycles at 50 Hz at 0°Phase
0% UTfor 250 cycles at 50 Hz at 0°Phase
Power Frequency (50/60 Hz) Magnetic
Field
IEC 61000-4-8
30 A/m
Conducted RF IEC 61000-4-6 150 kHz to 80 MHz 3 Vrms
ISM and Amateur radio bands
between 150 kHz to 80 MHz 6 Vrms
Radiated RF IEC 61000-4-3 80 MHz – 2.7 GHz 10 V/m
380 – 390 MHz 27 V/m
430 – 470 MHz 28 V/m
704 – 787 MHz 9 V/m
800 – 960 MHz 28 V/m
1.7 – 1.99 GHz 28 V/m
2.4 – 2.57 GHz 28 V/m
5.1 – 5.8 GHz 9 V/m
Note: UTis the AC mains voltage before application of the test level.

15
Technical Information
Specifications
Charge Time 180 minutes
Power Requirements 12 VDC / 1.5 A
Charge Indicator Bicolor LED (green, amber)
Temperature (Operating) -20 to +40 C (-4 to +104 F)
Temperature (Storage/Transportation): -40 to +70 C (-40 to +158 F)
Humidity (Operating) 10 to 90% noncondensing
Humidity (Storage/Transportation): 10 to 95% noncondensing
Dimensions 5.5 cm H x 11.6 cm W x 8.6 cm D
(2.2 in H x 4.6 in W x 3.4 in D)
Weight 90.3 g (3.2 oz)
Patient Isolation Not applicable
Leakage Current <0.5 mA at 265 VAC, 50 Hz
