nor-tec SE 50 User manual

Designed to deliver
reliable humidity from
facility steam boilers.
Pressure
Steam
Humidifiers
Live
Steam®

Humidifiers designed to deliver
reliable humidity from facility
steam boilers.
hospitals
educational facilities
government buildings
institutional buildings
printing plants
museums and galleries
commercial offices
People spend 90% of their lives indoors, therefore the
importance of correct temperature and humidity levels
are critical to personal health and comfort. Too much
humidity can be as destructive as too little.
Manufacturing and industrial processes are
also directly affected by the indoor environment.
Like people, machines work better in favorable
surroundings. All equipment and processes respond in
various ways to temperature and humidity fluctuations.
For maximum performance, reliable temperature and
humidity are essential.
NORTEC LiveSteam (LS Series) steam injection
humidifiers and NORTEC SE Series steam exchange
humidifiers deliver reliable humidity from the facility
steam boiler. Constructed of premium quality 304
and 316 stainless steel, NORTEC LS and SE Series
equipment are designed for long operating life with
minimal maintenance.
In hospitals, universities, museums, galleries, and
other facilities, steam injection humidification is
a tried and true way to achieve a critical balance
between temperature and humidity control.
2

Steam Injection
NORTEC LiveSteam delivers precise humidity
control. Utilizing tried and true components and
304 stainless steel tubing, LiveSteam is the
dependable steam injection system for your
facility.
LiveSteam distributors are available in a wide
variety of lengths ranging from 12" to 144" to
suit your exact duct size for the best possible
steam dispersion. Multi-tube units are also
available.
Steam Exchange
On NORTEC SE Series Steam Exchange
humidifiers, the boiler steam passes through
the SE internal heat exchanger(s) bringing the
surrounding water in the tank to atmospheric clean
steam vapor. The chemical treatment from the
boiler does not enter the air steam.
The SE Series heat exchanger utilizes 316
stainless steel and is designed to give maximum
output while taking up minimal space. It is easy to
remove for cleaning and the flat smooth surfaces
help reduce maintenance time.
Precise Control
In facilities with existing steam boilers LS and SE
Series offer a cost effective way to add precise
humidity control. With a wide variety of control
options and unit capacities NORTEC LS and SE
Series are ideal for job engineered systems.
operating advantages
STEAM
CONDENSATE
DISPERSED STEAM
DISPERSED STEAM
3

technology
1
9
7
5
6
4
2
10
3
8
1 Steam inlet, strainer upstream to
remove impurities.
2 Steam jacketed dispersion tube.
3 Tube support bracket, ensures
proper unit installation.
4 Interconnecting pipes between
dispersion tube and separator.
5 Steam separator ensures only
condensate-free steam is
discharged into the air stream.
6 Condensate outlet to steam trap
for recirculation to boiler for
energy efficient operation.
7 Steam control valve meters
steam entering dispersion tube.
8 Electric on/off and electric
modulating actuators standard.
Pneumatic valve actuator optional.
9 Tube adaptor connecting valve to
dispersion tube. Factory installed
silencers are available.
10 Steam outlet orifices sized for
exact humidity output.
LiveSteam mounted
with a SAM-e manifold
for short absorption
distance applications
Available for single or
multiple tube applications
Pressure ranges from
2-50 PSIG
High capacity system
(up 3209 lbs/hr)
Economical and cost effective
system to meet high humidity
requirements
Delivers precise humidity
control
Steam jacketed dispersion
tubes to prevent wetting
Support brackets on tubes
over 2 feet in length
Available for regular or purified
boiler steam
Available for pneumatic or
electric controls
▶
▶
▶
▶
▶
▶
▶
▶
▶
Live
Steam®
Steam
Injection
Humidifiers
4

1
9
7
5
6
4
2
10
3
8
SE
Series™
Steam
Exchange
Humidifiers
Capacity up to 1050 lbs/hr
NORTEC Total Controller
Intuitive scale management
based on steam production
All components suitable for
RO or DI water
Internal water tempering for
drain water cooling
Fully modulating
Built-in float and
thermostatic steam trap(s)
▶
▶
▶
▶
▶
▶
▶
Built-in P-trap
Fully insulated tank for
efficient operation
Pre-cleaning sequence
ensures shorter
maintenance time
Building management
system compatible
Network up to 10 units
Small SE 50 lbs/hr for easy
ceiling mounting
▶
▶
▶
▶
▶
▶
SETC 100
5
SE Series Features Comparison
SETC
SEP
Steam capacity adjustment •
Full size alphanumeric display and keypad •
Configurable date and time indication •
Transducer signal acceptance •
Individual component diagnostic capability •
Keypad set-point adjustment (humidity) •
Display of relative humidity •
Low and high relative humidity alarms •
Keep warm feature •
Networking capability up to 10 units •
Pre-cleaning sequence •
Troubleshooting Guide •
Self diagnostic capabilities •
Fault history •
Smart drain water cooling •
Single or Dual modulation signal acceptance •
Time to next maintenance alarm •
System demand indication •
Backlit display •
Built-in Float & Thermostatic steam trap(s) • •
3-day drain with no call for humidity • •
Full tank blow down capability via time of
day, timer, or signal from BMS
• •
Remote fault indication • •
Industry standard modulation signal acceptance • •
Internal Drain water cooler • •
Blow down based on steam production • •
Precise five level water level indication • •
Status indicator lamps • •
Single or multiple steam outlet options • •
Large Side tank cleaning port • •
Top access cleaning • •
Single water connection • •
Fully modulating down to 25% of total capacity • •
Options
Interaction with BMS system (Contact Factory) •
Freeze protection •
Floor stand • •
Distribution Systems
SAM-e • •
Steam distributor • •
Blower pack • •

options
Steam Distributor
Systems
Nortec offers flexible steam distribution choices
to satisfy a wide range of requirements:
Stainless Steel Steam Distributors to
distribute atmospheric steam into ducts.
Independant Blower Packs for in space
applications (remote mounted).
SAM-e Short Absorption Manifold for use
in air handlers or ducts where short steam
absorption distance is critical.
•
•
•
NORTEC OnLine
NORTEC OnLine is a remote interactive
communication package that allows satellite
contacts to monitor, maintain and control
a humidification center from any location
worldwide using standard internet connections.
This advanced software shows graphic
representations of the humidifier and its key
parameters (up to 75 functions).
NORTEC LINKS
NORTEC Links offers monitoring and control
allowing humidifier(s) to communicate to your
Building Management System (BMS). The
controller is factory installed and is located
internally to the humidifier. Simply specify at time
of order what operating protocol you are using –
BACnet IP, BACnet MSTP, LonWorks, Modbus or
Jonhson N2.
www.nortecOnLine.com
NORTEC Humidifier
Customer
NORTEC Technical Services
Communication through the internet or email.
Atmospheric steam distributor
SAM-e Short Absorption Manifold
6
Blower pack

SPECIFICATION
MODEL 200
MODEL LS1
MODEL 300
MODEL LS2
MODEL 450
MODEL LS3
MODEL 600
MODEL LS3
MODEL 800
MODEL LS3
SAM-e
mini SAM-e
Pressure range - psig (kPa) 2-50 (14-345) 2-50 (14-345) 2-50 (14-345) 2-50 (14-345) 2-50 (14-345) 2-50 (14-345)
Max. capacity single tube - lbs/hr (kg/hr) 284 (129) 571 (259) 916 (417) 1258 (572) N/A N/A
Max. capacity multi-tube - lbs/hr (kg/hr) 374 (170) 653 (297) 1030 (468) 1664 (757) 3209 (1456) 3200 (1451.5)
Separator physical data -
Height x Diameter
7.7" x 6"
195mm x 152mm
8.8" x 6"
223mm x 152mm
10.5" x 6"
268mm x 152mm
11.2" x 9"
284mm x 229mm
12.6" x 9"
322mm x 229mm Custom
Standard actuator Electric Modulating 0-10 VDC, 24 VAC
Standard steam trap Float & Thermostatic
Separator and dispersion tube material Stainless Steel 304
OPTIONS:
Pneumatic actuator yes yes yes yes yes yes
Electric on/off actuator yes yes yes yes yes yes
Tube insulation yes yes yes yes yes no
DI water installation yes yes no no no yes
technical data
SPECIFICATION SE 50 SE 100 SE 175 SE 250 SE 375 SE 475 SE 675 SE 950 SE 1050
Pressure range - psig (kPa) 5-15 (35-105)
Max. capacity single tube - lbs/hr (kg/hr) 17-50
(8-23)
5-100
(2-45)
7-175
(3-79)
11-250
(5-114)
15-375
(7-170)
24-475
(11-215)
30-675
(14-306)
58-950
(26-430)
67-1050
(30-476)
Physical data -
Width x Height x Depth
25.6" x 20.6"
x 18.4"
65.1cm x 52.4cm
x 46.7cm
46.4" x 32.0"x 20.0"
117.8cm x 81.4cm x 50.8cm
46.4" x 32.0"x 26.4"
117.8cm x 81.4cm x 67.1cm
46.4" x 32.0"x 42.0"
117.8cm x 81.4cm x 106.7cm
46.4" x 32.0"x 58.0"
117.8cm x 81.4cm x 147.3cm
Standard actuator Electric Modulating 0-10 VDC, 24 VAC
Built-in steam trap Float & Thermostatic
Insulation & Cabinetry Standard
Voltage/Phase 110-120/1
Full load amps 2.1
Internal Smart Drain Water Cooler Standard
Steam Outlets (s) - OD 1 x 1.75" (1 x 4.44cm) 1 x 3" (1 x 7.62cm) 1 x 4" (1 x 10.16cm) 2 x 4" (2 x 10.16cm)
OPTIONS:
NORTEC Links BMS BACnet, LonWorks, Johnson Control N2 Bus or Modbus (SETC model only)
NORTEC OnLine SETC model only
Keep Warm Feature no yes yes yes yes yes yes yes yes
Freeze Protection no yes yes yes yes yes yes yes yes
Outdoor Model no yes yes yes yes yes yes yes yes
Floor Stand yes yes yes yes yes yes yes yes yes
LiveSteam
SE Series
7
